Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in SUPPLEMENTAL RESTRAINT SYSTEM and SEAT BELTS articles.

WARNING

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SUPPLEMENTAL RESTRAINT SYSTEM (SRS) . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING

When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service.

Precaution Necessary for Steering Wheel Rotation After Battery Disconnect

Note. This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYSTEM). Remove and install all control units after disconnecting both battery cables with the ignition knob in the "LOCK" position. Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.

For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mechanism is adopted on the key cylinder.

For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and steering wheel rotation will become impossible.

If steering wheel rotation is required when battery power is interrupted, follow the procedure below before starting the repair operation.

Special Service Tool

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

TOOL DESCRIPTION CHART Tool number (Kent-Moore No.) Tool name Description KV10115801 (J-38956) Oil filter wrench Removing and installing oil filter 64.3 mm (2.531 in) KV991J0010 (J-23688) Engine coolant refractometer Checking concentration of ethylene glycol in engine coolant EG17650301 (J-33984-A) Radiator cap tester adapter Adapting radiator cap tester to radiator cap and radiator filler neck 28 (1.10) dia. 31.4 (1.236) dia. 41.3 (1.626) dia. Unit: mm (in) KV991J0070 (J-45695) Coolant Refill Tool Refilling engine cooling system

Scheme 21

Scheme 21: Special Service Tool

Scheme 22

Commercial Service Tool

TOOL DESCRIPTION CHART (Kent-Moore No.) Tool name Description Power tool Loosening bolts and nuts Spark plug wrench Removing and installing spark plug

General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform checks and inspections themselves or they can have their NISSAN dealers do them.

OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

Item		Reference
Tires	Check the pressure with a gauge often and always prior to long distance trips. Adjust the pressure in all tires, including the spare, to the specified pressure. Check carefully for damage, cuts or excessive wear.	" TIRE "
Wheel nuts	When checking the tires, make sure no nuts are missing, and check for any loose nuts. Tighten if necessary.	" ADJUSTMENT "
Windshield	Clean the windshield on a regular basis. Check the windshield at least every six months for cracks or other damage. Repair as necessary.
Tire rotation	Tires should be rotated every 12,000 km (7,500 miles).	" ADJUSTMENT "
Tire pressure monitoring system (TPMS) transmitter components	Replace the TPMS transmitter grommet seal, valve core and cap when the tires are replaced due to wear or age.	" TRANSMITTER (PRESSURE SENSOR) "
Wheel alignment and balance	If the vehicle pulls to either side while driving on a straight and level road, or if you detect uneven or abnormal tire wear, there may be a need for wheel alignment. If the steering wheel or seat vibrates at normal highway speeds, wheel balancing may be needed.	" WHEEL ALIGNMENT (UNLADEN*) " and " ADJUSTMENT "
Windshield wiper blades	Check for cracks or wear if they do not wipe properly.
Doors and engine hood	Check that all doors and the engine hood operate smoothly as well as the trunk lid and back hatch. Also make sure that all latches lock securely. Lubricate if necessary. Make sure that the secondary latch keeps the hood from opening when the primary latch is released. When driving in areas using road salt or other corrosive materials, check lubrication frequently.	" LUBRICATING LOCKS, HINGES AND HOOD LATCH "
Lamps	Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other lamps are all operating properly and installed securely. Also check headlamp aim. Clean the headlamps on a regular basis.	" AIMING ADJUSTMENT "

ITEM REFERENCE CHART

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.

Item		Reference
Warning lamps and chimes	Make sure that all warning lamps and chimes are operating properly.
Windshield wiper and washer	Check that the wipers and washer operate properly and that the wipers do not streak.
Windshield defroster	Check that the air comes out of the defroster outlets properly and in sufficient quantity when operating the heater or air conditioning.
Steering wheel	Check that it has the specified play. Be sure to check for changes in the steering condition, such as excessive play, hard steering or strange noises. Free play: Less than 35 mm (1.38 in)
Seats	Check seat position controls such as seat adjusters, seat back recliner, etc. to make sure they operate smoothly and that all latches lock securely in every position. Check that the head restraints move up and down smoothly and that the locks (if equipped) hold securely in all latched positions. Check that the latches lock securely for folding-down rear seat backs.
Seat belts	Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and retractors) operate properly and smoothly and are installed securely. Check the belt webbing for cuts, fraying, wear or damage.	" SEAT BELT INSPECTION "
Accelerator pedal	Check the pedal for smooth operation and make sure the pedal does not catch or require uneven effort. Keep the floor mats away from the pedal.
Clutch pedal	Make sure the pedal operates smoothly and check that it has the proper free play.	CHECKING CLUTCH FLUID LEVEL AND LEAKS
Brakes	Check that the brake does not pull the vehicle to one side when applied.
Brake pedal and booster	Check the pedal for smooth operation and make sure it has the proper distance under it when depressed fully. Check the brake booster function. Be sure to keep floor mats away from the pedal.	CHECKING BRAKE FLUID LEVEL AND LEAKS and CHECKING BRAKE LINE AND CABLES
Parking brake	Check that the lever has the proper travel and make sure that the vehicle is held securely on a fairly steep hill when only the parking brake is applied.	PARKING BRAKE CONTROL
CVT P (Park) position mechanism	On a fairly steep hill check that the vehicle is held securely with the selector lever in the "P" position without applying any brakes.

ITEM REFERENCE CHART

UNDER THE HOOD AND VEHICLE

The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).

Item		Reference
Windshield washer fluid	Check that there is adequate fluid in the tank.
Engine coolant level	Check the coolant level when the engine is cold.	ENGINE COOLANT (MR) ENGINE COOLANT (QR)
A/C condenser, radiator and hoses	Check the front of the condenser and radiator and clean off any dirt, insects, leaves, etc., that may have accumulated. Make sure the radiator hoses have no cracks, deformation, deterioration or loose connections.
Brake and clutch fluid levels	Make sure that the brake and clutch fluid levels are between the "MAX" and "MIN" lines on the reservoirs.	CHECKING BRAKE FLUID LEVEL AND LEAKS and CHECKING CLUTCH FLUID LEVEL AND LEAKS
Battery	Check the fluid level in each cell. It should be between the "MAX" and "MIN" lines. Vehicles operated in high temperatures or under severe conditions require frequent checks of the battery fluid level.
Engine drive belts	Make sure that no belt is frayed, worn, cracked or oily.	DRIVE BELTS (MR) DRIVE BELT (QR)
Engine oil level	Check the level on the dipstick after parking the vehicle on a level spot and turning off the engine.	ENGINE OIL LEVEL (MR) ENGINE OIL (QR)
Exhaust system	Make sure there are no loose supports, cracks or holes. If the sound of the exhaust seems unusual or there is a smell of exhaust fumes, immediately locate the trouble and correct it.	CHECKING EXHAUST SYSTEM
Underbody	The underbody is frequently exposed to corrosive substances such as those used on icy roads or to control dust. It is very important to remove these substances, otherwise rust will form on the floor pan, frame, fuel lines and around the exhaust system. At the end of winter, the underbody should be thoroughly flushed with plain water, being careful to clean those areas where mud and dirt can easily accumulate.
Fluid leaks	Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle has been parked for a while. Water dripping from the air conditioner after use is normal. If you should notice any leaks or gasoline fumes are evident, check for the cause and correct it immediately.

