Wiper & Washer: Diagnosis Nissan Note E12

Wiper/washer Systems 6 illustrations ~2211 words

ACTIVE TEST

Test ItemDescription
FR WIPERThis test is able to check front wiper operation [INT/Lo/Hi/Off].
RR WIPERThis test is able to check rear wiper operation [On/Off].
Test ItemDescription
FR WIPERThis test is able to check front wiper operation [INT/Lo/Hi/Off].
RR WIPERThis test is able to check rear wiper operation [On/Off].

Inspection in Auto Active Test

When auto active test is actuated, the following operation sequence is repeated 3 times.

Operation sequenceInspection locationOperation
1Front wiperLO for 5 seconds --> HI for 5 seconds
2Parking lamp License plate lamp Tail lamp Front fog lamp10 seconds
3HeadlampLO for 10 seconds --> HI ON <==> OFF 5 times
4A/C compressor (magnet clutch)ON <==> OFF 5 times
5Cooling fanLO for 5 seconds --> MID for 3 seconds --> HI for 2 seconds

Scheme 7

Scheme 7: Concept of Auto Active Test
  1. IPDM E/R starts the auto active test with the door switch signals transmitted by BCM via CAN communication. Therefore, the CAN communication line between IPDM E/R and BCM is considered normal if the auto active test starts successfully.
  2. The auto active test facilitates troubleshooting if any systems controlled by IPDM E/R cannot be operated.

Diagnosis Chart in Auto Active Test

SymptomInspection contentsPossible cause
Any of the following components do not operate Parking lamp License plate lamp Tail lamp Front fog lamp Headlamp (HI, LO) Front wiper (HI, LO)Perform auto active test. Does the applicable system operate?YESBCM signal input circuit
NOLamp or motor Lamp or motor ground circuit Harness or connector between IPDM E/R and applicable system IPDM E/R
A/C compressor does not operatePerform auto active test. Does the magnet clutch operate?YESBCM signal input circuit CAN communication signal between BCM and ECM CAN communication signal between ECM and IPDM E/R
NOMagnet clutch Harness or connector between IPDM E/R and magnet clutch IPDM E/R
Cooling fan does not operatePerform auto active test. Does the cooling fan operate?YESECM signal input circuit CAN communication signal between ECM and IPDM E/R
NOCooling fan motor Harness or connector between IPDM E/R and cooling fan motor IPDM E/R

SELF DIAGNOSTIC RESULT

Refer to " DTC INDEX ".

Test itemDescription
HORNThis test is able to check horn operation [On].
FRONT WIPERThis test is able to check wiper motor operation [Hi/Lo/Off].
MOTOR FANThis test is able to check cooling fan operation [4/3/2/1].
EXTERNAL LAMPSThis test is able to check external lamp operation [Fog/Hi/Lo/TAIL/Off].

When auto active test is actuated, the following operation sequence is repeated 3 times.

Operation sequenceInspection locationOperation
1Front wiperLO for 5 seconds --> HI for 5 seconds
2Parking lamp License plate lamp Tail lamp Front fog lamp10 seconds
3HeadlampLO for 10 seconds -->HI ON <==> OFF 5 times
4A/C compressor (magnet clutch)ON <==> OFF 5 times
5Cooling fanLO for 5 seconds --> MID for 3 seconds --> HI for 2 seconds

Concept of Auto Active Test

  1. IPDM E/R starts the auto active test with the door switch signals transmitted by BCM via CAN communication. Therefore, the CAN communication line between IPDM E/R and BCM is considered normal if the auto active test starts successfully.
  2. The auto active test facilitates troubleshooting if any systems controlled by IPDM E/R cannot be operated.
SymptomInspection contentsPossible cause
Any of the following components do not operate Parking lamp License plate lamp Tail lamp Front fog lamp Headlamp (HI, LO) Front wiper (HI, LO)Perform auto active test. Does the applicable system operate?YESBCM signal input circuit
NOLamp or motor Lamp or motor ground circuit Harness or connector between IPDM E/R and applicable system IPDM E/R
A/C compressor does not operatePerform auto active test. Does the magnet clutch operate?YESBCM signal input circuit CAN communication signal between BCM and ECM CAN communication signal between ECM and IPDM E/R
NOMagnet clutch Harness or connector between IPDM E/R and magnet clutch IPDM E/R
Cooling fan does not operatePerform auto active test. Does the cooling fan operate?YESECM signal input circuit CAN communication signal between ECM and IPDM E/R
NOCooling fan motor Harness or connector between IPDM E/R and cooling fan motor IPDM E/R

Refer to " DTC INDEX ".

