Mirrors (Without Adp): Overhaul Nissan Quest IV

DOOR MIRROR ASSEMBLY: Disassembly and Assembly

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

1. Remove door mirror assembly from the door panel. Refer to " «DOOR MIRROR ASSEMBLY: REMOVAL AND INSTALLATION»(ref-672675-S31444872282014112400000) ".
2. Remove glass mirror. Refer to " «GLASS MIRROR: REMOVAL AND INSTALLATION»(ref-672675-S18989015382014112400000) ".
3. Remove door mirror cover. Refer to " «DOOR MIRROR COVER: REMOVAL AND INSTALLATION»(ref-672675-S12676375722014112400000) ".
4. Remove door mirror actuator (1). Remove the mounting screws (A). Disconnect the harness connectors behind the actuator.
5. Remove around view camera finisher assembly (1). (with around view camera) Remove around view camera finisher mounting screw (A). Disconnect harness connector (B) and remove mounting screws (C). Disengage around view camera finisher assembly (1) fixing pawls and remove it from door mirror housing.
6. Remove around view camera mounting screws and then remove it from around view camera finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-672660-S15657782322014112400000) ".
7. Remove door mirror under cover (1). (with side turn signal lamp) Remove door mirror under cover mounting screw (A). Remove door mirror under cover mounting screws (A) and disengage the fixing pawl. Remove door mirror side turn signal lamp mounting screws (A) and remove side turn signal lamp.
8. Remove door mirror under cover (1). (without side turn signal lamp) Remove door mirror under cover mounting screw (A). Remove door mirror under cover mounting screws (A) and disengage the fixing pawl.
9. Remove the mounting bolts (A) and remove door mirror base from door mirror housing.
10. Remove power fold unit. Remove power fold unit assembly fixing screws (A). Remove power fold unit assembly from door mirror housing according to the numerical order shown in the figure below.
11. Remove the mounting bolts (A) and (B), and then remove actuator bracket (1) from power fold unit (2).

ASSEMBLY

Assemble in the reverse order of disassemble.

Scheme 65

Scheme 66

1. Place the glass mirror upward.
2. As shown in the figure, insert a flat-bladed screwdriver (A) into the recess between glass mirror (1) and actuator. Push up both pawls simultaneously to remove glass mirror lower half side. NOTE: Insert the screwdriver between the fixing pawls. Insert screwdriver into recesses, and push up while rotating (twisting) to make work easier. CAUTION: Put a strip of protective tape (B) on housing assembly.
3. Lift up and slide glass mirror as shown by the arrows in the figure to disengage the fixing pawls.
4. Remove BSW indicator harness connector (A). (if equipped)
5. Remove both terminals of mirror heater attachment (B). (if equipped)
6. Lightly lift up lower side of glass mirror, and detach both pawls of upper side as if pulling it out. Remove glass mirror from actuator. NOTE: Be certain not to allow grease on sealing agent in center of mirror or back side of glass mirror.
