Body Control Module
The body control module is installed in the relay box (on�board computer module) on the left in the plenum chamber.
There are 3 versions of body control modules:
- Body Control Multitimer
- Body Control Multitimer and Central Locking
- Body Control Multitimer, Central Locking and Anti�Theft Warning System
The body control module can be diagnosed. After being replaced, the software for the body control module has to be adapted to the vehicle equipment, e.g. can the daylight driving lamps function be set.
The body control module connects the V bus to the E bus, both are CAN buses.
- Body control module