Test itemDescription
HORNThis test is able to check horn operation [On].
FRONT WIPERThis test is able to check wiper motor operation [Hi/Lo/Off].
MOTOR FANThis test is able to check cooling fan operation [4/3/2/1].
EXTERNAL LAMPSThis test is able to check external lamp operation [Fog/Hi/Lo/TAIL/Off].

Diagnosis Procedure

  1. CHECK FUSES Check that the following fuses are not blown. Component Capacity Fuse No. Location Front wiper motor 30 A 39 IPDM E/R Front and rear washer motor 10 A 6 Fuse block (J/B) Is the fuse blown? YES: Replace the fuse after repairing the affected circuit. NO: Inspection End.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK FRONT WIPER MOTOR FUSE Turn the ignition switch OFF. Check that the following fuse is not blown. Component Capacity Fuse No. Location Front wiper motor 30 A 39 IPDM E/R Is the fuse blown? YES: Replace the fuse after repairing the affected circuit. NO: GO TO 2.
  2. CHECK FRONT WIPER MOTOR (LO) OUTPUT VOLTAGE Turn the ignition switch ON. Select FR WIPER of BCM (WIPER) active test item. While performing the active test, check voltage between IPDM E/R harness connector and ground. IPDM E/R Ground FRONT WIPER Voltage (Approx.) Connector Terminal E45 17 LO Battery voltage OFF 0V Is the inspection result normal? YES: GO TO 3. NO: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION»(ref-675597-S28632663882014120500000) " (with Intelligent Key) or " «REMOVAL AND INSTALLATION»(ref-675598-S27210814052014120500000) " (without Intelligent Key).
  3. CHECK FRONT WIPER MOTOR (LO) OPEN CIRCUIT Turn the ignition switch OFF. Disconnect IPDM E/R and front wiper motor. Check continuity between IPDM E/R harness connector and front wiper motor harness connector. IPDM E/R Front wiper motor Continuity Connector Terminal Connector Terminal E45 17 E1 3 Yes Is the inspection result normal? YES: Replace front wiper motor. Refer to " «REMOVAL AND INSTALLATION»(ref-675631-S23641355152014120500000) ". NO: Repair or replace harness.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK FRONT WIPER MOTOR FUSE Turn the ignition switch OFF. Check that the following fuse is not blown. Component Capacity Fuse No. Location Front wiper motor 30 A 39 IPDM E/R Is the fuse blown? YES: Replace the fuse after repairing the affected circuit. NO: GO TO 2.
  2. CHECK FRONT WIPER MOTOR (HI) OUTPUT VOLTAGE Turn the ignition switch ON. Select FR WIPER of BCM (WIPER) active test item. While performing the active test, check voltage between IPDM E/R harness connector and ground. IPDM E/R Ground FRONT WIPER Voltage (Approx.) Connector Terminal E45 18 HI Battery voltage OFF 0V Is the inspection result normal? YES: GO TO 3. NO: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION»(ref-675597-S28632663882014120500000) " (with Intelligent Key) or " «REMOVAL AND INSTALLATION»(ref-675598-S27210814052014120500000) " (without Intelligent Key).
  3. CHECK FRONT WIPER MOTOR (HI) OPEN CIRCUIT Turn the ignition switch OFF. Disconnect IPDM E/R and front wiper motor. Check continuity between IPDM E/R harness connector and front wiper motor harness connector. IPDM E/R Front wiper motor Continuity Connector Terminal Connector Terminal E45 18 E1 5 Yes Is the inspection result normal? YES: Replace front wiper motor. Refer to " «REMOVAL AND INSTALLATION»(ref-675631-S23641355152014120500000) ". NO: Repair or replace harness.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK FRONT WIPER MOTOR (AUTO STOP) OUTPUT VOLTAGE Turn the ignition switch ON. Check voltage between IPDM E/R harness connector and ground. IPDM E/R Ground FRONT WIPER Voltage (Approx.) Connector Terminal E46 74 Except stop position Battery voltage Stop position 0 V Is the inspection result normal? YES: Check for intermittent failure. NO: GO TO 2.
  2. CHECK FRONT WIPER MOTOR (AUTO STOP) SHORT CIRCUIT Turn the ignition switch OFF. Disconnect IPDM E/R and front wiper motor. Check continuity between IPDM E/R harness connector and ground. IPDM E/R Ground Continuity Connector Terminal E46 74 No Is the inspection result normal? YES: Repair or replace harness. NO: GO TO 3.
  3. CHECK FRONT WIPER MOTOR (AUTO STOP) CIRCUIT CONTINUITY Check continuity between IPDM E/R harness connector and front wiper motor harness connector. IPDM E/R Front wiper motor Continuity Connector Terminal Connector Terminal E46 74 E1 4 Yes Is the inspection result normal? YES: Replace front wiper motor. Refer to " «REMOVAL AND INSTALLATION»(ref-675631-S23641355152014120500000) ". NO: Repair or replace harness.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK FRONT WIPER MOTOR GROUND CIRCUIT Turn the ignition switch OFF. Disconnect front wiper motor. Check continuity between front wiper motor harness connector and ground. Front wiper motor Ground Continuity Connector Terminal E1 2 Yes Is the inspection result normal? YES: Front wiper motor ground circuit is normal. NO: Repair or replace harness.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ", " WIRING DIAGRAM ".

