Precaution for Work
- When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
- When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
- Protect the removed parts with a shop cloth and prevent them from being dropped.
- Replace a deformed or damaged clip.
- If a part is specified as a non-reusable part, always replace it with a new one.
- Be sure to tighten bolts and nuts securely to the specified torque.
- After installation is complete, be sure to check that each part works properly.
- Follow the steps below to clean components: Water soluble dirt
- Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
- Then rub with a soft, dry cloth. Oily dirt
- Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
- Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
- Then rub with a soft, dry cloth. Do not use organic solvent such as thinner, benzene, alcohol or gasoline. For genuine leather seats, use a genuine leather seat cleaner.
Special Service Tool
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number (Kent-Moore No.) Tool name Description - (J-46534) Trim Tool Set Removing trim components
Scheme 11
Scheme 11: Special Service Tool
Scheme 12
Scheme 12: Component Parts Location
| No. | Component parts | Function |
|---|
| 1. | BCM | Supplies power supply to power window switch. Controls retained power. Refer to " BODY CONTROL SYSTEM: COMPONENT PARTS LOCATION " for detailed installation location. |
| 2. | Power window main switch | Refer to " POWER WINDOW MAIN SWITCH ". |
| 3. | Front power window motor (driver side) | Refer to " POWER WINDOW MOTOR ". |
| 4. | Front door switch (driver side) | Inputs door open/close condition to BCM. Refer to " INTELLIGENT KEY SYSTEM: DOOR SWITCH " for detailed installation location. |
| 5. | Rear power window switch LH | Refer to " POWER WINDOW SWITCH ". |
| 6. | Rear power window motor LH | Refer to " POWER WINDOW MOTOR ". |
Scheme 13
Scheme 13: Power Window Main Switch
- Power window main switch controls all power windows.
- Power window main switch integrates UP/DOWN switch, power window lock switch, and door lock/unlock switch.
- Power window main switch controls the power window lock function.
Scheme 14
Scheme 14: Power Window Switch
- Each power window switch transmits UP/DOWN signal to each motor.
- Each power window switch transmits UP/DOWN signal from power window main switch to each motor.
Scheme 15
Scheme 15: Power Window Motor
- Starts operation according to signals from power window main switch (front driver side).
- Transmits front power window motor (driver side) rotation as a pulse signal to power window main switch.
- Excepting power window motor for driver door, starts operation according to signals from power window main switch or each power window switches.
Scheme 16
Scheme 16: SYSTEM DIAGRAM
POWER WINDOW LOCK
Ground circuit inside power window main switch shuts off when power window lock switch is ON. This inhibits each power window switch operation except the power window main switch.
RETAINED ACCESSORY POWER CANCEL CONDITIONS
- Front door CLOSE (door switch OFF)-->OPEN (door switch ON).
- When ignition switch is ON again.
- When timer expires. (45 seconds)
DATA MONITOR
| Monitor Item [Unit] | Description |
|---|
| DOOR SW-DR [On/Off] | Indicates condition of front door switch LH. |
| DOOR SW-AS [On/Off] | Indicates condition of front door switch RH. |
| Monitor Item [Unit] | Description |
|---|
| DOOR SW-DR [On/Off] | Indicates condition of front door switch LH. |
| DOOR SW-AS [On/Off] | Indicates condition of front door switch RH. |
List of ECU Reference
| ECU | Reference |
|---|
| BCM (with Intelligent Key system) | " REFERENCE VALUE " |
| " FAIL-SAFE " |
| " DTC INSPECTION PRIORITY CHART " |
| " DTC INDEX " |
| BCM (without Intelligent Key system) | " REFERENCE VALUE " |
| " FAIL-SAFE " |
| " DTC INSPECTION PRIORITY CHART " |
| " DTC INDEX " |
Scheme 17
Scheme 17: TERMINAL LAYOUT
PHYSICAL VALUES
| Terminal No. (Wire color) | Description | Condition | Voltage (Approx.) |
|---|
| + | | Signal name | Input/Output |
| 1 (BR) | Ground | Rear power window motor LH UP signal | Output | When rear LH switch in power window main switch is UP at operated. | Battery voltage |
| 3 (G) | Ground | Rear power window motor LH DOWN signal | Output | When rear LH switch in power window main switch is DOWN at operated. | Battery voltage |
| 5 (Y) | Ground | Rear power window motor RH DOWN signal | Output | When rear RH switch in power window main switch is DOWN at operated. | Battery voltage |
| 7 (V) | Ground | Rear power window motor RH UP signal | Output | When rear RH switch in power window main switch is UP at operated. | Battery voltage |
| 8 (R) | Ground | Front power window motor (driver side) UP signal | Output | When front LH switch in power window main switch is UP at operated. | Battery voltage |
| 10 (L) | Ground | Ignition switch power supply | Input | Ignition switch ON | Battery voltage |
| Other than above | 0 |
| 11 (LG) | Ground | Front power window motor (driver side) DOWN signal | Output | When front LH switch in power window main switch is DOWN at operated. | Battery voltage |
| 12 (SB) | Ground | Front power window motor (passenger side) DOWN signal | Output | When front RH switch in power window main switch is DOWN at operated. | Battery voltage |
| 16 (W) | Ground | Front power window motor (passenger side) UP signal | Output | When front RH switch in power window main switch is UP at operated. | Battery voltage |
| 17 (B) | Ground | Ground | | | 0 |
FAIL-SAFE CONTROL
Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when error beyond regulation value is detected between the fully closed position and the actual position of the glass.
