Scheme 43: Special Service Tool
Scheme 44
Commercial Service Tool
Tool name Description Power tool Loosening nuts, screws and bolts - (223-50000) Oil filter wrench assortment Removing oil filter
General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform the checks and inspections themselves or have their NISSAN dealers do them.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.
| Item | Reference |
|---|
| Tires | Check the pressure with a gauge often and always prior to long distance trips. Adjust the pressure in all tires, including the spare, to the pressure specified. Check carefully for damage, cuts or excessive wear. | SERVICE DATA AND SPECIFICATIONS (SDS) |
| Wheel nuts | When checking the tires, make sure no nuts are missing, and check for any loose nuts. Tighten if necessary. | |
| Tire rotation | Tires should be rotated every 5, 000 miles (8, 000 km). If the vehicle is equipped with different sized tires in the front and rear, tires cannot be rotated. | ADJUSTMENT |
| Tire Pressure Monitoring System (TPMS) transmitter components | Replace the TPMS transmitter grommet seal, valve core and cap when the tires are replaced due to wear or age. | EXPLODED VIEW |
| Wheel alignment and balance | If the vehicle should pull to either side while driving on a straight and level road, or if you detect uneven or abnormal tire wear, there may be a need for wheel alignment. If the steering wheel or seat vibrates at normal highway speeds, wheel balancing may be needed. For additional information regarding tires, refer to "Important Tire Safety Information" (US) or "Tire Safety Information" (Canada) in the NISSAN Warranty Information Booklet. | WHEEL ALIGNMENT WHEEL ALIGNMENT ADJUSTMENT |
| Windshield | Clean the windshield on a regular basis. Check the windshield at least every six months for cracks or other damage. Repair as necessary. | |
| Windshield wiper blades | Check for cracks or wear if they do not wipe properly. | |
| Doors and engine hood | Check that all doors and the engine hood operate smoothly as well as the back door. Also make sure that all latches lock securely. Lubricate if necessary. Make sure that the secondary latch keeps the hood from opening when the primary latch is released. When driving in areas using road salt or other corrosive materials, check lubrication frequently. | LOCKS, HINGES AND HOOD LATCH |
| Lamps | Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other lamps are all operating properly and installed securely. Also check headlamp aim. Clean the headlamps on a regular basis. | |
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.
| Item | Reference |
|---|
| Warning lamps and chimes | Make sure that all warning lamps and chimes are operating properly. | |
| Windshield wiper and washer | Check that the wipers and washer operate properly and that the wipers do not streak. | |
| Windshield defroster | Check that the air comes out of the defroster outlets properly and in sufficient quantity when operating the heater or air conditioner. | |
| Steering wheel | Check that it has the specified play. Check for changes in the steering condition, such as excessive play, hard steering or strange noises. Free play: Less than 35 mm (1.38 in) | |
| Seats | Check seat position controls such as seat adjusters, seatback recliner, etc. to make sure they operate smoothly and that all latches lock securely in every position. Check that the head restrains move up and down smoothly and that the locks (if equipped) hold securely in all latched positions. Check that the latches lock securely for folding-down rear seatbacks. | |
| Seat belts | Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and retractors) operate properly and smoothly and are installed securely. Check the belt webbing for cuts, fraying, wear or damage. | SEAT BELT, BUCKLES, RETRACTORS, ANCHORS AND ADJUSTERS |
| Accelerator pedal | Check the pedal for smooth operation and make sure the pedal does not catch or require uneven effort. Keep the floor mats away from the pedal. | |
| Brakes | Check that the brake does not pull the vehicle to one side when applied. | |
| Brake pedal and booster | Check the pedal for smooth operation and make sure it has the proper distance under it when depressed fully. Check the brake booster function. Be sure to keep the floor mats away from the pedal. | PERIODIC MAINTENANCE BRAKE BOOSTER |
| Parking brake | Check that the lever or the pedal has the proper travel and make sure that the vehicle is held securely on a fairly steep hill when only the parking brake is applied. | PERIODIC MAINTENANCE |
| CVT P (Park) position mechanism | On a fairly steep hill check that the vehicle is held securely with the selector lever in the P (Park) position without applying any brakes. | |
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
| Item | Reference |
|---|
| Windshield washer fluid | Check that there is adequate fluid in the tank. | |