  1. CHECK FRONT AND REAR WASHER MOTOR FUSE Turn the ignition switch OFF. Check that the following fuse is not blown. Component Capacity Fuse No. Location Front and rear washer motor 10A 6 Fuse block (J/B) Is the fuse blown? YES: Replace the fuse after repairing the affected circuit. NO: GO TO 2.
  2. CHECK FRONT AND REAR WASHER MOTOR POWER SUPPLY Disconnect front and rear washer motor. Turn ignition switch ON. Check voltage between front and rear washer motor harness connector and ground. CONNECTOR TERMINAL REFERENCE (FRONT WASHER) Front and rear washer motor Ground Washer switch Voltage (Approx.) Connector Terminal OFF 0 E2 1 ON Battery voltage CONNECTOR TERMINAL REFERENCE (REAR WASHER) Front and rear washer motor Ground Washer switch Voltage (Approx.) Connector Terminal OFF 0 E2 2 ON Battery voltage Is the inspection result normal? YES: Replace front and rear washer motor. Refer to " «REMOVAL AND INSTALLATION»(ref-675631-S08921001712014120500000) ". NO: GO TO 3.
  3. CHECK WASHER SWITCH Check washer switch. Refer to " «COMPONENT INSPECTION»(ref-675631-S36142381452014120500000) ". Is the inspection result normal? YES: Repair harness between front and rear washer motor and washer switch. NO: Replace washer switch. Refer to " «REMOVAL AND INSTALLATION»(ref-675612-S00835399382014120500000) " (with Intelligent Key) or " «REMOVAL AND INSTALLATION»(ref-675613-S18450722682014120500000) " (without Intelligent Key).

Scheme 8

Scheme 8: Description
  1. Washer switch is integrated with the combination switch.
  2. Combination switch (wiper and washer switch) switches polarity between front washer operating and rear washer operating to supply power and ground to the front and rear washer motor.

Scheme 9

Scheme 9: Component Inspection

Scheme 10

Scheme 10
  1. CHECK FRONT WASHER SWITCH Turn the ignition switch OFF. Disconnect combination switch (wiper and washer switch). Check continuity between the combination switch (wiper and washer switch) terminals. Combination switch (wiper and washer switch) Condition Continuity Terminal 1 6 Front washer switch ON Yes 3 4 Is the inspection result normal? YES: GO TO 2. NO: Replace combination switch (wiper and washer switch). Refer to " «REMOVAL AND INSTALLATION»(ref-675612-S00835399382014120500000) " (with Intelligent Key) or " «REMOVAL AND INSTALLATION»(ref-675613-S18450722682014120500000) " (without Intelligent Key).
  2. CHECK REAR WASHER SWITCH Check continuity between the combination switch (wiper and washer switch) terminals. Combination switch (wiper and washer switch) Condition Continuity Terminal 1 4 Rear washer switch ON Yes 6 3 Is the inspection result normal? YES: Wiper and washer switch is normal. NO: Replace combination switch (wiper and washer switch). Refer to " «REMOVAL AND INSTALLATION»(ref-675612-S00835399382014120500000) " (with Intelligent Key) or " «REMOVAL AND INSTALLATION»(ref-675613-S18450722682014120500000) " (without Intelligent Key).

