Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Automatic Transmission Oil Cooler Line Fitting | 25 N.m | 18 lb ft |
| Coolant Reservoir Screws | 10 N.m | 89 lb in |
| Cooling Fan Motor Screws | 5 N.m | 44 lb in |
| Oil Pan Shield | 30 N.m | 22 lb ft |
| Thermostat Housing to Water Pump Bolts | 14 N.m | 10 lb ft |
| Water Pump Bolts |
| First Pass | 15 N.m | 11 lb ft |
| Final Pass | 25 N.m | 18 lb ft |
| Water Pump Inlet | 14 N.m | 10 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Engine Cooling Schematics
Scheme 2
Scheme 2: Cooling System Component Views
| Callout | Component Name |
|---|
| 1 | Left Fan |
| 2 | Left Fan Motor |
| 3 | Left Fan Motor Electrical Connector |
| 4 | Left And Right Fan Motor Electrical Connector |
| 5 | Right Fan |
| 6 | Right Fan Motor |
| 7 | Fan Shroud |
| 8 | Radiator |
Scheme 3
| Callout | Component Name |
|---|
| 1 | Engine Cooling Fan 1 |
| 2 | Engine Cooling Fan 2 |
| 3 | Engine Cooling Fan 3 |
