Special Service Tools
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
SPECIAL SERVICE TOOLS REFERENCE Tool number (Kent-Moore No.) Tool name Description KV10115801 (J-38956) Oil filter wrench Removing and installing oil filter a: 64.3 mm (2.531 in) KV991J0010 (J-23688) Engine coolant refractometer Checking concentration of ethylene glycol in engine coolant EG17650301 (J-33984-A) Radiator cap tester adapter Adapting radiator cap tester to radiator cap and radiator filler neck a: 28 (1.10) dia. b: 31.4 (1.236) dia. c: 41.3 (1.626) dia. Unit: mm (in) KV991J0070 (J-45695) Coolant Refill Tool Refilling engine cooling system EG17650301 (J-33984-A) Radiator cap tester adapter Adapting radiator cap tester to radiator cap and radiator filler neck a: 28 (1.10) dia. b: 31.4 (1.236) dia. c: 41.3 (1.626) dia. Unit: mm (in)
Scheme 21
Scheme 21: Special Service Tools
Scheme 22
Commercial Service Tools
COMMERCIAL SERVICE TOOLS REFERENCE (Kent-Moore No.) Tool name Description Power tool Loosening bolts and nuts Spark plug wrench Removing and installing spark plug
General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform checks and inspections themselves or they can have their NISSAN dealers do them.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.
| Item | Reference |
|---|
| Tires | Check the pressure including the spare, at least once a month and always prior to a long distance trip. Adjust to the specified pressure if necessary. Check carefully for damage, cuts or excessive wear. | " TIRE " |
| Wheel nuts | When checking the tires, make sure no nuts are missing, and check for any loose nuts. Tighten if necessary. | " ROTATION " |
| Windshield | Clean the windshield on a regular basis. Check the windshield at least every six months for cracks or other damage. Repair as necessary. | |
| Tire rotation | Tires should be rotated every 12,000 km (7,500 miles). | " ROTATION " |
| Component parts of tire pressure monitoring system (TPMS) | Replace grommet seal, valve core and cap of the transmitter in TPMS every tire replacement when reaching wear limit of tire. | " TRANSMITTER (PRESSURE SENSOR) " |
| Wheel alignment and balance | If the vehicle pulls to either side while driving on a straight and level road, or if you detect uneven or abnormal tire wear, there may be a need for wheel alignment. If the steering wheel or seat vibrates at normal highway speeds, wheel balancing may be needed. | " WHEEL ALIGNMENT (UNLADEN*) " and " BALANCING WHEELS " |
| Windshield wiper blades | Check for cracks or wear if they do not wipe properly. | |
| Doors and engine hood | Check that all doors and the engine hood operate smoothly as well as the trunk lid and back hatch. Also make sure that all latches lock securely. Lubricate if necessary. Make sure that the secondary latch keeps the hood from opening when the primary latch is released. When driving in areas using road salt or other corrosive materials, check lubrication frequently. | " LUBRICATING LOCKS, HINGES AND HOOD LATCH " |
| Lamps | Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other lamps are all operating properly and installed securely. Also check headlamp aim. Clean the headlamps on a regular basis. | |
GENERAL MAINTENANCE OUTSIDE VEHICLE REFERENCE CHART
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.
| Item |
|---|
| Warning lamps and buzzers/chimes | Make sure that all warning lamps and buzzers/chimes are operating properly. |
| Windshield wiper and washer | Check that the wipers and washer operate properly and that the wipers do not streak. |
| Windshield defroster | Check that the air comes out of the defroster outlets properly and in sufficient quantity when operating the heater or air conditioning. |
| Steering wheel | Check that it has the specified play. Be sure to check for changes in the steering condition, such as excessive play, hard steering or strange noises. Free play: Less than 35 mm (1.38 in) |
| Seats | Check seat position controls such as seat adjusters, seat back recliner, etc. to make sure they operate smoothly and that all latches lock securely in every position. Check that the head restraints move up and down smoothly and that the locks (if equipped) hold securely in all latched positions. Check that the latches lock securely for folding-down rear seat backs. |
| Seat belts | Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and retractors) operate properly and smoothly and are installed securely. Check the belt webbing for cuts, fraying, wear or damage. |
| Accelerator pedal | Check the pedal for smooth operation and make sure the pedal does not catch or require uneven effort. Keep the floor mats away from the pedal. |
| CLUTCH PEDAL | Make sure the pedal operates smoothly and check that it has the proper free play. |
| Brakes | Check that the brake does not pull the vehicle to one side when applied. |
| BRAKE PEDAL AND BOOSTER | Check the pedal for smooth operation and make sure it has the proper distance under it when depressed fully. Check the brake booster function. Be sure to keep floor mats away from the pedal. |
| Parking brake | Check that the lever has the proper travel and make sure that the vehicle is held securely on a fairly steep hill when only the parking brake is applied. |
| CVT P (Park) position mechanism | On a fairly steep hill check that the vehicle is held securely with the selector lever in the "P" position without applying any brakes. |
GENERAL MAINTENANCE INSIDE VEHICLE REFERENCE CHART
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
| Item |
|---|
| Windshield washer fluid | Check that there is adequate fluid in the tank. |
| ENGINE COOLANT LEVEL | Check the coolant level when the engine is cold. |
| A/C condenser, radiator and hoses | Check the front of the condenser and radiator and clean off any dirt, insects, leaves, etc., that may have accumulated. Make sure the radiator hoses have no cracks, deformation, deterioration or loose connections. |
| BRAKE AND CLUTCH FLUID LEVELS | Make sure that the brake and clutch fluid levels are between the "MAX" and "MIN" lines on the reservoirs. |
| Battery | Check the fluid level in each cell. It should be between the "MAX" and "MIN" lines. Vehicles operated in high temperatures or under severe conditions require frequent checks of the battery fluid level. |
| ENGINE DRIVE BELTS | Make sure that no belt is frayed, worn, cracked or oily. |
| ENGINE OIL LEVEL | Check the level on the dipstick after parking the vehicle on a level spot and turning off the engine. |
| AUTOMATIC TRANSAXLE FLUID LEVEL | Check the level on the dipstick after putting the selector lever in "P" with the engine idling. |
| EXHAUST SYSTEM | Make sure there are no loose supports, cracks or holes. If the sound of the exhaust seems unusual or there is a smell of exhaust fumes, immediately locate the trouble and correct it. |
| Underbody | The underbody is frequently exposed to corrosive substances such as those used on icy roads or to control dust. It is very important to remove these substances, otherwise rust will form on the floor pan, frame, fuel lines and around the exhaust system. At the end of winter, the underbody should be thoroughly flushed with plain water, being careful to clean those areas where mud and dirt can easily accumulate. |
| Fluid leaks | Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle has been parked for a while. Water dripping from the air conditioner after use is normal. If you should notice any leaks or gasoline fumes are evident, check for the cause and correct it immediately. |
GENERAL MAINTENANCE UNDER HOOD VEHICLE REFERENCE CHART
Two different maintenance schedules are provided, and should be used, depending upon the conditions in which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic maintenance at the same mileage/time intervals.