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK REAR WIPER MOTOR OUTPUT VOLTAGE CONSULT ACTIVE TEST Turn the ignition switch OFF. Disconnect rear wiper motor. Turn the ignition switch ON. Select RR WIPER of BCM active test item. While operating the test item, check voltage between BCM harness connector and ground. CONNECTOR TERMINAL REFERENCE (WITH INTELLIGENT KEY) BCM Ground Test item Voltage (Approx.) Connector Terminal REAR WIPER M100 54 ON Battery voltage OFF 0V CONNECTOR TERMINAL REFERENCE (WITHOUT INTELLIGENT KEY) BCM Ground Test item Voltage (Approx.) Connector Terminal REAR WIPER M20 68 ON Battery voltage OFF 0V Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
  2. CHECK REAR WIPER MOTOR GROUND CIRCUIT Turn the ignition switch OFF. Check continuity between rear wiper motor harness connector and ground. Rear wiper motor Ground Continuity Connector Terminal D502 4 Yes Is the inspection result normal? YES: Replace rear wiper motor. Refer to " «REMOVAL AND INSTALLATION»(ref-675631-S13780721532014120500000) ". NO: Repair or replace harness.
  3. CHECK REAR WIPER MOTOR OPEN CIRCUIT Check continuity between BCM harness connector and rear wiper motor harness connector. CONNECTOR TERMINAL REFERENCE (WITH INTELLIGENT KEY) BCM Rear wiper motor Continuity Connector Terminal Connector Terminal M100 54 D502 2 Yes CONNECTOR TERMINAL REFERENCE (WITHOUT INTELLIGENT KEY) BCM Rear wiper motor Continuity Connector Terminal Connector Terminal M20 68 D502 2 Yes Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness.
  4. CHECK REAR WIPER MOTOR SHORT CIRCUIT Check continuity between BCM harness connector and ground. CONNECTOR TERMINAL REFERENCE (WITH INTELLIGENT KEY) BCM Ground Continuity Connector Terminal M100 54 No CONNECTOR TERMINAL REFERENCE (WITHOUT INTELLIGENT KEY) BCM Ground Continuity Connector Terminal M20 68 No Is the inspection result normal? YES: Repair or replace harness. NO: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-675612-S22326735462014120500000) " (with Intelligent Key) or " «REMOVAL AND INSTALLATION»(ref-675613-S40874896552014120500000) " (without Intelligent Key).

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK REAR WIPER MOTOR AUTO STOP CIRCUITS FOR OPEN Turn ignition switch OFF. Disconnect BCM and rear wiper motor. Check continuity between BCM harness connector terminal and rear wiper motor harness connector terminal. CONNECTOR TERMINAL REFERENCE (WITH INTELLIGENT KEY) BCM Rear wiper motor Continuity Connector Terminal Connector Terminal M100 44 D502 3 Yes CONNECTOR TERMINAL REFERENCE (WITHOUT INTELLIGENT KEY) BCM Rear wiper motor Continuity Connector Terminal Connector Terminal M20 56 D502 3 Yes Is inspection result normal? YES: GO TO 2. NO: Repair or replace harness.
  2. CHECK AUTO STOP CIRCUITS FOR SHORT TO GROUND Check continuity between BCM harness connector terminal and ground. CONNECTOR TERMINAL REFERENCE (WITH INTELLIGENT KEY) BCM Ground Continuity Connector Terminal M100 44 No CONNECTOR TERMINAL REFERENCE (WITHOUT INTELLIGENT KEY) BCM Ground Continuity Connector Terminal M20 56 No Is inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-675612-S22326735462014120500000) " (with Intelligent Key) or " «REMOVAL AND INSTALLATION»(ref-675613-S40874896552014120500000) " (with Intelligent Key). NO: Repair or replace harness.