ITEM REFERENCE CHART

Two different maintenance schedules are provided, and should be used, depending upon the conditions in which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic maintenance at the same mileage/time intervals .

Schedule 1	Follow Periodic Maintenance Schedule 1 if your driving habits frequently includes one or more of the following driving conditions: Repeated short trips of less than 5 miles (8 km). Repeated short trips of less than 10 miles (16 km) with outside temperatures remaining below freezing. Operating in hot weather in stop-and-go "rush hour" traffic. Extensive idling and/or low speed driving for long distances, such as police, taxi or door-to-door delivery use. Driving in dusty conditions. Driving on rough, muddy, or salt spread roads. Towing a trailer, using a camper or a car-top carrier.	Emission Control System Maintenance	EMISSION CONTROL SYSTEM MAINTENANCE
Schedule 1		Chassis and Body Maintenance	CHASSIS AND BODY MAINTENANCE
Schedule 2	Follow Periodic Maintenance Schedule 2 if none of the driving conditions shown in Schedule 1 apply to your driving habits.	Emission Control System Maintenance	EMISSION CONTROL SYSTEM MAINTENANCE
Schedule 2		Chassis and Body Maintenance	CHASSIS AND BODY MAINTENANCE

PERIODIC MAINTENANCE REFERENCE CHART

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only
MAINTENANCE OPERATION		MAINTENANCE INTERVAL								Reference
Perform at number of miles, kilometers or months, whichever comes first.	Miles x 1,000 (km x 1,000) Months	3.75 (6) 3	7.5 (12) 6	11.25 (18) 9	15 (24) 12	18.75 (30) 15	22.5 (36) 18	26.25 (42) 21	30 (48) 24	Reference
Drive belt	NOTE (1)									DRIVE BELTS (MR) DRIVE BELT (QR)
Air cleaner filter	NOTE (2)								[R]	AIR CLEANER FILTER (MR) AIR CLEANER FILTER (QR)
EVAP vapor lines									I (6)	EVAP VAPOR LINES (MR) EVAP VAPOR LINES (QR)
Fuel lines									I (6)	FUEL LINES (MR) FUEL LINES (QR)
Fuel filter	NOTE (3)
Engine coolant	NOTE (4)									ENGINE COOLANT (MR) ENGINE COOLANT (QR)
Engine oil		R	R	R	R	R	R	R	R	ENGINE OIL (MR) ENGINE OIL (QR)
Engine oil filter (Use genuine NISSAN oil filter or equivalent)		R	R	R	R	R	R	R	R	OIL FILTER (MR) OIL FILTER (QR)
Spark plugs (Iridium-tipped type)		Replace every 105,000 miles (169,000 km)								SPARK PLUG (MR) SPARK PLUG (QR)
Intake and exhaust valve clearance (6)	NOTE (5)									SERVICE DATA AND SPECIFICATIONS (SDS) (MR) SERVICE DATA AND SPECIFICATIONS (SDS) (QR)
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, go to the FUEL SYSTEM . (4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. (5) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (6) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

(1)	After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit.

(2)	If operating mainly in dusty conditions, more frequent maintenance may be required.

(3)	Maintenance-free item. For service procedures, go to the FUEL SYSTEM .

(4)	After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.

(5)	Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance.

(6)	Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

EMISSION CONTROL SYSTEM MAINTENANCE REFERENCE CHART

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only
MAINTENANCE OPERATION		MAINTENANCE INTERVAL								Reference
Perform at number of miles, kilometers or months, whichever comes first.	Miles x 1,000 (km x 1,000) Months	33.75 (54) 27	37.5 (60) 30	41.25 (66) 33	45 (72) 36	48.75 (78) 39	52.5 (84) 42	56.25 (90) 45	60 (96) 48	Reference
Drive belt	NOTE (1)								I (6)	DRIVE BELTS (MR) DRIVE BELT (QR)
Air cleaner filter	NOTE (2)								[R]	AIR CLEANER FILTER (MR) AIR CLEANER FILTER (QR)
EVAP vapor lines									I (6)	EVAP VAPOR LINES (MR) EVAP VAPOR LINES (QR)
Fuel lines									I (6)	FUEL LINES (MR) FUEL LINES (QR)
Fuel filter	NOTE (3)
Engine coolant	NOTE (4)								R (6)	ENGINE COOLANT (MR) ENGINE COOLANT (QR)
Engine oil		R	R	R	R	R	R	R	R	ENGINE OIL (MR) ENGINE OIL (QR)
Engine oil filter (Use genuine NISSAN oil filter or equivalent)		R	R	R	R	R	R	R	R	OIL FILTER (MR) OIL FILTER (QR)
Spark plugs (Iridium-tipped type)		Replace every 105,000 miles (169,000 km)								SPARK PLUG (MR) SPARK PLUG (QR)
Intake and exhaust valve clearance (6)	NOTE (5)									SERVICE DATA AND SPECIFICATIONS (SDS) (MR) SERVICE DATA AND SPECIFICATIONS (SDS) (QR)
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, go to the FUEL SYSTEM . (4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. (5) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (6) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

(1)	After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit.

(2)	If operating mainly in dusty conditions, more frequent maintenance may be required.

(3)	Maintenance-free item. For service procedures, go to the FUEL SYSTEM .

(4)	After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.

(5)	Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance.

(6)	Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

EMISSION CONTROL SYSTEM MAINTENANCE REFERENCE CHART

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. L = Lubricate.
MAINTENANCE OPERATION		MAINTENANCE INTERVAL								Reference
Perform at number of miles, kilometers or months, whichever comes first.	Miles x 1,000 (km x 1,000) Months	3.75 (6) 3	7.5 (12) 6	11.25 (18) 9	15 (24) 12	18.75 (30) 15	22.5 (36) 18	26.25 (42) 21	30 (48) 24	Reference
Brake lines & cables					I				I	CHECKING BRAKE LINE AND CABLES
Brake pads, rotors, drums & linings			I		I		I		I	CHECKING DISC BRAKE
Manual transaxle oil	NOTE (1)				I				I	CHECKING M/T OIL - RS6F94R (RS6F94R) CHECKING M/T OIL - RS6F52A AND RS6F52H (RS6F52A and RS6F52H)
CVT fluid	NOTE (2)				I				I	CHECKING CVT FLUID
Steering gear & linkage, axle & suspension parts			I		I		I		I	AXLE AND SUSPENSION PARTS , AXLE AND SUSPENSION PARTS
Tire rotation	NOTE (3)									ROAD WHEEL TIRE ASSEMBLY
Front drive shaft boots			I		I		I		I	DRIVE SHAFT
Exhaust system			I		I		I		I	CHECKING EXHAUST SYSTEM
In-cabin microfilter					R				R	CHANGING IN-CABIN MICROFILTER
(1) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000 km) or 24 months. (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-III every 60,000 miles (96,000 km), then change CVT fluid NS-2 if necessary. (Refer to CVT ). If CONSULT-III is not available, change (not just inspect) CVT fluid NS-2 every 60,000 miles (96,000 km). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty . (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this service information.

(1)	If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000 km) or 24 months.

(2)

If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-III every 60,000 miles (96,000 km), then change CVT fluid NS-2 if necessary. (Refer to CVT ). If CONSULT-III is not available, change (not just inspect) CVT fluid NS-2 every 60,000 miles (96,000 km). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty .

