Mirrors (With Adp): Removal & Installation Nissan Quest IV

Mirrors 9 illustrations ~337 words

INSTALLATION

Install in the reverse order of removal.

CAUTIONWhen inserting the inside mirror into the mirror base, be sure to push the pawl until it get connected to the mirror base (manual anti-dazzling type only).

Scheme 3

Scheme 3: Exploded View
Scheme 3: Exploded View

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

DOOR MIRROR ASSEMBLY: Removal and Installation

CAUTIONWhen removing, always use a remover tool that is made of plastic. Be careful not to scratch or damage door mirror body when removing. Always replace door mirror corner cover after every disassembly.

Scheme 6

Scheme 6: REMOVAL
Scheme 6: REMOVAL

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Remove front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-672656-S07016970752014112400000) ".
  2. Remove front door module assembly mounting bolts, pull out the front door module assembly to make space in order to disengage the harness connector.
  3. Remove harness connector (A).
  4. Remove front door speaker and then, from the hole of front door speaker disconnect the harness connectors.
  5. Peel off front door weather-strip (1), and then remove door mirror mounting nuts (B).
  6. Remove door mirror corner cover. Disengage the door mirror corner cover fixing pawls with remover tool (A). (front door side) CAUTION: Apply protective tape (B) on the part to protect it from damage. Disengage the door mirror corner cover fixing pawls with remover tool (A). (front fender side) CAUTION: Apply protective tape (B) on the part to protect it from damage.
  7. Remove door mirror mounting bolt.
  8. Remove door mirror assembly from door panel.
  1. Insert door mirror harness connector through the door outer panel hole.
  2. Install door mirror assembly into the door panel and tighten the mounting bolt and nuts.
  3. Install the door mirror harness fixing clips to the door panel from the hole of door speaker.
  4. Install front door finisher.

Install in the reverse order of disassemble.

CAUTIONAfter installation, visually check that pawls are securely engaged.

DOOR MIRROR COVER: Removal and Installation

CAUTIONWhen removing, always use a remover tool that is made of plastic.

Scheme 9

Scheme 9: REMOVAL
Scheme 9: REMOVAL

Scheme 10

Scheme 10
Scheme 10
  1. Remove the glass mirror. Refer to " «GLASS MIRROR: REMOVAL AND INSTALLATION»(ref-672670-S00737924702014112400000) ".
  2. With a remover tool, disengage the fixing pawls (A).
  3. Insert a remover tool between door mirror cover and mirror housing to disengage the fixing pawls, and then remove the door mirror cover from the door mirror assembly.

Install in the reverse order of disassemble.

CAUTIONAfter installation, visually check that pawls are securely engaged.

Scheme 11

Scheme 11: REMOVAL
Scheme 11: REMOVAL
  1. Remove the power window main switch finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-672656-S07016970752014112400000) ".
  2. Remove door mirror remote control switch (1) from power window main switch finisher (2) using remover tool (A).

Install in the reverse order of removal.