Symptom Table

CAUTIONPerform the self-diagnosis with CONSULT before performing the diagnosis by symptom. Perform the diagnosis by DTC if DTC is detected.
SymptomPossible malfunctionReference
Front wiper does not operate in...HI onlyCombination switch (wiper and washer switch) Harness between combination switch (wiper and washer switch) and BCM BCMCombination switch (wiper and washer switch) Refer to " SYMPTOM TABLE " (with Intelligent Key) or " SYMPTOM TABLE " (without Intelligent Key).
IPDM E/R Harness between IPDM E/R and front wiper motor Front wiper motorFront wiper motor (HI) circuit Refer to " COMPONENT FUNCTION CHECK ".
Front wiper request signal (IPDM E/R)Check FR WIP REQ in DATA MONITOR of IPDM E/R. Refer to " CONSULT FUNCTION (IPDM E/R) " (with Intelligent Key) or " CONSULT FUNCTION (IPDM E/R) " (without Intelligent Key).
LO and INTCombination switch (wiper and washer switch) Harness between combination switch (wiper and washer switch) and BCM BCMCombination switch (wiper and washer switch) Refer to " SYMPTOM TABLE " (with Intelligent Key) or " SYMPTOM TABLE " (without Intelligent Key).
IPDM E/R Harness between IPDM E/R and front wiper motor Front wiper motorFront wiper motor (LO) circuit Refer to " COMPONENT FUNCTION CHECK ".
Front wiper request signal (IPDM E/R)Check FR WIP REQ in DATA MONITOR of IPDM E/R. Refer to " CONSULT FUNCTION (IPDM E/R) " (with Intelligent Key) or " CONSULT FUNCTION (IPDM E/R) " (without Intelligent Key).
INT onlyCombination switch (wiper and washer switch) Harness between combination switch (wiper and washer switch) and BCM BCMCombination switch (wiper and washer switch) Refer to " SYMPTOM TABLE " (with Intelligent Key) or " SYMPTOM TABLE " (without Intelligent Key).
Front wiper request signal (IPDM E/R)Check FR WIP REQ in DATA MONITOR of IPDM E/R. Refer to " CONSULT FUNCTION (IPDM E/R) " (with Intelligent Key) or " CONSULT FUNCTION (IPDM E/R) " (without Intelligent Key).
Any modeRefer to " DIAGNOSIS PROCEDURE ".
Front wiper does not stop in...Any modeFront wiper auto stop signal (IPDM E/R)Refer to " COMPONENT FUNCTION CHECK ".
Combination switch (wiper and washer switch) BCMCombination switch (wiper and washer switch) Refer to " SYMPTOM TABLE " (with Intelligent Key) or " SYMPTOM TABLE " (without Intelligent Key).
Front wiper operates abnormally because...Intermittent adjustments cannot be made.Combination switch (wiper and washer switch) Harness between combination switch (wiper and washer switch) and BCM BCMCombination switch (wiper and washer switch) Refer to " SYMPTOM TABLE " (with Intelligent Key) or " SYMPTOM TABLE " (without Intelligent Key).
Wiper/washer will not operate together.Combination switch (wiper and washer switch) Harness between combination switch (wiper and washer switch) and BCM BCMCombination switch (wiper and washer switch) Refer to " SYMPTOM TABLE " (with Intelligent Key) or " SYMPTOM TABLE " (without Intelligent Key).
Wipers will not return to stop position (repeatedly operates for 10 seconds and then stops for 20 seconds. Wipers then stop operating).IPDM E/R Harness between IPDM E/R and front wiper motor Front wiper motorFront wiper auto stop signal circuit Refer to " COMPONENT FUNCTION CHECK ".
Rear wiper does not operate.ON onlyCombination switch (wiper and washer switch) Harness between combination switch (wiper and washer switch) and BCM BCMCombination switch (wiper and washer switch) Refer to " SYMPTOM TABLE " (with Intelligent Key) or " SYMPTOM TABLE " (without Intelligent Key).
INT onlyCombination switch (wiper and washer switch) Harness between combination switch (wiper and washer switch) and BCM BCMCombination switch (wiper and washer switch) Refer to " SYMPTOM TABLE " (with Intelligent Key) or " SYMPTOM TABLE " (without Intelligent Key).
ON and INTCombination switch (wiper and washer switch) Harness between combination switch (wiper and washer switch) and BCM BCMCombination switch (wiper and washer switch) Refer to " SYMPTOM TABLE " (with Intelligent Key) or " SYMPTOM TABLE " (without Intelligent Key).
BCM Harness between rear wiper motor and BCM Harness between rear wiper motor and ground Rear wiper motorRear wiper motor circuit Refer to " DIAGNOSIS PROCEDURE ".
Rear wiper does not stop.ON onlyCombination switch (wiper and washer switch) BCMRear wiper motor circuit Refer to " DIAGNOSIS PROCEDURE ".
