Interior Lighting System: Other Nissan Versa II

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS articles of this Service Information.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

Precaution for Work

1. When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
2. When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
3. Protect the removed parts with a shop cloth and prevent them from being dropped.
4. Replace a deformed or damaged clip.
5. If a part is specified as a non-reusable part, always replace it with a new one.
6. Be sure to tighten bolts and nuts securely to the specified torque.
7. After installation is complete, be sure to check that each part works properly.
8. Follow the steps below to clean components: Water soluble dirt
9. Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
10. Then rub with a soft, dry cloth. Oily dirt
11. Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
12. Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
13. Then rub with a soft, dry cloth. Do not use organic solvent such as thinner, benzene, alcohol or gasoline. For genuine leather seats, use a genuine leather seat cleaner.

Special Service Tool

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Tool number (Kent-Moore No.) Tool name Description - (J-46534) Trim Tool Set Removing trim components

Scheme 16

Scheme 17

OUTLINE

1. Interior room lamp* is controlled by the interior room lamp timer control function of the BCM.
2. Trunk room lamp is controlled by the trunk room lamp control function of the BCM.

The timer control functions of the BCM activate based on inputs from the key cylinder lock/unlock switch LH, the door switches, the key switch and door lock/unlock switches.

*Interior room lamp and map lamp (if equipped) (when lamp switch is in DOOR position).

INTERIOR LAMP BATTERY SAVER CONTROL

If an interior lamp is left ON and does not turn OFF even when the doors are closed, the BCM turns off power to the interior lamps automatically to save the battery 15 minutes after the ignition switch is turned OFF. The BCM controls power and ground to all interior lamps.

After the battery saver system turns the lamps OFF, the lamps will illuminate again when

1. a signal is received from a key fob, main power window and door lock/unlock switch, power window and door lock/unlock switch RH or when the front door lock assembly LH (key cylinder switch) is locked or unlocked
2. a door is opened or closed
3. the key is removed from or inserted into the ignition switch (without intelligent key).

The interior lamp battery saver control time period can be changed with the function setting of CONSULT.

Scheme 18

BATTERY SAVER CONTROL

When the combination switch (lighting and turn signal switch) is in the 1st or 2nd position and the ignition switch is turned from ON or ACC to OFF, the battery saver control feature is activated. Under this condition, the illumination lamps remain illuminated for 15 minutes unless the combination switch (lighting and turn signal switch) position is changed. If the combination switch (lighting and turn signal switch) position is changed, then the illumination lamps are turned off after a 30 second delay. When the combination switch (lighting and turn signal switch) is turned from OFF to 1st or 2nd position after illumination lamps have been turned off by the battery saver control, the illumination lamps illuminate again.

DATA MONITOR

WORK SUPPORT

WITH INTELLIGENT KEY

WITHOUT INTELLIGENT KEY

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

DETAILED FLOW

1. INTERVIEW FOR MALFUNCTION Interview the symptom to the customer. : GO TO 2.
2. SYMPTOM CHECK Check the symptom from the customer's information. : GO TO 3.
3. BASIC INSPECTION Check the operation of each part. Check that any symptom occurs other than the interviewed symptom. : GO TO 4.
4. SELF-DIAGNOSIS WITH CONSULT Perform the self-diagnosis with CONSULT. Check that any DTC is detected. Is any DTC detected? YES: GO TO 5. NO: GO TO 6 .
5. TROUBLE DIAGNOSIS BY DTC Perform the trouble diagnosis for the detected DTC. Specify the malfunctioning part. : GO TO 9 .
6. FAIL-SAFE ACTIVATION CHECK Check that the symptom is applied to the fail-safe activation. Does the fail-safe activate? YES: GO TO 7. NO: GO TO 8 .
7. SYSTEM DIAGNOSIS Perform the system diagnosis for the system that the fail-safe activates. Specify the malfunctioning part. : GO TO 9 .
8. SYMPTOM DIAGNOSIS Perform the symptom diagnosis. Specify the malfunctioning part. : GO TO 9.
9. MALFUNCTION PART REPAIR Repair or replace the malfunctioning part. : GO TO 10.
10. REPAIR CHECK (SELF-DIAGNOSIS WITH CONSULT) Perform the self-diagnosis with CONSULT. Check that any DTC is not detected. Erase DTC if DTC is detected before the repair. Check that DTC is not detected again. Is any DTC detected? YES: GO TO 5 . NO: GO TO 11.
11. REPAIR CHECK (OPERATION CHECK) Check the operation of each part. Does it operate normally? YES: INSPECTION END NO: GO TO 3 .

Component Function Check

1. CHECK BATTERY SAVER OUTPUT/POWER SUPPLY FUNCTION CONSULT Turn ignition switch ON. Turn each interior lamp to the ON position. Interior room lamp Map lamp (if equipped) Trunk room lamp Select BATTERY SAVER of BCM (BATTERY SAVER) active test item. While operating the test item, check that each interior room lamp turns ON/OFF. OFF: Interior room lamp OFF ON: Interior room lamp ON Is the inspection result normal? YES: Battery saver output/power supply circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-605982-S12313954602014032500000) ".

1. CHECK INTERIOR ROOM LAMP CONTROL FUNCTION CONSULT Switch the map lamp switch or interior room lamp switch to DOOR. Turn ignition switch ON. Select INT LAMP of BCM (INT LAMP) ACTIVE TEST item. While operating the test items, check that each interior room lamp turns ON/OFF. On: Interior room lamp gradual brightening Off: Interior room lamp gradual dimming Does the interior room lamp turns ON/OFF (gradual brightening/dimming)? YES: Interior room lamp control circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-605982-S39314583612014032500000) ".

1. CHECK PUSH-BUTTON IGNITION SWITCH ILLUMINATION OPERATION CONSULT Turn the ignition switch ON. Select ENGINE SW ILLUMI of BCM (INTELLIGENT KEY) active test item. While operating the test item, check that the push-button ignition switch illumination turns ON/OFF ON: Push-button ignition switch illumination ON OFF: Push-button ignition switch illumination OFF Is the inspection result normal? YES: Push-button ignition switch illumination circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-605982-S34557919672014032500000) ".

ROOM LAMP

Scheme 34

1. Remove lens (1) and remove the room lamp by pulling down to release the room lamp metal clips (A).
2. Disconnect the harness connector from the room lamp and remove.

Scheme 35

1. Remove lens (1) by inserting suitable tool and releasing LH (switch side first).
2. Remove bulb (2).
