Audio, Visual & Navigation System (Navigation): Diagnosis Nissan Note E12

Navigation System 19 illustrations ~4027 words

DTC INDEX

DTCDescription
DTC U0428STEERING ANGLE SENSOR
DTC U1000CAN COMM CIRCUIT
DTC U1010CONTROL UNIT (CAN)
DTC U111AREAR CAMERA IMAGE SIGNAL CIRCUIT
DTC U111BSIDE CAMERA RH IMAGE SIGNAL CIRCUIT
DTC U111CFRONT CAMERA IMAGE SIGNAL CIRCUIT
DTC U111DSIDE CAMERA LH IMAGE SIGNAL CIRCUIT
DTC U1200AV CONTROL UNIT
DTC U1217AV CONTROL UNIT
DTC U1229AV CONTROL UNIT
DTC U122FAV CONTROL UNIT
DTC U1232STEERING ANGLE SENSOR
DTC U1244GPS ANTENNA
DTC U1258SATELLITE RADIO ANTENNA
DTC U1263USB
DTC U1264ANTENNA AMP.
DTC U12AACONFIGURATION ERROR
DTC U12ACAV CONTROL UNIT
DTC U12ADAV CONTROL UNIT
DTC U12AEAV CONTROL UNIT
DTC U12AFAV CONTROL UNIT
DTC U12B0POWER SUPPLY VOLTAGE
DTC U12B1POWER SUPPLY VOLTAGE
DTC U1304CAMERA IMAGE CALIBRATION
DTC U1305CONFIG UNFINISH

DTC INDEX

SELF DIAGNOSTIC RESULT

Refer to " DTC INDEX ".

Refer to " DTC INDEX ".

VALUES ON THE DIAGNOSIS TOOL

Monitor ItemConditionValue/Status
VHCL SPD SIGVehicle speed = 0 km/h (0 MPH).Off
Vehicle speed > 0 km/h (0 MPH).On
ILLUM SIGIllumination signal is not received.Off
Illumination signal is received.On
IGN SIGIgnition switch OFF or ACC.Off
Ignition switch ON.On
REV SIGSelector lever in any position other than R.Off
Selector lever in R position.On

Scheme 13

Scheme 13: TERMINAL LAYOUT
Scheme 13: TERMINAL LAYOUT
CONSULT DisplayRefer to
U1000: CAN COMM CIRCUIT" AV CONTROL UNIT: DTC LOGIC "
U1010: CONTROL UNIT (CAN)" AV CONTROL UNIT: DTC LOGIC "
U1200: Cont Unit" DTC LOGIC "
U1217: BLUETOOTH MODULE" DTC LOGIC "
U1229: iPod CERTIFICATION" DTC LOGIC "
U122F: Digital broadcasting connection error" DTC LOGIC "
U1244: GPS ANTENNA CONN" DTC LOGIC "
U1258: XM ANTENNA CONN" DTC LOGIC "
U1263: USB OVERCURRENT" DTC LOGIC "
U1264: ANTENNA AMP TERMINAL" DTC LOGIC "
U12AA: Configuration Error" DTC LOGIC "
U12AC: Display Temperature too High" DTC LOGIC "
U12AD: ECU Temperature too High" DTC LOGIC "
U12AE: Internal Amplifier temperature Warning" DTC LOGIC "
U12AF: CD Mechanism Temperature Warning" DTC LOGIC "
U12B0: Supply Voltage Goes below 9V > 20s" DTC LOGIC "
U12B1: Supply Voltage Goes High > 16V for 20s" DTC LOGIC "
Monitor ItemConditionValue/Status
CAMERA OFF SIGNALCAMERA switch ON.Off
CAMERA switch OFF.On
CAMERA SWITCH SIGNALCAMERA switch OFF.Off
CAMERA switch ON.On
DR-SIDE CAMERA IMAGE SIGSide camera LH inoperative.NG
Side camera LH operative.OK
F-CAMERA IMAGE SIGFront camera inoperative.NG
Front camera operative.OK
PA-SIDE CAMERA IMAGE SIGSide camera RH inoperative.NG
Side camera RH operative.OK
REAR CAMERA IMAGE SIGNALRear camera LH inoperative.NG
Rear camera LH operative.OK
REVERSE SIGNALWhen selector lever is in any position other than R (reverse).Off
When selector lever in R (reverse).On
ST ANGLE SENSOR SIGNALAround view monitor control unit is not receiving steering angle sensor signal.Off
Around view monitor control unit is receiving steering angle sensor signal.On
ST ANGLE SENSOR TYPESteering angle sensor type.Absolute
ST GEAR RATIO TYPESteering gear ratio type.Type O
STEERING POSITIONLeft hand drive vehicle.LHD
Right hand drive vehicle.RHD
VEHICLE SPEED SIGNALWhile driving, equivalent to speedometer readingMph, km/h

