Engine Mechanical: Removal & Installation Nissan Note E12

Removal and Disassembly

1. When instructed to use SST, use specified tools. Always be careful to work safely, avoid forceful or unin-structed operations.
2. Use care to avoid damage to mating or sliding surfaces.
3. Dowel pins are used for several parts alignment. When replacing and reassembling parts with dowel pins, check that dowel pins are installed in the original position.
4. Cover openings of engine system with a tape or equivalent, if necessary, to seal out foreign materials.
5. Mark and arrange disassembly parts in an organized way for easy troubleshooting and reassembly.
6. When loosening nuts and bolts, start with the one furthest outside, then the one diagonally opposite, and so on. If the order of loosening is specified, do exactly as specified. Power tools may be used in the step.

Assembly and Installation

1. Use torque wrench to tighten bolts or nuts to specification.
2. Tighten nuts and bolts in order exactly as specified in the procedure. If a tightening order or procedure is not specified, tighten nuts and bolts equally in several different steps. Start with the nuts or bolts in the center and then tighten diagonally starting with the inside and moving to the outside in a spiral pattern.
3. Replace with new gasket, packing, oil seal or O-ring.
4. Thoroughly wash, clean, and air-blow each part. Carefully check engine oil or engine coolant passages for restrictions and blockages.
5. Avoid damaging sliding or mating surfaces. Before assembling, completely remove foreign materials such as cloth lint or dust, and oil the sliding surfaces.
6. After refilling engine coolant, bleed the air from the cooling system.
7. After repairing, start the engine and increase engine speed to check for engine coolant leaks, fuel leaks, engine oil leaks, and exhaust gas leaks.

REMOVAL

1. Remove engine undercover. Refer to " «FRONT UNDER COVER: REMOVAL AND INSTALLATION»(ref-675580-S30708354602014120500000) ".
2. Remove wheel and tire (RH) using a power tool. Refer to " «REMOVAL AND INSTALLATION»(ref-675581-S28220831532014120500000) ".
3. Partially remove the fender protector (RH). Refer to " «REMOVAL AND INSTALLATION»(ref-675580-S35121108852014120500000) ".
4. Loosen the lock nut and then release the belt tension by turning the adjusting bolt.
5. Remove the drive belt.

INSTALLATION

1. Pull the idler pulley in the loosening direction, and then temporarily tighten the lock nut to the following torque. Lock nut: 4.4 N.m (0.45 kg-m, 39 in-lb) (Temporary tightening) NOTE: Do not move the lock nut from the temporary tightened position. Go to step 2.
2. Install the drive belt on each pulley. CAUTION: Check that there is no engine oil, grease, or engine coolant, etc. in pulley grooves. Check that the belt seats securely inside the groove on each pulley.
3. Adjust drive belt tension by turning the adjusting bolt. Refer to " «ADJUSTMENT»(ref-675577-S02767297912014120500000) ". CAUTION: Perform the belt tension adjustment with the lock nut temporarily tightened to the torque specification listed in step 1 which prevents the idler pulley from tilting. When checking immediately after installation, first adjust it to the specified value. Then, after turning crankshaft two turns or more, readjust to the specified value to avoid variation in deflection between pulleys.
4. Tighten the lock nut to final tightening specification. Lock nut (Final tightening): 34.8 N.m (3.5 kg-m, 26 ft-lb)
5. Check that belt tension is within the specification using suitable tool. Refer to " «DRIVE BELT»(ref-675577-S35610149322014120500000) ".

Scheme 36

1. Inspection should be done only when engine is cold or over 30 minutes after the engine is stopped.
2. Visually check belt for wear, damage, and cracks on inside and edges.
3. Turn crankshaft pulley clockwise twice, and check that the tension on all pulleys equalizes before testing.
4. When measuring deflection, apply 98.1 N (10 kg, 22 lb) at the ( <==)) marked point.
5. Measure the belt tension and frequency using suitable tool at the ( <==)) marked point. CAUTION: When checking immediately after installation, first adjust it to the specified value. Then, after turning crankshaft two turns or more, readjust to the specified value to avoid variation in deflection between pulleys. Belt deflection/belt tension and frequency: Refer to " «DRIVE BELT»(ref-675577-S35610149322014120500000) ".

