Field Remedy: 2716
| Subject: | Engine K12B - Wrong Intake Manifold Spacer Installed |
| Models: | Engines: | Option: |
|---|---|---|
| Agila-B 2008... | K12B |
| Complaint: | Emission light illuminates, P0401 set. |
|---|---|
| Cause: | Faulty intake manifold spacer has been installed in production. |
| Production: | No changes in production because engine production has expired by 30. September 2010. |
Remedy:
In case of customer complaint check the intake manifold spacer and replace it if necessary.
Working Procedure:
1. Perform visual check on the intake manifold spacer (Picture I and II)
- No stamping = Part OK
- O-Stamping = Part NOK
2. Replace the intake manifold spacer if a O is stamped.
- see working procedure "Intake Manifold Gasket Replacement", group "Engine / Engine mechanics – K12B", Service Instruction Agila-B. (Document Number 00610399)
Spare-Parts: Part-No.: Catalogue-No.:
Plate, Spacer, Induction Manifold 93168662 47 11 353
Labour Times: TC: Hours:
U3 271 60 Intake Manifold Spacer Replacement 90 1,8
The costs for this repair will be covered during warranty and policy. For policy please refer to the Policy Guideline (WebPG/Kuugel). The regular Warranty Procedure will apply.
| FunctionalGroup: | J - Engine |
|---|---|
| Complaint Group: | 06 - Failure Code Setting by Control Unit,19 - Engine Driveability,23 - Wrong Indication |
| Trouble Code: | P 0401 |