Scheme 14

Scheme 14: TERMINAL LAYOUT
Scheme 14: TERMINAL LAYOUT
CONSULT DisplayRefer to
U0428: ST ANG SEN CALIB" DTC LOGIC "
U1000: CAN COMM CIRCUIT" AROUND VIEW MONITOR CONTROL UNIT: DTC LOGIC "
U1010: CONTROL UNIT (CAN)" AROUND VIEW MONITOR CONTROL UNIT: DTC LOGIC "
U111A: Rear display output signal diagnosis (Harness disconnection)" DTC LOGIC "
U111B: Right side display output signal diagnosis (Harness disconnection)" DTC LOGIC "
U111C: Front display output signal diagnosis (Harness disconnection)" DTC LOGIC "
U111D: Left side display output signal diagnosis (Harness disconnection)" DTC LOGIC "
U1232: ST ANG SEN CALIB" DTC LOGIC "
U1304: Non-completion of the calibration" DTC LOGIC "
U1305: Non-completion of the configuration" DTC LOGIC "

Scheme 15

Scheme 15: Wiring Diagram
Scheme 15: Wiring Diagram

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18: Connector End Views
Scheme 18: Connector End Views

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31: OVERALL SEQUENCE
Scheme 31: OVERALL SEQUENCE

DTC DETECTION LOGIC

CONSULT DisplayDTC Detection ConditionPossible Cause
ST ANG SEN CALIB [U0428]The neutral position adjustment of the steering angle sensor is incomplete.Adjust neutral position of the steering angle sensor.

Diagnosis Procedure

  1. ADJUST THE NEUTRAL POSITION OF THE STEERING ANGLE SENSOR When U0428 is detected, adjust the neutral position of the steering angle sensor. : Perform adjustment of the neutral position of the steering angle sensor. Refer to " «CONSULT FUNCTION»(ref-675624-S19306948042014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
CAN COMM CIRCUIT [U1000]AV control unit is not transmitting or receiving CAN communication signal for 2 seconds or more.CAN communication system.

AV CONTROL UNIT: Diagnosis Procedure

  1. PERFORM SELF DIAGNOSTIC RESULT Turn ignition switch ON and wait for 2 seconds or more. Perform Self Diagnostic Result for MULTI AV. Is CAN COMM CIRCUIT displayed? YES: Refer to " «TROUBLE DIAGNOSIS FLOW CHART»(ref-675575-S41142210102014120500000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-675571-S38824794042014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
CAN COMM CIRCUIT [U1000]Around view monitor control unit is not transmitting or receiving CAN communication signal for 2 seconds or more.CAN communication system.