| Engine coolant level | Check the coolant level when the engine is cold. | PERIODIC MAINTENANCE |
| Radiator and hoses | Check the front of the radiator and clean off any dirt, insects, leaves, etc., that may have accumulated. Make sure the hoses have no cracks, deformation, deterioration or loose connections. | RADIATOR |
| Brake fluid level | Make sure that the brake fluid level is between the "MAX" and "MIN" lines on the reservoir. | BRAKE FLUID |
| Battery | Check the fluid level in each cell. It should be between the "MAX" and "MIN" lines. Vehicles operated in high temperatures or under severe conditions require frequent checks of the battery fluid level. | BASIC INSPECTION |
| Engine drive belts | Make sure that no belt is frayed, worn, cracked or oily. | PERIODIC MAINTENANCE |
| Engine oil level | Check the level on the oil level gauge after parking the vehicle on a level spot and turning off the engine. | PERIODIC MAINTENANCE |
| Exhaust system | Make sure there are no loose supports, cracks or holes. If the sound of the exhaust seems unusual or there is a smell of exhaust fumes, immediately locate the trouble and correct it. | PERIODIC MAINTENANCE |
| Underbody | The underbody is frequently exposed to corrosive substances such as those used on icy roads or to control dust. It is very important to remove these substances, otherwise rust will form on the floor pan, frame, fuel lines and around the exhaust system. At the end of winter, the underbody should be thoroughly flushed with plain water, being careful to clean those areas where mud and dirt can easily accumulate. | |
| Fluid leaks | Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle has been parked for a while. Water dripping from the air conditioner after use is normal. If you should notice any leaks or gasoline fumes are evident, check for the cause and correct it immediately. | |
The following tables show the normal maintenance schedule. Depending upon weather and atmospheric conditions, varying road surfaces, individual driving habits and vehicle usage, additional or more frequent maintenance may be required.
Periodic maintenance beyond the last period shown on the tables requires similar maintenance.
| Abbreviations: R = Replace, I = Inspect and correct or replace as necessary |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
| Perform either at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 5 (8) 6 | 10 (16) 12 | 15 (24) 18 | 20 (32) 24 | 25 (40) 30 | 30 (48) 36 | 35 (56) 42 | 40 (64) 48 | 45 (72) 48 |
| Drive belts | NOTE (1) | | | | | | | | I (8) | |
| Air cleaner filter | NOTE (2) | | | | | | R | | | |
| EVAP vapor lines | | | | | I (8) | | | | I (8) | |
| Fuel lines | | | | | I (8) | | | | I (8) | |
| Fuel filter | NOTE (3) | | | | | | | | | |
| Engine coolant (8) | NOTE (4) (5) | | | | | | | | | |
| Engine oil | | R | R | R | R | R | R | R | R | R |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent) | | R | R | R | R | R | R | R | R | R |
| Spark plugs (Iridium-tipped type) | NOTE (6) | Replace every 105, 000 miles (168, 000 km) |
| Intake & exhaust valve clearance | NOTE (7) | | | | | | | | | |
| (1) After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to FUEL SYSTEM . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. (5) Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. (6) Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in), even if within specified periodic replacement mileage. (7) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (8) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| (1) | After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. |
| (2) | If operating mainly in dusty conditions, more frequent maintenance may be required. |
| (3) | Maintenance-free item. For service procedures, refer to FUEL SYSTEM . |
| (4) | First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. |
| (5) | Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. |
| (6) | Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in), even if within specified periodic replacement mileage. |
| (7) | Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. |
| (8) | Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
|---|
| Perform either at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 50 (80) 60 | 55 (88) 66 | 60 (96) 72 | 65 (104) 78 | 70 (112) 84 | 75 (120) 90 | 80 (128) 96 | 85 (136) 102 | 90 (144) 108 |
| Drive belts | NOTE (1) | I (8) | | I (8) | | I (8) | | I (8) | | I (8) |
| Air cleaner filter | NOTE (2) | | | R | | | | | | R |
| EVAP vapor lines | | | | I (8) | | | | I (8) | | |
| Fuel lines | | | | I (8) | | | | I (8) | | |
| Fuel filter | NOTE (3) | | | | | | | | | |
| Engine coolant (8) | NOTE (4) (5) | | | | | | | | | |
| Engine oil | | R | R | R | R | R | R | R | R | R |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent) | | R | R | R | R | R | R | R | R | R |
