Engine Control System - 3.5L - Troubleshooting: Overview Pontiac G6 I

Circuit/System Description

Ignition voltage is supplied to the malfunction indicator lamp (MIL). The engine control module (ECM) turns the MIL ON by grounding the MIL control circuit.

This Engine Cranks but Does Not Run is an organized approach to identify a condition which causes the engine to crank but not start. This diagnostic directs the technician to the appropriate system diagnosis.

This diagnostic assumes the system voltage levels are adequate for starter motor operation. Refer to Battery Inspection/Test, and Engine Cranks Slowly. Fuel level and fuel quality should be determined for correct diagnosis.

Test Description

The number below refers to the step number on the diagnostic table.

1. 9: Any change in RPM verifies that the controller is able to receive a signal.

Scheme 213

Scheme 214

Crankshaft Position Sensor System Diagnosis (Steps 18-23). Scheme 215

The numbers below refer to the step numbers on the diagnostic table.

1. 3: This step determines if the condition is located on the coil side or the switch side of the circuit.
2. 4: This step verifies that the PCM is providing voltage to the fuel pump relay.
3. 5: This step tests for an open in the ground circuit to the fuel pump relay.
4. 6: This step determines if a voltage is constantly being applied to the fuel pump relay.
5. 13: This step determines if the condition with the circuit is intermittent. If the fuse does not open, inspect the supply voltage circuit between the fuse and the fuel pump for an intermittent condition.

Fuel Pump Electrical Diagnosis

System Description

The powertrain control module (PCM) enables the fuel pump relay when the ignition switch is turned ON. The PCM will disable the fuel pump relay within 2 seconds unless the PCM detects ignition reference pulses. The PCM continues to enable the fuel pump relay as long as ignition reference pulses are detected. The PCM disables the fuel pump relay within 2 seconds if ignition reference pulses cease to be detected and the ignition remains ON.

The fuel system is a returnless on-demand design. The fuel pressure regulator is a part of the fuel sender assembly, eliminating the need for a return pipe from the engine. A returnless fuel system reduces the internal temperature of the fuel tank by not returning hot fuel from the engine to the fuel tank. Reducing the internal temperature of the fuel tank results in lower evaporative emissions (EVAP).

The fuel tank stores the fuel supply. An electric turbine style fuel pump attaches to the fuel sender assembly inside the fuel tank. The fuel pump supplies high pressure fuel through the fuel filter and the fuel feed pipe to the fuel injection system. The fuel pump provides fuel at a higher rate of flow than is needed by the fuel injection system. The fuel pump also supplies fuel to a venturi pump located on the bottom of the fuel sender assembly. The function of the venturi pump is to fill the fuel sender assembly reservoir. The fuel pressure regulator, a part of the fuel sender assembly, maintains the correct fuel pressure to the fuel injection system. The fuel pump and sender assembly contain a flow check valve. The check valve and the fuel pressure regulator maintain fuel pressure in the fuel feed pipe and the fuel rail in order to prevent long cranking times.

Fuel System Diagnosis

The control module enables the appropriate fuel injector pulse for each cylinder. The ignition voltage is supplied directly to the fuel injectors. The control module controls each fuel injector by grounding the control circuit via a solid state device called a driver. A fuel injector coil winding resistance that is too high or too low will affect the engine driveability. A fuel injector control circuit DTC may not set, but a misfire may be apparent. The fuel injector coil windings are affected by temperature. The resistance of the fuel injector coil windings will increase as the temperature of the fuel injector increases.

The CH-47976 is used to test the fuel pump, fuel system leak down, and the fuel injectors. Following the User Guide, CH 47976-11 , and the on screen prompts or selections, will indicate the steps required to perform each of the available tests. The tester will perform all of the tests automatically and display results of the test. The results can also be down loaded for storage and printing.

The control module enables the appropriate fuel injector pulse for each cylinder. The ignition voltage is supplied directly to the fuel injectors. The control module controls each fuel injector by grounding the control circuit via a solid state device called a driver. A fuel injector coil winding resistance that is too high or too low will affect the engine driveability. A fuel injector control circuit DTC may not set, but a misfire may be apparent. The fuel injector coil windings are affected by temperature. The resistance of the fuel injector coil windings will increase as the temperature of the fuel injector increases.

When performing the fuel injector balance test, the scan tool is first used to energize the fuel pump relay. The fuel injector tester or the scan tool is then used to pulse each injector for a precise amount of time, allowing a measured amount of the fuel to be injected. This causes a drop in the system fuel pressure that can be recorded and used to compare each injector.