AROUND VIEW MONITOR CONTROL UNIT: Diagnosis Procedure

  1. PERFORM SELF DIAGNOSTIC RESULT Turn ignition switch ON and wait for 2 seconds or more. Perform Self Diagnostic Result for AVM. Is CAN COMM CIRCUIT displayed? YES: Refer to " «TROUBLE DIAGNOSIS FLOW CHART»(ref-675575-S41142210102014120500000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-675571-S38824794042014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
CONTROL UNIT (CAN) [U1010]Error during CAN controller hardware initialization (VCAN).Replace the AV control unit if the malfunction occurs constantly. Refer to " REMOVAL AND INSTALLATION ".
CONSULT DisplayDTC Detection ConditionPossible Cause
CONTROL UNIT (CAN) [U1010]Error during CAN controller hardware initialization (VCAN).Replace the Around view monitor control unit if the malfunction occurs constantly. Refer to " REMOVAL AND INSTALLATION ".
CONSULT DisplayDTC Detection ConditionPossible Cause
Rear display output signal diagnosis (Harness disconnection) [U111A]Rear view camera image signal circuit open or short.Check rear view camera image signal circuit.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK REAR VIEW CAMERA POWER SUPPLY AND GROUND CIRCUIT CONTINUITY Turn ignition switch OFF. Disconnect around view monitor control unit and rear view camera connectors. Check continuity between around view monitor control unit connector B54 and rear view camera connector D501. Around view monitor control unit Rear view camera Continuity Connector Terminals Connector Terminals B54 26 D501 2 Yes 25 1 Check continuity between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Continuity Connector Terminal B54 26 No Is the inspection result normal? YES: GO TO 2. NO: Repair or replace harness or connectors.
  2. CHECK REAR VIEW CAMERA POWER SUPPLY VOLTAGE Connect around view monitor control unit and rear view camera connectors. Turn ignition switch ON. Check voltage between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Condition Voltage (Approx.) Connector Terminal B54 26 - CAMERA switch is ON or selector lever in R (reverse). 6.0 V Is the inspection result normal? YES: GO TO 3. NO: Replace around view monitor control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S21627058292014120500000) ".
  3. CHECK REAR VIEW CAMERA IMAGE SIGNAL AND IMAGE SIGNAL GROUND CIRCUIT CONTINUITY Turn ignition switch OFF. Disconnect around view monitor control unit and rear view camera connectors. Check continuity between around view monitor control unit connector B54 and rear view camera connector D501. Around view monitor control unit Rear view camera Continuity Connector Terminals Connector Terminals B54 28 D501 4 Yes 27 5 Check continuity between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Continuity Connector Terminal B54 28 No Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness or connectors.
  4. CHECK REAR VIEW CAMERA IMAGE SIGNAL Connect around view monitor control unit and rear view camera connectors. Turn ignition switch ON. Check signal between the terminals of around view monitor control unit connector B54. Around view monitor control unit connector B54 Condition Reference value (+) (-) Terminal Terminal 28 27 CAMERA switch is ON or selector lever in R (reverse). Is the inspection result normal? YES: Replace around view monitor control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S21627058292014120500000) ". NO: Replace rear view camera. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S19578528852014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
Right side display output signal diagnosis (Harness disconnection) [U111B]Right side camera image signal circuit open or short.Check right side camera image signal circuit.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK RH SIDE CAMERA POWER SUPPLY AND GROUND CIRCUIT CONTINUITY Turn ignition switch OFF. Disconnect around view monitor control unit and RH side camera connectors. Check continuity between around view monitor control unit connector B54 and RH side camera connector D107. Around view monitor control unit RH side camera Continuity Connector Terminals Connector Terminals B54 34 D107 2 Yes 33 1 Check continuity between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Continuity Connector Terminal B54 34 No Is the inspection result normal? YES: GO TO 2. NO: Repair or replace harness or connectors.
  2. CHECK RH SIDE CAMERA POWER SUPPLY VOLTAGE Connect around view monitor control unit and RH side camera connectors. Turn ignition switch ON. Check voltage between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Condition Voltage (Approx.) Connector Terminal B54 34 - CAMERA switch is ON or selector lever in R (reverse). 6.0 V Is the inspection result normal? YES: GO TO 3. NO: Replace around view monitor control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S21627058292014120500000) ".
