Steering Gear Replacement
| Callout | Component Name |
|---|
| Caution: Secure the steering wheel utilizing a strap to prevent rotation. Locking of the steering column will prevent damage and a possible malfunction of the SIR system. The steering wheel must be secured in position before disconnecting the following components: • The steering column • The intermediate shaft • The steering gear After disconnecting these components, do not move the front tires and wheels. Failure to follow these procedures may cause improper alignment of some components during installation and result in possible damage to the SIR coil. Preliminary Procedure Remove the front tire/wheel assemblies. Refer to Tire and Wheel Removal and Installation |
| 1 | Steering Linkage Outer Tie Rod Nut (Qty: 2) Caution: Refer to Fastener Caution in the Preface section. Tighten 30 N·m (22 lb ft) plus an additional 115 degrees |
| 2 | Steering Linkage Outer Tie Rod End (Qty: 2) Procedure Refer to Steering Linkage Outer Tie Rod Replacement for removal. |
| 3 | Steering Gear Inlet and Outlet Hose Fitting (Qty: 2) Procedure Place drain pans under the vehicle as needed to catch any power steering fluid. Tighten 27 N·m (20 lb ft) |
| 4 | Steering Gear Bolt (Qty: 2) Tighten 60 N·m (44 lb ft) |