(3)	Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this service information.

CHASSIS AND BODY MAINTENANCE REFERENCE CHART

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. L = Lubr
MAINTENANCE OPERATION		MAINTENANCE INTERVAL								Reference
Perform at number of miles, kilometers or months, whichever comes first.	Miles x 1,000 (km x 1,000) Months	33.75 (54) 27	37.5 (60) 30	41.25 (66) 33	45 (72) 36	48.75 (78) 39	52.5 (84) 42	56.25 (90) 45	60 (96) 48	Reference
Brake lines & cables					I				I	CHECKING BRAKE LINE AND CABLES
Brake pads, rotors, drums & linings			I		I		I		I	CHECKING DISC BRAKE
Manual transaxle oil	NOTE (1)				I				I	CHECKING M/T OIL - RS6F94R (RS6F94R) CHECKING M/T OIL - RS6F52A AND RS6F52H (RS6F52A and RS6F52H)
CVT fluid	NOTE (2)				I					CHECKING CVT FLUID
Steering gear & linkage, axle & suspension parts			I		I		I		I	AXLE AND SUSPENSION PARTS , AXLE AND SUSPENSION PARTS
Tire rotation	NOTE (3)									ROAD WHEEL TIRE ASSEMBLY
Front drive shaft boots			I		I		I		I	DRIVE SHAFT
Exhaust system			I		I		I		I	CHECKING EXHAUST SYSTEM
In-cabin microfilter					R				R	CHANGING IN-CABIN MICROFILTER
(1) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000 km) or 24 months. (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-III every 60,000 miles (96,000 km), then change CVT fluid NS-2 if necessary. (Refer to CVT ). If CONSULT-III is not available, change (not just inspect) CVT fluid NS-2 every 60,000 miles (96,000 km). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty . (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this service information.

(1)	If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000 km) or 24 months.

(2)

(3)	Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this service information.

CHASSIS AND BODY MAINTENANCE REFERENCE CHART

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only
MAINTENANCE OPERATION		MAINTENANCE INTERVAL								Reference
Perform at number of miles, kilometers or months, whichever comes first.	Miles x 1,000 (km x 1,000) Months	7.5 (12) 6	15 (24) 12	22.5 (36) 18	30 (48) 24	37.5 (60) 30	45 (72) 36	52.5 (84) 42	60 (96) 48	Reference
Drive belt	NOTE (1)								I (5)	DRIVE BELTS (MR) DRIVE BELT (QR)
Air cleaner filter					[R]				[R]	AIR CLEANER FILTER (MR) AIR CLEANER FILTER (QR)
EVAP vapor lines					I (5)				I (5)	EVAP VAPOR LINES (MR) EVAP VAPOR LINES (QR)
Fuel lines					I (5)				I (5)	FUEL LINES (MR) FUEL LINES (QR)
Fuel filter	NOTE (2)
Engine coolant	NOTE (3)								R (5)	ENGINE COOLANT (MR) ENGINE COOLANT (QR)
Engine oil		R	R	R	R	R	R	R	R	ENGINE OIL (MR) ENGINE OIL (QR)
Engine oil filter (Use genuine NISSAN oil filter or equivalent.)		R	R	R	R	R	R	R	R	OIL FILTER (MR) OIL FILTER (QR)
Spark plugs (Iridium-tipped type)		Replace every 105,000 miles (169,000 km)								SPARK PLUG (MR) SPARK PLUG (QR)
Intake and exhaust valve clearance) (5)	NOTE (4)									SERVICE DATA AND SPECIFICATIONS (SDS) (MR) SERVICE DATA AND SPECIFICATIONS (SDS) (QR)
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belt if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) Maintenance-free item. (3) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. (4) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (5) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

(1)	After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belt if found damaged or if the auto belt tensioner reading reaches the maximum limit.

(2)	Maintenance-free item.

(3)	After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.

(4)	Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance.

(5)	Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

EMISSION CONTROL SYSTEM MAINTENANCE REFERENCE CHART

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. L = Lubricate.
MAINTENANCE OPERATION		MAINTENANCE INTERVAL								Reference
Perform at number of miles, kilometers or months, whichever comes first.	Miles x 1,000 (km x 1,000) Months	7.5 (12) 6	15 (24) 12	22.5 (36) 18	30 (48) 24	37.5 (60) 30	45 (72) 36	52.5 (84) 42	60 (96) 48	Reference
Brake lines & cables			I		I		I		I	CHECKING BRAKE LINE AND CABLES
Brake pads, rotors, drums & linings			I		I		I		I	CHECKING DISC BRAKE
Manual transaxle oil			I		I		I		I	CHECKING M/T OIL - RS6F94R (RS6F94R) CHECKING M/T OIL - RS6F52A AND RS6F52H (RS6F52A and RS6F52H)
CVT fluid	NOTE (1)		I		I		I		I	CHECKING CVT FLUID
Steering gear & linkage, axle & suspension parts					I				I	AXLE AND SUSPENSION PARTS , AXLE AND SUSPENSION PARTS
Tire rotation	NOTE (2)									ROAD WHEEL TIRE ASSEMBLY
Front drive shaft boots			I		I		I		I	DRIVE SHAFT
Exhaust system					I				I	CHECKING EXHAUST SYSTEM
In-cabin microfilter			R		R		R		R	CHANGING IN-CABIN MICROFILTER
(1) Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. (2) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this service information.

(1)	Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty.

(2)	Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this service information.

CHASSIS AND BODY MAINTENANCE REFERENCE CHART

MR20DE

Description		Capacity (Approximate)			Recommended Fluids/Lubricants
Description		Liter	US measure	Imp measure	Recommended Fluids/Lubricants
Fuel		55.0	14 1/2 gal	12 1/8 gal	Unleaded gasoline with an octane rating of at least 87 AKI (RON 91)
Engine oil Drain and refill	With oil filter change	3.9	4 1/8 qt	3 3/8 qt	Engine oil with API Certification Mark (1) Viscosity SAE 5W-30
Engine oil Drain and refill	Without oil filter change	3.6	3 7/8 qt	3 1/8 qt
Dry engine (engine overhaul)		4.4	4 5/8 qt	3 7/8 qt
Cooling system (with reservoir at max level)		7.0	7 3/8 qt	6 1/8 qt	Genuine NISSAN Long Life Anti-freeze Coolant or equivalent
Manual transaxle fluid (MTF)		2.0	4 1/4 pt	3 1/2 pt	Genuine NISSAN gear oil (XT4447 M+) 75W-80, Genuine NISSAN gear oil (ETL8997B) 75W-80 or equivalent (2)
CVT fluid		7.3	7 3/4 qt	6 3/8 qt	Genuine NISSAN CVT Fluid NS-2 (3)
Brake and clutch fluid					Genuine NISSAN Super Heavy Duty Brake Fluid (4) or equivalent DOT 3 (US FMVSS No. 116)
Multi-purpose grease					NLGI No. 2 (Lithium soap base)
Windshield washer fluid		3.5	3 3/4 qt	3 1/8 qt	Genuine NISSAN Windshield Washer Concentrate Cleaner & Anti-Freeze or equivalent
Air conditioning system refrigerant		0.50 ± 0.05 kg	1.10 ± 0.11 lb	1.10 ± 0.11 lb	HFC-134a (R-134a) (4)
Air conditioning system oil		150 m l	5.03 fl oz	5.3 fl oz	NISSAN A/C System Lubricant Type S or equivalent (4)
(1) For further details, see " ENGINE OIL RECOMMENDATION ". (2) If Genuine NISSAN gear oil is not available, API GL-4, Viscosity SAE 75W-80 may be used as a temporary replacement. However, use Genuine NISSAN gear oil as soon as possible. (3) Using transaxle fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. (4) Available in mainland U.S.A. through a NISSAN dealer.For further details, see "Air conditioner specification label".

