Lighting System: Overview Nissan Versa I

System Description

Headlamp operation is controlled by the BCM (body control module) based on inputs from the combination switch (lighting switch). When the lighting switch is placed in the 2ND position, the BCM receives an input signal requesting the headlamps (and tail lamps) illuminate. The BCM sends a signal, via the CAN communication lines, to the IPDM E/R (intelligent power distribution module engine room) requesting the headlamps be turned ON. The CPU (central processing unit) located in the IPDM E/R controls ground for the headlamp high and headlamp low relay coils. These relays direct power to the respective headlamps, which then illuminate.

Low Beam Operation

With the lighting switch in 2ND position, the BCM receives an input signal requesting the headlamps to illuminate. The BCM then sends a signal, via the CAN communication lines, to the IPDM E/R requesting the low beam headlamps be turned ON. The CPU located in the IPDM E/R controls ground to the headlamp low relay coil, which when energized, directs power

1. through 15A fuse (No. 41, located in IPDM E/R)
2. through IPDM E/R terminal 54
3. to headlamp RH terminal 3, and
4. through 15A fuse (No. 40, located in IPDM E/R)
5. through IPDM E/R terminal 52
6. to headlamp LH terminal 3.

Ground is supplied

1. to headlamp RH and LH terminals 2
2. through grounds E15 and E24.

With power and ground supplied, low beam headlamps illuminate.

High Beam Operation/Flash-to-Pass Operation

With the lighting switch in 2ND position and high beam switch in the HIGH position, the BCM receives an input signal requesting the headlamp high beams to illuminate. The flash to pass feature can be used any time and also sends a signal to the BCM. This input signal is then communicated to the IPDM E/R and the combination meter via the CAN communication. The CPU located in the IPDM E/R controls the headlamp high relays (LH and RH), which when energized, directs power

1. through 10A fuse (No. 34, located in IPDM E/R)
2. through IPDM E/R terminal 56
3. to headlamp RH terminal 1, and
4. through 10A fuse (No. 35, located in IPDM E/R)
5. through IPDM E/R terminal 55
6. to headlamp LH terminal 1.

Ground is supplied

1. to headlamp RH and LH terminal 2
2. through grounds E15 and E24.

With power and ground supplied, the high beam headlamps illuminate.

The BCM sends a signal, via the CAN communication lines, to the combination meter requesting the high beam indicator lamp be turned ON.

CAN COMMUNICATION SYSTEM DESCRIPTION

Refer to " SYSTEM DESCRIPTION ".

Scheme 1

Headlamp operation is controlled by the BCM (body control module) based on inputs from the combination switch (lighting switch). When the lighting switch is placed in the 2ND position, the BCM receives an input signal requesting the headlamps (and tail lamps) illuminate. The request is then communicated to the IPDM E/R (intelligent power distribution module engine room) via the CAN communication lines. The CPU (central processing unit) located in the IPDM E/R controls ground for the headlamp high and headlamp low relay coils. These relays direct power to the respective headlamps, which then illuminate. When the headlamp switch is OFF or in the 1ST position (parking lamps ON), the parking brake is released and the engine is running, the IPDM E/R de-energizes the headlamp relays and supplies ground to the daytime light relay 1 to actuate the daytime light function.

With the lighting switch in 2ND position, the BCM receives an input signal requesting the headlamps to illuminate. This input signal is communicated to the IPDM E/R via the CAN communication lines. The CPU located in the IPDM E/R controls the headlamp low relay coil, which when energized, directs power

1. through 15A fuse (No. 41, located in IPDM E/R)
2. through IPDM E/R terminal 54
3. to daytime light relay 2 terminals 1 and 5 (energizing the relay)
4. through daytime light relay 2 terminal 3
5. to front combination lamp RH terminal 3, and
6. through 15A fuse (No. 40, located in IPDM E/R)
7. through IPDM E/R terminal 52
8. to front combination lamp LH terminal 3.

Ground is supplied

1. to front combination lamp LH terminal 2
2. through grounds E15 and E24
3. to headlamp RH terminal 2 via
4. daytime light relay 1 terminals 3 and 4
5. through grounds E15 and E24.