Installation is in the reverse order of removal.

Note. Check that the air cleaner filter is securely placed in the air cleaner body.

Scheme 37

Scheme 38

1. Remove ignition coil. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S28920989812014120500000) ". CAUTION: Do not drop or shock ignition coil.
2. Remove spark plug using a suitable tool. Diameter (a): 14 mm (0.55 in) CAUTION: Do not drop or shock spark plug.

Scheme 39

Scheme 40

1. If the spark plug tip is covered with carbon, a spark plug cleaner may be used. Cleaner air pressure: Less than 588 kPa (6 kg/cm 2 , 85 psi) Cleaning time: Less than 20 seconds CAUTION: Do not use a wire brush for cleaning.
2. Checking and adjusting spark plug gap is not required between change intervals. Do not adjust the gap; replace the spark plug as necessary if out of specification.

Installation is in the reverse order of removal.

Note. The ground electrode of the spark plug is positioned in the area of maximum ignitability to improve combustion eficiency in the cylinder, reduce CO2 (carbon dioxide) emission and improve fuel economy.

Scheme 41

Scheme 42

1. Remove the fender protector (RH). Refer to " «REMOVAL AND INSTALLATION»(ref-675580-S35121108852014120500000) ".
2. Remove the air duct inlet assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S21280789682014120500000) ".
3. Remove drive belt. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S24278316382014120500000) ".
4. Remove the lock nut, and then remove the plate, tensioner idler pulley, and washer.
5. Remove the center shaft together with the spacer and the adjusting bolt.

Scheme 43

1. Insert the center shaft (1) into the slide groove of the spacer (2). Fully screw in the adjusting bolt (3) in the belt loosening direction ( <==)). At that time, place the flange (a) of the adjusting bolt and the seat (b) of the center shaft on the spacer.
2. Place each surface (c/d) of the spacer on the generator bracket. Install the washer, tensioner idler pulley, and plate, and then temporarily tighten the lock nut. Lock nut (Temporary tightening): 4.4 N.m (0.45 kg-m, 39 in-lb)
3. Installation of remaining components is in the reverse order of removal.

Scheme 44

Note. Mass air flow sensor is removable as an assembly with the air cleaner cover.

1. Remove air duct (inlet) from the air cleaner body.
2. Disconnect PCV hose from the air duct.
3. Remove the air duct (between air cleaner case and electric throttle control actuator). Add matching marks if necessary for easier installation.
4. Remove air cleaner assembly with the following steps: Disconnect the mass air flow sensor harness connector. Remove the air cleaner body bolts. Pull up on the air cleaner assembly to disengage it from the grommet and remove the air cleaner assembly. CAUTION: Do not shock the mass air flow sensor. Do not disassemble the mass air flow sensor. Do not touch the sensor of the mass air flow sensor.

Installation is in the reverse order of removal.

Note. Align marks, attach each joint and screw clamps firmly.

Scheme 45

Note. When removing components such as hoses, tubes/lines, etc., cap or plug openings to prevent fluid from spilling.

Scheme 46

Scheme 47

1. Remove air duct (inlet), air duct and air cleaner. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S21280789682014120500000) ".
2. Disconnect water hoses from the electric throttle actuator (if necessary). CAUTION: Perform this step when the engine is cold. Do not spill engine coolant on the drive belt.
3. Remove electric throttle control actuator. CAUTION: Handle carefully to avoid any shock to electric throttle control actuator. Do not disassemble electric throttle control actuator.
4. Disconnect EVAP purge control solenoid valve harness connector and vacuum hose from EVAP purge control solenoid valve. CAUTION: Handle EVAP canister purge volume control solenoid valve carefully and avoid impacts.
5. Disconnect vacuum hose for brake booster from intake manifold.
6. Remove intake manifold bolts (A) at the rocker cover.
7. Loosen bolts in reverse order as shown in the figure. CAUTION: Cover engine openings to avoid entry of foreign materials.
8. Remove intake manifold and intake manifold gasket.
9. Remove EVAP purge control solenoid valve from intake manifold (if necessary). CAUTION: Handle EVAP canister purge volume control solenoid valve carefully and avoid impacts.