| Schedule 1 | Follow Periodic Maintenance Schedule 1 if your driving habits frequently includes one or more of the following driving conditions: Repeated short trips of less than 5 miles (8 km). Repeated short trips of less than 10 miles (16 km) with outside temperatures remaining below freezing. Operating in hot weather in stop-and-go "rush hour" traffic. Extensive idling and/or low speed driving for long distances, such as police, taxi or door-to-door delivery use. Driving in dusty conditions. Driving on rough, muddy, or salt spread roads. Towing a trailer, using a camper or a car-top carrier. | EMISSION CONTROL SYSTEM MAINTENANCE |
|---|
| CHASSIS AND BODY MAINTENANCE |
| Schedule 2 | Follow Periodic Maintenance Schedule 2 if none of the driving conditions shown in Schedule 1 apply to your driving habits. | EMISSION CONTROL SYSTEM MAINTENANCE |
| CHASSIS AND BODY MAINTENANCE |
PERIODIC MAINTENANCE REFERENCE CHART
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1,000 (km x 1,000) Months | 3.75 (6) 3 | 7.5 (12) 6 | 11.25 (18) 9 | 15 (24) 12 | 18.75 (30) 15 | 22.5 (36) 18 | 26.25 (42) 21 | 30 (48) 24 |
| DRIVE BELT | NOTE (1) | | | | | | | | |
| AIR CLEANER FILTER | NOTE (2) | | | | | | | | R |
| EVAP VAPOR LINES | | | | | | | | | I (6) |
| FUEL LINES | | | | | | | | | I (6) |
| Fuel filter | NOTE (3) | | | | | | | | |
| ENGINE COOLANT | NOTE (4) | | | | | | | | |
| ENGINE OIL | | R | R | R | R | R | R | R | R |
| ENGINE OIL FILTER (USE GENUINE OIL FILTER OR EQUIVALENT) | | R | R | R | R | R | R | R | R |
| SPARK PLUGS (PLATINUM-TIPPED TYPE) | | Replace every 105,000 miles (169,000 km) |
| Intake and exhaust valve clearance | NOTE (5) | | | | | | | | |
| (1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) (3) Maintenance-free item. For service procedures, go to the FUEL SYSTEM . (4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. (5) If valve noise increases, inspect valve clearance. (6) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| (1) | After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. |
| (2) | If operating mainly in dusty conditions, more frequent maintenance may be required. |
| (3) | (3) Maintenance-free item. For service procedures, go to the FUEL SYSTEM . |
| (4) | After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. |
| (5) | If valve noise increases, inspect valve clearance. |
| (6) | Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
EMISSION CONTROL SYSTEM MAINTENANCE REFERENCE CHART
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1,000 (km x 1,000) Months | 33.75 (54) 27 | 37.5 (60) 30 | 41.25 (66) 33 | 45 (72) 36 | 48.75 (78) 39 | 52.5 (84) 42 | 56.25 (90) 45 | 60 (96) 48 |
| DRIVE BELTS | NOTE (1) | | | | | | | | I (6) |
| AIR CLEANER FILTER | NOTE (2) | | | | | | | | R |
| EVAP VAPOR LINES | | | | | | | | | I (6) |
| FUEL LINES | | | | | | | | | I (6) |
| Fuel filter | NOTE (3) | | | | | | | | |
| ENGINE COOLANT | NOTE (4) | | | | | | | | R (6) |
| ENGINE OIL | | R | R | R | R | R | R | R | R |
| ENGINE OIL FILTER (USE GENUINE OIL FILTER OR EQUIVALENT.) | | R | R | R | R | R | R | R | R |
| SPARK PLUGS (PLATINUM-TIPPED TYPE) | | Replace every 105,000 miles (169,000 km). |
| Intake & exhaust valve clearance | NOTE (5) | | | | | | | | |
| (1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, go to the FUEL SYSTEM . (4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. (5) If valve noise increases, inspect valve clearance. (6) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| (1) | After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. |
| (2) | If operating mainly in dusty conditions, more frequent maintenance may be required. |
| (3) | Maintenance-free item. For service procedures, go to the FUEL SYSTEM . |
| (4) | After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. |
| (5) | If valve noise increases, inspect valve clearance. |
| (6) | Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
MAINTENANCE OPERATION REFERENCE CHART
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. L = Lubricate. |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1,000 (km x 1,000) Months | 3.75 (6) 3 | 7.5 (12) 6 | 11.25 (18) 9 | 15 (24) 12 | 18.75 (30) 15 | 22.5 (36) 18 | 26.25 (42) 21 | 30 (48) 24 |
| BRAKE LINES & CABLES | | | | | I | | | | I |
| BRAKE PADS, ROTORS, DRUMS & LININGS | | | I | | I | | I | | I |
| MANUAL TRANSAXLE OIL | NOTE (1) | | | | I | | | | I |
| CVT FLUID | NOTE (2) | | | | I | | | | I |
| STEERING GEAR & LINKAGE, AXLE & SUSPENSION PARTS | | | I | | I | | I | | I |
| TIRE ROTATION | NOTE (3) | | | | | | | | |
| FRONT DRIVE SHAFT BOOTS | | | I | | I | | I | | I |
| EXHAUST SYSTEM | | | I | | I | | I | | I |
| IN-CABIN MICROFILTER | | | | | R | | | | R |
| BRAKE LINES & CABLES | | | | | I | | | | I |
| BRAKE PADS, ROTORS, DRUMS & LININGS | | | I | | I | | I | | I |
| MANUAL TRANSAXLE OIL | NOTE (1) | | | | I | | | | I |
| CVT FLUID | NOTE (2) | | | | I | | | | |
| STEERING GEAR & LINKAGE, AXLE & SUSPENSION PARTS | | | I | | I | | I | | I |
