Scheme 34
OUTLINE
FRONT WIPER CONTROL (BASIC)
- BCM detects the combination switch position by the combination switch reading function.
- BCM transmits the front wiper request signal to the IPDM E/R using CAN communication.
- IPDM E/R controls the integrated front wiper relay and front wiper high relay based on the status of the front wiper request signal.
- IPDM E/R provides power to operate the front wiper motor.
The rear wiper is controlled by each function of BCM.
Control by BCM
- Combination switch reading function
- Rear wiper control function
Rear wiper ON operating condition
- Ignition switch ON
- Rear wiper switch ON
DATA MONITOR
| Monitor Item [Unit] | Description |
|---|---|
| PUSH SW [On/Off] | Indicates condition of push-button ignition switch. |
| VEH SPEED 1 [km/h] | Indicates vehicle speed signal received from ABS on CAN communication line. |
| FR WIPER HI [On/Off] | Indicates condition of wiper operation of combination switch. |
| FR WIPER LOW [On/Off] | |
| FR WASHER SW [On/Off] | |
| FR WIPER INT [On/Off] | |
| FR WIPER STOP [On/Off] | Indicates front wiper auto stop signal received from IPDM E/R on CAN communication line. |
| INT VOLUME [1 - 7] | Indicates condition of intermittent wiper operation of combination switch. |
| RR WIPER ON [On/Off] | Indicates condition of rear wiper operation of combination switch. |
| RR WIPER INT [On/Off] | |
| RR WASHER SW [On/Off] | |
| RR WIPER STOP [On/Off] | Indicates rear wiper motor auto stop input from rear wiper motor. |
WORK SUPPORT
| Support Item | Setting | Description |
|---|---|---|
| WIPER SPEED SETTING | On | Front wiper intermittent time linked with vehicle speed and wiper dial position. |
| Off (1) | Front wiper intermittent time linked with wiper dial position. | |
| (1) Initial setting | ||
| (1) | Initial setting |
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [On/Off] | Indicates condition of ignition switch ON position. |
| IGN SW CAN [On/Off] | Indicates ignition switch ON signal received from IPDM E/R on CAN communication line. |
| FR WIPER HI [On/Off] | Indicates condition of wiper operation of combination switch. |
| FR WIPER LOW [On/Off] | |
| FR WIPER INT [On/Off] | |
| FR WASHER SW [On/Off] | |
| FR WIPER STOP [On/Off] | Indicates front wiper auto stop signal received from IPDM E/R on CAN communication line. |
| INT VOLUME [1 - 7] | Indicates condition of intermittent wiper operation of combination switch. |
| RR WIPER ON [On/Off] | Indicates condition of rear wiper operation of combination switch. |
| RR WIPER INT [On/Off] | |
| RR WASHER SW [On/Off] | |
| RR WIPER STOP [On/Off] | Indicates rear wiper motor auto stop input from rear wiper motor. |
| REVERSE SW CAN [On/Off] | Indicates reverse switch signal received from TCM on CAN communication line. |
| VEHICLE SPEED [km/h/mph] | Indicates vehicle speed signal received from combination meter on CAN communication line. |
| Support Item | Setting | Description |
|---|---|---|
| WIPER SPEED SETTING | On | Front wiper intermittent time linked with vehicle speed and wiper dial position. |
| Off (1) | Front wiper intermittent time linked with wiper dial position. | |
| (1) Initial setting | ||
| (1) | Initial setting |
| Monitor Item [Unit] | Main Signals | Description |
|---|---|---|
| MOTOR FAN REQ [1/2/3/4] | X | Indicates cooling fan speed signal received from ECM on CAN communication line |
| AC COMP REQ [On/Off] | X | Indicates A/C compressor request signal received from ECM on CAN communication line |
| TAIL & CLR REQ [On/Off] | X | Indicates position light request signal received from BCM on CAN communication line |
| HL LO REQ [On/Off] | X | Indicates low beam request signal received from BCM on CAN communication line |
| HL HI REQ [On/Off] | X | Indicates high beam request signal received from BCM on CAN communication line |
| FR FOG REQ [On/Off] | X | Indicates front fog light request signal received from BCM on CAN communication line |
| FR WIP REQ [Stop/1LOW/Low/Hi] | X | Indicates front wiper request signal received from BCM on CAN communication line |
| WIP AUTO STOP [STOP P/ACT P] | X | Indicates condition of front wiper auto stop signal |
| WIP PROT [Off/BLOCK] | X | Indicates condition of front wiper fail-safe operation |
| IGN RLY1-REQ [On/Off] | Indicates ignition switch ON signal received from BCM on CAN communication line | |
| IGN RLY [On/Off] | X | Indicates condition of ignition relay |
| PUSH SW [On/Off] | Indicates condition of push-button ignition switch | |
| INTER/NP SW [On/Off] | Indicates condition of CVT shift position | |
| ST RLY CONT [On/Off] | Indicates starter relay status signal received from BCM on CAN communication line | |
| IHBT RLY-REQ [On/Off] | Indicates starter control relay signal received from BCM on CAN communication line | |
| ST/INHI RLY [Off/ST/INHI] | Indicates condition of starter relay and starter control relay | |
| DETENT SW [On/Off] | Indicates condition of CVT shift selector (park position switch) | |
| DTRL REQ [Off] | Indicates daytime light request signal received from BCM on CAN communication line | |
| THFT HRN REQ [On/Off] | Indicates theft warning horn request signal received from BCM on CAN communication line | |
| HORN CHIRP [On/Off] | Indicates horn reminder signal received from BCM on CAN communication line |
CAN DIAG SUPPORT MNTR
Refer to " CAN DIAGNOSTIC SUPPORT MONITOR ".