| Spark plugs (Iridium-tipped type) | NOTE (6) | Replace every 105, 000 miles (168, 000 km) |
| Intake&exhaust valve clearance | NOTE (7) | | | | | | | | | |
| (1) After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to FUEL SYSTEM . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. (5) Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. (6) Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in), even if within specified periodic replacement mileage. (7) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (8) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| (1) | After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. |
| (2) | If operating mainly in dusty conditions, more frequent maintenance may be required. |
| (3) | Maintenance-free item. For service procedures, refer to FUEL SYSTEM . |
| (4) | First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. |
| (5) | Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. |
| (6) | Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in), even if within specified periodic replacement mileage. |
| (7) | Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. |
| (8) | Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference |
|---|
| Perform either at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 95 (152) 114 | 100 (160) 120 | 105 (168) 126 | 110 (176) 132 | 115 (184) 138 | 120 (192) 144 |
| Drive belts | NOTE (1) | | I (8) | | I (8) | | I (8) | PERIODIC MAINTENANCE |
| Air cleaner filter | NOTE (2) | | | | | | R | AIR CLEANER FILTER |
| EVAP vapor lines | | | I (8) | | | | I (8) | EVAPORATIVE EMISSION SYSTEM |
| Fuel lines | | | I (8) | | | | I (8) | PERIODIC MAINTENANCE |
| Fuel filter | NOTE (3) | | | | | | | |
| Engine coolant (8) | NOTE (4) (5) | | | | | | | PERIODIC MAINTENANCE |
| Engine oil | | R | R | R | R | R | R | PERIODIC MAINTENANCE |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent) | | R | R | R | R | R | R | INSPECTION |
| Spark plugs (Iridium-tipped type) | NOTE (6) | Replace every 105, 000 miles (168, 000 km) | SPARK PLUG |
| Intake&exhaust valve clearance | NOTE (7) | | | | | | | |
| (1) After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to FUEL SYSTEM . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. (5) Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. (6) Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in), even if within specified periodic replacement mileage. (7) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (8) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| (1) | After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. |
| (2) | If operating mainly in dusty conditions, more frequent maintenance may be required. |
| (3) | Maintenance-free item. For service procedures, refer to FUEL SYSTEM . |
| (4) | First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. |
| (5) | Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. |
| (6) | Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in), even if within specified periodic replacement mileage. |
| (7) | Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. |
| (8) | Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| Abbreviations: R= Replace. I = Inspect. Correct or replace if necessary. |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
| Perform either at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 5 (8) 6 | 10 (16) 12 | 15 (24) 18 | 20 (32) 24 | 25 (40) 30 | 30 (48) 36 | 35 (56) 42 | 40 (64) 48 | 45 (72) 54 |
| Brake line & cables | | | I | | I | | I | | I | |
| Brake pads, rotors (1) | | | I | | I | | I | | I | |
| Brake fluid (1) | | | | | R | | | | R | |
| CVT fluid | NOTE (2) | | I | | I | | I | | I | |
| Transfer oil&differential gear oil | NOTE (3) | | I | | I | | I | | I | |
| Steering gear and linkage, axle and suspension parts (1) | | | | | I | | | | I | |
| Tire rotation | NOTE (4) | | | | | | | | | |
| Propeller shaft (AWD)&drive shaft boots (1) | | | I | | I | | I | | I | |
| Exhaust system (1) | | | | | I | | | | I | |
| In-cabin microfilter | | | | R | | | R | | | R |
| (1) Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (2) Use only Genuine NISSAN CVT fluid. If towing a trailer, using a camper or a car-top carrier, of driving on rough or muddy roads, inspect CVT fluid deterioration at an NISSAN dealer every 60, 000 miles (96, 000 km), then change CVT fluid if necessary. And if the inspection is not performed, change (not just inspect) CVT fluid every 60, 000 miles (96, 000 km). (3) If tower a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. (4) Refer to " TIRE ROTATION " under "GENERAL MAINTENANCE" heading earlier in this article. |
| (1) | Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". |