| TIRE ROTATION | NOTE (3) | | | | | | | | |
| FRONT DRIVE SHAFT BOOTS | | | I | | I | | I | | I |
| EXHAUST SYSTEM | | | I | | I | | I | | I |
| IN-CABIN MICROFILTER | | | | | R | | | | R |
| (1) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000 km) or 24 months. (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-III every 60,000 miles (96,000 km), then change CVT fluid NS-2 if necessary. (Refer to CVT ). If CONSULT-III is not available, change (not just inspect) CVT fluid NS-2 every 60,000 miles (96,000 km). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this section. |
| (1) | If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles (48,000 km) or 24 months. |
| (2) | If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, inspect CVT fluid deterioration with CONSULT-III every 60,000 miles (96,000 km), then change CVT fluid NS-2 if necessary. (Refer to CVT ). If CONSULT-III is not available, change (not just inspect) CVT fluid NS-2 every 60,000 miles (96,000 km). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. |
| (3) | Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this section. |
CHASSIS AND BODY MAINTENANCE REFERENCE CHART
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1,000 (km x 1,000) Months | 7.5 (12) 6 | 15 (24) 12 | 22.5 (36) 18 | 30 (48) 24 | 37.5 (60) 30 | 45 (72) 36 | 52.5 (84) 42 | 60 (96) 48 |
| DRIVE BELT | NOTE (1) | | | | | | | | I (5) |
| AIR CLEANER FILTER | | | | | [R] | | | | [R] |
| EVAP VAPOR LINES | | | | | I (5) | | | | I (5) |
| FUEL LINES | | | | | I (5) | | | | I (5) |
| Fuel filter | NOTE (2) | | | | | | | | |
| ENGINE COOLANT | NOTE (3) | | | | | | | | R (5) |
| ENGINE OIL | | R | R | R | R | R | R | R | R |
| ENGINE OIL FILTER (USE GENUINE OIL FILTER OR EQUIVALENT.) | | R | R | R | R | R | R | R | R |
| SPARK PLUGS (PLATINUM-TIPPED TYPE) | | Replace every 105,000 miles (169,000 km) |
| Intake and exhaust valve clearance) | NOTE (4) | | | | | | | | |
| (1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belt if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) Maintenance-free item. (3) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. (4) If valve noise increases, inspect valve clearance. (5) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| (1) | After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belt if found damaged or if the auto belt tensioner reading reaches the maximum limit. |
| (2) | Maintenance-free item. |
| (3) | After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. |
| (4) | If valve noise increases, inspect valve clearance. |
| (5) | Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
EMISSION CONTROL SYSTEM MAINTENANCE REFERENCE CHART
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. L = Lubricate. |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1,000 (km x 1,000) Months | 7.5 (12) 6 | 15 (24) 12 | 22.5 (36) 18 | 30 (48) 24 | 37.5 (60) 30 | 45 (72) 36 | 52.5 (84) 42 | 60 (96) 48 |
| BRAKE LINES & CABLES | | | I | | I | | I | | I |
| BRAKE PADS, ROTORS, DRUMS & LININGS | | | I | | I | | I | | I |
| MANUAL TRANSAXLE OIL | | | I | | I | | I | | I |
| CVT FLUID | NOTE (1) | | I | | I | | I | | I |
| STEERING GEAR & LINKAGE, AXLE & SUSPENSION PARTS | | | | | I | | | | I |
| TIRE ROTATION | NOTE (2) | | | | | | | | |
| FRONT DRIVE SHAFT BOOTS | | | I | | I | | I | | I |
| EXHAUST SYSTEM | | | | | I | | | | I |
| IN-CABIN MICROFILTER | | | R | | R | | R | | R |
| (1) Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. (2) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this section. |
| (1) | Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. |
| (2) | Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this section. |
CHASSIS AND BODY MAINTENANCE REFERENCE CHART
MR20DE
| Description | Capacity (Approximate) | Recommended Fluids/Lubricants |
|---|
| Liter | US measure | Imp measure |
| Fuel | 55.0 | 14 1/2 gal | 12 1/8 gal | Unleaded gasoline with an octane rating of at least 87 AKI (RON 91) |
| Engine oil Drain and refill | With oil filter change | 3.8 | 4 qt | 3 3/8 qt | API Certification Mark (1) |
| Without oil filter change | 3.6 | 3 7/8 qt | 3 1/8 qt |
| Dry engine (engine overhaul) | 4.4 | 4 5/8 qt | 3 7/8 qt |
| Cooling system (with reservoir at max level) | 7.0 | 1 7/8 gal | 1 1/2 gal | Genuine NISSAN Long Life Anti-freeze Coolant or equivalent |
| Manual transaxle fluid (MTF) | 2.0 | 4 1/4 pt | 3 1/2 pt | ELF XT4447 M+ 75W-80 or API GL-4, Viscosity SAE 75W-80 |
| CVT fluid | 8.3 | 8 3/4 qt | 7 1/4 qt | Genuine NISSAN CVT Fluid NS-2 (2) |
| Brake and clutch fluid | | | | Genuine NISSAN Super Heavy Duty Brake Fluid (3) or equivalent DOT 3 (US FMVSS No. 116) |
| Multi-purpose grease | | | | NLGI No. 2 (Lithium soap base) |
| Windshield washer fluid | 3.5 | 3 3/4 qt | 3 1/8 qt | Genuine NISSAN Windshield Washer Concentrate Cleaner & Anti-Freeze or equivalent |
| Air conditioning system refrigerant | 0.50 ± 0.05 kg | 1.10 ± 0.11 lb | 1.10 ± 0.11 lb | HFC-134a (R-134a) (4) |