| Monitor Item [Unit] | Main Signals | Description |
|---|---|---|
| MOTOR FAN REQ [1/2/3/4] | X | Indicates cooling fan speed signal received from ECM on CAN communication line |
| AC COMP REQ [On/Off] | X | Indicates A/C compressor request signal received from ECM on CAN communication line |
| TAIL & CLR REQ [On/Off] | X | Indicates position light request signal received from BCM on CAN communication line |
| HL LO REQ [On/Off] | X | Indicates low beam request signal received from BCM on CAN communication line |
| HL HI REQ [On/Off] | X | Indicates high beam request signal received from BCM on CAN communication line |
| FR FOG REQ [On/Off] | X | Indicates front fog light request signal received from BCM on CAN communication line |
| FR WIP REQ [Stop/1LOW/Low/Hi] | X | Indicates front wiper request signal received from BCM on CAN communication line |
| WIP AUTO STOP [STOP P/ACT P] | X | Indicates condition of front wiper auto stop signal |
| WIP PROT [Off/BLOCK] | X | Indicates condition of front wiper fail-safe operation |
| IGN RLY1-REQ [On/Off] | Indicates ignition switch ON signal received from BCM on CAN communication line | |
| IGN RLY [On/Off] | X | Indicates condition of ignition relay |
| PUSH SW [On/Off] | Indicates condition of push-button ignition switch | |
| INTER/NP SW [On/Off] | Indicates condition of CVT shift position | |
| ST RLY CONT [On/Off] | Indicates starter relay status signal received from BCM on CAN communication line | |
| IHBT RLY-REQ [On/Off] | Indicates starter control relay signal received from BCM on CAN communication line | |
| ST/INHI RLY [Off/ST/INHI] | Indicates condition of starter relay and starter control relay | |
| DETENT SW [On/Off] | Indicates condition of CVT shift selector (park position switch) | |
| DTRL REQ [Off] | Indicates daytime light request signal received from BCM on CAN communication line | |
| THFT HRN REQ [On/Off] | Indicates theft warning horn request signal received from BCM on CAN communication line | |
| HORN CHIRP [On/Off] | Indicates horn reminder signal received from BCM on CAN communication line |
Refer to " CAN DIAGNOSTIC SUPPORT MONITOR ".
List of ECU Reference
| ECU | Reference |
|---|---|
| BCM (with Intelligent Key) | " REFERENCE VALUE " |
| " FAIL-SAFE " | |
| " DTC INSPECTION PRIORITY CHART " | |
| " DTC INDEX " | |
| BCM (without Intelligent Key) | " REFERENCE VALUE " |
| " FAIL-SAFE " | |
| " DTC INSPECTION PRIORITY CHART " | |
| " DTC INDEX " | |
| IPDM E/R (with Intelligent Key) | " REFERENCE VALUE " |
| " FAIL-SAFE " | |
| " DTC INDEX " | |
| IPDM E/R (without Intelligent Key) | " REFERENCE VALUE " |
| " FAIL-SAFE " | |
| " DTC INDEX " |
Scheme 35
Scheme 36
Scheme 37
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
Scheme 43
Scheme 44
Scheme 45
Scheme 46
DETAILED FLOW
- REVIEW CUSTOMER COMPLAINT Review customer complaint. Try to obtain detailed information about the conditions when the symptom occurs. : GO TO 2
- VERIFY THE SYMPTOM Verify the symptom by performing an operational check. Refer to " «FRONT WIPER AND WASHER SYSTEM: SYSTEM DESCRIPTION»(ref-675631-S42339624162014120500000) ". : GO TO 3
- PERFORM TROUBLE DIAGNOSIS BY SYMPTOM Diagnose the vehicle by performing the appropriate trouble diagnosis. Refer to " «SYMPTOM TABLE»(ref-675631-S30304915102014120500000) ". : GO TO 4
- REPAIR OR REPLACE MALFUNCTIONING PARTS Repair or replace the specific parts. : GO TO 5
- FINAL CHECK Perform a final inspection of the system. Is the inspection result normal? YES: Inspection End. NO: GO TO 2 .
