Replace Flex Fix System Bowden Cable Opel Antara I

Remove

1. 1. Disconnect the battery • Detach earth clamp from earth terminal – Loosen nut
2. 2. Detach rear panelling on both sides from the wheel housing inner trim • Unscrew 8x bolt (5) on both sides
3. 3. Detach rear panelling below • Remove 4x body-bound rivet (4)
4. 4. Detach rear panelling above • Release seal below • Remove 4x body-bound rivet (1)
5. 5. Detach rear panelling completely • Unclip rear panelling (arrows)

Note. 2nd person required.

6. 6. If fitted: release and detach park pilot (3) wiring harness plug

7. 7. Detach right storage compartment (1) • Unclip 6x
8. 8. Detach actuation lever (2) panel • Unclip 4x

9. 9. Detach actuating lever (1) with bracket (4) • Unscrew 2x bolt (2), (3) • Extract actuating lever (1) with bracket (4) and Bowden cable through opening in storage compartment

10. 10. Detach actuating lever (1) from bracket • Unscrew 2x bolt (3)
11. 11. Detach Bowden cable from actuating lever • Detach Bowden cable (2)

12. 12. Detach Bowden cable (2) below • Disconnect spring (6) • Detach Bowden cable (2) • Detach Bowden cable bracket (4) – Unscrew bolt (3) • Detach rubber grommet (5)
13. 13. Pull out Bowden cable (2) • Detach rubber grommet (1) • Pull Bowden cable through hole in rear wall

Install

14. 14. Feed Bowden cable through • Feed Bowden cable through rear wall from below • Insert rubber grommet
15. 15. Attach Bowden cable below • Attach Bowden cable • Attach spring • Attach Bowden cable bracket – Tighten bolt
16. 16. Connect park pilot wiring harness plug
17. 17. Attach rear panelling • Clip in rear panelling

Note. 2nd person required.

18. 18. Fasten rear panelling above • Install 4x body-bound rivet
19. 19. Fasten rear panelling below • Install 4x body-bound rivet
20. 20. Attach rear panelling on both sides to the wheel housing inner trim • Tighten 8x bolt
21. 21. Attach Bowden cable to actuating lever
22. 22. Attach actuation lever to bracket • Insert lever with Bowden cable through opening in storage compartment • Tighten 2x bolt
23. 23. Attach actuation lever with bracket

Note. Watch for spacer plate

24. 24. Install actuation lever panel • Clip in 4 clips
25. 25. Install right storage compartment • Clip in 6x clips
26. 26. Connect the battery
27. 27. Program volatile memories
