Lighting System: Removal & Installation Nissan Versa I

Exterior Lights 12 illustrations ~633 words

Bulb Replacement

CAUTIONAfter installing bulb, be sure to install plastic cap and bulb socket securely to ensure watertightness.

INSTALLATION

Installation is in the reverse order of removal.

  1. After installation, perform aiming adjustment. Refer to " «AIMING ADJUSTMENT»(ref-337636-S38950149002009080600000) ".

Scheme 14

Scheme 14: Disassembly and Assembly
Scheme 14: Disassembly and Assembly
CAUTIONAfter installing bulb, be sure to install plastic cap and bulb socket securely to ensure watertightness.

REMOVAL

  1. Disconnect the negative battery terminal.
  2. Remove front bumper fascia. Refer to " «FRONT BUMPER»(ref-337622-S10043309532009080600000) ".
  3. Remove headlamp bolts (A).
  4. Pull headlamp (1) toward the vehicle front, disconnect connector, and remove headlamp.

Installation is in the reverse order of removal.

  1. After installation, perform aiming adjustment. Refer to " «AIMING ADJUSTMENT»(ref-337636-S24069905882009080600000) ".

Scheme 15

Scheme 15: Disassembly and Assembly
Scheme 15: Disassembly and Assembly
  1. Turn over the fender protector and undercover to obtain work space between the fender protector and fender.
  2. Disconnect front fog lamp connector.
  3. Remove pawl, and front bumper finisher from front bumper.
  4. Remove bolt and remove front fog lamp from bracket.

Installation is in the reverse order of removal.

Scheme 16

Scheme 16: Component Parts and Harness Connector Location
Scheme 16: Component Parts and Harness Connector Location

Bulb Replacement of Front Turn Signal Lamp

Refer to " BULB REPLACEMENT ".

Bulb Replacement of Rear Turn Signal Lamp

Refer to " BULB REPLACEMENT ".

Removal and Installation of Front Turn Signal Lamp

Refer to " REMOVAL AND INSTALLATION ".

Removal and Installation of Rear Turn Signal Lamp

Refer to " REMOVAL AND INSTALLATION ".

Scheme 17

Scheme 17: REMOVAL
Scheme 17: REMOVAL
  1. Remove steering column cover. Refer to " «INSTRUMENT PANEL ASSEMBLY»(ref-337620-S34347761412009080600000) ".
  2. While pressing pawls (A) in direction as shown, pull lighting and turn signal switch (1) toward LH door and disconnect from the base.

Installation is in the reverse order of removal.

Scheme 18

Scheme 18: REMOVAL
Scheme 18: REMOVAL
  1. Remove cluster lid C. Refer to " «INSTRUMENT PANEL ASSEMBLY»(ref-337620-S34347761412009080600000) ".
  2. Disconnect hazard switch connector.
  3. Press pawl (A) on reverse side and remove the hazard switch (1).

Installation is in the reverse order of removal.

Removal and Installation

Refer to " LIGHTING AND TURN SIGNAL SWITCH ".

Bulb Replacement of Rear Combination Lamp for Stop Lamp

Refer to " BULB REPLACEMENT ".

Scheme 19

Scheme 19: Removal
Scheme 19: Removal
  1. Remove the rear hatch finish panel. Refer to " «LUGGAGE FLOOR TRIM»(ref-337622-S35319546222009080600000) ".
  2. Disconnect the high-mounted stop lamp connector.
  3. Remove the nuts and remove the high-mounted stop lamp from rear hatch.

Installation is in the reverse order of removal.

CAUTIONProperly seal the high-mounted stop lamp base to the rear hatch to prevent water leaks.

Scheme 20

Scheme 20: Removal
Scheme 20: Removal
  1. Remove the rear parcel shelf. Refer to " «REMOVAL AND INSTALLATION»(ref-337622-S10551708272009080600000) ".
  2. Remove the high-mounted stop lamp screws (A) and remove the high-mounted stop lamp (1).
  3. Remove the high-mounted stop lamp finisher screws (A) and remove the high-mounted stop lamp finisher (1).

Installation is in the reverse order of removal.

Removal and Installation of Rear Combination Lamp for Stop Lamp

Refer to " REMOVAL AND INSTALLATION ".

Refer to " BULB REPLACEMENT ".

Refer to " REMOVAL AND INSTALLATION ".

Scheme 21

Scheme 21: Component Parts and Harness Connector Location
Scheme 21: Component Parts and Harness Connector Location
  1. Press the license plate lamp pawl on the side of the rear bumper fascia, then swing the license plate lamp down to release the license plate lamp hook from the rear bumper fascia.
  2. Disconnect the license plate lamp connector and remove the licence plate lamp.

Installation is in the reverse order of removal.

Scheme 22

Scheme 22: Removal
Scheme 22: Removal
  1. Remove the license plate lamp finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-337622-S19734622502009080600000) ".
  2. Remove the license plate lamp assembly (1).

Installation is in the reverse order of removal.

  1. Remove rear combination lamp nuts.
  2. Pull the rear combination lamp toward rear of the vehicle and remove from the vehicle.
  3. Disconnect rear combination lamp connector, and remove rear combination lamp.

Installation is in the reverse order of removal.

Scheme 23

Scheme 23: Removal
Scheme 23: Removal
  1. Remove trunk side finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-337622-S20706753252009080600000) ".
  2. Remove the rear combination lamp nuts (1).
  3. Remove the rear combination lamp (2).
  4. Remove the rear combination lamp seal (3).

Installation is in the reverse order of removal.

Installation is in the reverse order of removal.

Scheme 24

Scheme 24: Disassembly
Scheme 24: Disassembly
  1. Remove screw (A).
  2. Remove sunroof switch (1).
  1. Remove luggage compartment lamp from the luggage side finisher LH.
  2. Disconnect luggage compartment lamp connector.

Installation is in the reverse order of removal.

Scheme 25

Scheme 25: Component Parts and Harness Connector Location
Scheme 25: Component Parts and Harness Connector Location

Installation is in the reverse order of removal.
