X-Body Control Module (BCM) Replace (Antara) Opel Antara I

Electronic Module 6 illustrations ~120 words

X-Body Control Module (BCM) Replace (Antara)

Remove

  1. Disconnect the negative battery cable.
  2. Remove the instrument cluster. Refer to Instrument Cluster Replace (Antara) .
  1. You can see the X-BCM through the bracket hole and put your hands into the hole along the arrow.
  1. Unlock both sides of X-BCM and remove two nuts through the hole.
  2. Pull out the bracket through the hole.
  1. Disconnect the electrical connector.
  2. Pull out the X-BCM through the hole.

Important: Perform the SPO reprogramming when X-BCM module is replaced.

Install

  1. Connect the electrical connector.
  2. Install the X-BCM and bracket with the nuts into the hole.
  1. Install the instrument cluster. Refer to Instrument Cluster Replace (Antara) .
  2. Connect the negative battery cable.