| Air conditioning system oil | 120 m l | 5.03 fl oz | 5.3 fl oz | NISSAN A/C System Lubricant Type S or equivalent (4) |
| (1) For further details, see " SAE VISCOSITY NUMBER ". (2) Using transaxle fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. (3) Available in mainland U.S.A. through your NISSAN dealer. (4) For further details, see "Air conditioner specification label". |
| (1) | For further details, see " SAE VISCOSITY NUMBER ". |
| (2) | Using transaxle fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. |
| (3) | Available in mainland U.S.A. through your NISSAN dealer. |
| (4) | For further details, see "Air conditioner specification label". |
QR25DE
| Description | Capacity (Approximate) | Recommended Fluids/Lubricants |
|---|
| Liter | US measure | Imp measure |
| Fuel | 55.0 | 14 1/2 gal | 12 1/8 gal | Unleaded gasoline with an octane rating of at least 87 AKI (RON 91) |
| Engine oil Drain and refill | With oil filter change | 4.9 | 5 1/8 qt | 4 3/8 qt | API Certification Mark (1) |
| Without oil filter change | 4.6 | 4 7/8 qt | 4 qt |
| Dry engine (engine overhaul) | 5.0 | 5 1/4 qt | 4 3/8 qt |
| Cooling system (with reservoir at max level) | 7.6 | 2 gal | 1 5/8 gal | Genuine NISSAN Long Life Anti-freeze / Coolant or equivalent |
| Manual transaxle fluid (MTF) | 2.0 | 4 1/4 pt | 3 1/2 pt | ELF XT4447 M+ 75W-80 or API GL-4, Viscosity SAE 75W-80 |
| CVT fluid | 8.3 | 8 3/4 qt | 7 1/4 qt | Genuine NISSAN CVT Fluid NS-2 (2) |
| Brake and clutch fluids | | | | Genuine NISSAN Super Heavy Duty Brake Fluid or equivalent, DOT 3 (US FMVSS No. 116) (3) |
| Multi-purpose grease | | | | NLGI No. 2 (Lithium soap base) |
| Windshield washer fluid | 3.5 | 3 3/4 qt | 3 1/8 qt | Genuine NISSAN Windshield Washer Concentrate Cleaner & Anti-freeze or equivalent |
| Air conditioning system refrigerant | 0.50 ± 0.05 kg | 1.10 ± 0.11 lb | 1.10 ± 0.11 lb | HFC-134a (R-134a) (4) |
| Air conditioning system oil | 120 m l | 5.03 fl oz | 5.3 fl oz | NISSAN A/C System Lubricant Type S or equivalent (4) |
| (1) For further details, see " SAE VISCOSITY NUMBER ". (2) Using transaxle fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. (3) Available in mainland U.S.A. through your NISSAN dealer. (4) For further details, see "Air conditioner specification label". |
| (1) | For further details, see " SAE VISCOSITY NUMBER ". |
| (2) | Using transaxle fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. |
| (3) | Available in mainland U.S.A. through your NISSAN dealer. |
| (4) | For further details, see "Air conditioner specification label". |
GASOLINE ENGINE OIL
SAE 5W-30 viscosity oil is recommended for all temperatures.
Scheme 23
Scheme 1: Gasoline Engine Oil Range
Anti-freeze Coolant Mixture Ratio
The engine cooling system is filled at the factory with a high-quality, long life, year-round, anti-freeze coolant solution. The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system additives are not necessary.
| Maximum outside temperature | Genuine NISSAN Anti-freeze Coolant or equivalent | Demineralized water or distilled water |
|---|
| °C | °F |
| 35 | 30 | 50% | 50% |
ANTI-FREEZE COOLANT MIXTURE RATIO REFERENCE CHART
| CAUTION | When adding or replacing coolant, be sure to use only a Genuine NISSAN Long Life Anti-Freeze coolant or equivalent with the proper mixture ratio. The use of other types of coolant solutions may damage the engine cooling system. |
Scheme 24
Scheme 2: Identifying Drive Belts Components
Checking Drive Belts
| WARNING | Be sure to perform this step when the engine is stopped. |
- Make sure that the indicator (notch on fixed side) of drive belt auto-tensioner is within the possible use range (A). NOTE: Check the drive belt auto-tensioner indication when the engine is cold. When new drive belt is installed, the indicator (notch on fixed side) should be within the range (B) in the figure.
- Visually check entire drive belt for wear, damage or cracks.
- If the indicator (notch on fixed side) is out of the possible use range or belt is damaged, replace drive belt.
Changing Engine Coolant
| WARNING | To avoid being scalded, do not change engine coolant when engine is hot. Wrap a thick cloth around radiator cap and carefully remove the cap. First, turn the cap a quarter of a turn to release built-up pressure. Then turn the cap all the way. Be careful not to allow engine coolant to contact drive belt. |
Scheme 25
Scheme 25: DRAINING ENGINE COOLANT
- Open radiator drain plug (1) at the bottom of radiator, and then remove radiator cap. <=Vehicle front When draining all of engine coolant in the system, open water drain plug on cylinder block. Refer to " «DISASSEMBLY»(ref-273041-S34574236922007113000000) ". CAUTION: Perform this step when engine is cold. Do not spill engine coolant on drive belt. (Scheme 23): Identifying Radiator Drain Plug
- Remove reservoir tank as necessary, and drain engine coolant and clean reservoir tank before installing. Refer to " «RADIATOR»(ref-273043-S11177302052007113000000) ".
