Audio, Visual & Navigation System (Navigation): Removal & Installation Nissan Note E12

Navigation System 18 illustrations ~909 words

BEFORE REPLACEMENT

When replacing AV control unit, save or print current vehicle specification with CONSULT configuration before replacement.

Note. If "Before Replace ECU" cannot be used, use the "After Replace ECU" or "Manual Configuration" after replacing AV control unit.

AFTER REPLACEMENT

CAUTIONWhen replacing AV control unit, you must perform "After Replace ECU" with CONSULT. Complete the procedure of "After Replace ECU" in order. If you set incorrect "After Replace ECU", incidents might occur. Configuration is different for each vehicle model. Confirm configuration of each vehicle model.

When replacing around view monitor control unit, save or print current vehicle specification with CONSULT configuration before replacement.

Note. If "Before Replace ECU" cannot be used, use the "After Replace ECU" or "Manual Configuration" after replacing around view monitor control unit.

CAUTIONWhen replacing around view monitor control unit, you must perform "After Replace ECU" with CONSULT. Complete the procedure of "After Replace ECU" in order. If you set incorrect "After Replace ECU", incidents might occur. Configuration is different for each vehicle model. Confirm configuration of each vehicle model.

REMOVAL

CAUTIONRemove battery terminal and AV control unit after a lapse of 30 seconds or more after turning the ignition switch OFF. Before replacing AV control unit, perform "READ CONFIGURATION" to save current vehicle specification. Refer to " CONFIGURATION (AV CONTROL UNIT): DESCRIPTION ".

Note. After the ignition switch is turned OFF, the AV control unit continues operating for approximately 30 seconds. Therefore, data corruption may occur if battery voltage is cut off within 30 seconds.

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34
  1. Remove the battery negative terminal. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-675572-S35311355862014120500000) ".
  2. Remove cluster lid C. Refer to " «REMOVAL AND INSTALLATION»(ref-675607-S20260849492014120500000) ".
  3. Remove the AV control unit screws (A) and partially remove the AV control unit (1).
  4. Disconnect the harness connectors from the AV control unit and remove.
  5. Remove the AV control unit bracket screws (A) and the AV control unit bracket (1) from each side of the AV control unit (if necessary).

INSTALLATION

Installation is in the reverse order of removal.

CAUTIONWhen replacing AV control unit, perform "WRITE CONFIGURATION". Refer to " CONFIGURATION (AV CONTROL UNIT): WORK PROCEDURE ". Perform camera image calibration. Refer to " CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR): WORK PROCEDURE ".

Scheme 35

Scheme 35: REMOVAL
Scheme 35: REMOVAL
  1. Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S20019847622014120500000) ".
  2. Disconnect the harness connector from front door speaker.
  3. Remove the front door speaker screws (A).
  4. Remove the front door speaker (1).

Installation is in the reverse order of removal.

Scheme 36

Scheme 36: REMOVAL
Scheme 36: REMOVAL
  1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S00960128362014120500000) ".
  2. Disconnect the harness connector from the rear door speaker.
  3. Remove the rear door speaker screws (A).
  4. Remove the rear door speaker (1).

Installation is in the reverse order of removal.

Scheme 37

Scheme 37: REMOVAL
Scheme 37: REMOVAL
  1. Remove the center console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-675607-S31298837932014120500000) ".
  2. Release the pawls (A) from the back of the center console assembly (2) using a suitable tool and remove the USB interface (1).

Installation is in the reverse order of removal.

  1. Remove the center console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-675607-S31298837932014120500000) ".
  2. Release the pawls (A) from the back of the center console assembly (2) using a suitable tool and remove the auxiliary input jack (1).

Installation is in the reverse order of removal.

Scheme 38

Scheme 38: REMOVAL
Scheme 38: REMOVAL

Scheme 39

Scheme 39
Scheme 39
  1. Remove the steering wheel. Refer to " «REMOVAL AND INSTALLATION»(ref-675600-S35361429072014120500000) ".
  2. Remove the steering wheel rear finisher (1) by releasing pawls (A).
  3. Remove the steering wheel audio control switch screws (A) from the back of the steering wheel.
  4. Remove the steering wheel audio control switches from the steering wheel.