Installation is in the reverse order of removal.

Scheme 48

1. Install the new intake manifold gasket to the intake manifold. Align the protrusions used for checking gasket installation condition with the clearance grooves (A) of the intake manifold groove. CAUTION: Do not reuse the intake manifold gasket. NOTE: New gasket for electric throttle control actuator can be installed when the electric throttle control actuator is installed.
2. Place the intake manifold into position. CAUTION: Check that the oil level gauge guide is not detached from the securing clip of the water inlet due to interference of intake manifold.
3. Tighten the bolts to specification in the numerical order as shown in the figure.
4. Tighten the intake manifold bolts (A) to specification at the rocker cover. Intake manifold bolts (A) 25.0 Nm (2.6 kg-m, 18 in-lb

Installation is in the reverse order of removal. Note the following

Scheme 49

Scheme 50

1. Drain engine oil. Refer to " «DRAINING»(ref-675583-S07061512712014120500000) ".
2. Loosen bolts in reverse order as shown in the figure.
3. Insert Tool (A) between oil pan (upper) and oil pan (lower). Tool number: KV10111100 (J-37228) CAUTION: Do not damage mating surfaces. Do not insert a screwdriver. This damages the mating surfaces.
4. Slide the Tool (A) by tapping on the side of tool with a suitable tool to loosen the oil pan (lower).
5. Remove oil pan (lower).

Scheme 51

Scheme 52

Scheme 53

1. Remove old liquid gasket from mating surfaces using suitable tool (A). Also remove old liquid gasket from mating surface of oil pan (upper). Remove old liquid gasket from the bolt holes and threads. CAUTION: Do not scratch or damage the mating surface when cleaning off old liquid gasket.
2. Apply a continuous bead of liquid gasket (A) with a tube presser as shown in the figure. Use Genuine Silicone RTV Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-675571-S19021012742014120500000) " CAUTION: Installation should be done within 5 minutes after applying liquid gasket. Do not fill the engine with oil for at least 30 minutes after the components are installed to allow the sealant to cure.
3. Tighten bolts in numerical order as shown in the figure.
4. Install oil pan drain plug. CAUTION: Do not reuse drain plug washer. Refer to exploded view installation direction of drain plug washer. Refer to «OIL PAN AND OIL STRAINER»(ref-675577-S04208161342014120500000) .
5. Refill the engine with engine oil. Refer to " «REFILLING»(ref-675583-S42901076442014120500000) ".

Removal and Installation (Upper Oil Pan)

Note. The oil strainer is included in the oil pan (upper) and cannot be removed.

Scheme 54

Scheme 55

1. Remove the oil pan (lower). Refer to " «REMOVAL AND INSTALLATION (LOWER OIL PAN)»(ref-675577-S21629391792014120500000) ".
2. Remove oil pump sprocket and crankshaft sprocket together with oil pump drive chain. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S36953346832014120500000) ".
3. Remove oil pan (upper). Loosen oil pan (upper) bolts in the reverse of the order as shown in the figure. Insert a suitable tool into the position ( <==)) as shown and open up a crack between the oil pan (upper) cylinder block. Insert the Tool between the oil pan (upper) and cylinder block. Slide Tool by tapping on the side of Tool with a hammer. Tool number: KV10111100 (J-37228) CAUTION: Be careful not to damage the mating surface. The liquid gasket used at the factory is very strong. Pry only in the areas shown in the figure. Do not remove oil pump and oil strainer from oil pan (upper).
4. Remove rear oil seal from crankshaft.

