Cooling System Connector End Views
| Connector 1: | Engine Coolant Level Switch |
|---|---|
| Connector 2: | Engine Cooling Fan |
Engine Coolant Level Switch
Connector Part Information OEM: 12052641 Description: 2-Way F Metri-Pack 150 Series (BK)
Engine Coolant Level Switch
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | 0.5 L-GN | 1478 | Coolant Level Switch Signal |
| B | 0.5 BK/WH | 451 | Ground |
Engine Cooling Fan
Connector Part Information OEM: 7283-8496-30 Description: 4-Way F Mixed Series, Sealed (BK)
Engine Cooling Fan
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | 8.0 RD/BK | 342 | Battery Positive Voltage |
| 2 | 8.0 BK | 650 | Ground |
| 3 | -- | -- | Not Available |
| 4 | 0.35 WH | 2368 | Cooling Fan Speed Control |
