Automatic Transmission Shift Interlock System: Overview Nissan Titan I

Scheme 285

Scheme 286

Scheme 287

1. Remove the select lever knob.
2. Remove console finisher. Refer to «A/T CONSOLE FINISHER»(ref-170082-S00241914092004122900000) in GAUGES & INSTRUMENT PANEL - TITAN article in ACCESSORIES & BODY, CAB.
3. Remove center console. Refer to «CENTER CONSOLE»(ref-170082-S38563162332004122900000) in «A/T CONSOLE FINISHER»(ref-170082-S00241914092004122900000) in GAUGES & INSTRUMENT PANEL - TITAN article in ACCESSORIES & BODY, CAB.
4. Disconnect A/T device harness connector.
5. Disconnect selector control cable.
6. Remove control device assembly.

Scheme 288

1. Remove the column shift control. Refer to «STEERING COLUMN»(ref-169464-S15558499192004120900000) article in STEERING.
2. Remove the A/T cable clip lock plate and remove the cable from column shifter pin.
