Starter Motor Repair Opel Antara I



Starter Motor Repair

Disassemble

1. Remove the starter. For Z20DMH and Z20DM refer to Starter Replace . For Z24XE refer to Starter Replace . For Z32SE refer to Starter Replace .
2. Remove the starter through-bolts.

3. Remove the commutator end frame and brush holder assembly.
4. Inspect the brushes, the pop-out springs and the brush holders for wear and damage. Replace the assembly, if needed.

5. Check the armature to see if it turns freely. If the armature does not turn freely, break down the assembly immediately, starting with Step 14. Otherwise, give the armature a no-load test.

Note: Complete the testing in a minimum amount of time to prevent overheating and damaging the solenoid.

Note: If the specified current draw does not include the solenoid, deduct from the armature reading the specified current draw of the solenoid hold-in winding.

6. To begin the no-load test, close the switch and compare the rpm, the current and the voltage readings with the specifications. Refer to Starter Specifications in this section. Make disconnections only with the switch open. Use the test results as follows:

7. Remove the solenoid assembly screws.

8. Remove the field connector nut. Disconnect the field connector.

9. Remove the plunger return spring.

Important: If the solenoid is not removed from the starting motor, the connector strap terminals must be removed from the terminal on the solenoid before making these tests.

10. Test the solenoid windings by checking the current draw.

Important: Current will decrease as the windings heat up. Current draw readings that are over specifications indicate shorted turns or a ground in the windings of the solenoid. Both conditions require replacement of the solenoid. Current draw readings that are under specifications indicate excessive resistance. No reading indicates an open circuit.

11. Check both windings, connecting them according to the preceding test.

12. Slide the field frame with enclosed armature assembly away from the starter assembly.
13. Remove the shield.

14. Separate the field frame from the armature.

15. Inspect the shaft and the pinion for discoloration, damage or wear. Replace, if necessary.
16. Inspect the armature commutator. If the commutator is rough it should be turned down. The outside diameter of the commutator must measure at least 26.9 - 27.1mm (1.059 - 1.067 in.) after it is undercut or turned. Do not turn out-of-round commutators.
17. Inspect the points where the armature conductors join the commutator bars. Make sure they have a good connection. A burned commutator bar is usually evidence of a poor connection.
18. If test equipment is available, check the armature for short circuits by placing it on a growler, and holding back a saw blade over the armature core while the armature is rotated. If the saw blade vibrates, replace the armature.
19. Recheck the armature after cleaning between the commutator bars. If the saw blade vibrates, replace the armature.

20. Remove the locking ring from the groove in the driveshaft.

21. Remove the pinion stop and the drive from the driveshaft.

22. If not done in the previous steps, remove the screws that hold the solenoid assembly into the housing, and remove the nut from the field coil connector.

23. Rotate the solenoid 90 degrees and remove it along with the return spring.

24. Remove the plunger with the boot and the shift lever assembly. Test the solenoid windings, if not done in Step 11.

Important: The pinion clearance must be correct to prevent the buttons on the shift lever yoke from rubbing on the clutch collar during the cranking.

25. When the starter motor is disassembled and the solenoid is replaced it is necessary to check the pinion clearance.

26. Disconnect the motor field coil connector from the solenoid motor terminal and carefully insulate the connector.
27. Connect one 12-volt battery lead to the solenoid switch terminal and the other to the starter frame.
28. Flash a jumper lead momentarily from the solenoid motor terminal to the starter frame allowing shifting of the pinion in the cranking position where it will remain until the battery is disconnected.

Important: A means for adjusting the pinion clearance is not provided on the starter motor. If the clearance does not fall within the limits, check for improper installation and replace all worn parts.

29. Push the pinion back as far as possible to take up any movement, and check the clearance with a feeler gauge. The clearance should be 0.25 to 0.356 mm (0.01 to 0.14 inch).

Assembly

1. Install the drive and the pinion stop on the driveshaft.

2. Install the lock ring into the groove on the driveshaft and insert the collar.

3. Install the shift lever, washer and the cushion.

4. Lubricate the drive end of the armature shaft with lubricant.

5. Position the solenoid assembly.

6. Fasten the solenoid assembly with the screws.

Tighten

Tighten the starter solenoid assembly screws to 8 N•m (71 lb-in).

7. Install the field coil connection to the starter terminal. Install the nut.

Tighten

Tighten the starter field coil connector nut to 8 N•m (71 lb-in).

8. Position the armature assembly into the field frame.
9. Place the shield on the armature and field frame assembly.
10. Install the armature and field frame assembly with the shield into the starter housing.

11. Position the commutator end frame/brush holder assembly, lining up the end frame holes with the through-bolt holes in the housing.

12. Install the starter through-bolts.
13. Install the starter. For Z20DMH and Z20DM refer to Starter Replace . For Z24XE refer to Starter Replace . For Z32SE refer to Starter Replace .

Tighten

Tighten the starter through-bolts to 6 N•m (53 lb-in).
