INSTALLATION
Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
- While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger room air pressure when a door is closed.
- The molding must be installed securely so that it is in position and leaves no gap.
- Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
| WARNING | Keep heat and open flames away from primers and adhesive as they are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the windshield in case of an accident. |
| CAUTION | Do not use an adhesive which is past its usable term. Shelf life of the adhesive is limited to six months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidities. The curing time will increase under lower temperatures and lower humidities. |
REMOVAL
- Partially remove the headlining (rear edge). Refer to " «REMOVAL AND INSTALLATION»(ref-367309-S08876778792010072700000) ".
- Remove the rear seat cushion and the rear seatback. Refer to " «REMOVAL AND INSTALLATION»(ref-367336-S34239533342010072700000) " (folding) or " «REMOVAL AND INSTALLATION»(ref-367336-S02222911272010072700000) " (fixed).
- Remove the rear seatback finisher and the rear pillar finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-367309-S25066500402010072700000) ".
- Remove the rear parcel shelf finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-367309-S14606623722010072700000) ".
- Disconnect the harness connector.
- Apply protective tape around the rear window glass to protect the painted surface from damage. After removing moldings, remove glass using piano wire or power cutting tool (A) and an inflatable pump bag (B). If a rear window glass is to be reused, mark the body and the glass with mating marks. WARNING: When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help prevent glass splinters from entering your eyes or cutting your hands. CAUTION: When a rear window glass is to be reused, do not use a cutting knife or power cutting tool. Be careful not to scratch the glass when removing. Do not set or stand the glass on its edge. Small chips may develop into cracks.
Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
- While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger room air pressure when a door is closed.
- The molding must be installed securely with the double-faced adhesive tape so that it is in position and leaves no gap.
- Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
| WARNING | Keep heat and open flames away from primers and adhesive as they are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the rear window glass in case of an accident. |
| CAUTION | Do not use an adhesive which is past its usable term. Shelf life of the adhesive is limited to six months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidity. The curing time will increase under lower temperature and lower humidity. |
Installation is in the reverse order of removal.
Scheme 65
Scheme 66
- Pull out all the terminals from the connector. NOTE: Before pulling out the terminal, note the connector terminal arrangement.
- Turn the mirror glass surface upward.
- Apply a protective tape (A) to the housing.
- Insert a suitable tool (B) into the concave gap between mirror holder (1) and power unit (2). Push up tabs (3) (two locations) on mirror holder to disengage lower part of mirror holder, and remove mirror body assembly. NOTE: When pushing up the tabs, do not forcefully push up only (1) concave position but try to push up (2) concave positions.
- Remove the mirror body (1) from the mirror housing assembly (2).
- Remove four screws from door mirror actuator in an alternating pattern.
- Remove door mirror actuator from mirror housing assembly and disconnect electrical connector.
Scheme 67
- Connect door mirror actuator electrical connector.
- Install door mirror actuator into door mirror housing using four screws and tighten in an alternating pattern.
- Warm the lower tabs with a dryer or equivalent. NOTE: Warm the lower tabs sufficiently before installing the mirror body. The tabs may be broken if it is cold. Be especially careful in the cold weather.
- Engage upper tabs of mirror body (1) with power unit (2). Then, press lower part of mirror glass down until the lower part snaps to allow engagement of lower tabs. NOTE: After installation, visually check that the lower tabs are securely engaged when viewed from the bottom of mirror surface.
- Insert the harness terminals into the connector. NOTE: Make sure to insert the harness terminals into the correct connector. Do not confuse the locations.
Insert a suitable tool (A) to release the inside mirror (1). Slide the inside mirror (1) upward and remove the inside mirror from the base (2).
Scheme 68
Installation is in the reverse order of removal.
| CAUTION | Be sure to insert the inside mirror to the mirror base until the pawl is engaged to the mirror base. |