(1)	For further details, see " ENGINE OIL RECOMMENDATION ".

(2)	If Genuine NISSAN gear oil is not available, API GL-4, Viscosity SAE 75W-80 may be used as a temporary replacement. However, use Genuine NISSAN gear oil as soon as possible.

(3)	Using transaxle fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty.

(4)	Available in mainland U.S.A. through a NISSAN dealer.For further details, see "Air conditioner specification label".

RECOMMENDED FLUIDS AND LUBRICANTS - MR20DE

QR25DE

Description		Capacity (Approximate)			Recommended Fluids/Lubricants
Description		Liter	US measure	Imp measure	Recommended Fluids/Lubricants
Fuel		55.0	14 1/2 gal	12 1/8 gal	Unleaded gasoline with an octane rating of at least 87 AKI (RON 91)
Engine oil Drain and refill	With oil filter change	4.3	4 1/2 qt	3 3/4 qt	Engine oil with API Certification Mark (1) Viscosity SAE 5W-30
Engine oil Drain and refill	Without oil filter change	4.0 4	1/4 qt	3 1/2 qt
Dry engine (engine overhaul)		5.1	5 3/8 qt	4 1/2 qt
Cooling system (with reservoir at max level)	M/T models	6.9	7 1/4 qt	6 1/8 qt	Genuine NISSAN Long Life Anti-freeze Coolant or equivalent
Cooling system (with reservoir at max level)	CVT models	7.1	7 1/2 qt	6 1/4 qt	Genuine NISSAN Long Life Anti-freeze Coolant or equivalent
Manual transaxle fluid (MTF)		1.7	3 5/8 pt	3 pt	Genuine NISSAN Manual Transmission (MTF) HQ Multi 75W-85 or API GL-4 viscosity SAE 75-W-85
CVT fluid		7.5	7 7/8 qt	6 5/8 qt	Genuine NISSAN CVT Fluid NS-2 (2)
Brake and clutch fluids					Genuine NISSAN Super Heavy Duty Brake Fluid or equivalent, DOT 3 (US FMVSS No. 116) (3)
Multi-purpose grease					NLGI No. 2 (Lithium soap base)
Windshield washer fluid		3.5	3 3/4 qt	3 1/8 qt	Genuine NISSAN Windshield Washer Concentrate Cleaner & Anti-freeze or equivalent
Air conditioning system refrigerant		0.50 ± 0.05 kg	1.10 ± 0.11 lb	1.10 ± 0.11 lb	HFC-134a (R-134a) (4)
Air conditioning system oil		150 m l	5.03 fl oz	5.3 fl oz	NISSAN A/C System Lubricant Type S or equivalent (4)
(1) For further details, see " ENGINE OIL RECOMMENDATION ". (2) Using transaxle fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. (3) Available in mainland U.S.A. through a NISSAN dealer. (4) For further details, see "Air conditioner specification label".

(1)	For further details, see " ENGINE OIL RECOMMENDATION ".

(2)	Using transaxle fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty.

(3)	Available in mainland U.S.A. through a NISSAN dealer.

(4)	For further details, see "Air conditioner specification label".

RECOMMENDED FLUIDS AND LUBRICANTS - QR25DE

Engine Oil Recommendation

NISSAN recommends the use of an energy conserving oil in order to improve fuel economy. Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubricant Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard. These oils have the API certification mark on the front of the container. Oils which do not have the specified quality label should not be used as they could cause engine damage.

Scheme 23

Scheme 23: Engine Oil Recommendation

ANTI-FREEZE COOLANT MIXTURE RATIO

The engine cooling system is filled at the factory with a high-quality, long life, year-round, anti-freeze coolant solution. The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system additives are not necessary.

For outside temperatures down to		Anti-freeze coolant mixture ratio
°C	°F	Genuine NISSAN Long Life Antifreeze coolant	Demineralized water or distilled water
35°	30°	50 %	50 %

ANTI-FREEZE COOLANT MIXTURE RATIO REFERENCE CHART

CAUTION

When adding or replacing coolant, be sure to use only Genuine NISSAN Long Life Anti-freeze coolant or equivalent with the proper mixture ratio of 50% anti-freeze and 50% demineralized water or distilled water. Other types of coolant solutions may damage your cooling system.

Maximum outside temperature		Genuine NISSAN Anti-freeze Coolant or equivalent	Demineralized water or distilledwater
°C	°F	Genuine NISSAN Anti-freeze Coolant or equivalent	Demineralized water or distilledwater
35	30	50%	50%

ANTI-FREEZE COOLANT MIXTURE RATIO REFERENCE CHART

CAUTION

When adding or replacing coolant, be sure to use only a Genuine NISSAN Long Life Anti-Freeze coolant or equivalent with the proper mixture ratio. The use of other types of coolant solutions may damage the engine cooling system.

Scheme 24

Scheme 24: DRIVE BELTS : Component

DRIVE BELTS : Checking Drive Belts

WARNING

Inspect the drive belt only when the engine is stopped.

Note. On vehicles not equipped with A/C, there is an idler pulley in the position for the drive belt routing.

Make sure that the indicator (notch on fixed side) of drive belt auto-tensioner is within the possible use range. NOTE: Check the drive belt auto-tensioner indicator (notch) when the engine is cold. When the new drive belt is installed, the range of possible use should be as shown. Visually check entire belt for wear, damage or cracks. If the indicator is out of allowable use range or belt is damaged, replace the drive belt.

CHECKING COOLING SYSTEM HOSES

Check hoses for the following

Improper attachment
Leaks
Cracks
Damage
Loose connections
Chafing
Deterioration

Scheme 25

Scheme 25: CHECKING RESERVOIR LEVEL

Check if the reservoir tank engine coolant level is within the MIN to MAX range when the engine is cool.
Adjust the engine coolant level as necessary.

CHECKING COOLING SYSTEM FOR LEAKS

To check for leaks, apply pressure to the cooling system using Tool.

Tool number : EG17650301 (J-33984-A)

Testing pressure : 157 kPa (1.6 kg/cm 2 , 23 psi)

Scheme 26

Scheme 26: CHECKING COOLING SYSTEM FOR LEAKS

WARNING

Never remove the radiator cap when the engine is hot. Serious burns could occur from high pressure coolant escaping from the radiator.

CAUTION

Higher pressure than specified may cause radiator damage.

