Radiator Replacement
| Callout | Component Name |
|---|---|
| Preliminary Procedure Drain the cooling system. Refer to Cooling System Draining and Filling . Remove the upper radiator air baffle. Refer to Radiator Air Upper Baffle and Deflector Replacement . Remove the fan shroud assembly. Refer to Cooling Fan and Shroud Replacement . Remove the radiator inlet hose from the radiator. Refer to Radiator Inlet Hose Replacement . Remove the radiator outlet hose from the radiator. Refer to Radiator Outlet Hose Replacement . Remove the radiator support brackets. Refer to Radiator Support Bracket Replacement . | |
| 1 | A/C Condenser Bracket Bolt Caution: Refer to Fastener Caution in the Preface section. Tighten 9 N·m (80 lb in) |
| 2 | A/C Condenser Bracket |
| 3 | Radiator Assembly |