With power and ground supplied, low beam headlamps illuminate.

High Beam/Flash-to-Pass Operation

With the lighting switch in 2ND position and high beam switch in the HIGH position, the BCM receives input signal requesting the headlamp high beams to illuminate. The flash-to-pass feature can be used any time and also sends a signal to the BCM. This input signal is communicated to the IPDM E/R and the combination meter via the CAN communication lines. The CPU located in the IPDM E/R controls the headlamp high relay coil, which when energized, directs power

1. through 10A fuse (No. 34, located in IPDM E/R)
2. through IPDM E/R terminal 56
3. to front combination lamp RH terminal 1, and
4. through 10A fuse (No. 35, located in IPDM E/R)
5. through IPDM E/R terminal 55
6. to front combination lamp LH terminal 1.

Ground is supplied

1. to front combination lamp LH terminal 2
2. through grounds E15 and E24, and
3. to front combination lamp RH terminal 2 via
4. daytime light relay 1 terminals 3 and 4
5. through grounds E15 and E24.

With power and ground supplied, the high beam headlamps illuminate.

The BCM sends a signal to the combination meter requesting the high beam indicator lamp to turn ON.

Daytime Light System Operation

With the lighting switch in the OFF or 1ST position (parking lamps ON), the BCM receives inputs requesting the headlights off. If the parking brake is released and the engine is running, the BCM then sends a signal, via the CAN communication lines, requesting the IPDM E/R to activate the daytime light system. The CPU located in the IPDM E/R controls the daytime light relay 1 coil, which when energized, directs power

1. from daytime light relay 1 terminal 3
2. to front combination lamp RH terminal 2
3. through front combination lamp RH high beam terminal 1
4. to IPDM E/R terminal 56
5. through 10A fuse (No. 34, located in IPDM E/R) and
6. through both de-energized headlamp high relays
7. to 10A fuse (No. 35, located in IPDM E/R)
8. through IPDM E/R terminal 55
9. to front combination lamp LH terminal high beam 1.

Ground is supplied

1. to front combination lamp LH terminal 2
2. through grounds E15 and E24
3. to daytime light relay 1 terminal 1
4. through IPDM E/R terminal 6.

With power and ground supplied, high beam headlamps illuminate at reduced intensity.

Refer to " LAN SYSTEM - VERSA article".

Scheme 2

The front fog lamps are controlled by lighting switch inputs to the BCM (body control module). The lighting switch must be in the 1ST or 2ND position with the high beams OFF before the BCM will request the IPDM E/R (intelligent power distribution module engine room) to turn the front fog lamps on. The BCM requests the front fog lamps over the CAN communication lines to the IPDM E/R. The CPU (central processing unit) of the IPDM E/R controls the front fog lamp relay coil ground. When energized, the relay directs power to the front fog lamps.

OUTLINE

Power is supplied at all times

1. to front fog lamp relay (located in IPDM E/R)
2. to ignition relay (located in IPDM E/R)
3. through 15A fuse (No. 52, located in IPDM E/R) and
4. through 20A fuse (No. 53, located in IPDM E/R)
5. to CPU located in IPDM E/R
6. through 40A fusible link (letter g, located in the fuse and fusible link box)
7. to BCM terminal 70
8. through 10A fuse [No. 8, located in fuse block (J/B)]
9. to BCM terminal 57
10. through 10A fuse [No. 13, located in fuse block (J/B)]
11. to combination meter terminal 27.

With the ignition switch in the ON or START position, power is supplied

1. to ignition relay (located in IPDM E/R)
2. through 10A fuse [No. 6, located in fuse block (J/B)]
3. to BCM terminal 38.

With the ignition switch in the ACC or ON position, power is supplied

1. through 10A fuse [No. 20, located in fuse block (J/B)]
2. to BCM terminal 11.

Ground is supplied

1. to BCM terminal 67
2. through grounds M57 and M61
3. to IPDM E/R terminals 39 and 59
4. through grounds E15 and E24.

