Terminal Assignment Opel Vectra B

Terminal Assignment

Terminal Assignment of Control Unit, 22P

1. S101 Switch-Air Conditioning (Terminal 58D)
2. S102 Switch-Air Circulation (Terminal 58D)
3. Air Conditioning System Cutoff Signal
4. S101 Switch-Air Conditioning
5. Air Conditioning System Request Signal
6. Ignition ON (Terminal 15A)
7. X13 Diagnostic Link 16P
8. Y14 Solenoid Valve-Coolant
9. Dimmed Illumination (Terminal 58D)
10. P13 Sensor-Outside Temperature (Ground)
11. S4 Switch-Back Window
12. S102 Solenoid Valve-Ventilation
13. Ground (Terminal 31)
14. Battery Voltage (Terminal 30)
15. Distance Signal
16. Ignition ON (Terminal 15)
17. Sensor-Outside Temperature (Signal lead)

Terminal Assignment of Control Unit, 26P

1. M10 Blower-Motor (Relay)
2. Y35 Solenoid Valve-Ventilation (Terminal 15)
3. M10 Blower-Motor (PTC)
4. M10 Blower-Motor (Diagnostic)
5. M75 Actuator-Leg Room
6. M75 Actuator-Leg Room
7. M74 Actuator-Defrost
8. M74 Actuator-Defrost
9. P41 Sensor-Outlet Temperature
10. M77 Actuator-Mixed Air Flap
11. M77 Actuator-Mixed Air Flap
12. M76 Actuator-Ventilation, Middle
13. Ground
14. Actuators Power Supply
15. P51 Sun Sensor
16. Y35 Solenoid Valve-Ventilation
17. M10 Blower-Motor (Command)
18. M75 Actuator-Leg Room
19. M75 Actuator-Leg Room
20. M74 Actuator-Defrost
21. M74 Actuator-Defrost
22. M77 Actuator-Mixed Air Flap
23. M77 Actuator-Mixed Air Flap
24. M76 Actuator-Ventilation, Middle
25. M76 Actuator-Ventilation, Middle
26. M76 Actuator-Ventilation, Middle