- Check drained engine coolant for contaminants such as rust, corrosion or discoloration.
If contaminated, flush the engine cooling system. Refer to " FLUSHING COOLING SYSTEM ".
Scheme 26
Scheme 26: REFILLING ENGINE COOLANT
Scheme 27
- Install the radiator drain plug. Install the reservoir tank and cylinder block drain plug, if removed for a total system drain or for engine removal or repair. The radiator must be completely empty of coolant and water. Apply sealant to the threads of the cylinder block drain plugs. Use Genuine High Performance Thread Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-273036-S11393009422007113000000) ". Radiator drain plug: Refer to " «REMOVAL AND INSTALLATION»(ref-273043-S33548175002007113000000) ". Cylinder block drain plug: Refer to " «REMOVAL AND INSTALLATION»(ref-273055-S11058384592007113000000) ".
- If disconnected, reattach the upper radiator hose at the engine side.
- Set the vehicle heater controls to the full HOT and heater ON position. Turn the vehicle ignition ON with the engine OFF as necessary to activate the heater mode.
- Install the Tool by installing the radiator cap adapter onto the radiator neck opening. Then attach the gauge body assembly with the refill tube and the venturi assembly to the radiator cap adapter. Tool number: KV991J0070 (J-45695)
- Insert the refill hose into the coolant mixture container that is placed at floor level. Make sure the ball valve is in the closed position. Use Genuine NISSAN Long Life Anti-freeze coolant or equivalent, mixed 50/50 with distilled water or demineralized water. Refer to " «ANTI-FREEZE COOLANT MIXTURE RATIO»(ref-273042-S40979316772007113000000) ". Engine coolant capacity (with reservoir tank): Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-273042-S04542523792007113000000) ".
- Install an air hose to the venturi assembly, the air pressure must be within specification. Compressed air supply pressure: 5.7 - 8.5 kPa (5.6 - 8.4 kg/cm 2, 80 - 120 psi) (Scheme 24): Attaching Gauge Body Assembly CAUTION: The compressed air supply must be equipped with an air dryer.
- The vacuum gauge will begin to rise and there will be an audible hissing noise. During this process open the ball valve on the refill hose slightly. Coolant will be visible rising in the refill hose. Once the refill hose is full of coolant, close the ball valve. This will purge any air trapped in the refill hose.
- Continue to draw the vacuum until the gauge reaches 28 inches of vacuum. The gauge may not reach 28 inches in high altitude locations, refer to the vacuum specifications based on the altitude above sea level. Altitude above sea level Vacuum gauge reading 0 - 100 m (328 ft): 28 inches of vacuum 300 m (984 ft): 27 inches of vacuum 500 m (1,641 ft): 26 inches of vacuum 1,000 m (3,281 ft): 24 - 25 inches of vacuum (Scheme 25): Checking Vacuum Gauge Reading
- When the vacuum gauge has reached the specified amount, disconnect the air hose and wait 20 seconds to see if the system loses any vacuum. If the vacuum level drops, perform any necessary repairs to the system and repeat steps 6 - 8 to bring the vacuum to the specified amount. Recheck for any leaks.
- Place the coolant container (with the refill hose inserted) at the same level as the top of the radiator. Then open the ball valve on the refill hose so the coolant will be drawn up to fill the cooling system. The cooling system is full when the vacuum gauge reads zero. CAUTION: Do not allow the coolant container to get too low when filling, to avoid air from being drawn into the cooling system.
- Remove the Tool from the radiator neck opening.
- Fill the cooling system reservoir tank to the specified level and install the radiator cap. Run the engine to warm up the cooling system and top up the system as necessary.
CHECKING COOLING SYSTEM FOR LEAKS
To check for leaks, apply pressure to the cooling system using Tool.
Tool number : EG17650301 (J-33984-A)
Testing pressure : 157 kPa (1.6 kg/cm 2 , 23 psi)
| WARNING | Never remove the radiator cap when the engine is hot. Serious burns could occur from high pressure coolant escaping from the radiator. |
| CAUTION | Higher pressure than specified may cause radiator damage. |
Scheme 28
Scheme 7: Applying Pressure To Cooling System
Checking Fuel Lines
Inspect fuel lines, fuel filler cap and fuel tank for improper attachment, leaks, cracks, damage, loose connections, chafing or deterioration.
If necessary, repair or replace damaged parts.
Scheme 29
Scheme 8: Identifying Engine, Fuel Line And Fuel Tank
Scheme 30
- Unclip the tabs (A) of both ends of the air cleaner cover (1). (Scheme 28): Locating Air Cleaner Cover And Tabs
- Remove the air cleaner filter and holder assembly from the air cleaner case.
- Remove the air cleaner filter from the holder.
ENGINE OIL APPEARANCE
- Check engine oil for white turbidity or heavy contamination.
- If engine oil becomes turbid and white, it is highly probable that it is contaminated with engine coolant. Repair or replace damaged parts.
ENGINE OIL LEAKAGE
Check for engine oil leakage around the following areas
- Oil pan (upper and lower)
- Oil pan drain plug
- Oil pressure switch
- Oil filter
- Intake valve timing control solenoid valve
- Front cover
- Mating surface between cylinder block and cylinder head
- Mating surface between cylinder head and rocker cover
- Crankshaft oil seals (front and rear)
- Oil filter (for intake valve timing control)
OIL PRESSURE CHECK
| WARNING | Be careful not to burn yourself, as engine oil may be hot. For engine oil pressure check the transaxle should be in " Park position" (CVT models) or "Neutral position" (M/T models), and apply the parking brake securely. |
Scheme 31
Scheme 32
- Disconnect harness connector at oil pressure switch (1), and remove oil pressure switch using a suitable tool. Oil pan (lower) (2) <= Front (Scheme 30): Identifying Oil Pressure Switch And Oil Pan
- Install oil pressure gauge and hose. Tool number: ST25051001 (J-25695-1): ST25052000 (J-25695-2) see scheme 12: Identifying Oil Pressure Gauge
- Check engine oil level. Refer to " «ENGINE OIL LEVEL»(ref-273042-S39761062122007113000000) ".