  3. CHECK RH SIDE CAMERA IMAGE SIGNAL AND IMAGE SIGNAL GROUND CIRCUIT CONTINUITY Turn ignition switch OFF. Disconnect around view monitor control unit and RH side camera connectors. Check continuity between around view monitor control unit connector B54 and RH side camera connector D107. Around view monitor control unit RH side camera Continuity Connector Terminals Connector Terminals B54 36 D107 8 Yes 35 7 Check continuity between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Continuity Connector Terminal B54 36 No Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness or connectors.
  4. CHECK RH SIDE CAMERA IMAGE SIGNAL Connect around view monitor control unit and RH side camera connectors. Turn ignition switch ON. Check signal between the terminals of around view monitor control unit connector B54. Around view monitor control unit connector B54 Condition Reference value (+) (-) Terminal Terminal 36 35 CAMERA switch is ON or selector lever in R (reverse). Is the inspection result normal? YES: Replace around view monitor control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S21627058292014120500000) ". NO: Replace RH side camera. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S06349626562014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
Front display output signal diagnosis (Harness disconnection) [U111C]Front camera image signal circuit open or short.Check front camera image signal circuit.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK FRONT CAMERA POWER SUPPLY AND GROUND CIRCUIT CONTINUITY Turn ignition switch OFF. Disconnect around view monitor control unit and front camera connectors. Check continuity between around view monitor control unit connector B54 and front camera connector E71. Around view monitor control unit Front camera Continuity Connector Terminals Connector Terminals B54 38 E71 1 Yes 37 2 Check continuity between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Continuity Connector Terminal B54 38 No Is the inspection result normal? YES: GO TO 2. NO: Repair or replace harness or connectors.
  2. CHECK FRONT CAMERA POWER SUPPLY VOLTAGE Connect around view monitor control unit and front camera connectors. Turn ignition switch ON. Check voltage between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Condition Voltage (Approx.) Connector Terminal B54 38 - CAMERA switch is ON or selector lever in R (reverse). 6.0 V Is the inspection result normal? YES: GO TO 3. NO: Replace around view monitor control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S21627058292014120500000) ".
  3. CHECK FRONT CAMERA IMAGE SIGNAL AND IMAGE SIGNAL GROUND CIRCUIT CONTINUITY Turn ignition switch OFF. Disconnect around view monitor control unit and front camera connectors. Check continuity between around view monitor control unit connector B54 and front camera connector E71. Around view monitor control unit Front camera Continuity Connector Terminals Connector Terminals B54 40 E71 3 Yes 39 4 Check continuity between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Continuity Connector Terminal B54 40 No Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness or connectors.
  4. CHECK FRONT CAMERA IMAGE SIGNAL Connect around view monitor control unit and front camera connectors. Turn ignition switch ON. Check signal between the terminals of around view monitor control unit connector B54. Around view monitor control unit connector B54 Condition Reference value (+) (-) Terminal Terminal 40 39 CAMERA switch is ON or selector lever in R (reverse). Is the inspection result normal? YES: Replace around view monitor control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S21627058292014120500000) ". NO: Replace front camera. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S14479361742014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
Left side display output signal diagnosis (Harness disconnection) [U111D]Left side camera image signal circuit open or short.Check left side camera image signal circuit.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK LH SIDE CAMERA POWER SUPPLY AND GROUND CIRCUIT CONTINUITY Turn ignition switch OFF. Disconnect around view monitor control unit and LH side camera connectors. Check continuity between around view monitor control unit connector B54 and LH side camera connector D4. Around view monitor control unit LH side camera Continuity Connector Terminals Connector Terminals B54 30 D4 2 Yes 29 1 Check continuity between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Continuity Connector Terminal B54 30 No Is the inspection result normal? YES: GO TO 2. NO: Repair or replace harness or connectors.
  2. CHECK LH SIDE CAMERA POWER SUPPLY VOLTAGE Connect around view monitor control unit and LH side camera connectors. Turn ignition switch ON. Check voltage between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Condition Voltage (Approx.) Connector Terminal B54 30 - CAMERA switch is ON or selector lever in R (reverse). 6.0 V Is the inspection result normal? YES: GO TO 3. NO: Replace around view monitor control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S21627058292014120500000) ".