| (2) | Use only Genuine NISSAN CVT fluid. If towing a trailer, using a camper or a car-top carrier, of driving on rough or muddy roads, inspect CVT fluid deterioration at an NISSAN dealer every 60, 000 miles (96, 000 km), then change CVT fluid if necessary. And if the inspection is not performed, change (not just inspect) CVT fluid every 60, 000 miles (96, 000 km). |
| (3) | If tower a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. |
| (4) | Refer to " TIRE ROTATION " under "GENERAL MAINTENANCE" heading earlier in this article. |
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
|---|
| Perform either at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 50 (80) 60 | 55 (88) 66 | 60 (96) 72 | 65 (104) 78 | 70 (112) 84 | 75 (120) 90 | 80 (128) 96 | 85 (136) 102 | 90 (144) 108 |
| Brake line & cables | | I | | I | | I | | I | | I |
| Brake pads, rotors (1) | | I | | I | | I | | I | | I |
| Brake fluid (1) | | | | R | | | | R | | |
| CVT fluid | NOTE (2) | I | | I | | I | | I | | I |
| Transfer oil&differential gear oil | NOTE (3) | I | | I | | I | | I | | I |
| Steering gear and linkage, axle and suspension parts (1) | | | | I | | | | I | | |
| Tire rotation | NOTE (4) | | | | | | | | | |
| Propeller shaft (AWD)&drive shaft boots (1) | | I | | I | | I | | I | | I |
| Exhaust system (1) | | | | I | | | | I | | |
| In-cabin microfilter | | | | R | | | R | | | R |
| (1) Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (2) Use only Genuine NISSAN CVT fluid. If towing a trailer, using a camper or a car-top carrier, of driving on rough or muddy roads, inspect CVT fluid deterioration at an NISSAN dealer every 60, 000 miles (96, 000 km), then change CVT fluid if necessary. And if the inspection is not performed, change (not just inspect) CVT fluid every 60, 000 miles (96, 000 km). (3) If tower a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. (4) Refer to " TIRE ROTATION " under "GENERAL MAINTENANCE" heading earlier in this article. |
| (1) | Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". |
| (2) | Use only Genuine NISSAN CVT fluid. If towing a trailer, using a camper or a car-top carrier, of driving on rough or muddy roads, inspect CVT fluid deterioration at an NISSAN dealer every 60, 000 miles (96, 000 km), then change CVT fluid if necessary. And if the inspection is not performed, change (not just inspect) CVT fluid every 60, 000 miles (96, 000 km). |
| (3) | If tower a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. |
| (4) | Refer to " TIRE ROTATION " under "GENERAL MAINTENANCE" heading earlier in this article. |
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
|---|
| Perform either at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 95 (152) 114 | 100 (160) 120 | 105 (168) 126 | 110 (176) 132 | 115 (184) 138 | 120 (192) 90 | Reference |
| Brake line & cables | | | I | | I | | I | BRAKE LINES AND CABLES |
| Brake pads, rotors&other brake components (1) | | | I | | I | | I | FRONT BRAKE REAR BRAKE |
| Brake fluid (1) | | | R | | | | R | BRAKE FLUID |
| CVT fluid | NOTE (2) | | I | | I | | I | CVT FLUID |
| Transfer oil & differential gear oil | NOTE (3) | | I | | I | | I | TRANSFER OIL |
| Steering gear and linkage, axle and suspension parts (1) | | | I | | | | I | STEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS |
| Tire rotation | NOTE (4) | | | | | | | REAR DIFFERENTIAL GEAR OIL: DRAINING |
| Propeller shaft (AWD)&drive shaft boots (1) | | | I | | I | | I | PERIODIC MAINTENANCE DRIVE SHAFT |
| Exhaust system (1) | | | I | | | | I | EXHAUST SYSTEM |
| In-cabin microfilter | | | | R | | | R | PERIODIC MAINTENANCE |
| (1) Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (2) Use only Genuine NISSAN CVT fluid. If towing a trailer, using a camper or a car-top carrier, of driving on rough or muddy roads, inspect CVT fluid deterioration at an NISSAN dealer every 60, 000 miles (96, 000 km), then change CVT fluid if necessary. And if the inspection is not performed, change (not just inspect) CVT fluid every 60, 000 miles (96, 000 km). (3) If tower a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. (4) Refer to " TIRE ROTATION " under "GENERAL MAINTENANCE" heading earlier in this article. |
| (1) | Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". |
| (2) | Use only Genuine NISSAN CVT fluid. If towing a trailer, using a camper or a car-top carrier, of driving on rough or muddy roads, inspect CVT fluid deterioration at an NISSAN dealer every 60, 000 miles (96, 000 km), then change CVT fluid if necessary. And if the inspection is not performed, change (not just inspect) CVT fluid every 60, 000 miles (96, 000 km). |
| (3) | If tower a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. |
| (4) | Refer to " TIRE ROTATION " under "GENERAL MAINTENANCE" heading earlier in this article. |
The maintenance intervals shown on the preceding articles are for normal operating conditions. If the vehicle is mainly operated under severe driving conditions as shown below, more frequent maintenance must be performed on the following items as shown in the table.
