Glass & Window System: Removal & Installation Nissan Note E12

Windows 4 illustrations ~1554 words

INSTALLATION

Installation is in the reverse order of removal.

  1. Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  2. Adhesive shall be continuously applied to assure watertightness. Glass installation shall be finished within five minutes after applying the adhesive.
  3. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger compartment air pressure when a door is closed.
  4. The molding must be installed securely so that it is in position and leaves no gap.
  5. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the windshield in case of an accident.
CAUTIONDo not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully read the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidity. The curing time will increase under lower temperatures and lower humidity.

REMOVAL

  1. Remove front pillar finisher. Refer to " «FRONT PILLAR FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S41976096022014120500000) ".
  2. Remove front fender. Refer to " «REMOVAL AND INSTALLATION»(ref-675592-S00468713442014120500000) ".
  3. Remove the opera window glass using piano wire or power cutting tool (A) and an inflatable pump bag (B).
WARNINGWhen cutting glass from the vehicle, always wear safety glasses and heavy gloves to prevent glass splinters from entering your eyes or cutting your hands.
CAUTIONBe careful not to scratch the glass when removing. Do not set or stand the glass on its edge. Small chips may develop into cracks. Apply protective tape around the opera window glass to protect the painted surface from damage.
  1. Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  2. Adhesive shall be continuously applied to assure watertightness. Glass installation shall be finished within five minutes after applying the adhesive.
  3. The start and finisher of the urethane adhesive application should be located at the bottom to assure watertightness.
  4. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger compartment air pressure when a door is closed.
  5. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive is completely cured may affect the performance of the opera window glass in case of an accident.
CAUTIONDo not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully read the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive is completely cured. Curing time varies depending on temperature and humidity. The curing time increases under lower temperature and lower humidity.
  1. Remove luggage side upper finisher. Refer to " «LUGGAGE SIDE UPPER FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S35853506082014120500000) ".
  2. Remove the side window glass using piano wire or power cutting tool (A) and an inflatable pump bag (B). WARNING: When cutting glass from the vehicle, always wear safety glasses and heavy gloves to prevent glass splinters from entering your eyes or cutting your hands. CAUTION: Be careful not to scratch the glass when removing. Do not set or stand the glass on its edge. Small chips may develop into cracks. Apply protective tape around the side window glass to protect the painted surface from damage.
  1. Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  2. Adhesive shall be continuously applied to assure watertightness. Glass installation shall be finished within five minutes after applying the adhesive.
  3. The start and finisher of the urethane adhesive application should be located at the bottom to assure watertightness.
  4. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger compartment air pressure when a door is closed.
  5. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive is completely cured may affect the performance of the side window glass in case of an accident.
CAUTIONDo not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully read the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive is completely cured. Curing time varies depending on temperature and humidity. The curing time increases under lower temperature and lower humidity.
  1. Remove high-mounted stop lamp. Refer to " «REMOVAL AND INSTALLATION»(ref-675604-S04811015542014120500000) ".
  2. Remove the back door inner finisher. Refer to " «BACK DOOR INNER FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S00933277502014120500000) ".
  3. Remove back door window glass using piano wire or power cutting tool (A) and an inflatable pump bag (B). Mark the body and the glass with matching marks if the back door window glass is reused. Apply protective tape around the back door window glass to protect the painted surface from damage. WARNING: When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help prevent glass splinters from entering your eyes or cutting your hands. CAUTION: Be careful not to scratch the glass when removing. Do not set or stand the glass on its edge. Small chips may develop into cracks. Apply protective tape around the back door window glass to protect the painted surface from damage.

Installation is in the reverse order of removal.

  1. Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  2. Adhesive shall be continuously applied to assure watertightness. Glass installation shall be finished within five minutes after applying the adhesive.
  3. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger compartment air pressure when a door is closed.
  4. The molding must be installed securely so that it is in position and leaves no gap.
  5. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the back door window glass in case of an accident.
CAUTIONDo not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully read the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidity. The curing time will increase under lower temperatures and lower humidity.

Removal and Installation

WARNINGBefore servicing, turn the ignition switch off, disconnect both battery terminals and wait at least three minutes. Do not use air tools or electric tools for servicing.