  3. CHECK LH SIDE CAMERA IMAGE SIGNAL AND IMAGE SIGNAL GROUND CIRCUIT CONTINUITY Turn ignition switch OFF. Disconnect around view monitor control unit and LH side camera connectors. Check continuity between around view monitor control unit connector B54 and LH side camera connector D4. Around view monitor control unit LH side camera Continuity Connector Terminals Connector Terminals B54 32 D4 8 Yes 31 7 Check continuity between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Continuity Connector Terminal B54 32 No Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness or connectors.
  4. CHECK LH SIDE CAMERA IMAGE SIGNAL Connect around view monitor control unit and LH side camera connectors. Turn ignition switch ON. Check signal between the terminals of around view monitor control unit connector B54. Around view monitor control unit connector B54 Condition Reference value (+) (-) Terminal Terminal 32 31 CAMERA switch is ON or selector lever in R (reverse). Is the inspection result normal? YES: Replace around view monitor control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S21627058292014120500000) ". NO: Replace LH side camera. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S06349626562014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
Cont Unit [U1200]Abnormalities are detected in Navigation control unit.Replace AV control unit if malfunction occurs constantly. Refer to " REMOVAL AND INSTALLATION ".
CONSULT DisplayDTC Detection ConditionPossible Cause
BLUETOOTH MODULE [U1217]Connection failure to the internal Blueooth® sub unit is detected.Replace AV control unit if malfunction occurs constantly. Refer to " REMOVAL AND INSTALLATION ".
CONSULT DisplayDTC Detection ConditionPossible Cause
IPod CERTIFICATION [U1229]IPod authentication chip error.Replace AV control unit if malfunction occurs constantly. Refer to " REMOVAL AND INSTALLATION ".
CONSULT DisplayDTC Detection ConditionPossible Cause
Digital broadcasting connection error [U122F]Communication error with digital audio broadcast module internal to AV control unit.Replace AV control unit if malfunction occurs constantly. Refer to " REMOVAL AND INSTALLATION ".
CONSULT DisplayDTC Detection ConditionPossible Cause
ST ANG SEN CALIB [U1232]The neutral position adjustment of the steering angle sensor is incomplete.Adjust neutral position of the steering angle sensor.
  1. ADJUST THE NEUTRAL POSITION OF THE STEERING ANGLE SENSOR When U1232 is detected, adjust the neutral position of the steering angle sensor. : Perform adjustment of the neutral position of the steering angle sensor. Refer to " «CONSULT FUNCTION»(ref-675624-S19306948042014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
GPS ANTENNA CONN [U1244]Open or short to ground is detected in GPS antenna connection.GPS antenna disconnection. Open or short to ground in GPS antenna signal circuit.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. GPS ANTENNA INSPECTION Visually inspect the GPS antenna and antenna feeder. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S19204498362014120500000) ". Is inspection result normal? YES: GO TO 2. NO: Repair or replace malfunctioning components.
  2. CHECK AV CONTROL UNIT VOLTAGE Disconnect AV control unit connector M108. Turn ignition switch ON. Check voltage between AV control unit connector M108 and ground. AV control unit Ground Voltage Connector Terminal M108 61 - 5.0 V Is inspection result normal? YES: Replace GPS antenna. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S19204498362014120500000) ". NO: Replace AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S08785922072014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
XM ANTENNA CONN [U1258]Open or short to ground is detected in satellite antenna connection.Satellite antenna disconnection. Open or short to ground in satellite antenna signal circuit.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. SATELLITE ANTENNA INSPECTION Visually inspect the satellite antenna and antenna feeder. Refer to " «FEEDER LAYOUT»(ref-675624-S19637552512014120500000) ". Is inspection result normal? YES: GO TO 2. NO: Repair or replace malfunctioning components.
  2. CHECK AV CONTROL UNIT VOLTAGE Turn ignition switch ON. Check voltage between AV control unit connector M109 and ground. AV control unit Ground Voltage Connector Terminal M109 63 - 5.0 V Is inspection result normal? YES: Replace satellite radio antenna " «REMOVAL AND INSTALLATION»(ref-675624-S33739377882014120500000) ". NO: Replace AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S08785922072014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
USB OVERCURRENT [U1263]Overcurrent in USB harness is detected.Device connected to USB interface. Harness between the AV control unit and USB interface.

