Continuously Variable Transmission (Cvt): Maintenance Nissan Sentra B16 рестайлинг

Automatic Trans 14 illustrations ~880 words

FLUID LEVEL CHECK

Fluid level should be checked with the fluid warmed up to 50° to 80°C (122° to 176°F).

Scheme 62

Scheme 62: FLUID LEVEL CHECK
Scheme 62: FLUID LEVEL CHECK

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65
  1. Check for fluid leakage.
  2. With the engine warmed up, drive the vehicle to warm up the CVT fluid. When ambient temperature is 20°C (68°F), it takes about 10 minutes for the CVT fluid to warm up to 50° to 80°C (122° to 176°F).
  3. Park the vehicle on a level surface and set the parking brake.
  4. With engine at idle, while depressing brake pedal, move the selector lever throughout the entire shift range and return it to the "P" position.
  5. Press the tab on the CVT fluid level gauge to release the lock and pull out the CVT fluid level gauge from the CVT fluid charging pipe.
  6. Wipe fluid off the CVT fluid level gauge. Then rotate the CVT fluid level gauge 180° and re-insert it into the CVT charging pipe as far as it will go. CAUTION: Always use lint free paper towels to wipe fluid off the CVT fluid level gauge.
  7. Remove the CVT fluid level gauge and check that the fluid level is within the specified range as shown in illustration. If the fluid level is at or below the low side of the range, add the necessary specified NISSAN CVT fluid through the CVT charging pipe. Fluid grade: Refer to " «MR20DE»(ref-367307-S10741710632010072700000) ". CAUTION: Only use specified NISSAN CVT fluid. Do not overfill the CVT.
  8. Install the CVT fluid level gauge to the CVT fluid charging pipe until it locks. CAUTION: When CVT fluid level gauge is installed into the CVT fluid charging pipe, make sure that the CVT fluid level gauge is securely locked in place.

FLUID CONDITION CHECK

Fluid statusConceivable causeRequired operation
Varnished (viscous varnish state)CVT fluid become degraded due to high temperatures.Replace the CVT fluid and check the CVT main unit and the vehicle for malfunctions (wire harness, cooler pipes, etc.)
Milky white or cloudyWater in the fluidReplace the CVT fluid and check for places where water is getting in.
Large amount of metal powder mixed in fluidUnusual wear of sliding parts within CVTReplace the CVT fluid and check for improper operation of the CVT.

FLUID CONDITION CHART

Scheme 66

Scheme 66
Scheme 66

Changing CVT Fluid

  1. Remove drain plug, and drain CVT fluid from oil pan.
  2. Install drain plug with new gasket to oil pan and tighten to the specified torque. Drain plug: Refer to " «CONTROL VALVE»(ref-367317-S18908192842010072700000) ". CAUTION: Do not reuse drain plug gasket.
  3. Fill CVT fluid from CVT fluid charging pipe to the specified level. Fluid grade and capacity: Refer to " «GENERAL SPECIFICATION»(ref-367317-S06546221312010072700000) ". CAUTION: Use only Genuine NISSAN CVT Fluid NS-2. Do not mix with other fluid. Using CVT fluid other than Genuine NISSAN CVT Fluid NS-2 will deteriorate in driveability and CVT durability, and may damage the CVT, which is not covered by the warranty. When filling CVT fluid, take care not to scatter fluid on heat generating parts such as exhaust. Sufficiently shake the container of CVT fluid before using.
  4. With the engine warmed up, drive the vehicle in an urban area. When ambient temperature is 20°C (68°F), it takes about 10 minutes for the CVT fluid to warm up to 50° to 80°C (122° to 176°F).
  5. Check CVT fluid level and condition. Refer to " «CHECKING CVT FLUID»(ref-367317-S27429227022010072700000) ".
  6. Repeat steps 1 through 5 if CVT fluid is contaminated. CAUTION: Delete CVT fluid deterioration date with CONSULT-III after changing CVT fluid.

Scheme 67

Scheme 67: Cross-Sectional View - RE0F10A
Scheme 67: Cross-Sectional View - RE0F10A

Scheme 68

Scheme 68: Control System
Scheme 68: Control System

Scheme 69

Scheme 69: Hydraulic Control System
Scheme 69: Hydraulic Control System

CVT Fluid Temperature Sensor

If an unexpected signal is sent from the CVT fluid temperature sensor to the TCM, the gear ratio in use before receiving the unexpected signal is maintained or the gear ratio is controlled to keep engine speed under 4500 rpm.

CVT FLUID CHECK

Fluid Leakage and Fluid Level Check

  1. Inspect for fluid leakage and check the fluid level. Refer to " «CHECKING CVT FLUID»(ref-367317-S27429227022010072700000) ".

Fluid Condition Check

Inspect the fluid condition.

Fluid statusConceivable causeRequired operation
Varnished (viscous varnish state)Clutch, brake scorchedReplace the CVT fluid and check the CVT main unit and the vehicle for malfunctions (wire harnesses, cooler pipes, etc.)
Milky white or cloudyWater in the fluidReplace the CVT fluid and check for places where water is getting in.
Large amount of metal powder mixed inUnusual wear of sliding parts within CVTReplace the CVT fluid and check for improper operation of the CVT.

FLUID CONDITION CHART

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71: Stall Test Procedure
Scheme 71: Stall Test Procedure

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75
  1. Inspect the amount of engine oil. Replenish the engine oil if necessary.
  2. Drive for about 10 minutes to warm up the vehicle so that the CVT fluid temperature is 50 to 80°C (122 to 176°F). Inspect the amount of CVT fluid. Replenish if necessary.
  3. Securely engage the parking brake so that the tires do not turn.
  4. Install a tachometer where it can be seen by driver during test. It is good practice to mark the point of specified engine rpm on indicator.
  5. Start engine, apply foot brake, and place selector lever in "D" position.
  6. While holding down the foot brake, gradually press down the accelerator pedal.
  7. Quickly read off the stall speed, and then quickly remove your foot from the accelerator pedal. CAUTION: Do not hold down the accelerator pedal for more than 5 seconds during this test. Stall speed: 2,500 - 3,000 rpm (with MR20DE) Stall speed: 2,050 - 3,550 rpm (with QR25DE)
  8. Move the selector lever to the "N" position.
  9. Cool down the CVT fluid. CAUTION: Run the engine at idle for at least 1 minute.
  10. Repeat steps 6 through 9 with selector lever in "R" position.

Check CVT Fluid Deterioration Date

"CVTF DETERIORATION DATE"

More than 210000

It is necessary to change CVT fluid.

Less than 210000

It is not necessary to change CVT fluid.

CAUTIONTouch "CLEAR" after changing CVT fluid, and then erase "CVTF DETERIORATION DATE".
  1. Turn ignition switch OFF.
  2. Disconnect CVT unit harness connector.
  3. Check resistance between CVT unit harness connector terminals. CONNECTOR TERMINAL RESISTANCE CHART Name Connector Terminal Temperature °C (°F) Resistance (Approx.) CVT fluid temperature sensor F46 17 - 19 20 (68) 6.5 kohms 80 (176) 0.9 kohms
  4. If NG, perform "SELF-DIAG RESULTS" mode for "TRANSMISSION".
NameConditionCONSULT-III "DATA MONITOR" (Approx.)Resistance (Approx.)
ATF TEMP SEN20°C (68°F)2.0 V6.5 kohms
80°C (176°F)1.0 V0.9 kohms

CVT FLUID TEMPERATURE SENSOR CHART