Severe driving conditions
- Repeated short trips of less than 5 miles (8 km).
- Repeated short trips of less than 10 miles (16 km) with outside temperatures remaining below freezing.
- Operating in hot weather in stop-and-go "rush hour" traffic.
- Extensive idling and/or low speed driving for long distances, such as police, taxi or door-to-door delivery use.
- Driving in dusty conditions.
- Driving on rough, muddy, or salt spread roads.
- Towing a trailer, using a camper or a car-top carrier
Maintenance operation: Check = Check and correct or replace as necessary.
| Maintenance item | Maintenance operation | Maintenance interval | Reference |
|---|
| Brake fluid | Replace | Every 10, 000 miles (16, 000 km) or 12 months | BRAKE FLUID |
| Brake pads, rotors | Inspect | Every 5, 000 miles (8, 000 km) or 6 months | FRONT DISC BRAKE FRONT DISC BRAKE REAR DISC BRAKE REAR DISC BRAKE |
| Steering gear&linkage, axle&suspension parts | Inspect | Every 5, 000 miles (8, 000 km) or 6 months | STEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS |
| Propeller shaft (AWD)&drive shaft boots | Inspect | Every 5, 000 miles (8, 000 km) or 6 months | REAR PROPELLER SHAFT AXLE AND SUSPENSION PARTS |
| Exhaust system | Inspect | Every 5, 000 miles (8, 000 km) or 6 months | EXHAUST SYSTEM |
Engine Oil Recommendation
NISSAN recommends the use of an resource conserving oil in order to improve fuel economy.
Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubricant Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard. These oils have the API certification mark on the front of the container. Oils which do not have the specified quality label should not be used as they could cause engine damage.
Scheme 45
Scheme 45: Engine Oil Recommendation
Anti-Freeze Coolant Mixture Ratio
The engine cooling system is filled at the factory with a pre-diluted mixture of 50% Genuine NISSAN Long Life Antifreeze/Coolant (blue) and 50% water to provide year-round anti-freeze and coolant protection. The antifreeze solution contains rust and corrosion inhibitors. Additional engine cooling system additives are not necessary.
| WARNING | Do not remove the radiator cap when the engine is hot. Serious burns could occur from high pressure engine coolant escaping from the radiator. Wrap a thick cloth around the cap. Slowly turn it a quarter turn to allow built-up pressure to escape. Carefully remove the cap by turning it all the way. The radiator is equipped with a pressure type radiator cap. To prevent engine damage, use only a genuine NISSAN radiator cap. |
| CAUTION | When adding or replacing coolant, be sure to use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent. Genuine NISSAN Long Life Antifreeze/Coolant (blue) is pre-diluted to provide antifreeze protection to -34°F (-37°C). If additional freeze protection is needed due to weather where you operate your vehicle, add Genuine NISSAN Long Life Antifreeze/Coolant (blue) concentrate following the directions on the container. If an equivalent coolant other than Genuine NISSAN Long Life Antifreeze/Coolant (blue) is used, follow the coolant manufactur's instructions to maintain minimum antifreeze protection to -34°F (-37°C). The use of other types of coolant solutions other than Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent may damage the engine cooling system. Mixing any other type of coolant other than Genuine NISSAN Long Life Antifreeze/Coolant (blue), including Genuine NISSAN Long Life Antifreeze/Coolant (green), or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. |
Scheme 46
Scheme 46: DRIVE BELTS: Exploded View
DRIVE BELTS: Checking
| WARNING | Inspect the drive belt only when the engine is stopped. |
- Visually check entire drive belt for wear, damage or cracks.