DTC CONFIRMATION PROCEDURE

  1. PERFORM SELF DIAGNOSTIC RESULT If there is a device connected to the USB interface, disconnect it. Turn ignition switch ON and wait for 2 seconds or more. Perform Self Diagnostic Result for MULTI AV. Is DTC U1263 displayed? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-675624-S08880531372014120500000) ". NO: Inspection End.
  1. CHECK USB INTERFACE HARNESS Visually inspect USB interface harness. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S23805054672014120500000) ". Is the inspection result normal? YES: GO TO 2. NO: Replace USB interface harness. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S23805054672014120500000) ".
  2. CHECK USB INTERFACE HARNESS Check USB interface harness. Refer to " «DIAGNOSIS PROCEDURE»(ref-675624-S21145007612014120500000) ". Is the inspection result normal? YES: Replace AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S08785922072014120500000) ". NO: Replace USB interface harness. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S23805054672014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
ANTENNA AMP TERMINAL [U1264]Open or short to ground is detected in Antenna amp. connection.Antenna amp. disconnection. Open or short to ground in antenna amp. ON signal circuit.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. ANTENNA AMP. INSPECTION Visually inspect the antenna base (antenna amp.) and antenna feeder. Refer to " «FEEDER LAYOUT»(ref-675624-S19637552512014120500000) ". Is inspection result normal? YES: GO TO 2. NO: Repair or replace malfunctioning components.
  2. CHECK CONTINUITY BETWEEN AV CONTROL UNIT AND ANTENNA BASE Turn ignition switch OFF. Disconnect AV control unit connector M73 and antenna base connector M351. Check continuity between AV control unit connector M73 and antenna base connector M351. AV control unit Antenna base Continuity Connector Terminal Connector Terminal M73 58 M351 1 Yes Check continuity between AV control unit connector M73 and ground. AV control unit Ground Continuity Connector Terminal M73 58 - No Is the inspection result normal? YES: GO TO 2. NO: Repair or replace harness or connectors.
  3. CHECK AV CONTROL UNIT VOLTAGE Connect AV control unit connector M73. Turn ignition switch ON. Check voltage between AV control unit connector M73 and ground. AV control unit Ground Voltage (Approx.) Connector Terminal M73 58 - Battery voltage Is the inspection result normal? YES: Replace antenna base. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S23129026362014120500000) ". NO: Replace AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S08785922072014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
Configuration Error [U12AA]AV control unit is not properly configured or configuration is corrupt.Configuration data needs to be written. Refer to " CONFIGURATION (AV CONTROL UNIT): WORK PROCEDURE ".
  1. PERFORM CONFIGURATION When U12AA is detected, configuration data must be written. : Write configuration data with CONSULT. Refer to " «CONFIGURATION (AV CONTROL UNIT): WORK PROCEDURE»(ref-675624-S04625709212014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
Display Temperature too High [U12AC]Display temperature has exceeded maximum temperature. Display is switched OFF to avoid irreversible damage.Replace AV control unit if malfunction occurs constantly. Refer to " REMOVAL AND INSTALLATION ".
CONSULT DisplayDTC Detection ConditionPossible Cause
ECU Temperature too High [U12AD]AV control unit temperature has exceeded maximum temperature.Replace AV control unit if malfunction occurs constantly. Refer to " REMOVAL AND INSTALLATION ".
CONSULT DisplayDTC Detection ConditionPossible Cause
Internal Amplifier temperature Warning [U12AE]Internal amplifier temperature has exceeded maximum temperature.Replace AV control unit if malfunction occurs constantly. Refer to " REMOVAL AND INSTALLATION ".
CONSULT DisplayDTC Detection ConditionPossible Cause
CD Mechanism Temperature Warning [U12AF]CD drive temperature has exceeded maximum temperature. CD drive is switched OFF to avoid irreversible damage.Replace AV control unit if malfunction occurs constantly. Refer to " REMOVAL AND INSTALLATION ".
CONSULT DisplayDTC Detection ConditionPossible Cause
Supply Voltage Goes below 9V > 20s [U12B0]AV control unit supply voltage exceeds lower limits.Charging system malfunction. AV control unit power supply or ground circuits.
  1. CHECK CHARGING SYSTEM Check the vehicle charging system. Refer to " «WORK FLOW (WITH EXP-800 NI OR GR8-1200 NI)»(ref-675585-S30369987922014120500000) " or " «WORK FLOW (WITHOUT EXP-800 NI OR GR8-1200 NI)»(ref-675585-S39576805192014120500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning components.
  2. CHECK AV CONTROL UNIT POWER SUPPLY AND GROUND CIRCUITS Perform the AV control unit power supply and ground circuit diagnosis procedure. Refer to " «AV CONTROL UNIT: DIAGNOSIS PROCEDURE»(ref-675624-S20630893472014120500000) ". Is the inspection result normal? YES: Replace the AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S08785922072014120500000) ". NO: Repair or replace harness or connectors.
CONSULT DisplayDTC Detection ConditionPossible Cause
Supply Voltage Goes High > 16V for 20s [U12B1]AV control unit supply voltage exceeds upper limits.Charging system malfunction.