INT onlyCombination switch (wiper and washer switch) BCMCombination switch (wiper and washer switch) Refer to " SYMPTOM TABLE " (with Intelligent Key) or " SYMPTOM TABLE " (without Intelligent Key).
Rear wiper does not operate normally.Wiper is not linked to the washer operation.Combination switch (wiper and washer switch) Harness between rear wiper motor and BCM BCMCombination switch (wiper and washer switch) Refer to " SYMPTOM TABLE " (with Intelligent Key) or " SYMPTOM TABLE " (without Intelligent Key).
BCM
Rear wiper does not return to the Stop position (Stops after a five-second operation).BCM Harness between rear wiper motor and BCM Rear wiper motorRear wiper auto stop signal circuit Refer to " DIAGNOSIS PROCEDURE ".
Rear wiper stops after operating for five seconds when ignition switch is turned ON.
Front and rear washer motor does not operate.Front and rear washer motor does not operate when the washing windshield.Combination switch (wiper and washer switch) Harness between combination switch (wiper and washer switch) and BCM BCMCombination switch (wiper and washer switch) Refer to " SYMPTOM TABLE " (with Intelligent Key) or " SYMPTOM TABLE " (without Intelligent Key).
Harness between rear combination switch (wiper and washer switch) and front and rear washer motor. Front and rear washer motorFront and rear washer motor circuit Refer to " DIAGNOSIS PROCEDURE ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK WIPER RELAY OPERATION IPDM E/R AUTO ACTIVE TEST Start IPDM E/R auto active test. Refer to " «DIAGNOSIS DESCRIPTION»(ref-675597-S07321007372014120500000) " (with Intelligent Key) or " «DIAGNOSIS DESCRIPTION»(ref-675598-S23603498062014120500000) " (without Intelligent Key). Check that the front wiper operates on LO and HI operation. CONSULT ACTIVE TEST Select FR WIPER of BCM (WIPER) active test item. Check front wiper operation. LO: Front wiper LO operation HI: Front wiper HI operation OFF: Front wiper stop Is the inspection result normal? YES: GO TO 5 . NO: GO TO 2.
  2. CHECK FRONT WIPER MOTOR FUSE Refer to " «DIAGNOSIS PROCEDURE»(ref-675631-S22697262562014120500000) ". Is the fuse blown? YES: Replace the fuse after repairing the affected circuit. NO: GO TO 3.
  3. CHECK FRONT WIPER MOTOR GROUND CIRCUIT Refer to " «DIAGNOSIS PROCEDURE»(ref-675631-S41845527422014120500000) ". Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness.
  4. CHECK FRONT WIPER MOTOR OUTPUT VOLTAGE Turn the ignition switch ON. With CONSULT, select FRONT WIPER of IPDM E/R ACTIVE TEST item. Check voltage between IPDM E/R harness connector and ground while wipers are operating. IPDM E/R Ground FRONT WIPER Voltage (Approx.) Connector Terminal E45 17 LO Battery voltage OFF 0 V 18 HI Battery voltage OFF 0 V Is the inspection result normal? YES: Replace front wiper motor. Refer to " «REMOVAL AND INSTALLATION»(ref-675631-S23641355152014120500000) ". NO: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION»(ref-675597-S28632663882014120500000) " (with Intelligent Key) or " «REMOVAL AND INSTALLATION»(ref-675598-S27210814052014120500000) " (without Intelligent Key).
  5. CHECK FRONT WIPER REQUEST SIGNAL INPUT With CONSULT, select FR WIP REQ in DATA MONITOR of IPDM E/R. Switch the front wiper switch to HI and LO. Check the status of FR WIP REQ while operating the switch. Data monitor Condition Status FR WIP REQ Front wiper switch OFF STOP Front wiper switch LO LOW Front wiper switch HI HI Is the inspection result normal? YES: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION»(ref-675597-S28632663882014120500000) " (with Intelligent Key) or " «REMOVAL AND INSTALLATION»(ref-675598-S27210814052014120500000) " (without Intelligent Key). NO: GO TO 6.
  6. CHECK COMBINATION SWITCH (WIPER AND WASHER SWITCH) Check combination switch (wiper and washer switch). Refer to " «COMPONENT INSPECTION»(ref-675631-S36142381452014120500000) ". Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-675612-S22326735462014120500000) " (with Intelligent Key) or " «REMOVAL AND INSTALLATION»(ref-675613-S40874896552014120500000) " (without Intelligent Key). NO: Repair or replace the applicable parts.

INSPECTION

Check that air can pass through the nozzle (1) by blowing into the nozzle and that air cannot flow in the opposite direction.

Scheme 11

Scheme 11: INSPECTION

Scheme 12

Scheme 12: Exploded View
