Maintenance: Removal & Installation Nissan Rogue II

Procedures 8 illustrations ~776 words

INSTALLATION

Installation is in the reverse order of removal.

  1. Install the drive belt onto all of the pulleys except for the drive belt auto-tensioner. Then install the drive belt onto drive belt auto-tensioner last. CAUTION: Confirm belts are completely set on the pulleys. Check for engine oil and engine coolant. Be sure it is not on the drive belt and each pulley groove.
  2. Release the drive belt auto-tensioner and apply tension to drive belt. WARNING: Avoid placing hand in a location where pinching may occur if the holding tool accidentally comes off.
  3. Turn crankshaft pulley clockwise several times to equalize tension between each pulley.
  4. Confirm the indicator is within the possible use range. Refer to " «DRIVE BELTS: CHECKING»(ref-616719-S10699093542014051900000) ".
  5. Install wheel and tire (RH). Refer to " «ADJUSTMENT»(ref-616718-S35728988592014051900000) ".

Scheme 20

Scheme 20: DRIVE BELTS: Removal and Installation of Drive Belt Auto-tensioner
Scheme 20: DRIVE BELTS: Removal and Installation of Drive Belt Auto-tensioner

REMOVAL

CAUTIONThe complete drive belt auto-tensioner must be replaced as a unit, including the pulley.
  1. Remove the drive belt. Refer to " «DRIVE BELTS: REMOVAL AND INSTALLATION»(ref-616719-S16136485102014051900000) ".
  2. Remove the drive belt auto-tensioner.

Installation is in the reverse order of removal.

CAUTIONInstall the drive belt auto-tensioner carefully so not to damage the water pump pulley.

Scheme 21

Scheme 21: AIR CLEANER FILTER: Exploded View
Scheme 21: AIR CLEANER FILTER: Exploded View

Installation is in the reverse order of removal.

Standard type (1)DENSO
FXE20HE11C
Gap (nominal)1.1 mm (0.043 in)
(1) Always check with the Parts Department for the latest parts information.
(1)Always check with the Parts Department for the latest parts information.
  1. Remove fender protector side cover (RH). Refer to " «FENDER PROTECTOR: EXPLODED VIEW»(ref-616717-S39205674252014051900000) ".
  2. Drain engine oil. Refer to " «ENGINE OIL: DRAINING»(ref-616719-S31392686232014051900000) ".
  3. Remove oil filter using suitable tool (A).

Scheme 22

Scheme 22
Scheme 22
WARNINGBe careful not to burn yourself, as engine oil may be hot.
CAUTIONWhen removing, prepare a shop cloth to absorb any engine oil leaks or spills. Do allow engine oil on drive belt. Completely wipe off any engine oil on engine and vehicle. Oil filter is provided with relief valve. Use genuine NISSAN oil filter or equivalent.

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24: INSTALLATION
Scheme 24: INSTALLATION

Scheme 25

Scheme 25
Scheme 25
  1. Remove foreign materials on oil filter installation surface.
  2. Apply new engine oil to the oil seal contact surface of new oil filter.
  3. Screw oil filter manually until it touches the installation surface, then tighten it by 2/3 turn (A). Or tighten to the specification. Oil filter: : 17.7 N.m (1.8 kg-m, 13 ft-lb)

CVT FLUID: Replacement

Recommended fluid and fluid capacity: Refer to " GENERAL SPECIFICATION ".

CAUTIONAlways use shop paper. Never use shop cloth. Replace a drain plug gasket with new ones at the final stage of the operation when installing. Use caution when looking into the drain hole as there is a risk of dripping fluid entering the eye. After replacement, always perform CVT fluid leakage check.

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27
  1. Select "Data Monitor" in "TRANSMISSION" using CONSULT.
  2. Select "FLUID TEMP" and confirm that the CVT fluid temperature is 40°C (104°F) or less.
  3. Check that the selector lever is in the "P" position, then completely engage the parking brake.
  4. Lift up the vehicle.
  5. Remove the drain plug and drain the CVT fluid from the oil pan. Refer to " «EXPLODED VIEW»(ref-616729-S02577175592014051900000) ".
  6. Install the drain plug to oil pan. CAUTION: Drain plug gasket use the old one.
  7. Remove the overflow plug from converter housing.
  8. Install the charging pipe set (KV311039S0) (A) into the overflow plug hole. CAUTION: Tighten the charging pipe by hand.
  9. Install the ATF changer hose (B) to the charging pipe. CAUTION: Press the ATF changer hose all the way onto the charging pipe until it stops.
  10. Fill approximately 3 liter (3-1/8 US qt, 2-5/8 lmp qt) of the CVT fluid.
  11. Remove the ATF changer hose and charging pipe, then install the overflow plug. NOTE: Perform this work quickly because CVT fluid leaks.
  12. Lift down the vehicle.
  13. Start the engine.
  14. While depressing the brake pedal, shift the selector lever to the entire position from "P" to "L", and shift it to the "P" position. NOTE: Hold the lever at each position for 5 seconds.
  15. Check that the CONSULT "Data Monitor" in "FLUID TEMP" is 35°C (95°F) to 45°C (113°F).
  16. Stop the engine.
  17. Lift up the vehicle.
  18. Remove the drain plug, and then drain CVT fluid from oil pan.
  19. Repeat steps 8 to 18 (one time).
  20. Tighten the drain plug to the specified torque. Refer to " «EXPLODED VIEW»(ref-616729-S02577175592014051900000) ".
  21. Remove the overflow plug.
  22. Install the charging pipe set (KV311039S0) into the overflow plug hole. CAUTION: Tighten the charging pipe by hand.
  23. Install the ATF changer hose to the charging pipe. CAUTION: Press the ATF changer hose all the way onto the charging pipe until it stops.
  24. Fill approximately 3 liter (3-1/8 US qt, 2-5/8 lmp qt) of the CVT fluid.
  25. Remove the ATF changer hose and charging pipe, then install the overflow plug. NOTE: Perform this work quickly because CVT fluid leaks.
  26. Lift down the vehicle.
  27. Start the engine.
  28. While depressing the brake pedal, shift the selector lever to the entire position from "P" to "L", and shift it to the "P" position. NOTE: Hold the lever at each position for 5 seconds.
  29. Check that the CONSULT "Data Monitor" in "FLUID TEMP" is 35°C (95°F) to 45°C (113°F).
  30. Lift up the vehicle.
  31. Remove the overflow plug and confirm that the CVT fluid is drained from the overflow plug hole. CAUTION: Perform this work with the vehicle idling. NOTE: If the CVT fluid is not drained, refer to "Adjustment" and refill with the CVT fluid.
  32. When the flow of CVT fluid slows to a drip, tighten the overflow plug to the specified torque. Refer to " «EXPLODED VIEW»(ref-616729-S02577175592014051900000) ". CAUTION: Never reuse O-ring.
  33. Lift down the vehicle.
  34. Select "Data Monitor" in "TRANSMISSION" using CONSULT.
  35. Select "CONFORM CVTF DETERIORTN".
  36. Select "Erase".
  37. Stop the engine.