  1. CHECK CHARGING SYSTEM Check the vehicle charging system. Refer to " «WORK FLOW (WITH EXP-800 NI OR GR8-1200 NI)»(ref-675585-S30369987922014120500000) " or " «WORK FLOW (WITHOUT EXP-800 NI OR GR8-1200 NI)»(ref-675585-S39576805192014120500000) ". Is the inspection result normal? YES: Replace the AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S08785922072014120500000) ". NO: Repair or replace the malfunctioning components.
CONSULT DisplayDTC Detection ConditionPossible Cause
Non-completion of the calibration [U1304]Camera image calibration is incomplete.Perform calibration of camera image.
  1. PERFORM CALIBRATION When U1304 is detected, perform calibration of camera image. : Refer to " «CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR): WORK PROCEDURE»(ref-675624-S09285176182014120500000) ".
CONSULT DisplayDTC Detection ConditionPossible Cause
Non-completion of the configuration [U1305]Configuration of around view monitor control unit is incomplete.Perform configuration of around view monitor control unit.
  1. PERFORM CONFIGURATION When U1305 is detected, perform configration of around view monitor control unit. : Refer to " «CONFIGURATION (AROUND VIEW MONITOR CONTROL UNIT): WORK PROCEDURE»(ref-675624-S05412494292014120500000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK FUSE Check that the following fuses are not blown. Terminal No. Signal name Fuse No. 7 ACC power supply 18 (10A) 19 Battery power supply 29 (15A) 37 Ignition power supply 5 (10A) Are the fuses blown? YES: Replace the blown fuse after repairing the affected circuit. NO: GO TO 2.
  2. CHECK POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect AV control unit connectors M70 and M71. Check voltage between AV control unit connectors M70 and M71 and ground. AV control unit Ground Condition Voltage (Approx.) Connector Terminal M70 19 - Ignition switch: OFF Battery voltage 7 Ignition switch: ON M71 37 Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connectors.
  3. CHECK GROUND CIRCUIT Turn ignition switch OFF. Check continuity between AV control unit connector M70 and ground. AV control unit Ground Continuity Connector Terminal M70 20 - Yes Is the inspection result normal? YES: Inspection End. NO: Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK FUSE Check that the following fuses are not blown. Terminal No. Signal name Fuse No. 4 Ignition signal 5 (10A) 2 Battery power supply 29 (15A) Are the fuses blown? YES: Replace the blown fuse after repairing the affected circuit. NO: GO TO 2.
  2. CHECK POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector B54. Check voltage between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Condition Voltage (Approx.) Connector Terminal B54 4 - Ignition switch: ON Battery voltage 2 Ignition switch: OFF Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connectors.
  3. CHECK GROUND CIRCUIT Turn ignition switch OFF. Check continuity between around view monitor control unit connector B54 and ground. Around view monitor control unit Ground Continuity Connector Terminal B54 1 - Yes Is the inspection result normal? YES: Inspection End. NO: Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CONNECTOR CHECK Check the AV control unit and speaker connectors for the following: Proper connection Damage Disconnected or loose terminals Is the inspection result normal? YES: GO TO 2. NO: Repair the terminals or connectors.
  2. CHECK FRONT DOOR SPEAKER SIGNAL CIRCUIT CONTINUITY Disconnect AV control unit connector M70 and suspect front door speaker connector. Check continuity between AV control unit connector M70 and suspect front door speaker connector. AV control unit Front door speaker Continuity Connector Terminal Connector Terminal M70 2 D12 (LH) 1 Yes 3 2 11 D112 (RH) 1 12 2 Check continuity between AV control unit connector M70 and ground. AV control unit Ground Continuity Connector Terminal M70 2 - No 3 11 12 Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connectors.
  3. CHECK FRONT DOOR SPEAKER SIGNAL Connect AV control unit connector M70 and suspect front door speaker connector. Turn ignition switch to ACC. Push AV control unit POWER switch. Check signal between the terminals of AV control unit connector M70. AV control unit connector M70 Condition Reference value (+) (-) Terminal Terminal 2 3 Audio signal output 11 12 Is the inspection result normal? YES: Replace front door speaker. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S28635914842014120500000) ". NO: Replace AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S08785922072014120500000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CONNECTOR CHECK Check the AV control unit and speaker connectors for the following: Proper connection Damage Disconnected or loose terminals Is the inspection result normal? YES: GO TO 2. NO: Repair the terminals or connectors.
  2. CHECK REAR DOOR SPEAKER SIGNAL CIRCUIT CONTINUITY Disconnect AV control unit connector M70 and suspect rear door speaker connector. Check continuity between AV control unit connector M70 and suspect rear door speaker connector. AV control unit Rear door speaker Continuity Connector Terminal Connector Terminal M70 4 D207 (LH) 1 Yes 5 2 13 D307 (RH) 1 14 2 Check continuity between AV control unit connector M70 and ground. AV control unit Ground Continuity Connector Terminal M70 4 - No 5 13 14 Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connectors.