Installation is in the reverse order of removal.

Scheme 40

Scheme 40: REMOVAL
Scheme 40: REMOVAL

Scheme 41

Scheme 41
Scheme 41
  1. Remove the microphone finisher from the headlining by releasing pawls (A) using a suitable tool.
  2. Disconnect the harness connector from microphone and remove.
  3. Separate the microphone from the finisher by releasing pawls (A) using a suitable tool.

Installation is in the reverse order of removal.

Note. Make sure to align the rib on the finisher with the slot in the microphone.

Make sure to install the microphone with the arrows pointing toward the RH side of the vehicle.

Scheme 42

Scheme 42: REMOVAL
Scheme 42: REMOVAL
  1. Remove the front passenger seat. Refer to " «PASSENGER SIDE: REMOVAL AND INSTALLATION»(ref-675605-S15787162872014120500000) ".
  2. Remove the floor trim. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S10078465842014120500000) ".
  3. Disconnect the harness connector from the around view monitor control unit.
  4. Remove the screws (A) from the around view monitor control unit bracket and remove.

Installation is in the reverse order of removal.

Note. Perform camera image calibration. Refer to " CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR): WORK PROCEDURE ".

Scheme 43

Scheme 43: REMOVAL
Scheme 43: REMOVAL
  1. Remove the front grille. Refer to " «REMOVAL AND INSTALLATION»(ref-675580-S16393645662014120500000) ".
  2. Remove the front camera screws (A) and remove.

Installation is in the reverse order of removal.

Note. Perform camera image calibration. Refer to " CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR): WORK PROCEDURE ".

Scheme 44

Scheme 44: REMOVAL
Scheme 44: REMOVAL
  1. Remove the back door outer finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-675580-S36269467122014120500000) ".
  2. Disconnect the harness connector from rear view camera.
  3. Remove the nuts (A) from the rear view camera and remove.

Installation is in the reverse order of removal.

Note. Perform camera image calibration. Refer to " CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR): WORK PROCEDURE ".

Scheme 45

Scheme 45: Exploded View
Scheme 45: Exploded View
  1. Remove the door mirror. Refer to " «REMOVAL AND INSTALLATION»(ref-675630-S00570073862014120500000) ".
  2. Remove the door mirror glass.
  3. Remove the door mirror actuator.
  4. Disconnect the harness connector from the side camera.
  5. Remove the side camera screws and remove.

Installation is in the reverse order of removal.

Note. Perform camera image calibration. Refer to " CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR): WORK PROCEDURE ".

Scheme 46

Scheme 46: REMOVAL
Scheme 46: REMOVAL
  1. Remove the combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ".
  2. Remove the AV control unit in order to disconnect the GPS antenna harness connector. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S08785922072014120500000) ".
  3. Remove the GPS antenna screw (A) from the GPS antenna.
  4. Disconnect the harness clip (B) and remove the GPS antenna.

Installation is in the reverse order of removal.

Removal and Installation

The satellite radio antenna is part of the rod antenna. Refer to " REMOVAL AND INSTALLATION ".

Scheme 47

Scheme 47: Exploded View
Scheme 47: Exploded View

Scheme 48

Scheme 48: REMOVAL
Scheme 48: REMOVAL
  1. Lower the rear portion of the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S00678727602014120500000) ".
  2. Disconnect the harness connectors from the antenna (satellite radio model shown).
  3. Remove the antenna nut (A) and remove the antenna.

Installation is in the reverse order of removal.

CAUTIONIf the antenna nut is tightened less than the specified torque this will lower the sensitivity of the antenna. If the antenna nut is tightened more than the specified torque this will deform the roof panel.

Scheme 49

Scheme 49: Feeder Layout
Scheme 49: Feeder Layout
