Removal and Installation
| WARNING | Do not touch bulb with your hand while it is on or right after being turned off. Burning may result. |
| CAUTION | Do not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. |
Scheme 5
Scheme 6
- Release lens pawls using suitable tool (A) and remove. CAUTION: Apply protect tape (B) on suitable tool (A).
- Release map lamp housing pawl using suitable tool (A). CAUTION: Apply protect tape (B) on suitable tool (A).
- Disconnect the harness connector from map lamp and remove.
INSTALLATION
Installation is in the reverse order of removal.
Bulb Replacement
| WARNING | Do not touch bulb with your hand while it is on or right after being turned off. Burning may result. |
| CAUTION | Do not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect the performance of lamp. When replacing bulb, be sure to replace it with new one. |
Scheme 7
- Release lens pawls using suitable tool (A) and remove. CAUTION: Apply protect tape (B) on suitable tool (A).
- Remove the bulb.
Installation is in the reverse order of removal.
Installation is in the reverse order of removal.
Installation is in the reverse order of removal.
Note. Insert the lens hook end RH side first to install lens.
| WARNING | Do not touch bulb with your hand while it is on or right after being turned off. Burning may result. |
| CAUTION | Do not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. |
Scheme 8
- Remove the center console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-605962-S15056721332014032500000) ".
- Rotate shift selector lamp assembly (1) counter-clockwise and remove.
Installation is in the reverse order of removal.
| WARNING | Do not touch bulb with your hand while it is on or right after being turned off. Burning may result. |
| CAUTION | Do not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect the performance of lamp. When replacing bulb, be sure to replace it with new one. |
Scheme 9
- Remove shift selector lamp. Refer to " «REMOVAL AND INSTALLATION»(ref-605962-S04944230152014032500000) ".
- Pull shift selector bulb from bulb socket (1).
Installation is in the reverse order of removal.
Scheme 10
| WARNING | Do not touch bulb with your hand while it is on or right after being turned off. Burning may result. |
| CAUTION | Do not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect the performance of lamp. When replacing bulb, be sure to replace it with new one. |
Scheme 11
Scheme 12
- Release the trunk room lamp pawl to open lens.
- Remove the bulb.
- Release trunk room lamp pawl with a suitable tool (A)
- Disconnect harness connector from trunk room lamp and remove.
Installation is in the reverse order of removal.
| WARNING | Do not touch bulb with your hand while it is on or right after being turned off. Burning may result. |
| CAUTION | Do not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to the bulb. Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect the performance of lamp. When replacing bulb, be sure to replace it with new one. |
Scheme 13
- Release the trunk room lamp pawl to open lens.
- Remove the bulb.
Installation is in the reverse order of removal.
The illumination control switch is integrated in the combination meter. Refer to " REMOVAL AND INSTALLATION " (TYPE A) or " REMOVAL AND INSTALLATION " (TYPE B).