- Check that the drive belt auto-tensioner indicator is within the possible use range. NOTE: When new drive belt is installed, the drive belt auto-tensioner indicator should be within the new drive belt range. Check the drive belt auto-tensioner indicator when the engine is cold.
- If the drive belt auto-tensioner indicator is out of the possible use range or belt is damaged, replace drive belt.
CHANGING THE AIR CLEANER FILTER
- Remove air duct assembly from air cleaner case (upper).
- Open the air cleaner case.
- Remove the air cleaner filter.
- Install a new air cleaner filter.
- Close the air cleaner case.
- Secure the air cleaner case clips.
ENGINE OIL LEVEL
Note. Before starting engine, put vehicle horizontally and check the engine oil level. If engine is already started, stop it and allow 5 minutes before checking.
- Pull out oil level gauge and wipe it clean.
- Insert oil level gauge and check the engine oil level is within the range (A) as shown below.
- If it is out of range, adjust it.
Scheme 47
ENGINE OIL APPEARANCE
- Check engine oil for white milky appearance or excessive contamination.
- If engine oil becomes turbid and white, it is highly probable that it is contaminated with engine coolant. Repair or replace damaged parts.
ENGINE OIL LEAKS
Check for engine oil leaks around the following areas
- Oil temperature sensor
- Oil level sensor
- Oil level gauge assembly O-ring.
- Crankshaft position sensor
- Camshaft position sensors
- Oil cooler
- Oil pan (upper and lower)
- Oil pan drain plug
- Oil pressure switch
- Oil filter
- Intake valve timing intermediate lock control solenoid valve
- Intake valve timing control solenoid valve
- Exhaust valve timing control solenoid valve
- Front cover
- Mating surface between cylinder head and camshaft bracket
- Mating surface between cylinder block and cylinder head
- Mating surface between cylinder head and rocker cover
- Crankshaft oil seals (front and rear)
OIL PRESSURE CHECK
| WARNING | Be careful not to get burn yourself, as engine oil may be hot. When checking engine oil pressure, CVT shift lever should be in "P" position. Be sure to apply parking brake. |
Scheme 48
- Check the engine oil level.
- Remove fender protector side cover (RH). Refer to " «FENDER PROTECTOR: EXPLODED VIEW»(ref-616717-S39205674252014051900000) ".
- Disconnect harness connector at oil pressure switch and remove oil pressure switch using suitable tool. CAUTION: Never drop or shock oil pressure switch.
- Install suitable tools (A/B).
- Start the engine and warm it up to normal operating temperature.
- Check the engine oil pressure with engine running under no-load. NOTE: When engine oil temperature is low, engine oil pressure becomes high. If difference is extreme, check oil passage and oil pump for engine oil leaks. Engine oil pressure: Refer to " «OIL PRESSURE»(ref-616722-S21372597632014051900000) ".
- After the inspections, install oil pressure switch as follows: Remove old liquid gasket on oil pressure switch and engine. Apply liquid gasket and tighten oil pressure switch to the specification. Use Genuine RTV Silicone Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-616709-S30035767112014051900000) ". Tightening torque: Refer to " «EXPLODED VIEW»(ref-616715-S37969382852014051900000) ".
- Check engine oil level.
- After warming up engine, check that there are no engine oil leaks with the engine running.
- Install fender protector side cover (RH). Refer to " «FENDER PROTECTOR: EXPLODED VIEW»(ref-616717-S39205674252014051900000) ".
TRANSFER OIL LEAKS
Check that transfer oil is not leaking from transfer assembly or around it.
TRANSFER OIL LEVEL
| CAUTION | Do not start engine while checking transfer oil level. |
Scheme 49
- Remove filler plug (1) and gasket.
- Transfer oil level (A) should be level with bottom of filler plug hole. Add transfer oil if necessary. Refer to " «FLUIDS AND LUBRICANTS»(ref-616719-S07077924722014051900000) ".
- Set a new gasket onto filler plug, and install it in the transfer and tighten to specified torque. Refer to " «EXPLODED VIEW»(ref-616726-S27721185422014051900000) ". CAUTION: Do not reuse gasket.
OIL LEAKS
Make sure that oil is not leaking from final drive assembly or around it.
Scheme 50
- Remove filler plug (1) and check oil level from filler plug mounting hole as shown below. CAUTION: Do not start engine while checking oil level.