FOG LAMP OPERATION

The front fog lamp switch is built into the lighting switch. The lighting switch must be in 1ST position or 2ND position and front fog lamp switch must be ON position for front fog lamp operation. The fog lamp will not operate with the high beam headlamps ON.

When the front fog lamp switch is in the ON position, the BCM sends a request, via the CAN communication lines, to the CPU of the IPDM E/R to ground the coil side of the front fog lamp relay. The front fog lamp relay then directs power

1. through 15A fuse (No. 56, located in IPDM E/R)
2. through IPDM E/R terminal 50
3. to front fog lamp LH terminal 1, and
4. through IPDM E/R terminal 51
5. to front fog lamp RH terminal 1.

Ground is supplied

1. to front fog lamp terminal 2
2. through grounds E15 and E24.

With power and grounds supplied, front fog lamps illuminate.

Refer to " LAN SYSTEM - VERSA article".

TURN SIGNAL OPERATION

Power is supplied at all times

1. through 40A fusible link (letter g, located in the fuse and fusible link box)
2. to BCM (body control module) terminal 70
3. through 10A fuse [No. 8, located in the fuse block (J/B)]
4. to BCM terminal 57
5. through 10A fuse [No. 13, located in the fuse block (J/B)]
6. to combination meter terminal 27.

With the ignition switch in the ON or START position, power is supplied

1. through 10A fuse [No. 6, located in fuse block (J/B)]
2. to BCM terminal 38
3. through 10A fuse [No. 3, located in fuse block (J/B)]
4. to combination meter terminal 28.

With the ignition switch in the ACC or ON position, power is supplied

1. through 10A fuse [No. 20, located in the fuse block (J/B)]
2. to BCM terminal 11.

Ground is supplied

1. to BCM terminal 67 and
2. to combination meter terminals 21, 22 and 23
3. through grounds M57 and M61.

HAZARD LAMP OPERATION

Power is supplied at all times

1. through 40A fusible link (letter g, located in fuse, fusible link and relay box)
2. to BCM terminal 70
3. through 10A fuse [No. 8, located in fuse block (J/B)]
4. to BCM terminal 57
5. through 10A fuse [No. 13, located in fuse block (J/B)]
6. to combination meter terminal 27.

Ground is supplied

1. to hazard switch terminal 1
2. to BCM terminal 67, and
3. to combination meter terminals 21, 22 and 23
4. through grounds M57 and M61.

When hazard switch is depressed, ground is supplied

1. through hazard switch terminal 2
2. to BCM terminal 29.

BCM then supplies power

1. to front combination lamp LH terminal 4 and
2. to rear combination lamp LH terminal 6
3. through BCM terminal 60
4. to front combination lamp RH terminal 4 and
5. to rear combination lamp RH terminal 6
6. through BCM terminal 61.

Ground is supplied

1. to front combination lamp LH and RH terminal 5
2. through grounds E15 and E24
3. to rear combination lamp LH terminal 1
4. through grounds B7 and B19
5. to rear combination lamp RH terminal 1
6. through grounds B117, B132 and D402 (hatchback).

The BCM also supplies input to combination meter across the CAN communication lines. This input is processed by unified meter control unit in combination meter, which in turn supplies ground to the left and right turn signal indicator lamps.

With power and input supplied, BCM controls flashing of hazard warning lamps.

REMOTE KEYLESS ENTRY SYSTEM OPERATION

Power is supplied at all times

1. through 40A fusible link (letter g, located in fuse, fusible link and relay box)
2. to BCM terminal 70
3. through 10A fuse [No. 13, located in fuse block (J/B)]
4. to combination meter terminal 27.

Ground is supplied

1. to BCM terminal 67 and
2. to combination meter terminals 21, 22 and 23
3. through grounds M57 and M61.

When the remote keyless entry system is triggered by input from the keyfob, the BCM supplies power

1. through BCM terminal 60
2. to front combination lamp LH terminal 4 and
3. to rear combination lamp LH terminal 6
4. through BCM terminal 61
5. to front turn signal lamp RH terminal 4 and
6. to rear combination lamp RH terminal 6.

