A/C SYSTEM SPECIFICATIONS
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in the article, AIR BAG RESTRAINT SYSTEM, in the ACCESSORIES/SAFETY EQUIPMENT section |
| CAUTION | When battery is disconnected, radio will go into anti-theft protection mode. Obtain radio anti-theft protection code from owner prior to servicing vehicle. |
| Application | Specification |
|---|
| Compressor Type | Harrison HD6/HT6 6-Cyl. |
| Compressor Belt Tension | (1) |
| System Oil Capacity | (2) 8 ozs. |
| Refrigerant Capacity | 32 ozs. |
| System Operating Pressures (3) |
| High Side | 185-245 psi (13.0-17.2 kg/cm 2 ) |
| Low Side | 29-37 psi (2.0-2.6 kg/cm 2 ) |
| (1) Belt tension is okay if indicator mark on belt tensioner is within marked limits. (2) Use PAG Refrigerant Oil (Part No. 12345923). (3) Specifications with approximate operating pressures at 80°F (27°C) and humidity at 40 percent or more. |
| (1) | Belt tension is okay if indicator mark on belt tensioner is within marked limits. |
| (2) | Use PAG Refrigerant Oil (Part No. 12345923). |
| (3) | Specifications with approximate operating pressures at 80°F (27°C) and humidity at 40 percent or more. |
A/C SYSTEM SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor-To-Compressor Mount Bolt |
| Front Bolt | 37 (50) |
| Rear Bolt | 20 (27) |
| Refrigerant Hose/Line Fitting |
| At Accumulator | 25 (34) |
| At Compressor | 17 (23) |
| At Condenser | 25 (34) |
| At Evaporator | 25 (34) |
| INCH Lbs. (N.m) |
| A/C Cooling Fan Pressure Switch | 44 (5) |
| Pressure Cycling Switch | 44 (5) |
Scheme 1
Scheme 1: VACUUM HOSE DIAGRAM(S)
Automatic A/C-Heater System Wiring Diagram (1 Of 2). Scheme 2
Automatic A/C-Heater System Wiring Diagram (2 Of 2). Scheme 3