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. Install the oil pan (upper): Remove old liquid gasket from mating surfaces using a suitable tool. Remove old liquid gasket from mating surface of cylinder block. Remove old liquid gasket from the bolt holes and threads. CAUTION: Do not scratch or damage the mating surfaces when cleaning off liquid gasket. Install O-ring to the cylinder block. Apply a continuous bead of liquid gasket to areas as shown using a suitable tool. Use Genuine Silicone RTV Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-675571-S19021012742014120500000) ". CAUTION: Attaching should be done within 5 minutes after coating. Allow 30 minutes for the liquid gasket to set before adding oil to the engine. Tighten bolts in the numerical order as shown in the figure. CAUTION: Install avoiding misalignment of both oil pan gasket and O-ring. The bolts are different according to the installation position. Refer to the numbers as shown in the figure. M8x180 mm (7.09 in) bolts: No. 9, 10 25.0 N.m (2.6 kg-m, 18 ft-lb) M8x25 mm (0.98 in) bolts: No. 4, 7, 8 25.0 N.m (2.6 kg-m, 18 ft-lb) M8x90 mm (3.54 in) bolts: No. 1, 2, 3, 5, 6 25.0 N.m (2.6 kg-m, 18 ft-lb)
2. Install rear oil seal: CAUTION: Installation of rear oil seal should be completed within 5 minutes after installing oil pan (upper). Do not reuse rear oil seal. Do not touch oil seal lip. Wipe off any liquid gasket protruding to the rear oil seal mounting part of oil pan (upper) and cylinder block using a suitable tool. Apply the liquid gasket lightly to entire outside area of new rear oil seal. Use Genuine Liquid Gasket or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-675571-S19021012742014120500000) ". Press-fit the rear oil seal using a suitable drift (A) with outer diameter 113 mm (4.45 in) and inner diameter 90 mm (3.54 in). Press-fit to the specified dimensions as shown in the figure. CAUTION: Do not touch the grease applied to the oil seal lip. Be careful not to damage the rear oil seal mounting part of oil pan (upper) and cylinder block or the crankshaft. Press-fit straight and check that oil seal does not curl or tilt. After press-fitting the rear oil seal, completely wipe off any liquid gasket protruding to rear end surface side.
3. Installation of the remaining components is in the reverse order of removal.