Ground is supplied

1. to front combination lamp LH and RH terminals 5
2. through grounds E15 and E24
3. to rear combination lamp LH terminal 1
4. through grounds B7 and B19
5. to rear combination lamp RH terminal 1
6. through grounds B117, B132 (all models) and D402 (with hatchback).

The BCM also supplies input to combination meter via the CAN communication lines. This input is processed by the unified meter control unit in combination meter, which in turn supplies ground to the left and right turn signal indicator lamps.

With power and ground supplied, BCM controls flashing of hazard warning lamps when keyfob is used to activate remote keyless entry system.

Refer to " LAN SYSTEM - VERSA article".

Scheme 3

The control of the parking, license plate and tail lamp operation is dependent upon the position of lighting switch. When the lighting switch is placed in the 1ST position, the BCM (body control module) receives input signal requesting the parking, license plate and tail lamps to illuminate. This input signal is communicated to the IPDM E/R (intelligent power distribution module engine room) via the CAN communication lines. The CPU (central processing unit) located in the IPDM E/R controls the tail lamp relay coil. This relay, when energized, directs power to parking, license plate and tail lamps, which then illuminate.

Power is supplied at all times

1. to ignition relay located in IPDM E/R
2. to tail lamp relay located in IPDM E/R
3. through 15A fuse (No. 52, located in IPDM E/R) and
4. through 20A fuse (No. 53, located in IPDM E/R)
5. to the CPU located in the IPDM E/R
6. through 40A fusible link (letter g, located in fuse and fusible link block)
7. to BCM terminal 70
8. through 10A fuse [No. 8, located in fuse block (J/B)]
9. to BCM terminal 57.

With the ignition switch in the ON or START position, power is supplied

1. through 10A fuse [No. 6, located in fuse block (J/B)]
2. to BCM terminal 38
3. to ignition relay located in IPDM E/R and
4. through the ignition relay
5. to the CPU of the IPDM E/R.

With the ignition switch in the ACC or ON position, power is supplied

1. through 10A fuse [No. 20, located in fuse block (J/B)]
2. to BCM terminal 11.

Ground is supplied

1. to BCM terminal 67
2. through grounds M20 and M61
3. to IPDM E/R terminals 59 and 39
4. through grounds E15 and E24.

OPERATION BY LIGHTING SWITCH

With the lighting switch in the 1ST or 2ND position, the BCM receives an input signal requesting parking, license plate and tail lamps to illuminate. This input signal is communicated to the IPDM E/R via the CAN communication lines. The CPU, located in the IPDM E/R, controls the tail lamp relay coil. When energized, the tail lamp relay directs power

1. through 10A fuse (No. 37, located in IPDM E/R)
2. through IPDM E/R terminal 26
3. to front combination lamp LH terminal 6, and
4. through IPDM E/R terminal 27
5. to front combination lamp RH terminal 6
6. through IPDM E/R terminal 28
7. to rear combination lamp LH terminal 4 and
8. to license plate lamp LH and RH terminal 1
9. through IPDM E/R terminal 29
10. to rear combination lamp RH terminal 4.

Ground is supplied

1. to front combination lamp LH and RH terminal 7
2. through grounds E15 and E24
3. to rear combination lamp LH terminal 1 and
4. to license plate lamp LH and RH terminal 2
5. through grounds B7 and B19, and
6. to rear combination lamp RH terminal 1
7. through grounds B117, B132 (all models) and D402 (with hatchback).

With power and ground supplied, parking, license plate and tail lamps illuminate.

Refer to " CAN FUNDAMENTAL ".

Scheme 4

When room lamp switch is in DOOR position, room lamp ON/OFF is controlled by timer according to signals from switches including key switch, front door switch LH, unlock signal from keyfob, door lock and unlock switch, key cylinder lock and unlock switch, ignition switch.

When room lamp turns ON, there is a gradual brightening over 1 second.

When room lamp turns OFF, there is a gradual dimming over 1 second.

