Folding Top Clock Spring Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Remove the top from the vehicle. Refer to Folding Top Replacement . |
| 1 | Outboard Spring Rivet Procedure Drill out the rivet to remove the springs. |
| 2 | Outboard Spring Procedure Spring has minimal tension when top is in stowed position. Remove the spacer. |
| 3 | Inboard Spring Tip • Inboard spring has minimal tension when top is in raised position. • Inboard spring is larger in diameter than outboard spring. • Inboard/Outboard springs have opposite winding. |