Component Function Check
- CHECK FRONT WIPER LO OPERATION IPDM E/R AUTO ACTIVE TEST Start IPDM E/R auto active test. Refer to " «DIAGNOSIS DESCRIPTION»(ref-675597-S07321007372014120500000) " (with Intelligent Key) or " «DIAGNOSIS DESCRIPTION»(ref-675598-S23603498062014120500000) " (without Intelligent Key). Check that the front wiper operates on LO operation. CONSULT ACTIVE TEST Select FR WIPER of BCM (WIPER) active test item. Check front wiper operation. LO: Front wiper (LO) operation OFF: Front wiper OFF Is the inspection result normal? YES: Front wiper motor LO circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-675631-S42155081502014120500000) ".
- CHECK FRONT WIPER HI OPERATION IPDM E/R AUTO ACTIVE TEST Start IPDM E/R auto active test. Refer to " «DIAGNOSIS DESCRIPTION»(ref-675597-S07321007372014120500000) " (with Intelligent Key) or " «DIAGNOSIS DESCRIPTION»(ref-675598-S23603498062014120500000) " (without Intelligent Key). Check that the front wiper operates on HI operation. CONSULT ACTIVE TEST Select FR WIPER of BCM (WIPER) active test item. Check front wiper operation. HI: Front wiper (HI) operation OFF: Front wiper OFF Is the inspection result normal? YES: Front wiper motor HI circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-675631-S39031789432014120500000) ".
- CHECK FRONT WIPER (AUTO STOP) SIGNAL Select FR WIPER STOP of BCM (WIPER) data monitor item. Operate the front wiper. Check that FR WIPER STOP changes from ON to OFF according to the wiper position. Data monitor Condition Status FR WIPER STOP Front wiper motor Stop position ON Except stop position OFF Is the inspection result normal? YES: Front wiper auto stop signal circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-675631-S28659029872014120500000) ".
- CHECK REAR WIPER ON OPERATION CONSULT ACTIVE TEST Select "RR WIPER" of BCM active test item. While operating the test item, check rear wiper operation. ON: Rear wiper ON operation OFF: Stop the rear wiper. Is rear wiper operation normal? YES: Rear wiper motor circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-675631-S24458190042014120500000) ".
- CHECK REAR WIPER (AUTO STOP) OPERATION CONSULT DATA MONITOR Select WIPER of BCM data monitor item. Operate the rear wiper. Check that RR WIPER STOP changes to ON and OFF linked with the wiper operation. Monitor item Condition Monitor status RR WIPER STOP Rear wiper motor Stop position ON Except stop position OFF Is the inspection result normal? YES: Rear wiper auto stop signal circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-675631-S32424995482014120500000) ".
FRONT WIPER PROTECTION FUNCTION
IPDM E/R detects front wiper stop position by a front wiper stop position signal.
When a front wiper stop position signal is in the conditions listed below, IPDM E/R stops power supply to wiper after repeating a front wiper 10 seconds activation and 20 seconds stop.
| Ignition switch | Front wiper switch | Front wiper stop position signal |
|---|---|---|
| ON | OFF | The front wiper stop position signal (stop position) cannot be input for 10 seconds. |
| ON | The front wiper stop position signal does not change for 10 seconds. |
Note. This operation status can be confirmed on the IPDM E/R "Data Monitor" that displays "BLOCK" for the item "WIP PROT" while the wiper is stopped.
REAR WIPER MOTOR PROTECTION FUNCTION
- BCM may stop rear wiper to protect the rear wiper motor when the rear wiper is stopped for 5 seconds or more due to a snowfall.
- Rear wiper operates normally one minute after the obstacles are removed with rear wiper OFF.
Scheme 47
Scheme 48
Scheme 49
Scheme 50
- Remove front under cover. Refer to " «FRONT UNDER COVER: REMOVAL AND INSTALLATION»(ref-675580-S30708354602014120500000) ".
- Remove fender protector (RH). Refer to " «REMOVAL AND INSTALLATION»(ref-675580-S35121108852014120500000) ".
- Remove washer tank clip (A) using a suitable tool.
- Release the front washer tube (2) and rear washer tube (1) from washer tank (3).
- Release the harness (4) from the washer tank (3).
- Disconnect the harness connector from the front washer motor.
- Remove bolts (A) and washer tank (1).
