Folding Top Pivot Bracket Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Open the folding top and stowage compartment lid. |
| 1 | Folding Top Pivot Bracket Nut (Qty: 3) Caution: Refer to Fastener Caution in the Preface section. Tip • Lift only the side of the folding top that the pivot bracket is to be replaced high enough to clear the adjusting pin. • Mark location relative to body of bracket. • Leave the alignment pin loose. Loose fit the top latch. Latch top to header. Check seal fit to door glass prior to tightening top alignment pin. • Adjust the folding top. Refer to Folding Top Adjustment . Tighten 9 N·m (80 lb ft) |
| 2 | Folding Top Pivot Bracket |
