Mirrors (Without Adp): Other Nissan Quest IV

Mirrors 12 illustrations ~349 words

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE- TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. Information necessary to service the system safely is included in the " SRS AIRBAG " and " SEAT BELTS " articles of this Service Information.

WARNINGAlways observe the following items to prevent accidental activation. To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision that would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see " SRS AIRBAG ". Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. The vehicle may be equipped with a passenger air bag deactivation switch which can be operated by the customer. When the passenger air bag is switched OFF, the passenger air bag is disabled and will not inflate. When the passenger air bag is switched ON, the passenger air bag is enabled and could inflate for certain types of collision. After SRS maintenance or repair, make sure the passenger air bag deactivation switch is in the same position (ON or OFF) as when the vehicle arrived for service.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNINGAlways observe the following items for preventing accidental activation. When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service.

Scheme 67

Scheme 67: Precautions for Removing Battery Terminal
  1. When removing the 12V battery terminal, turn OFF the ignition switch and wait at least 30 seconds. NOTE: ECU may be active for several tens of seconds after the ignition switch is turned OFF. If the battery terminal is removed before ECU stops, then a DTC detection error or ECU data corruption may occur.
  2. For vehicles with the 2-batteries, be sure to connect the main battery and the sub battery before turning ON the ignition switch. NOTE: If the ignition switch is turned ON with any one of the terminals of main battery and sub battery disconnected, then DTC may be detected.
  3. After installing the 12V battery, always check "Self Diagnosis Result" of all ECUs and erase DTC. NOTE: The removal of 12V battery may cause a DTC detection error.

Special Service Tools

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Tool number (Kent-Moore No.) Tool name Description (J-39570) Chassis ear Locates the noise (J-50397) NISSAN Squeak and Rattle Kit Repairs the cause of noise

Scheme 68

Scheme 68: Special Service Tools

Scheme 69

Scheme 69

Commercial Service Tools

Tool name Description Remover tool Remove the clip, pawl and metal clip

Scheme 70

Scheme 70: Commercial Service Tools

Scheme 71

Scheme 71: Wiring Diagram

Scheme 72

Scheme 72: Connector End View

Scheme 73

Scheme 73

Scheme 74

Scheme 74: Wiring Diagram

Scheme 75

Scheme 75: Connector End View

Scheme 76

Scheme 76: Exploded View

Scheme 77

Scheme 77

Scheme 78

Scheme 78: Manual anti-dazzling type
  1. Insert a flat-bladed screwdriver (A) under the inside mirror (1).
  2. Slide the inside mirror to the upper side while pushing the pawl downward.
CAUTIONNever reuse the inside mirror disassembled from inside mirror base. Never use excessive force to remove the inside mirror because it is inserted tightly into the mirror base. Wrap the flat-bladed screwdriver with a shop cloth to avoid damage on the windshield glass.

Auto anti-dazzling type

  1. Remove inside mirror cover.
  2. Disconnect harness connector from inside mirror.
  3. Loosen TORX bolt and slide inside mirror upward to remove.