Scheme 27

Scheme 27: CHECKING RADIATOR CAP

Scheme 28

Inspect the radiator cap. Replace the cap if the metal plunger cannot be seen around the edge of the black rubber gasket. Replace the cap if deposits of waxy residue or other foreign material are on the black rubber gasket or the metal retainer. NOTE: Thoroughly wipe out the radiator filler neck to remove any waxy residue or foreign material.
Pull the negative-pressure valve to open it and check that it closes completely when released. Check that there is no dirt or damage on the valve seat of the radiator cap negative-pressure valve. Check that there are no abnormalities in the opening and closing conditions of the negative-pressure valve.
Check radiator cap relief pressure using Tool. Tool number : EG17650301 (J-33984-A) Standard: 78 - 98 kPa (0.8 - 1.0 kg/cm 2 , 11 - 14 psi) When connecting the radiator cap to the tester, apply water or coolant to the cap seal surface. Replace the radiator cap if there is an abnormality in the negative-pressure valve, or if the open-valve pressure is outside of the standard values.

CHECKING RADIATOR

Check radiator for mud or clogging. If necessary, clean radiator as follows.

Be careful not to bend or damage the radiator fins.
When radiator is cleaned without removal, remove all surrounding parts such as cooling fan shroud and horns. Then tape the harness and electrical connectors to prevent water from entering.

Apply water by hose to the back side of the radiator core, with the hose pointed vertically downward.
Apply water again to all radiator core surfaces once per minute.
Stop washing if any stains no longer flow out from the radiator.
Blow air into the back side of radiator core, with the air hose pointed vertically downward. Use compressed air lower than 490 kPa (5 kg/cm 2 , 71 psi) and keep distance more than 30 cm (11.8 in).
Blow air again into all the radiator core surfaces once per minute until no water sprays out.
Check for leaks.

ENGINE COOLANT : Changing Engine Coolant

WARNING

To avoid being scalded, do not change the engine coolant when the engine is hot. Wrap a thick cloth around radiator cap and carefully remove the cap. First, turn the cap a quarter of a turn to release built-up pressure. Then push down and turn the cap all the way to remove. Be careful not to allow engine coolant to contact drive belt.

Scheme 29

Scheme 29: DRAINING ENGINE COOLANT

Remove the engine undercover. Refer to " «REMOVAL AND INSTALLATION»(ref-367309-S07728457182010072700000) ".
Open the radiator drain plug (1) at the bottom of the radiator, and remove the radiator filler cap. This is the only step required when partially draining the cooling system (radiator only). <= Front CAUTION: Perform this step when engine is cold. Do not spill engine coolant on drive belt.
Follow this step for heater core removal/replacement only. Disconnect the upper heater hose at the engine side and apply moderate air pressure [103.46 kPa (15 psi, 1.055 kg/cm 2 ) maximum air pressure] into the hose for 30 seconds to blow the excess coolant out of the heater core.
When draining all of the coolant in the system, remove the reservoir tank and drain the coolant, then clean the reservoir tank before installation.
When draining all of the coolant in the system for engine removal or repair, open the drain plug on the cylinder block. Refer to " «COMPONENT»(ref-367306-S28720226612010072700000) ".
Check the drained engine coolant for contaminants such as rust, corrosion or discoloration. If the coolant is contaminated, flush the engine cooling system. Follow the "FLUSHING COOLING SYSTEM" procedure.

Scheme 30

Scheme 30: REFILLING ENGINE COOLANT

Scheme 31

Install the radiator drain plug. Install the reservoir tank and cylinder block drain plug, if removed for a total system drain or for engine removal or repair. The radiator must be completely empty of coolant and water. Apply sealant to the threads of the cylinder block drain plugs. Use Genuine High Performance Thread Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCT AND SEALANT»(ref-367300-S11705964442010072700000) ". Radiator drain plug : Refer to " «COMPONENT»(ref-367308-S36236308522010072700000) ". Cylinder block drain plug : Refer to " «REMOVAL AND INSTALLATION»(ref-367322-S41249865712010072700000) ".
If disconnected, reattach the upper radiator hose at the engine side.
Set the vehicle heater controls to the full HOT and heater ON position. Turn the vehicle ignition ON with the engine OFF as necessary to activate the heater mode.
Install the Tool by installing the radiator cap adapter onto the radiator neck opening. Then attach the gauge body assembly with the refill tube and the venturi assembly to the radiator cap adapter. Tool number : KV991J0070 (J-45695)
Insert the refill hose into the coolant mixture container that is placed at floor level. Make sure the ball valve is in the closed position. Use Genuine NISSAN Long Life Anti-freeze coolant or equivalent, mixed 50/50 with distilled water or demineralized water . Refer to " «ANTI-FREEZE COOLANT MIXTURE RATIO»(ref-367307-S01440857592010072700000) ". Engine coolant capacity (with reservoir tank) : Refer to «ENGINE COOLANT»(ref-367307-S21093027802010072700000) .
Install an air hose to the venturi assembly, the air pressure must be within specification. Compressed air supply pressure : 549 - 824 kPa (5.6 - 8.4 kg/cm 2 , 80 - 120 psi) CAUTION: The compressed air supply must be equipped with an air dryer.
The vacuum gauge will begin to rise and there will be an audible hissing noise. During this process open the ball valve on the refill hose slightly. Coolant will be visible rising in the refill hose. Once the refill hose is full of coolant, close the ball valve. This will purge any air trapped in the refill hose.
Continue to draw the vacuum until the gauge reaches 28 inches of vacuum. The gauge may not reach 28 inches in high altitude locations, use the vacuum specifications below based on the altitude above sea level. Altitude above sea level Vacuum gauge reading 0 - 100 m (328 ft) : 28 inches of vacuum 300 m (984 ft) : 27 inches of vacuum 500 m (1,641 ft) : 26 inches of vacuum 1,000 m (3,281 ft) : 24 - 25 inches of vacuum
When the vacuum gauge has reached the specified amount, disconnect the air hose and wait 20 seconds to see if the system loses any vacuum. If the vacuum level drops, perform any necessary repairs to the system and repeat steps 6 - 8 to bring the vacuum to the specified amount. Recheck for any leaks.
Place the coolant container (with the refill hose inserted) at the same level as the top of the radiator. Then open the ball valve on the refill hose so the coolant will be drawn up to fill the cooling system. The cooling system is full when the vacuum gauge reads zero. CAUTION: Do not allow the coolant container to get too low when filling, to avoid air from being drawn into the cooling system.
Remove the Tool from the radiator neck opening.
Fill the cooling system reservoir tank to the specified level and install the radiator cap. Run the engine to warm up the cooling system and top up the system as necessary.

FUEL LINES : Checking Fuel Line

Inspect fuel lines, fuel filler cap and fuel tank for improper attachment, leaks, cracks, damage, loose connections, chafing or deterioration.

If necessary, repair or replace damaged parts.

Scheme 32

Scheme 32: FUEL LINES : Checking Fuel Line

Scheme 33

Scheme 33: AIR CLEANER FILTER : Component

Scheme 34

Scheme 34: REMOVAL

Unclip the tabs (A) of both ends of the air cleaner cover (1).
Remove the air cleaner filter and holder assembly from the air cleaner case.
Remove the air cleaner filter from the holder.

ENGINE OIL LEVEL

Note. Before starting engine, park vehicle on a level surface and check the engine oil level. If engine is already started, stop it and allow 10 minutes before checking.

Scheme 35

Scheme 35: ENGINE OIL LEVEL

Pull out oil level gauge and wipe it clean.
Insert oil level gauge and make sure the engine oil level is within the range (A) as shown in illustration.
If it is out of range, add oil as necessary.