Removal and Installation

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

1. Release the fuel pressure. Refer to " «WORK PROCEDURE»(ref-675578-S29860079602014120500000) ".
2. Remove intake manifold. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S04088089192014120500000) ".
3. Disconnect fuel feed hose from fuel tube. Disconnect quick connector: NOTE: There is no fuel return path. Remove quick connector cap (engine side) (1) from quick connector connection. Disconnect fuel feed hose from hose clamp. With the sleeve (B) side of quick connector release (A) facing quick connector (2), install quick connector release (A) onto fuel tube (1) as shown in the figure. Insert quick connector release (A) into quick connector (2) until sleeve (B) contacts and goes no further. Hold quick connector release (A) in that position (D). CAUTION: Inserting quick connector release hard will not disconnect quick connector. Hold quick connector release where it contacts and goes no further. Draw and pull out quick connector (E) straight up from fuel tube (1). CAUTION: Pull quick connector up (E) from holding position (C) as shown in the figure. Do not pull with lateral force applied. O-ring inside quick connector may be damaged. Prepare container and cloth beforehand as fuel will leak out. Discard O-ring, do not reuse. Avoid fire and sparks. Keep parts away from heat source. Be especially careful when welding is performed. Do not expose parts to battery electrolyte or other acids. Do not bend or twist connection between quick connector and fuel feed tube during installation or removal. Be sure to cover openings of disconnected fuel feed hose (A) and fuel tube (C) with plug or plastic bag (B) to avoid fuel leaks and entry of foreign material.
4. Disconnect fuel feed hose from fuel pipe as follows: NOTE: There is no fuel return path. Remove quick connector cap (floor piping side) (1) from quick connector connection. Disconnect fuel feed hose from hose clamp (1). Hold the quick connector (1) while pushing in tabs (F), and pull out the hard tube (A). CAUTION: Inserting quick connector release hard will not disconnect quick connector. Hold quick connector release where it contacts and goes no further. The tube can be removed when the tabs are completely depressed. Do not twist it more than necessary. Do not use any tools to remove the quick connector. Keep the resin tube away from heat. Be especially careful when welding near the tube. Prevent acid such as battery electrolyte etc. from getting on the resin tube. Do not bend or twist the tube during installation and removal. Remove the remaining retainer only when the tube is replaced. When the tube is replaced, also replace the retainer. Be sure to cover openings of disconnected pipes with plug or plastic bag (B) to avoid fuel leaks and entry of foreign material.
5. Disconnect harness connectors from fuel injectors.
6. Disconnect harness connectors from intake and exhaust valve timing control solenoid valves.
7. Remove fuel tube protector. Loosen bolts in reverse order as shown in the figure.
8. Remove fuel injector and fuel tube assembly: Loosen two nuts in reverse order as shownin the figure. Pull the fuel tube straight out until injector lower O-rings are clear. Remove the nuts and the fuel tube. CAUTION: When removing, be careful to avoid interference with fuel injectors. Use a shop cloth to absorb any fuel leaks from fuel tube.
9. Remove fuel injector from fuel tube: Open and remove clip (1). Remove fuel injectors (3) and (4) from fuel tube (2) by pulling straight out. CAUTION: Be careful with remaining fuel that may leak from fuel tube. Be careful not to damage fuel injector nozzle during removal. Do not bump or drop fuel injector. Do not disassemble fuel injector. Do not reuse O-rings.

Scheme 70

Scheme 71

Scheme 72

Scheme 73

1. Install O-rings on the fuel injector. CAUTION: Upper and lower O-rings are different. Be careful not to interchange them. Fuel tube side: Black Nozzle side: Green Handle O-ring with bare hands. Do not wear gloves. Lubricate O-ring with new engine oil. Do not clean O-ring with solvent. Check that O-ring and its mating part are free of foreign material. When installing O-ring, be careful not to scratch it. Do not twist or stretch O-ring. If O-ring was stretched while it was being attached, allow it to retract before inserting it into fuel tube. Insert O-ring straight into fuel tube. Do not angle or twist it.
2. Install fuel injector (4) to fuel tube (1): Insert new clip (2) into clip groove (G) on fuel injector (4). Insert new clip (2) so that protrusion (F) of fuel injector matches cut-out (D) of clip. CAUTION: Do not reuse clip. Replace it with a new one. Be careful to keep clip from interfering with O-ring. If interference occurs, replace O-ring. Insert fuel injector (4) into fuel tube (1) with clip (2) attached. Insert fuel injector (4) while matching it to the axial center. Insert fuel injector (4) so that protrusion (B) of fuel tube matches cut-out (C) of clip (2). Check that fuel tube flange (A) is securely located in flange groove (E) on clip (2). Check that installation is complete by checking that fuel injector (4) does not rotate or come off.
3. Set fuel tube and fuel injector assembly in position for installation on cylinder head. CAUTION: For installation, be careful not to interfere with fuel injector nozzle. Tighten bolts in numerical order as shown in the figure.
4. Install fuel tube protector. Tighten bolts in numerical order as shown in the figure.
5. Connect harness connectors to fuel injectors.
6. Connect harness connectors to intake and exhaust valve timing control solenoid valves.
7. Connect fuel feed tube (engine side): Check for damage or foreign material on the fuel tube and quick connector. Apply new engine oil lightly to area around the top of fuel tube. Align center to insert quick connector straight into fuel tube. Insert quick connector (1) to fuel tube until the top spool (C) on fuel tube is inserted completely and the 2nd level spool (D) is positioned slightly below quick connector bottom end. CAUTION: Hold in position (A) as shown when inserting fuel tube into quick connector. Carefully align center to avoid inclined insertion to prevent damage to O-ring inside quick connector. Insert until you hear a "click" sound and actually feel the engagement. To avoid misidentification of engagement with a similar sound, pull quick connector hard by hand. Check it is completely engaged (connected) so that it does not come out from fuel tube. Install quick connector cap (engine side) (1) to quick connector connection. Install quick connector cap (engine side) (1) with the side arrow facing quick connector side (fuel feed tube side) as shown below. CAUTION: Check that the quick connector and fuel tube are securely engaged with the quick connector cap (engine side) groove. If the quick connector cap (engine side) cannot be installed easily the quick connector may not be connected correctly. Remove and reconnect. Install fuel feed hose to hose clamp.
8. Connect fuel feed tube (floor piping side): Check the connection for damage or any foreign materials. Align the quick connector with the tube, then insert the connector straight into the centralized under floor piping until a click is heard. After connecting, check that the connection is secure: Visually confirm that the two retainer tabs are connected to the connector. With the fuel feed hose not fixed to the clamp, pull quick connector (A) hard by hand to check that the quick connector (A) is not disconnected from the centralized underfloor piping (1) and that the quick connector (1) is securely connected.
9. Install remaining parts in the reverse order of removal.