Scheme 28

Scheme 28: Removal
Scheme 28: Removal

Scheme 29

Scheme 29
Scheme 29
  1. Disconnect the battery positive and negative terminals then wait at least three minutes. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-675572-S35311355862014120500000) ".
  2. Remove front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S20019847622014120500000) ".
  3. Remove the vapor barrier. Refer to " «EXPLODED VIEW»(ref-675629-S12054018602014120500000) ". CAUTION: Use care not to damage or tear vapor barrier during removal.
  4. Disconnect the harness connector from the door mirror.
  5. Temporarily reconnect both battery terminals and the main power window and door lock/unlock switch (LH door) or power window and door lock/unlock switch (RH door) to raise/lower the front door glass until the bolts can be seen through the access holes (with power window).
  6. Temporarily reinstall the front door glass handle and raise/lower the front door glass until the bolts can be seen through the access holes (without power window).
  7. Remove front door glass bolts (A).
  8. While holding the front door glass, raise it at the rear end and pull it out of the front door glass rear run toward the outside of the door to remove.
  9. Remove the front door glass front run bolts and remove (if necessary).
  10. Remove the front door glass rear run bolts and remove (if necessary).

Installation is in the reverse order of removal.

CAUTIONTighten bolts to specification. Refer to " EXPLODED VIEW ".
  1. Disconnect the battery positive and negative terminals then wait at least three minutes. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-675572-S35311355862014120500000) ".
  2. Remove front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S20019847622014120500000) ".
  3. Remove the vapor barrier. Refer to " «EXPLODED VIEW»(ref-675629-S12054018602014120500000) ". CAUTION: Use care not to damage or tear vapor barrier during removal.
  4. Disconnect the harness connector from the door mirror.
  5. Temporarily reconnect both battery terminals and the main power window and door lock/unlock switch (LH door) or power window and door lock/unlock switch (RH door) to raise/lower the front door glass until the bolts can be seen through the access holes (with power window).
  6. Temporarily reinstall the front door glass handle and raise/lower the front door glass until the bolts can be seen through the access holes (without power window).
  7. Remove front door glass bolts (A).
  8. Raise the front door glass and hold it in place with a suitable tool or approximately two inches of mashing tape.
  9. Remove bolts and front door glass regulator.
  10. Remove front power window motor from front door glass regulator (if necessary). Refer to " «REMOVAL AND INSTALLATION»(ref-675629-S24193669442014120500000) ".

Installation is in the reverse order of removal.

CAUTIONTighten front door regulator bolts to specification. Refer to " EXPLODED VIEW ".

Fitting Inspection

  1. Make sure that the glass fits securely into the sash groove.
  2. Lower the glass slightly [approximately 10 to 20 mm (0.394 to 0.787 in)], and check that the clearance to the sash is parallel. Loosen the regulator bolts, door sash bolts and glass bolts to correct the glass position if the clearance between the glass and sash is not parallel.
  1. Remove front door glass regulator. Refer to " «REMOVAL AND INSTALLATION»(ref-675629-S07620084982014120500000) ".
  2. Remove bolts and front power window motor.

Installation is in the reverse order of removal.

Scheme 30

Scheme 30: Exploded View
Scheme 30: Exploded View

Scheme 31

Scheme 31: Removal
Scheme 31: Removal
  1. Remove rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S00960128362014120500000) ".
  2. Remove vapor barrier. Refer to " «EXPLODED VIEW»(ref-675629-S39410055752014120500000) ". CAUTION: Use care not to damage or tear vapor barrier during removal.
  3. Temporarily reconnect the rear power window switch to raise/lower the rear door glass until the bolts can be seen through the access holes (with power window).
  4. Temporarily reinstall the rear door glass handle and raise/lower the rear door glass until the bolts can be seen through the access holes (without power window).
  5. Remove rear door glass bolts (A) and rear door glass (1).
  6. Remove rear door glass front run bolts and remove (if necessary).
  7. Remove rear door glass rear run bolts and remove (if necessary).

Installation is in the reverse order of removal.

CAUTIONTighten bolts to specification. Refer to " EXPLODED VIEW ".
  1. Remove rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S00960128362014120500000) ".
  2. Remove vapor barrier. Refer to " «EXPLODED VIEW»(ref-675629-S39410055752014120500000) ". CAUTION: Use care not to damage or tear vapor barrier during removal.
  3. Temporarily reconnect the rear power window switch to raise/lower the rear door glass until the bolts can be seen through the access holes (with power window).
  4. Temporarily reinstall the rear door glass handle and raise/lower the rear door glass until the bolts can be seen through the access holes (without power window).
  5. Remove rear door glass bolts (A). 1: Rear door glass
  6. Raise the rear door glass and hold in place with a suitable tool or approximately two inches of masking tape.
  7. Remove bolts and rear door glass regulator.
  8. Remove rear power window motor from rear door glass regulator (if necessary). Refer to " «REMOVAL AND INSTALLATION»(ref-675629-S19317880732014120500000) ".

Installation is in the reverse order of removal.

CAUTIONTighten rear door glass regulator bolts to specification. Refer to " EXPLODED VIEW ".
  1. Remove rear door glass regulator. Refer to " «REMOVAL AND INSTALLATION»(ref-675629-S25851597402014120500000) ".
  2. Remove bolts and rear power window motor.

Installation is in the reverse order of removal.
