Folding Top Link Replacement
| Callout | Component Name |
|---|
| 1 | Folding Top Link Nut Caution: Refer to Fastener Caution in the Preface section. Procedure Open the folding top to gain access to the link nuts. Adjust the folding top link ball-socket to 4-6 mm (0.157-0.236 in) from the base/shoulder of the threads, or no more than 4 threads showing on the folding top link. Tighten 25 N·m (18 lb ft) |
| 2 | Folding Top Link Procedure For old design, pull off the ball stud. To install new design, perform the following procedure: 2.1. Remove the nut and ball stud from the rear seal retainer support panel. 2.2. Install the new star washer on the ball-socket, and install the ball-socket to the rearmost position in the slot on the support panel. 2.3. Install the nut. Tighten 12 N·m (106 lb in) |