Scheme 74

1. Disconnect the battery negative terminal.
2. Remove intake manifold. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S04088089192014120500000) ".
3. Remove ignition coil. CAUTION: Do not drop or shock ignition coil. Do not disassemble ignition coil.

1. Installation is in the reverse order of removal.

Scheme 75

Scheme 76

1. Remove ignition coil. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S29901089692014120500000) ".
2. Remove fuel tube protector. Refer to " «EXPLODED VIEW»(ref-675577-S06336226562014120500000) ".
3. Remove PCV hose from rocker cover.
4. Remove PCV valve (if necessary).
5. Remove rocker cover. Loosen bolts in reverse order as shown in the figure.
6. Remove rocker cover gasket from rocker cover.
7. Remove all traces of liquid gasket from cylinder head and front cover using suitable tool. CAUTION: Do not scratch or damage the mating surface when cleaning off old liquid gasket.

Scheme 77

Scheme 78

Scheme 79

1. Install the rocker cover: Press gasket onto the bosses for the rocker cover bolt holes as shown to prevent the gasket from dropping off. Apply liquid gasket to the cylinder head (1) and front cover (2) as shown in the figure. Use Genuine RTV Silicone Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-675571-S19021012742014120500000) ". CAUTION: The components must be installed within 5 minutes of the liquid gasket application. Then allow 30 minutes for the liquid gasket to set before putting oil in the engine. Install rocker cover to cylinder head. CAUTION: Check that the gasket has not slipped out of position. Tighten bolts in numerical order in at least three separate stages as shown in the figure.
2. Installation of the remaining components is in the reverse order of removal.

Scheme 80

Note. When removing components such as hoses, tubes/lines, etc., cap or plug openings to prevent fluid from spilling. When removing the camshafts, the oil pump drive chain does not need to be removed.