- Start engine and warm it up to normal operating temperature.
- Check oil pressure with engine running under no-load. NOTE: When engine oil temperature is low, engine oil pressure becomes high. Engine oil pressure [Engine oil temperature at 80°C (176°F)] ENGINE OIL PRESSURE REFERENCE Engine speed rpm Approximate discharge pressure kPa (bar, kg/cm 2, psi) Idle speed More than 60 (0.60, 0.61, 9) 2,000 More than 200 (2.0, 2.0, 29) If difference is extreme, check oil passage and oil pump for oil leaks.
- After the inspections, install oil pressure switch as follows: Remove old liquid gasket adhering to oil pressure switch and engine. Apply liquid gasket and tighten oil pressure switch to specification. Use Genuine Silicone RTV Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-273036-S11393009422007113000000) ". Oil pressure switch: 14.7 N.m (1.5 kg-m, 11 ft-lb) Check engine oil level. Refer to " «ENGINE OIL LEVEL»(ref-273042-S39761062122007113000000) ". After warming up engine, make sure there are no engine leaks of oil with running engine.
Changing Engine Oil
| WARNING | Be careful not to burn yourself, as engine oil may be hot. Prolonged and repeated contact with used engine oil may cause skin cancer; try to avoid direct skin contact with used engine oil. If skin contact is made, wash thoroughly with soap or hand cleaner as soon as possible. |
Scheme 33
- Warm up engine, park vehicle on a level surface and check for engine oil leakage from engine components. Refer to " «ENGINE OIL LEAKAGE»(ref-273042-S26193597562007113000000) ".
- Stop engine and wait for 10 minutes.
- Loosen oil filler cap (1) and then remove drain plug (2). Oil filter (3) <= Vehicle front
- Drain engine oil.
- Install drain plug (2) with new washer. Refer to " «OIL PAN»(ref-273041-S00545375612007113000000) ". CAUTION: Be sure to clean drain plug (2) and install with new washer.
- Refill with new engine oil. Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-273042-S04542523792007113000000) ". CAUTION: The refill capacity depends on the engine oil temperature and drain time. Use these specifications for reference only. Always use oil level gauge to determine the proper amount of engine oil in the engine.
- Warm up engine and check area around drain plug (2) and oil filter (3) for engine oil leakage.
- Stop engine and wait for 10 minutes.
- Check the engine oil level. Refer to " «ENGINE OIL LEVEL»(ref-273042-S39761062122007113000000) ". (Scheme 31): Identifying Oil Filler Cap And Drain Plug
Scheme 34
- Remove oil filter using Tool (A). Tool number: KV10115801 (J-38956) <= Front CAUTION: Oil filter is provided with relief valve. Use Genuine NISSAN Oil Filter or equivalent. Be careful not to get burned when engine and engine oil may be hot. When removing, prepare a shop cloth to absorb any engine oil leakage or spillage. Do not allow engine oil to adhere to drive belt. Completely wipe off any engine oil that adheres to engine and vehicle. (Scheme 32): Identifying Oil Filter
Scheme 35
Scheme 36
- Remove foreign materials adhering to the oil filter installation surface.
- Apply new engine oil to the oil seal contact surface of new oil filter. (Scheme 33): Applying Engine Oil To Oil Filter Seal
- Screw oil filter manually until it touches the installation surface, then tighten it by 2/3 turn. Or tighten to specification. Oil filter:: 17.7 N.m (1.8 kg-m, 13 ft-lb) (Scheme 34): Identifying Oil Filter Tightening Angle
Checking EVAP Vapor Lines
- Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections, chafing and deterioration.
- Inspect fuel tank filler cap vacuum relief valve for clogging, sticking, etc. Refer to " «EVAPORATIVE EMISSION SYSTEM»(ref-273047-S24146890812007113000000) ".
Scheme 37
Scheme 22: Checking Drive Belts
| WARNING | Inspect the drive belt only when the engine is stopped. |
Note. On vehicles not equipped with A/C, there is an idler pulley in the position for the drive belt routing.
- Make sure that the stamp mark of drive belt auto-tensioner is within the usable range. NOTE: Check the drive belt auto-tensioner indicator (notch) when the engine is cold. When the new drive belt is installed, the range should be "A" as shown. Visually check entire belt for wear, damage or cracks. If the indicator is out of allowable use range or belt is damaged, replace the belt.
| WARNING | To avoid being scalded, never change the coolant when the engine is hot. Wrap a thick cloth around cap and carefully remove the cap. First, turn the cap a quarter of a turn to release built-up pressure. Then push down and turn the cap all the way to remove. |
Scheme 38
Scheme 38: DRAINING ENGINE COOLANT
- Remove the engine undercover using power tool.
- Open the radiator drain plug at the bottom of the radiator, and remove the radiator filler cap. This is the only step required when partially draining the cooling system (radiator only). Do not to allow the coolant to contact the drive belts.
- Follow this step for heater core removal/replacement only. Disconnect the upper heater hose at the engine side and apply moderate air pressure [103.46 kPa (15 psi, 1.055 kg/cm 2 ) maximum air pressure] into the hose for 30 seconds to blow the excess coolant out of the heater core.
- When draining all of the coolant in the system, remove the reservoir tank and drain the coolant, then clean the reservoir tank before installation.
