Block Diagram of Body Control Module
| 15 | Ignition ON (terminal 15) |
|---|
| 30 | Battery positive (terminal 30) |
| |
| A12 | Interior compartment add�on heater (diesel) |
| A15 | Body control module |
| A75 | Control unit, electronic power steering |
| A110 | Immobiliser control unit |
| |
| E68 | Inner lamp delayed |
| |
| F1 | Fuse |
| F11 | Fuse |
| F17 | Fuse |
| F22 | Fuse |
| |
| G8 | Alternator |
| |
| K53 | Dipped beam relay |
| K56 | Rear screen wiper relay |
| K58 | Rear fog lamp relay |
| K66_L | Left turn signal relay |
| K66_R | Right turn signal relay |
| K69(1) | Windscreen wiper 1st level |
| K69(2) | Windscreen wiper 2nd level |
14.8 Block Diagram of Body Control Module
| A15 | Body control module |
|---|
| |
| H12 | Seat belt switch (Japan) |
| |
| S32 | Reversing lamp switch |
| S39 | Load compartment switch |
| S120 | Switch for LED/ATWS warning light |
| S124 | Light switch unit |
| S128 | Switch for high/low beam, headlamp flasher |
| S129 | Switch for turn signal left, right |
| S135 | Switch for bonnet, ATWS |
| S149 | Starter switch |
| S250 | Wiper system switch |
14.8 Block Diagram of Body Control Module
| A14 | Heater controls |
|---|
| A15 | Body Control Module |
| A37 | Anti�lock brake system control unit |
| A38 | ABS control unit & traction control |
| |
| B79 | Interior ATWS sensor |
| (Ultrasound sensor) |
| B53 | Fuel supply sensor |
| |
| K29.1 | Washer pump relay |
| Windscreen |
| K29.2 | Washer pump relay |
| Rear screen |
| K39 | Front fog lamp relay |
| K45 | High beam relay |
| K46 | Headlamp washer relay |
| K47 | Fanfare relay |
| K53 | Dipped beam relay |
| K54_L | Left position light relay |
| K54_R | Right position light relay |
| K58 | Rear fog lamp relay |
| K58_D | Terminal 58D relay |
| (Output for dimmed instrument panel illumination) |
| K58_K | Terminal 58K relay |
| (Licence plate lamp) |
| K67 | Horn ATWS relay |
| K72 | Terminal 15A relay |
14.8 Block Diagram of Body Control Module
| A15 | Body Control Module |
|---|
| |
| R22 | Rear screen heating |
| (Glass breakage sensor ATWS) |
| |
| S36 | Switch for residual brake fluid |
| S63.1 | Driver's door contact switch |
| S63.2 | Passenger's door contact switch |
| S63.3 | Rear left door contact switch |
| S63.4 | Rear right door contact switch |
| S181 | Parking brake switch |
14.8 Block Diagram of Body Control Module
| A15 | Body Control Module |
|---|
| A37 | Anti�lock brake system control unit |
| A38 | ABS control unit & traction control |
| A51_D | Central locking motor, driver |
| A51_P | Central locking motor, passenger |
| A84_A | Multec�S (F) control unit |
| A84_B | Control for Motronic ME 1.5.5 |
| A84_C | Multec�S (F) control unit |
| A84_D | Diesel control unit (EDC�ECD V5) |
| A112_B | MTA transmission control unit |
| |
| K24.1 | Locking mechanism relay |
| K24.2 | Relay for driver's door locking mechanism |
| K24.3 | Unlocking mechanism relay |
| K24.4 | Anti�theft protection relay |
| |
| M16 | Sliding roof motor |
14.8 Block Diagram of Body Control Module
| A15 | Body control module |
|---|
| |
| M16 | Sliding roof motor |
| |
| P3 | Instrument module |
| |
| XD | Diagnostic plug |
| |
| Y10 | Central locking motor for fuel tank cover |
| Y29 | Central locking motor for tailgate |
| Y35_L | Central locking motor for rear left door |
| Y35_R | Central locking motor for rear right door |
| |
| CAN�E | CAN�BUS with slower transmission rate |
| CAN�V | CAN�BUS with faster transmission rate |
| |
| 31 | Terminal 31 (ground) |