- Set a new gasket on filler plug and install it on final drive assembly. Refer to " «EXPLODED VIEW»(ref-616754-S06538377522014051900000) ". CAUTION: Do not reuse gasket.
Scheme 51
Scheme 51: REAR DIFFERENTIAL GEAR OIL: Draining
- Stop engine.
- Remove drain plug (1) and drain gear oil.
- Set a new gasket on drain plug and install it to final drive assembly and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-616754-S06538377522014051900000) ". CAUTION: Do not reuse gasket.
BALANCING WHEELS (ADHESIVE WEIGHT TYPE)
Preparation Before Adjustment
Remove inner and outer balance weights from the wheel. Using releasing agent, remove double-faced adhesive tape from the wheel and tire.
| CAUTION | Be careful not to scratch the wheel and tire during removal. After removing double-faced adhesive tape, wipe clean all traces of releasing agent from the wheel and tire. |
| CAUTION | DO NOT use center hole cone-type clamping machines to hold the wheel during tire removal/installation or balancing or damage to the wheel paint, cladding or chrome may result. Use only rim-type or universal lug-type clamping machines to hold the wheel during servicing. |
Scheme 52
Scheme 53
Scheme 54
- If a balancer machine has an adhesive weight mode setting, select the adhesive weight mode setting and skip Step 2 below. If a balancer machine only has the clip-on (rim flange) weight mode setting, follow Step 2 to calculate the correct size adhesive weight. Set wheel and tire on balancer machine using the center hole as a guide. Start the balancer machine. For balancer machines that only have a clip-on (rim flange) weight mode setting, follow this step to calculate the correct size adhesive weight to use. When inner and outer imbalance values are shown on the balancer machine indicator, multiply outer imbalance value by 5/3 (1.67) to determine balance weight that should be used. Select the outer balance weight with a value closest to the calculated value above and install in to the designated outer position of or at the designated angle in relation to the wheel and tire. Indicated imbalance value x 5/3 (1.67) = balance weight to be installed Calculation example: 23 g (0.81 oz) x 5/3 (1.67) = 38.33 g (1.35 oz) --> 40 g (1.41 oz) balance weight (closer to calculated balance weight value) NOTE: Note that balance weight value must be closer to the calculated balance weight value. Example: 37.4 --> 35 g (1.23 oz) 37.5 --> 40 g (1.41 oz) Install balance weight in the position shown below. CAUTION: Do not install the inner balance weight before installing the outer balance weight. Before installing the balance weight, be sure to clean the mating surface of the wheel and tire. When installing balance weight (1) to wheel and tire, set it into the grooved area (A) on the inner wall of the wheel and tire as shown below so that the balance weight center (B) is aligned with the balancer machine indication position (angle) (C). CAUTION: Always use Genuine NISSAN adhesive balance weights. Balance weights are non-reusable; always replace with new ones. Do not install more than three sheets of balance weights. If calculated balance weight value exceeds 50 g (1.76 oz), install two balance weight sheets in line with each other as shown below. CAUTION: Do not install one balance weight sheet on top of another. Start balancer machine again. Install balance weight on inner side of wheel and tire in the balancer machine indication position (angle). CAUTION: Do not install more than two balance weights. Start balancer machine. Make sure that inner and outer residual imbalance values are 5 g (0.17 oz) each or below. If either residual imbalance value exceeds 5 g (0.17 oz), repeat installation procedures. Wheel balance Dynamic (At flange) Static (At flange) Maximum allowable imbalance Refer to " «WHEEL»(ref-616718-S10741828032014051900000) ".
TIRE ROTATION
- Follow the maintenance schedule for tire rotation service intervals. Refer to " «INTRODUCTION OF PERIODIC MAINTENANCE»(ref-616719-S28866073532014051900000) ".
- Rotate the wheels and tires front to back in the pattern as shown below.