- When draining all of the coolant in the system for engine removal or repair, open the drain plug on the cylinder block. see scheme 23: Opening Drain Plug On Cylinder Block
- Check the drained coolant for contaminants such as rust, corrosion or discoloration. If the coolant is contaminated, flush the engine cooling system. Refer to " «FLUSHING COOLING SYSTEM»(ref-273056-S02620552812007113000000) ".
Inspect the fuel lines and fuel tank for improperly attached hoses, leaks, cracks, damage, loose connections, chafing, or deterioration. If necessary, repair or replace any damaged parts.
CHANGING THE AIR CLEANER ELEMENT
- Depress the air cleaner case lid side clips and remove.
- Remove the air cleaner element.
- Install a new air cleaner element.
- Installation is in the reverse order of removal.
Scheme 39
- Before starting the engine, check the oil level. If the engine is already started, stop it and allow 10 minutes before checking.
- Check that the oil level is within the range on the dipstick.
- If it is out of range, add oil as necessary. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-273036-S11393009422007113000000) ". see scheme 27: Checking Engine Oil Level
- Check engine oil for white milky or excessive contamination.
- If engine oil becomes milky, it is highly probable that it is contaminated with engine coolant. Repair or replace damaged parts.
OIL LEAKAGE
Check for oil leakage around the following areas
- Oil pan
- Oil pan drain plug
- Oil pressure sensor
- Oil filter
- IVTC cover
- Front cover
- Mating surface between cylinder block and cylinder head
- Mating surface between cylinder head and rocker cover
- Crankshaft oil seal
| WARNING | Be careful not to burn yourself, as the engine oil may be hot. Prolonged and repeated contact with used engine oil may cause skin cancer: try to avoid direct skin contact with used oil. If skin contact is made, wash thoroughly with soap or hand cleaner as soon as possible. |
- Position the vehicle so it is level on the hoist.
- Warm up the engine, and check for oil leaks from the engine.
- Stop engine and wait for 10 minutes.
- Remove the oil pan drain plug and oil filler cap.
- Drain the engine oil.
- Install the oil pan drain plug with a new washer and refill the engine with new engine oil. Oil specification and capacity : Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-273036-S11393009422007113000000) ". Oil pan drain plug : 34.3 N.m (3.5 kg-m, 25 ft-lb) Oil Capacity (Approximate) OIL CAPACITY REFERENCE Drain and refill With oil filter change 4.3 l (4 1/2 US qt, 3 3/4 Imp qt) Without oil filter change 4.0 l (4 1/4 US qt, 3 1/2 Imp qt) Dry engine (engine overhaul) 4.6 l (4 7/8 US qt, 4 Imp qt) CAUTION: Be sure to clean the drain plug and install using a new washer. The refill capacity depends on the oil temperature and drain time. Use these specifications for reference only. Always use the dipstick to determine when the proper amount of oil is in the engine.
- Warm up the engine and check the area around the drain plug and oil filter for oil leakage.
- Stop the engine and wait for 10 minutes.
- Check the oil level using the dipstick. CAUTION: Do not overfill the engine oil.
Scheme 40
Scheme 41
- Remove the oil filter using Tool. Tool number: KV10115801 (J-38956) CAUTION: Be careful not to get burned when the engine and engine oil are hot. When removing, prepare a shop cloth to absorb any oil leakage or spillage. Do not allow engine oil to adhere to the drive belts. Completely wipe off any oil that adheres to the engine and the vehicle. see scheme 28: Identifying Oil Pressure Gauge The oil filter has a built in pressure relief valve. Use a genuine NISSAN oil filter or equivalent (Scheme 39): Identifying Oil Filter Body
Spark Plug Types
| Temperature range | NGK |
|---|
| Standard type | DILKAR6A-11 |
| Gap (nominal) | 1.1 mm (0.043 in) |
- Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections, chafing and deterioration.
- Inspect fuel tank filler cap vacuum relief valve for clogging and sticking.
Scheme 42
Scheme 36: Identifying Filter Cover, Heater And Cooling Unit Assembly
Scheme 43
- Remove the filter cover. Release the filter cover tab (A) the pull the bottom of the filter cover out tilting it at an angle Pull down the filter cover to disengage the hook at the top and remove the filter cover. see scheme 37: Identifying Filter Cover Tab
- Remove the in-cabin microfilter.
- Install the new in-cabin microfilter. CAUTION: Insert the new filter with the "UP" arrow in the correct orientation. Insert the new filter with the "UP" arrow side of the filter facing the front of the vehicle.
- Install the filter cover. Insert the hook at the top of the filter cover into the heater and cooling unit case. Swing the filter cover into the heater and cooling unit case until the filter cover tab (A) snaps securely on the heater and cooling unit case. CAUTION: Check the filter cover to make sure it is securely fastened to the heater and cooling unit case. (Scheme 42): Identifying Filter Cover Tab
Checking Exhaust System
Check the exhaust pipes, muffler, and exhaust mounts for improper attachment, leaks, cracks, damage, chafing, or deterioration.
Scheme 44
Scheme 39: Checking Exhaust Pipes, Muffler, And Exhaust Mounts
Checking Clutch System
Check fluid lines and operating cylinder for improper attachment, cracks, damage, loose connections, chafing and deterioration.
Scheme 45
- Start engine and let it run to warm up transaxle.
- Stop engine. Remove drain plug (1) and drain oil.
- Install a new gasket onto drain plug (1) and install it into transaxle. Tighten drain plug to specification. Refer to " «CASE AND HOUSING COMPONENTS»(ref-273050-S33669064822007113000000) ". CAUTION: Do not reuse gasket. see scheme 45: Identifying Drain Plug
Scheme 46
- Remove filler plug (1). Fill with new oil until oil level reaches the specified limit at filler plug hole as shown. Oil grade and capacity: Refer to " «MR20DE»(ref-273042-S33967798442007113000000) ".
