Aiming Adjustment
The front fog lamp is a semi-sealed beam type which uses a replaceable halogen bulb. Before performing aiming adjustment, make sure of the following.
- Keep all tires inflated to correct pressure.
- Place vehicle on level surface.
- Set that there is no-load in vehicle other than the driver (or equivalent weight placed in driver's position). Coolant, engine oil filled up to correct level and full fuel tank, spare tire, jack and tools are properly stowed.
Adjust aiming in the vertical direction by turning the adjusting screw (A).
Scheme 6
Scheme 7
- Set the distance (C) between the screen and the center of front fog lamp lens (E) as shown.
- Turn front fog lamps (1) to ON.
- Adjust front fog lamps using adjusting screw so that the top edge of the high intensity zone (A) is as shown. AIMING SPECIFICATION Aiming distance from center of fog lamp to screen (C) 25,000 mm (984.3 in) Foglamp beam width (D) 870 mm (34.3 in) Horizontal distance from ground to bottom edge of high intensity zone (B) 220 mm (8.7 in) Horizontal distance from bottom edge to top edge of high intensity zone (A) 21.75 mm (0.9 in) NOTE: When performing adjustment, if necessary, cover the headlamps and opposite front fog lamp.
Scheme 8
- Turn lighting switch OFF.
- Turn off the fender protector (front) to obtain work space between the fender protector and fender.
- Disconnect front fog lamp connector (1).
- Turn bulb socket (2) counterclockwise unlock and remove it.
- Remove bulb from its socket.