- When installing the wheel, tighten wheel nuts to the specified torque. " «INTRODUCTION OF PERIODIC MAINTENANCE»(ref-616719-S28866073532014051900000) "
Scheme 55
| WARNING | Do not include the spare tire (if equipped) when rotating tires. After rotating tires, check and adjust the tire pressure. |
| CAUTION | When installing wheel nuts, tighten them diagonally by dividing the work two to three times in order to prevent the wheels from developing any distortion. Be careful not to tighten the wheel nuts to a torque exceeding specification to prevent strain on the disc brake rotor. Use Genuine NISSAN wheel nuts. |
Wheel nut tightening torque: " WHEEL "
- Perform the ID registration after tire rotation. Refer to " «WORK PROCEDURE»(ref-616718-S31120210352014051900000) ".
APPEARANCE
Check surface of disc brake rotor for uneven wear, cracks or damage. Replace if any abnormal conditions exist.
RUNOUT
- Check the wheel bearing axial end play before the inspection. Refer to " «INSPECTION»(ref-616723-S37012231752014051900000) "(FWD) or " «INSPECTION»(ref-616731-S20838574372014051900000) " (AWD).
- Secure the disc brake rotor to the wheel hub and bearing with wheel nuts at two wheel nut locations.
- Inspect the runout with a dial gauge, measured at 10 mm (0.39 in) inside the disc brake rotor edge. Runout: Refer to " «FRONT DISC BRAKE»(ref-616742-S37706174292014051900000) ".
- Find the installation position with a minimum runout by shifting the disc brake rotor-to-wheel hub and bearing installation position by one hole at a time if the runout exceeds the limit value.
- Refinish the disc brake rotor if the runout is outside the limit even after performing the above operation. When refinishing, use Tool.
Scheme 56
| CAUTION | Check in advance that the thickness of the disc brake rotor is wear thickness + 0.3 mm (0.012 in) or more. If the thickness is less than wear thickness + 0.3 mm (0.012 in), replace the disc brake rotor. |
Wear thickness: Refer to " FRONT DISC BRAKE ".
THICKNESS
Check the thickness of the disc brake rotor using a micrometer. Replace the disc brake rotor if the thickness is below the wear limit.
Wear thickness: Refer to " FRONT DISC BRAKE ".
Thickness variation: Refer to " FRONT DISC BRAKE ".
Scheme 57
STEERING GEAR
- Check gear housing and boots for looseness, damage and grease leakage.
- Check connection with steering column for looseness.
Scheme 58
STEERING LINKAGE
Check ball joint, dust cover and other component parts for looseness, wear, damage and grease leakage.
WITH INTELLIGENT KEY SYSTEM
For hood and hood lock illustration.
- Hood: Refer to " «EXPLODED VIEW»(ref-616728-S09833185712014051900000) ".
- Hood lock control: Refer to " «EXPLODED VIEW»(ref-616728-S09833185712014051900000) ".
For front door and front door lock illustration.
- Front door: Refer to " «EXPLODED VIEW»(ref-616728-S14933220132014051900000) ".
- Front door lock: Refer to " «EXPLODED VIEW»(ref-616728-S35776511962014051900000) ".
- Rear door: Refer to " «EXPLODED VIEW»(ref-616728-S24221767242014051900000) ".
- Rear door lock: Refer to " «EXPLODED VIEW»(ref-616728-S13251421472014051900000) ".
For back door and back door lock illustration.
- Back door: Refer to " «EXPLODED VIEW»(ref-616728-S08125964532014051900000) ".
- Back door lock: Refer to " «EXPLODED VIEW»(ref-616728-S21821830112014051900000) ".
WITHOUT INTELLIGENT KEY SYSTEM
For hood and hood lock illustration.
- Hood: Refer to " «EXPLODED VIEW»(ref-616773-S10118068262014051900000) ".
- Hood lock control: Refer to " «EXPLODED VIEW»(ref-616773-S34239516382014051900000) ".
For front door and front door lock illustration.
- Front door: Refer to " «EXPLODED VIEW»(ref-616773-S01197234542014051900000) ".
- Front door lock: Refer to " «EXPLODED VIEW»(ref-616773-S06910985732014051900000) ".
- Rear door: Refer to " «EXPLODED VIEW»(ref-616773-S33694986502014051900000) ".
- Rear door lock: Refer to " «EXPLODED VIEW»(ref-616773-S06910985732014051900000) ".
For back door and back door lock illustration.
- Back door: Refer to " «EXPLODED VIEW»(ref-616773-S22234938342014051900000) ".
- Back door lock: Refer to " «EXPLODED VIEW»(ref-616773-S37223810022014051900000) ".