- After refilling oil, check oil level. Install a new gasket on filler plug (1), then install it into transaxle. Tighten filler plug to specification. Refer to " «CASE AND HOUSING COMPONENTS»(ref-273050-S33669064822007113000000) ". CAUTION: Do not reuse gasket. see scheme 46: Identifying Filler Plug
OIL LEAKAGE AND OIL LEVEL
- Make sure that oil is not leaking from transaxle or around it.
- Remove filler plug (1) and check oil level at filler plug hole as shown. CAUTION: Do not start engine while checking oil level.
- Install a new gasket onto filler plug (1) and install it into transaxle. Tighten filler plug to specification. Refer to " «CASE AND HOUSING COMPONENTS»(ref-273050-S33669064822007113000000) ". CAUTION: Do not reuse gasket. (Scheme 45): Identifying Filler Plug
Scheme 47
- Start engine and let it run to warm up transaxle.
- Stop engine. Remove drain plug and drain oil.
- Set a gasket on drain plug and install it to transaxle. Tighten drain plug to the specified torque. Refer to " «CASE AND HOUSING COMPONENTS»(ref-273050-S13586112632007113000000) ". CAUTION: Never reuse gasket. (Scheme 46): Locating Drain Plug
Scheme 48
- Remove plug (with ABS models) (1) or speedometer pinion gear (without ABS models) (1). Fill with new oil to transaxle. Oil grade and viscosity: Refer to " «MR20DE»(ref-273042-S33967798442007113000000) ". Oil capacity (reference): Refer to " «GENERAL SPECIFICATIONS»(ref-273050-S19635186692007113000000) ". see scheme 49: Checking Oil Level
- After refilling oil, check oil level.
- Set a O-ring on plug (with ABS models) (1) or speedometer pinion gear (without ABS models) (1) and then install it to transaxle. Tighten mounting bolt to the specified torque. Refer to " «CASE AND HOUSING COMPONENTS»(ref-273050-S13586112632007113000000) ". CAUTION: Never reuse O-ring.
Scheme 49
Scheme 49: OIL LEAKAGE AND OIL LEVEL
- Make sure that oil is not leaking from transaxle or around it.
- Remove plug (with ABS models) (1) or speedometer pinion gear (without ABS models) (1).
- Measure oil level using a suitable gauge (A) as shown in the figure, and then check if it is within the specifications. Oil level "L": Refer to " «GENERAL SPECIFICATIONS»(ref-273050-S19635186692007113000000) ". CAUTION: Never start engine while checking oil level.
- Set a O-ring on plug (with ABS models) (1) or speedometer pinion gear (without ABS models) (1) and then install it to transaxle. Tighten mounting bolt to the specified torque. Refer to " «CASE AND HOUSING COMPONENTS»(ref-273050-S13586112632007113000000) ". CAUTION: Never reuse O-ring. (Scheme 47): Checking Oil Level
ROTOR
Check the rotor condition and thickness. Resurface or replace the rotor as necessary. Refer to " FRONT DISC BRAKE ".
Locating Brake Pads. Scheme 50
Scheme 58: Checking Rotor Thickness
CALIPER
Check the caliper for leakage.
Locating Wheel Cylinder. Scheme 51
Scheme 59: Checking Caliper For Fluid Leakage
PAD
Check the brake pads for wear or damage. Refer to " PAD WEAR INSPECTION ".
Scheme 50: Locating Brake Pads
WHEEL CYLINDER
Scheme 51: Locating Wheel Cylinder
LINING
Check for lining thickness (A). Refer to " DISASSEMBLY AND ASSEMBLY OF WHEEL CYLINDER ".
Checking Lining Thickness. Scheme 52
Scheme 52: Checking Lining Thickness
Axle and Suspension Parts
Check front and rear axle and suspension parts for excessive play, cracks, wear or other damage.
Scheme 53
Scheme 53: Axle and Suspension Parts
Scheme 54
- Shake each wheel to check for excessive play.
- Check wheel bearings for smooth operation.
- Check axle and suspension nuts and bolts for looseness.
- Check strut (shock absorber) for oil leakage or other damage.
- Check suspension ball joint for grease leakage and ball joint dust cover for cracks or other damage. see scheme 63: Checking Axle And Suspension Parts For Excessive Play see scheme 64: Checking Shock Absorber And Suspension Ball Joint For Leakage
Drive Shaft
Check boot and drive shaft for cracks, wear, damage and grease leakage.
Scheme 55
Scheme 65: Checking Boot And Drive Shaft For Leakage
Scheme 56
Scheme 66: Identifying Lubricating Locks, Hinges And Hood Latch
Checking Seat Belts, Buckles, Retractors, Anchors and Adjusters
Check the seat belt buckles, webbing, retractors, anchors and adjusters. Replace any seat belt assembly as necessary. Refer to " SEAT BELT INSPECTION ".
- Check the seat belt anchors for loose bolts, damage, or excessive wear.
- Check the seat belt webbing for any damage, cuts, fraying, or excessive wear.
- Check the retractor for smooth operation.
- Check the function of the buckles by inserting the seat belt tongue and checking for proper engagement of the buckle and press the button on the buckle to check for proper release of the seat belt tongue.
| CAUTION | After any collision, inspect all seat belt assemblies, including retractors and other attached components, such as the guide rail set. NISSAN recommends replacing all seat belt assemblies in use during a collision, unless they are not damaged and are inspected to confirm they are operating properly after a minor collision. Also inspect all seat belt assemblies that are not in use during a collision, and replace any components if damaged or not operating properly. The seat belt pre-tensioner should be replaced even if the seat belts are not in use during a frontal collision where the driver and passenger air bags have been deployed. If any component of the seat belt assembly is suspected of being damaged or not operating properly, do not repair the component. Replace the components as an assembly. If the seat belt webbing is cut, frayed, or damaged then replace the seat belt assembly. Never lubricate the seat belt buckle or tongue. When replacing any seat belt assembly always use a Genuine NISSAN seat belt assembly. |
