PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
Special Service Tool
The actual shapes of Kent-Moore tools may from those of special service tools illustrated here.
Tool number (Kent-Moore No.) Tool name Description KV991J0070 (J-45695) Coolant refill tool Refilling engine cooling system EG17650301 (J-33984-A) Radiator cap tester adapter Adapting radiator cap tester to radiator cap and radiator filler neck 28 (1.10) dia. 31.4 (1.236) dia. 41.3 (1.626) dia. Unit: mm (in) - (J-23688) Engine coolant refractometer Checking concentration of ethylene glycol in engine coolant
Scheme 24
Scheme 25
Commercial Service Tool
Tool name Description Power tool Loosening nuts, screws and bolts Radiator cap tester Checking radiator and radiator cap
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
CHECKING COOLING SYSTEM HOSES
Check hoses for the following
- Improper attachment
- Leaks
- Cracks
- Damage
- Loose connections
- Chafing
- Deterioration
Scheme 31
- Check that the reservoir tank engine coolant level is within the MAX (A) to MIN (B) range when the engine is cool.
- Adjust the engine coolant level if necessary. CAUTION: Refill the engine cooling system with the specified coolant or equivalent. Refer to " «FLUIDS AND LUBRICANTS»(ref-605940-S11091129442014032500000) ".
CHECKING COOLING SYSTEM FOR LEAKS
To check for leaks, apply pressure to the cooling system using suitable tool (A) and Tool (B).
Tool number (B): EG17650301 (J-33984-A)
Testing pressure: Refer to " RADIATOR: INSPECTION ".
Scheme 32
| WARNING | Do not remove the radiator cap when the engine is hot. Serious burns could occur from high-pressure coolant escaping from the radiator. |
| CAUTION | Higher test pressure than specified may cause radiator damage. |
Cooling fan and shroud
Inspect cooling fan and shroud for nicks, cracks, breaks and warping. Replace if necessary.
Water Inlet
After installation, attach the water inlet clip (A) on the oil level gauge guide (1) positioned at location (B) as shown below.
Scheme 33
Radiator
| Unit: kPa (kg/cm 2 , psi) | ||
|---|---|---|
| Cap relief pressure | Standard | 88 (0.90, 12.8) |
| Radiator leak test pressure | 156 (1.59, 22.6) | |
Thermostat
| Valve opening temperature | 80.5 - 83.5°C (177 - 182°F) |
|---|---|
| Maximum valve lift | 8.0 mm/95°C (0.315 in/203°F) |
| Valve closing temperature | 77°C (171°F) |
STANDARD VALUE SPECIFICATION