ENGINE OIL APPEARANCE

Check engine oil for white milky or excessive contamination.
If engine oil becomes milky, it is highly probable that it is contaminated with engine coolant. Repair or replace damaged parts.

ENGINE OIL LEAKAGE

Check for engine oil leakage around the following areas

Oil pan (upper and lower)
Oil pan drain plug
Oil pressure switch
Oil filter
Intake valve timing control solenoid valve
Front cover
Mating surface between cylinder block and cylinder head
Mating surface between cylinder head and rocker cover
Crankshaft oil seals (front and rear)
Oil filter (for intake valve timing control)

OIL PRESSURE CHECK

WARNING

Be careful not to burn yourself, as engine oil may be hot. For M/T models, put the gearshift lever in the Neutral "N" position and apply the parking brake securely. For CVT models, put the selector lever in the Park "P" position.

Scheme 36

Scheme 37

Check engine oil level.
Remove the engine undercover. Refer to " «REMOVAL AND INSTALLATION»(ref-367309-S07728457182010072700000) ".
Disconnect harness connector at oil pressure switch (1), and remove oil pressure switch using a suitable tool. Oil pan (lower) (2) <= : Front CAUTION: Do not drop or shock oil pressure switch.
Install oil pressure gauge and hose. Tool number : ST25051001 (J-25695-1) : ST25052000 (J-25695-2)
Start engine and warm it up to normal operating temperature.
Check oil pressure with engine running under no-load. Refer to " «OIL PRESSURE»(ref-367312-S16355940092010072700000) ". NOTE: When engine oil temperature is low, engine oil pressure becomes high. If difference is extreme, check oil passage and oil pump for oil leaks.
After the inspections, install oil pressure switch as follows: Remove old liquid gasket adhering to oil pressure switch and engine. Apply liquid gasket and tighten oil pressure switch to specification. Use Genuine Silicone RTV Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCT AND SEALANT»(ref-367300-S11705964442010072700000) ". Oil pressure switch : 14.7 N.m (1.5 kg-m, 11 ft-lb) Check engine oil level. After warming up engine, make sure there are no leaks of engine oil with running engine.

ENGINE OIL : Changing Engine Oil

WARNING

Be careful not to burn yourself, as engine oil may be hot. Prolonged and repeated contact with used engine oil may cause skin cancer; try to avoid direct skin contact with used engine oil. If skin contact is made, wash thoroughly with soap or hand cleaner as soon as possible.

Scheme 38

Park vehicle on a level surface and check for engine oil leakage from engine components. Refer to " «ENGINE OIL : INSPECTION»(ref-367307-S01463436312010072700000) ".
Warm up the engine.
Stop engine and wait for 10 minutes.
Remove oil filler cap (1) and then remove oil pan drain plug (2). Oil filter (3) <=: Engine front
Drain the engine oil.
Install the oil pan drain plug (2) with a new washer. Oil pan drain plug : 34.3 N.m (3.5 kg-m, 25 ft-lb) CAUTION: Be sure to clean drain plug (2) and install with new washer.
Refill with new engine oil. Refer to " «MR20DE»(ref-367307-S10741710632010072700000) ". CAUTION: The refill capacity depends on the engine oil temperature and drain time. Use these specifications for reference only. Always use oil level gauge to determine the proper amount of engine oil in the engine.
Warm up engine and check area around drain plug (2) and oil filter (3) for engine oil leakage.
Stop engine and wait for 10 minutes.
Check the engine oil level. Refer to " «ENGINE OIL : INSPECTION»(ref-367307-S01463436312010072700000) ". CAUTION: Do not overfill the engine with oil.

Scheme 39

Scheme 39: REMOVAL

Scheme 40

Remove the engine under cover. Refer to " «REMOVAL AND INSTALLATION»(ref-367309-S07728457182010072700000) ".
Drain engine oil. Refer to " «CHANGING ENGINE OIL»(ref-367312-S41119229172010072700000) ".
Remove oil filter using Tool (A). Tool number : KV10115801 (J-38956) <=: Front WARNING: Be careful not to get burned, engine and engine oil may be hot. CAUTION: When removing, prepare a shop cloth to absorb any engine oil leakage or spillage. Do not allow engine oil to adhere to drive belt. Completely wipe off any engine oil that adheres to the engine and the vehicle. The oil filter has a built in pressure relief valve. Use Genuine NISSAN oil filter or equivalent.

Scheme 41

Scheme 41: INSTALLATION

Scheme 42

Remove foreign materials adhering to the oil filter installation surface.
Apply new engine oil to the oil seal contact surface of the new oil filter.
Screw the new oil filter manually until it touches the installation surface, then tighten it by 2/3 turn. Or tighten to specification. Oil filter: : 17.7 N.m (1.8 kg-m, 13 ft-lb)
Refill the engine with new engine oil. Refer to " «CHANGING ENGINE OIL»(ref-367312-S41119229172010072700000) ".
Install the engine under cover. Refer to " «REMOVAL AND INSTALLATION»(ref-367309-S07728457182010072700000) ".

EVAP VAPOR LINES : Checking EVAP Vapor Line

Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections, chafing and deterioration.
Inspect fuel tank filler cap vacuum relief valve for clogging, sticking, etc. Refer to «EVAPORATIVE EMISSION SYSTEM»(ref-367313-S33580254372010072700000) .

Scheme 43

Scheme 43: DRIVE BELT : Checking Drive Belts

WARNING

Inspect the drive belt only when the engine is stopped.

Make sure that the indicator (notch on fixed side) of drive belt auto-tensioner is within the possible use range. NOTE: Check the drive belt auto-tensioner indicator (notch) when the engine is cold. When the new drive belt is installed, the range of possible use should be as shown in illustration. Visually check entire belt for wear, damage or cracks. If the indicator is out of allowable use range or belt is damaged, replace the drive belt.

Check hoses for the following

Improper attachment
Leaks
Cracks
Damage
Loose connections
Chafing
Deterioration

CHECKING RESERVOIR LEVEL

Check if the reservoir tank engine coolant level is within MIN to MAX when the engine is cool.
Adjust the engine coolant level as necessary.

To check for leaks, apply pressure to the cooling system using suitable tool and Tool.

Tool number : EG17650301 (J-33984-A)

Testing pressure : 157 kPa (1.6 kg/cm 2 , 23 psi)

WARNING

Never remove the radiator cap when the engine is hot. Serious burns could occur from high pressure coolant escaping from the radiator.

CAUTION

Higher pressure than specified may cause radiator damage.

CHECKING RADIATOR CAP

Inspect the radiator cap. Replace the cap if the metal plunger cannot be seen around the edge of the black rubber gasket. Replace the cap if deposits of waxy residue or other foreign material are on the black rubber gasket or the metal retainer. NOTE: Thoroughly wipe out the radiator filler neck to remove any waxy residue or foreign material.
Pull the negative-pressure valve to open it and check that it closes completely when released. Check that there is no dirt or damage on the valve seat of the radiator cap negative-pressure valve. Check that there are no abnormalities in the opening and closing conditions of the negative-pressure valve.
Check radiator cap relief pressure using suitable tool and Tool. Tool number : EG17650301 (J-33984-A) Standard : 78 - 98 kPa (0.8 - 1.0 kg/cm 2 , 11 - 14 psi) When connecting the radiator cap to the tester, apply water or coolant to the cap seal surface. Replace the radiator cap if there is an abnormality in the negative-pressure valve, or if the open-valve pressure is outside of the standard values.

