Power Supply, Ground & Circuit Elements: Removal & Installation Nissan Quest IV

How To Remove Extended Storage Fuse Switch

Type A

Scheme 1

1. Turn the ignition switch OFF.
2. Turn the extended storage fuse switch OFF.
3. Press pawl (A) and tilt to disengage the extended storage fuse switch. Press pawl (B) and tilt to remove the extended storage fuse switch. NOTE: Extended storage fuse switch and fuse are removed together. Remove fuse from extended storage fuse switch, if necessary. Extended storage fuse switch is for transportation and storage. Reinstallation is not required after the removal.

Type B

Scheme 2

1. Turn the ignition switch OFF.
2. Turn the extended storage fuse switch OFF.
3. Hold (A) and pull up the extended storage fuse switch hard in (B) direction. NOTE: Extended storage fuse switch and fuse may be removed together. Remove fuse from extended storage fuse switch, if necessary. Extended storage fuse switch is for transportation and storage. Reinstallation is not required after the removal.

Type C

Scheme 3

1. Turn the ignition switch OFF.
2. Turn the extended storage fuse switch OFF.
3. Hold (A) and pull up the extended storage fuse switch hard in (B) direction. NOTE: Extended storage fuse switch and fuse are removed together. Remove fuse from extended storage fuse switch, if necessary. Extended storage fuse switch is for transportation and storage. Reinstallation is not required after the removal.

REMOVAL

1. Remove air duct (inlet). Refer to " «REMOVAL AND INSTALLATION»(ref-672620-S13912561332014112400000) ".
2. Disconnect the battery cable from the negative terminal. CAUTION: To prevent damage to the parts, disconnect the battery cable from the negative terminal first.
3. Remove the nut and bolt and remove the ECM bracket from the battery fix frame.
4. Remove cover of battery positive terminal.
5. Disconnect the battery cable from the positive terminal.
6. Remove battery fix frame mounting nuts and battery fix frame.
7. Remove battery.

INSTALLATION

Install in the reverse order of removal.

Reset electronic systems as necessary. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: REQUIRED PROCEDURE AFTER BATTERY DISCONNECTION ".

Scheme 4

1. Disconnect the battery cable from the negative terminal. Refer to " «EXPLODED VIEW»(ref-672612-S30530544732014112400000) ". CAUTION: To prevent damage to the parts, disconnect the battery cable from the negative terminal first.
2. Remove cover of battery positive terminal.
3. Disconnect the battery cable from the positive terminal. Refer to " «EXPLODED VIEW»(ref-672612-S30530544732014112400000) ".
4. Remove harness mounting nut and battery terminal with fusible link mounting nut.
5. Disconnect harness connector and remove battery terminal with fusible link.

Install in the reverse order of removal.

Scheme 5

1. Disconnect the battery cable from the negative terminal. Refer to " «EXPLODED VIEW»(ref-672612-S30530544732014112400000) ".
2. Disconnect the battery current sensor connector.
3. Remove the battery current sensor mounting nut.
4. Remove the battery current sensor from battery cable.

Install in the reverse order of removal.