The numbers below refer to the step numbers on the diagnostic table.

1. 3: This step tests each fuel injector resistance within a specific temperature range. If any of the fuel injectors display a resistance outside of the specified value, replace the fuel injector.
2. 4: This step determines if all of the fuel injectors are within 3 ohms of each other. If the highest resistance value is within 3 ohms of the lowest resistance value, then all of the fuel injector coil windings are OK.
3. 6: This step determines if the ignition 1 voltage circuit under the intake plenum is causing the concern.
4. 8: This step determines which fuel injector is faulty. After subtracting the highest and lowest resistance values from the average value, replace the fuel injector that has the greatest resistance difference from the average.

Fuel Injector Coil Test

Scheme 216

The scan tool is first used to energize the fuel pump relay. The fuel injector tester is then used to pulse each injector for a precise amount of time, allowing a measured amount of fuel into the manifold. This causes a drop in system fuel pressure that can be recorded and used to compare each injector.

Fuel Injector Balance Test Example (Actual Results May Vary)

The numbers below refer to the step numbers on the diagnostic table.

1. 3: The engine coolant temperature (ECT) must be below the operating temperature in order to avoid irregular fuel pressure readings due to hot soak fuel boiling.
2. 6: If the pressure drop value for each fuel injector is within 20 kPa (3 psi) of the average pressure drop value, the fuel injectors are flowing properly.

Fuel Injector Balance Test with Special Tool

The number below refers to the step number on the diagnostic table.

1. 3: The engine coolant temperature (ECT) must be below the operating temperature in order to avoid irregular fuel pressure readings due to hot soak fuel boiling.

Fuel Injector Balance Test with Tech 2

The number below refers to the step number on the diagnostic table.

1. 4: This step tests the MAP sensor's ability to correctly indicate BARO.

1. 12: The measurement noted in this step will be used in subsequent steps if the measurement does not exceed the specified value.

1. 15: This step calculates the resistance in the 5-volt reference circuit.

1. 16: This step calculates the resistance in the low reference circuit.

Manifold Absolute Pressure (MAP) Sensor Diagnosis

Description

Several states require that a vehicle pass on-board diagnostic (OBD) system tests and the inspection/maintenance (I/M) emission inspection in order to renew license plates. This is accomplished by viewing the I/M System Status display on a scan tool. Using a scan tool, the technician can observe the I/M System Status in order to verify that the vehicle meets the criteria that comply with the local area requirements.

The purpose of the inspection/maintenance (I/M) complete system set procedure is to satisfy the enable criteria necessary to execute all of the I/M readiness diagnostics, and complete the trips for those particular diagnostics. When all diagnostic tests are completed, the I/M System Status indicators are set to YES. Perform this test when more than one or all of the I/M System Status indicators are set to NO.

The numbers below refer to the step numbers on the diagnostic table.

1. 2: This step is to run the heated oxygen sensor (HO2S) Heater Tests and initiate the evaporative emission (EVAP) System Test. Preprogramming the scan tool will reduce the amount of time the oxygen sensor heaters operate while verifying the enable criteria.
2. 3: This step is to run the EVAP, and the Oxygen Sensor Tests. The EVAP Test begins once the engine coolant reaches a calibrated temperature. The AIR Test, if equipped, begins shortly after Closed Loop and the indicated speed is achieved. The Oxygen Sensor Tests begin once the engine is at operating temperature, in Closed Loop Fuel Control, and a calibrated amount of time has elapsed.
3. 4: This step is to run the exhaust gas recirculation (EGR) Tests. The EGR Tests are run during a gradual deceleration with a closed throttle. The vehicle speed is required in order to maintain a high, steady manifold absolute pressure (MAP) signal.
4. 5: This step is to run the Catalyst Tests. This test runs during the idle period immediately following a cruise period that meets a minimum calibrated RPM and time period.
5. 7: The I/M System Status only reports on whether or not a diagnostic has run, not what the outcome of the test was. If any emission related DTC sets after the tests are complete, the DTC will require diagnosis.

Inspection/Maintenance (I/M) Complete System Set Procedure

The evaporative emission (EVAP) Service Bay Test raises the engine coolant temperature (ECT) threshold so that the temperature sensitive EVAP diagnosis tests can run while in service environments. When the EVAP tests are run the service bay test will indicate a pass or will indicate a specific DTC has failed. The EVAP service bay test can be used to verify an existing condition and verify that the EVAP system is OK after a repair is completed.