Check radiator for mud or clogging. If necessary, clean radiator as follows.

Be careful not to bend or damage the radiator fins.
When radiator is cleaned without removal, remove all surrounding parts such as cooling fan shroud and horns. Then tape the harness and electrical connectors to prevent water from entering.

Apply water by hose to the back side of the radiator core, with the hose pointed vertically downward.
Apply water again to all radiator core surfaces once per minute.
Stop washing if any stains no longer flow out from the radiator.
Blow air into the back side of radiator core, with the air hose pointed vertically downward. Use compressed air lower than 490 kPa (5 kg/cm 2 , 71 psi) and keep distance more than 30 cm (11.8 in).
Blow air again into all the radiator core surfaces once per minute until no water sprays out.
Check for leaks.

WARNING

Scheme 44

Remove the engine undercover. Refer to " «REMOVAL AND INSTALLATION»(ref-367309-S07728457182010072700000) ".
Open the radiator drain plug (1) at the bottom of the radiator, and remove the radiator filler cap. This is the only step required when partially draining the cooling system (radiator only). <= Front CAUTION: Perform this step when engine is cold. Do not spill engine coolant on drive belt.
Follow this step for heater core removal/replacement only. Disconnect the upper heater hose at the engine side and apply moderate air pressure [103.46 kPa (15 psi, 1.055 kg/cm 2 ) maximum air pressure] into the hose for 30 seconds to blow the excess coolant out of the heater core.
When draining all of the coolant in the system, remove the reservoir tank and drain the coolant, then clean the reservoir tank before installation.
When draining all of the coolant in the system for engine removal or repair, open the drain plug on the cylinder block.
Check the drained engine coolant for contaminants such as rust, corrosion or discoloration. If the coolant is contaminated, flush the engine cooling system. Follow the "FLUSHING COOLING SYSTEM" procedure.

Inspect the fuel lines and fuel tank for improper attachment, leaks, cracks, damage, loose connections, chafing, or deterioration. If necessary, repair or replace damaged parts.

Scheme 45

Scheme 45: AIR CLEANER FILTER : Removal and Installation

CHANGING AIR CLEANER FILTER

Depress the air cleaner case lid side clips and remove.
Remove the air cleaner filter.
Install a new air cleaner filter.
Installation is in the reverse order of removal.

Note. Before starting engine, park vehicle on a level surface and check the engine oil level. If engine is already started, stop it and allow 10 minutes before checking.

Scheme 46

Scheme 46: ENGINE OIL LEVEL

Pull out oil level gauge and wipe it clean.
Insert oil level gauge and make sure the engine oil level is within the range as shown in illustration.
If it is out of range, add oil as necessary.

Check engine oil for white milky or excessive contamination.
If engine oil becomes milky, it is highly probable that it is contaminated with engine coolant. Repair or replace damaged parts.

Check for engine oil leakage around the following areas

Oil pan (upper and lower)
Oil pan drain plug
Oil pressure sensor
Oil filter
Intake valve timing control solenoid valve
Front cover
Mating surface between cylinder block and cylinder head
Mating surface between cylinder head and rocker cover
Crankshaft oil seals (front and rear)

WARNING

Check engine oil level.
Remove the engine undercover. Refer to " «REMOVAL AND INSTALLATION»(ref-367309-S07728457182010072700000) ".
Disconnect harness connector at oil pressure sensor, and remove oil pressure sensor using a suitable tool. CAUTION: Do not drop or shock oil pressure sensor.
Install oil pressure gauge and hose. Tool numbers : ST25051001 (J-25695-1) : ST25052000 (J-25695-2)
Start engine and warm it up to normal operating temperature.
Check oil pressure with engine running under no-load. Refer to " «OIL PRESSURE»(ref-367326-S19421178532010072700000) ". NOTE: When engine oil temperature is low, engine oil pressure becomes high. If difference is extreme, check oil passage and oil pump for oil leaks.
After the inspections, install oil pressure sensor as follows: Remove old liquid gasket adhering to oil pressure sensor and engine. Apply liquid gasket and tighten oil pressure sensor to specification. Use Genuine RTV Silicone Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCT AND SEALANT»(ref-367300-S11705964442010072700000) ". Oil pressure sensor : 14.7 N.m (1.5 kg-m, 11 ft-lb) Check engine oil level. After warming up engine, make sure there are no leaks of engine oil with running engine.

WARNING

Park vehicle on a level surface and check for engine oil leakage from engine components. Refer to " «INSPECTION»(ref-367326-S35647538452010072700000) ".
Warm up the engine.
Stop engine and wait for 10 minutes.
Remove oil filler cap and then remove oil pan drain plug.
Drain the engine oil.
Install the oil pan drain plug with a new washer. Oil pan drain plug : 34.3 N.m (3.5 kg-m, 25 ft-lb) CAUTION: Be sure to clean drain plug and install with new washer.
Refill with new engine oil. Refer to " «QR25DE»(ref-367307-S26373397962010072700000) ". CAUTION: The refill capacity depends on the engine oil temperature and drain time. Use these specifications for reference only. Always use oil level gauge to determine when the proper amount of engine oil is in the engine.
Warm up engine and check area around drain plug and oil filter for engine oil leakage.
Stop engine and wait for 10 minutes.
Check the engine oil level. Refer to " «INSPECTION»(ref-367326-S35647538452010072700000) ". CAUTION: Do not overfill the engine with oil.

Scheme 47

Scheme 47: REMOVAL

Drain the engine oil. Refer to " «CHANGING ENGINE OIL»(ref-367326-S12680536362010072700000) "
Remove splash shield RH. Refer to " «REMOVAL AND INSTALLATION»(ref-367309-S17675621432010072700000) ".
Remove the oil filter using Tool. Tool number : KV10115801 (J-38956) WARNING: Be careful not to get burned, engine and engine oil may be hot. CAUTION: When removing, prepare a shop cloth to absorb any engine oil leakage or spillage. Do not allow engine oil to adhere to drive belt. Completely wipe off any engine oil that adheres to the engine and the vehicle. The oil filter has a built in pressure relief valve. Use Genuine NISSAN oil filter or equivalent

Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections, chafing and deterioration.
Inspect fuel tank filler cap vacuum relief valve for clogging and sticking.

Scheme 48

Scheme 48: Changing In-cabin Microfilter

Scheme 49

Remove the filter cover. Release the filter cover tab (A), pull the bottom of the filter cover out tilting it at an angle Pull down the filter cover to disengage the hook at the top and remove the filter cover.
Remove the in-cabin microfilter.
Install the new in-cabin microfilter. CAUTION: Insert the new filter with the "UP" arrow in the correct orientation. Insert the new filter with the "UP" arrow side of the filter facing the front of the vehicle.
Install the filter cover. Insert the hook at the top of the filter cover into the heater and cooling unit case. Swing the filter cover into the heater and cooling unit case until the filter cover tab (A) snaps securely on the heater and cooling unit case. CAUTION: Check the filter cover to make sure it is securely fastened to the heater and cooling unit case.

Checking Exhaust System

Check the exhaust pipes, muffler, and mounting for improper attachment, leaks, cracks, damage, or deterioration.

Scheme 50

Scheme 50: Checking Exhaust System

If necessary, repair or replace damaged parts.