Interior room lamp timer is controlled by BCM (body control module).

Interior room lamp timer control settings can be changed with CONSULT-III.

SWITCH OPERATION

When map lamp switch is ON (with map lamp), ground is supplied

1. through grounds M57 and M61.
2. to map lamp terminal 1

Power is supplied

1. through BCM terminal 56
2. to map lamp terminal 4.

When interior room lamp switch is ON, ground is supplied

1. to interior room lamp terminal 1
2. through map lamp (with map lamp) terminal 7
3. through map lamp (with map lamp) terminal 1
4. through grounds M57 and M61.

Power is supplied

1. through BCM terminal 56
2. through map lamp (with map lamp) terminal 4
3. through map lamp (with map lamp) terminal 6
4. to room lamp terminal 3.

The control of the illumination lamps operation is dependent upon the position of the lighting switch. When the lighting switch is placed in the 1ST or 2ND position, the BCM (body control module) receives input signal requesting the illumination lamps to illuminate. This input signal is communicated to IPDM E/R (intelligent power distribution module engine room) across CAN communication lines. CPU (central processing unit) located in the IPDM E/R controls the tail lamp relay coil. This relay, when energized, directs power to the illumination lamps, which then illuminate.

Power is supplied at all times

1. to ignition relay, located in IPDM E/R
2. to tail lamp relay, located in IPDM E/R
3. through 15A fuse (No. 52, located in IPDM E/R) and
4. through 20A fuse (No. 53, located in IPDM E/R)
5. to CPU located in IPDM E/R
6. through 40A fusible link (letter g , located in fuse and fusible link box)
7. to BCM terminal 70, and
8. through 10A fuse [No. 8, located in fuse block (J/B)]
9. to BCM terminal 57.

With the ignition switch in the ON or START position, power is supplied

1. to ignition relay, located in IPDM E/R, and
2. through 10A fuse [No. 6, located in fuse block (J/B)]
3. to BCM terminal 38.

With the ignition switch in the ACC or ON position, power is supplied

1. through 10A fuse [No. 20, located in fuse block (J/B)]
2. to BCM terminal 11.

Ground is supplied

1. to BCM terminal 67
2. through grounds M57 and M61, and
3. to IPDM E/R terminals 39 and 59
4. through grounds E15 and E24.

ILLUMINATION OPERATION BY LIGHTING SWITCH

With the lighting switch in the 1ST or 2ND position, BCM receives input signal requesting the illumination lamps to illuminate. This input signal is communicated to IPDM E/R across CAN communication lines. CPU located in the IPDM E/R controls the tail lamp relay coil, which, when energized, directs power

1. through 10A fuse (No. 37, located in IPDM E/R)
2. through IPDM E/R terminal 29
3. to microphone terminal 3 (with Bluetooth)
4. to illumination control switch terminal 1
5. to glove box lamp terminal 1 (with glovebox lamp)
6. to audio unit terminal 9
7. to front air control terminal 5
8. to A/T device terminal 3 (with 4-speed A/T)
9. to CVT device terminal 3 (with CVT)
10. to hazard switch terminal 3
11. to combination meter terminal 12
12. to door mirror remote control switch terminal 16, and
13. to main power window and door lock/unlock switch terminal 4 (with hatchback early production).

Ground is supplied

1. to microphone terminal 2 (with Bluetooth)
2. to glove box lamp terminal 2 (with glove box lamp), and
3. to illumination control switch terminal 3
4. through grounds M57 and M61.

The illumination control switch controls illumination intensity by varying the ground to the following

1. through illumination control switch terminal 2
2. to audio unit terminal 8
3. to front air control terminal 6
4. to A/T device terminal 4 (with 4-speed A/T)
5. to CVT device terminal 3 (with CVT)
6. to hazard switch terminal 4
7. to combination meter terminal 13
8. to door mirror remote control switch terminal 15
9. to main power window and door lock/unlock switch terminal 14 (with hatchback early production).

With power and ground supplied, illumination lamps illuminate.

Refer to " LAN SYSTEM - VERSA article".

Scheme 5
