Power Steering Pump Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Remove the intake manifold cover. Refer to Intake Manifold Cover Replacement . Remove the air cleaner assembly. Refer to Air Cleaner Assembly Replacement . Remove the power steering pump pulley. Refer to Power Steering Pump Pulley Replacement . |
| 1 | Power Steering Fluid Reservoir Outlet Hose Clamp Procedure Remove as much power steering fluid as possible from the remote power steering fluid reservoir. |
| 2 | Power Steering Fluid Reservoir Outlet Hose |
| 3 | Power Steering Gear Inlet Hose Fitting Caution: Refer to Fastener Caution in the Preface section. Tighten 27 N·m (20 lb ft) |
| 4 | Power Steering Pump Bolt (Qty: 3) Tighten 22 N·m (16 lb ft) |
| 5 | Power Steering Pump Procedure Remove the power steering pump from the top of the vehicle. Fill and bleed the power steering system. Refer to Power Steering System Bleeding . |