  3. CHECK REAR DOOR SPEAKER SIGNAL Connect AV control unit connector M70 and suspect rear door speaker connector. Turn ignition switch to ACC. Push AV control unit POWER switch. Check signal between the terminals of AV control unit connector M70. AV control unit connector M70 Condition Reference value (+) (-) Terminal Terminal 4 5 Audio signal output 13 14 Is the inspection result normal? YES: Replace rear door speaker. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S20188638522014120500000) ". NO: Replace AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S08785922072014120500000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK MICROPHONE SIGNAL CIRCUIT CONTINUITY Turn ignition switch OFF. Disconnect AV control unit connector M71 and microphone connector R15. Check continuity between AV control unit connector M71 and microphone connector R15. AV control unit Microphone Continuity Connector Terminal Connector Terminal M71 41 R15 2 Yes 42 4 43 1 Check continuity between AV control unit connector M71 and ground. AV control unit Ground Continuity Connector Terminal M71 42 - No 43 Is inspection result normal? YES: GO TO 2. NO: Repair or replace harness or connectors.
  2. CHECK MICROPHONE VCC VOLTAGE Connect AV control unit connector M71. Turn ignition switch ON. Check voltage between terminals of AV control unit connector M71. AV control unit connector M71 Voltage (Approx.) (+) (-) Terminal Terminal 42 41 5.0 V Is the inspection result normal? YES: GO TO 3. NO: Replace AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S08785922072014120500000) ".
  3. CHECK MICROPHONE SIGNAL Connect microphone connector. Check signal between terminals of AV control unit connector M71. AV control unit connector M71 Condition Reference value (+) (-) Terminal Terminal 43 41 Speak into microphone. Is the inspection result normal? YES: Replace AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S08785922072014120500000) ". NO: Replace microphone. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S36465127372014120500000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK STEERING WHEEL AUDIO CONTROL SWITCH RESISTANCE Turn ignition switch OFF. Disconnect combination switch connector M88. Check resistance between the terminals of combination switch connector M88. Combination switch connector M88 Condition Resistance ohms (Approx.) Terminal Terminal 14 17 Depress SOURCE switch. 1 Depress ↑ switch. 121 Depress switch. 321 Depress switch. 723 15 Depress- switch. 1 Depress + switch. 121 Depress switch. 321 Is the inspection result normal? YES: GO TO 2. NO: Replace steering switches. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S34988579272014120500000) ".
  2. CHECK COMBINATION SWITCH Check continuity between combination switch connectors M88 and M30. Combination switch Continuity Connector Terminal Connector Terminal M88 14 M30 24 Yes 15 31 17 33 Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «REMOVAL AND INSTALLATION»(ref-675573-S26258277352014120500000) ".
  3. CHECK HARNESS BETWEEN COMBINATION SWITCH AND AV CONTROL UNIT Disconnect AV control unit connector M70. Check continuity between combination switch connector M30 and AV control unit connector M70. Combination switch AV control unit Continuity Connector Terminal Connector Terminal M30 24 M70 6 Yes 31 16 33 15 Check continuity between combination switch connector M30 and ground. Combination switch Ground Continuity Connector Terminal M30 24 - No 31 33 Is the inspection result normal? YES: Replace AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S08785922072014120500000) ". NO: Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK USB INTERFACE HARNESS CONTINUITY Turn ignition switch OFF. Disconnect AV control unit connector M76 and USB interface connector M72. Check continuity between AV control unit connector M76 and USB interface connector M72. AV control unit USB interface Continuity Connector Terminal Connector Terminal M76 53 M72 4 Yes 55 2 56 3 57 5 Check continuity between AV control unit connector M76 and ground. AV control unit - Continuity Connector Terminal M76 53 Ground No 55 Is the inspection result normal? YES: Replace the USB interface. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S23805054672014120500000) ". NO: Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

  1. CHECK AUX JACK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect AV control unit connector M71 and AUX jack connector M215. Check continuity between AV control unit connector M71 and AUX jack connector M215. AV control unit AUX jack Continuity Connector Terminal Connector Terminal M71 30 M215 1 Yes 31 3 32 4 Check continuity between AV control unit connector M71 and ground. AV control unit - Continuity Connector Terminal M71 30 Ground No 32 Is the inspection result normal? YES: Replace the AUX jack. Refer to " «REMOVAL AND INSTALLATION»(ref-675624-S01300864522014120500000) ". NO: Repair or replace harness or connectors.

More articles — Audio, Visual & Navigation System (Navigation)