Checking Clutch System

Check fluid lines and operating cylinder for improper attachment, cracks, damage, loose connections, chafing and deterioration.

Scheme 51

Scheme 51: DRAINING

Start engine and let it run to warm up transaxle.
Stop engine. Remove drain plug (1) and drain oil.
Install a new gasket onto drain plug (1) and install it into transaxle. Tighten drain plug to specification. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-367316-S03683865852010072700000) ". CAUTION: Do not reuse gasket.

Scheme 52

Scheme 52: FILLING

Remove filler plug (1). Fill with new oil until oil level reaches the specified limit at filler plug hole as shown in illustration. Oil grade and capacity : Refer to " «MR20DE»(ref-367307-S10741710632010072700000) ".
After refilling oil, check oil level. Install a new gasket on filler plug (1), then install it into transaxle. Tighten filler plug to specification. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-367316-S03683865852010072700000) ". CAUTION: Do not reuse gasket.

OIL LEAKAGE AND OIL LEVEL

Make sure that oil is not leaking from transaxle or around it.
Remove filler plug (1) and check oil level at filler plug hole as shown in illustration. CAUTION: Do not start engine while checking oil level.
Install a new gasket onto filler plug (1) and install it into transaxle. Tighten filler plug to specification. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-367316-S03683865852010072700000) ". CAUTION: Do not reuse gasket.

Scheme 53

Scheme 53: DRAINING

Start engine and let it run to warm up transaxle.
Stop engine. Remove transaxle drain plug and drain oil.
Set a gasket on drain plug and install it to transaxle. Tighten drain plug to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-367327-S39338589362010072700000) ". CAUTION: Do not reuse gasket.

Scheme 54

Scheme 54: FILLING

Remove plug (1). Fill the transaxle with new oil and check the oil level (L) using suitable gauge (A) as shown in illustration. Oil grade and capacity : Refer to " «QR25DE»(ref-367307-S26373397962010072700000) ". Oil level (L) : 61.0 - 67.0 mm (2.402 - 2.638 in)
Set an O-ring on plug (1) and then install it to transaxle. Tighten to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-367327-S39338589362010072700000) ". CAUTION: Do not reuse O-ring.

Make sure that oil is not leaking from transaxle or around it.
Remove plug (1).
Check the oil level (L) using suitable gauge (A) as shown in illustration. Oil level (L) : 61.0 - 67.0 mm (2.402 - 2.638 in) CAUTION: Do not start engine while checking oil level.
Set an O-ring on plug (1) and then install it to transaxle. Tighten to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-367327-S39338589362010072700000) ". CAUTION: Do not reuse O-ring.

ROTOR

Check the rotor condition and thickness. Resurface or replace the rotor as necessary. Refer to " FRONT DISC BRAKE ".

Scheme 55

Scheme 55: ROTOR

CALIPER

Check the caliper for leakage.

Scheme 56

Scheme 56: CALIPER

PAD

Check the brake pads for wear or damage. Refer to " ON BOARD INSPECTION ".

Scheme 57

Scheme 57: PAD

WHEEL CYLINDER

Check for leakage.

Scheme 58

Scheme 58: WHEEL CYLINDER

LINING

Check for lining thickness (A). Refer to " DISASSEMBLY AND ASSEMBLY OF WHEEL CYLINDER ".

Scheme 59

Scheme 59: LINING

Axle and Suspension Parts

Check front and rear axle and suspension parts for excessive play, cracks, wear or other damage.

Scheme 60

Scheme 60: Axle and Suspension Parts

Scheme 61

Shake each wheel to check for excessive play.
Check wheel bearings for smooth operation.
Check axle and suspension nuts and bolts for looseness.
Check strut (shock absorber) for oil leakage or other damage.
Check suspension ball joint for grease leakage and ball joint dust cover for cracks or other damage.

Drive Shaft

Check boot and drive shaft for cracks, wear, damage and grease leakage.

Scheme 62

Scheme 62: Drive Shaft

Scheme 63

Scheme 63: Lubricating Locks, Hinges and Hood Latch

Checking Seat Belts, Buckles, Retractors, Anchors and Adjusters

Check the seat belt buckles, webbing, retractors, anchors and adjusters. Replace any seat belt assembly as necessary. Refer to " SEAT BELT INSPECTION ".

Check the seat belt anchors for loose bolts, damage, or excessive wear.
Check the seat belt webbing for any damage, cuts, fraying, or excessive wear.
Check the retractor for smooth operation.
Check the function of the buckles by inserting the seat belt tongue and checking for proper engagement of the buckle and press the button on the buckle to check for proper release of the seat belt tongue.

CAUTION

After any collision, inspect all seat belt assemblies, including retractors and other attached components, such as the guide rail set. NISSAN recommends replacing all seat belt assemblies in use during a collision, unless they are not damaged and are inspected to confirm they are operating properly after a minor collision. Also inspect all seat belt assemblies that are not in use during a collision, and replace any components if damaged or not operating properly. The seat belt pre-tensioner should be replaced even if the seat belts are not in use during a frontal collision where the driver and passenger air bags have been deployed. If any component of the seat belt assembly is suspected of being damaged or not operating properly, do not repair the component. Replace the components as an assembly. If the seat belt webbing is cut, frayed, or damaged then replace the seat belt assembly. Never lubricate the seat belt buckle or tongue. When replacing any seat belt assembly always use a Genuine NISSAN seat belt assembly.

Maintenance: Other Nissan Sentra B16 рестайлинг

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

Precaution Necessary for Steering Wheel Rotation After Battery Disconnect

Special Service Tool

Scheme 21

Scheme 22

Commercial Service Tool

OUTSIDE THE VEHICLE

INSIDE THE VEHICLE

UNDER THE HOOD AND VEHICLE

MR20DE

QR25DE

Engine Oil Recommendation

Scheme 23

ANTI-FREEZE COOLANT MIXTURE RATIO

Scheme 24

DRIVE BELTS : Checking Drive Belts

CHECKING COOLING SYSTEM HOSES

Scheme 25

CHECKING COOLING SYSTEM FOR LEAKS

Scheme 26

Scheme 27

Scheme 28

CHECKING RADIATOR

ENGINE COOLANT : Changing Engine Coolant

Scheme 29

Scheme 30

Scheme 31

FUEL LINES : Checking Fuel Line

Scheme 32

Scheme 33

Scheme 34

ENGINE OIL LEVEL

Scheme 35

ENGINE OIL APPEARANCE

ENGINE OIL LEAKAGE

OIL PRESSURE CHECK

Scheme 36

Scheme 37

ENGINE OIL : Changing Engine Oil

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

EVAP VAPOR LINES : Checking EVAP Vapor Line

Scheme 43

CHECKING RESERVOIR LEVEL

CHECKING RADIATOR CAP

Scheme 44

Scheme 45

CHANGING AIR CLEANER FILTER

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Checking Exhaust System

Scheme 50

Checking Clutch System

Scheme 51

Scheme 52

OIL LEAKAGE AND OIL LEVEL

Scheme 53

Scheme 54

ROTOR

Scheme 55

CALIPER

Scheme 56

PAD

Scheme 57

WHEEL CYLINDER

Scheme 58

LINING

Scheme 59

Axle and Suspension Parts

Scheme 60

Scheme 61

Drive Shaft

Scheme 62
