Radiator Air Upper Baffle and Deflector Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Remove the charge air cooler inlet pipe if equipped. Refer to Charge Air Cooler Inlet Pipe Replacement . Remove the charge air cooler outlet pipe if equipped. Refer to Charge Air Cooler Outlet Pipe Replacement . Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . |
| 1 | Radiator Air Deflector Bolt - Front (Qty: 2) Caution: Refer to Fastener Caution in the Preface section. Tighten 9 N·m (80 lb in) |
| 2 | Radiator Air Deflector Assembly - Front |
| 3 | Air Inlet Shroud Retainer (Qty: 2) |
| 4 | Air Inlet Shroud |
