INSTALLATION
Note the following, and install in the reverse order of removal.
Align the cut outs of inner socket, ring and instrument lower cover center.
Scheme 130
Scheme 131
Scheme 132
- Remove clips on the rear side of the luggage side lower finisher (LH) to obtain space for work. Refer to " «LUGGAGE SIDE LOWER FINISHER: REMOVAL AND INSTALLATION»(ref-672656-S36994415002014112400000) ".
- Disconnect power socket connector.
- Pull out inner socket (1) by pushing the pawl (B) of the ring (2) from the inner socket hole (square) (A).
- Press the ring pawl from the back of the luggage side lower finisher (LH) to remove the ring.
Note the following, and install in the reverse order of removal. Align the cut outs of inner socket, ring and luggage side lower finisher (LH).
Scheme 133
| Rated voltage | DC 12 V |
|---|---|
| Maximum electric capacity | 120 W or less (Total) |
| Maximum current | 10 A or less (Total) |