| Error | Error condition |
|---|
| Pulse sensor malfunction | When only one side of pulse signal is being detected for more than the specified value. |
| Both pulse sensors malfunction | When both pulse signals have not been detected for more than the specified value during glass open/close operation. |
| Pulse direction malfunction | When the pulse signal that is detected during glass open/close operation detects the opposite condition of power window motor operating direction. |
| Glass recognition position malfunction 1 | When it detects the error between glass fully closed position in power window switch memory and actual fully closed position during glass open/close operation is more than the specified value. |
| Glass recognition position malfunction 2 | When it detects pulse count more than the value of glass full stroke during glass open/close operation. |
It changes to condition before initialization and the following functions do not operate when switched to fail-safe control.
- Auto-up operation
- Anti-pinch function
- Retained power function
Perform initial operation to recover when switched to fail-safe mode. However, it switches back to fail-safe control when malfunction is found in power window main switch or front power window motor (driver side).
Scheme 18
Scheme 18: Wiring Diagram
Scheme 19
Scheme 19: Connector End Views
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 25: OVERALL SEQUENCE
DETAILED FLOW
- OBTAIN INFORMATION ABOUT SYMPTOM Interview the customer to obtain as much information as possible about the conditions and environment under which the malfunction occurred. : GO TO 2.
- CONFIRM THE SYMPTOM Check the malfunction on the vehicle that the customer describes. Inspect the relation of the symptoms and the condition when the symptoms occur. : GO TO 3.
- IDENTIFY THE MALFUNCTIONING SYSTEM WITH SYMPTOM DIAGNOSIS Use Symptom diagnosis from the symptom inspection result in step 2 and then identify where to start performing the diagnosis based on possible causes and symptoms. : GO TO 4.
- PERFORM THE COMPONENT DIAGNOSIS OF THE OF THE APPLICABLE SYSTEM Perform the diagnosis with Component diagnosis of the applicable system. : GO TO 5.
- REPAIR OR REPLACE THE MALFUNCTIONING PARTS Repair or replace the specified malfunctioning parts. : GO TO 6.
- FINAL CHECK Check that malfunctions are not reproduced when obtaining the malfunction information from the customer, referring to the symptom inspection result in step 2 . Are the malfunctions corrected? YES: Inspection End. NO: GO TO 3 .
Component Function Check
- CHECK FUNCTION Check front power window motor RH operation with front power window switch RH. Is the inspection result normal? YES: Inspection End. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-675626-S14467269332014120500000) ".
- CHECK FUNCTION Check rear power window motor operation with rear power window switch. Is the inspection result normal? YES: Inspection End. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-675626-S17697476732014120500000) ".
DRIVER SIDE: Component Function Check
- CHECK FUNCTION Check front power window motor LH operation with power window main switch. Is the inspection result normal? YES: Inspection End. NO: Refer to " «DRIVER SIDE: DIAGNOSIS PROCEDURE»(ref-675626-S36765041782014120500000) ".
PASSENGER SIDE: Component Function Check
- CHECK FUNCTION Check front power window motor RH operation with power window main switch or front power window switch RH. Is the inspection result normal? YES: Inspection End. NO: Refer to " «PASSENGER SIDE: DIAGNOSIS PROCEDURE»(ref-675626-S01238984522014120500000) ".
REAR LH: Component Function Check
- CHECK FUNCTION Check rear power window motor LH operation with power window main switch or rear power window switch LH. Is the inspection result normal? YES: Inspection End. NO: Refer to " «REAR LH: DIAGNOSIS PROCEDURE»(ref-675626-S01115351022014120500000) ".
REAR RH: Component Function Check
- CHECK FUNCTION Check rear power window motor RH operation with power window main switch or rear power window switch RH. Is the inspection result normal? YES: Inspection End. NO: Refer to " «REAR RH: DIAGNOSIS PROCEDURE»(ref-675626-S26439887462014120500000) ".
WITH INTELLIGENT KEY: Component Function Check
- CHECK FUNCTION Select DOOR LOCK of BCM using CONSULT. Select DOOR SW-DR, DOOR SW-AS, DOOR SW-RL and DOOR SW-RR in DATA MONITOR mode. Check that the function operates normally according to the following conditions. Monitor item Condition Status DOOR SW-DR Front door LH Open ON Closed OFF DOOR SW-AS Front door RH Open ON Closed OFF DOOR SW-RL Rear door LH Open ON Closed OFF DOOR SW-RR Rear door RH Open ON Closed OFF Is the inspection result normal? YES: Door switch is OK. NO: Refer to " «WITH INTELLIGENT KEY: DIAGNOSIS PROCEDURE»(ref-675626-S39922860032014120500000) ".
WITHOUT INTELLIGENT KEY: Component Function Check
- CHECK FUNCTION With CONSULT Check door switches DOOR SW-DR, DOOR SW-AS, DOOR SW-RL, DOOR SW-RR in Data Monitor mode with CONSULT. Monitor item Condition DOOR SW-DR CLOSE --> OPEN: OFF --> ON DOOR SW-AS DOOR SW-RL DOOR SW-RR Is the inspection result normal? YES: Door switch is OK. NO: Refer to " «WITHOUT INTELLIGENT KEY: DIAGNOSIS PROCEDURE»(ref-675626-S26533288772014120500000) ".