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

1. Remove front wheel and tire (RH). Refer to " «REMOVAL AND INSTALLATION»(ref-675581-S28220831532014120500000) ".
2. Remove front fender protector (RH). Refer to " «REMOVAL AND INSTALLATION»(ref-675580-S35121108852014120500000) ".
3. Drain engine oil. Refer to " «DRAINING»(ref-675583-S07061512712014120500000) ". CAUTION: Perform this step when engine is cold. Do not spill engine oil on drive belt.
4. Drain coolant. Refer to " «DRAINING ENGINE COOLANT»(ref-675579-S13508668632014120500000) ".
5. Remove the drive belt. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S24278316382014120500000) ".
6. Remove the rocker cover. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S28920989812014120500000) ".
7. Remove the water pump pulley. Refer to " «REMOVAL AND INSTALLATION»(ref-675579-S29301848412014120500000) ".
8. Support the bottom surface of engine (1) using a transmission jack (2), and then remove engine mounting insulator (RH). Refer to " «EXPLODED VIEW»(ref-675577-S30174247702014120500000) ". CAUTION: Position a suitable jack under the engine and transaxle assembly as shown in the figure. Do not damage the front exhaust tube or transaxle oil pan with the jack.
9. Set No. 1 cylinder at TDC of its compression stroke: Rotate crankshaft pulley (2) clockwise and align TDC mark (without paint mark) (A) to timing indicator (1) on front cover. Check the matching marks on each camshaft sprocket are positioned as shown in the figure. If not, rotate crankshaft pulley one more turn to align matching marks to the positions.
10. Remove crankshaft pulley: Secure crankshaft pulley (1) using suitable tool (A) and loosen crankshaft pulley bolt. CAUTION: Do not remove the crankshaft pulley bolt as it will be used as a supporting point for the pulley puller. Attach Tool (A) in the M 6 thread hole on crankshaft pulley, and remove crankshaft pulley. Tool number: KV11123000 (-)
11. Remove front cover: Loosen bolts in the reverse order as shown in the figure. Cut liquid gasket by prying the position ( (<==) as shown in the figure, and then remove the front cover.
12. Remove front oil seal from front cover using a suitable tool. CAUTION: Be careful not to damage the front cover.
13. Remove chain tensioner (1): Fully push down the chain tensioner lever (A), and then push the plunger (C) into the inside of tensioner. The tab (B) is released by fully pushing the lever down. Then the plunger can be moved. Pull up the lever to align its hole position with the body hole position. When the lever hole is aligned with the body hole position, the plunger is secured. When the protrusion parts of the plunger ratchet and the tab face each other, both hole positions are not aligned. At that time, correctly engage them and align these hole positions by slightly moving the plunger. Insert the stopper pin (D) into the body hole through the lever hole, and then secure the lever at the upper position. NOTE: A hexagonal wrench of 2.5 mm (0.098 in) is used as a stopper pin (D). Remove chain tensioner.
14. Remove the timing chain tension guide (2) and the timing chain slack guide (1).
15. Remove the timing chain (2). Pull the timing chain slack toward the camshaft sprocket (EXH) (1), and then remove the timing chain and start the removal from camshaft sprocket (EXH) side. CAUTION: Do not rotate crankshaft or camshaft while timing chain is removed. It causes interference between valve and piston.
16. Remove the crankshaft sprocket and the oil pump drive: Remove oil pump drive chain tensioner (1). Pull out from the shaft (B) and spring attaching holes (A). Hold the top of the oil pump shaft using the socket (size: E8), and then loosen the oil pump sprocket nut and remove it. Remove the crankshaft sprocket (1), the oil pump drive chain (2), and the oil pump sprocket (3) at the same time.

Note. For installation follow the relationship between the matching mark on each timing chain and that of the corresponding sprocket, with the components installed.

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

1. Install the crankshaft sprocket and the oil pump drive related parts: Install the crankshaft sprocket (1), the oil pump drive chain (2), and the oil pump sprocket (3) at the same time. Install the crankshaft sprocket so that its invalid gear area (A) is toward the back of the engine. Install the oil pump sprocket so that its protrusion faces the front of engine. NOTE: There is no matching mark in the oil pump drive related parts. Hold the top of the oil pump shaft using the socket (size: E8), and then tighten the oil pump sprocket nut. Install oil pump drive chain tensioner (1). Insert the body into the shaft (B) while inserting the spring into the attaching hole (A) of cylinder block front surface. Check that the tension is applied to the oil pump drive chain after installing.
2. Install timing chain: Install by aligning matching marks on each sprocket and timing chain. If these matching marks are not aligned, rotate the camshaft slightly to correct the position. CAUTION: After the matching marks are aligned, keep them aligned by holding them. To avoid skipped teeth, do not rotate crankshaft and camshaft until front cover is installed.
3. Install timing chain tension guide (2) and timing chain slack guide (1).
4. Install chain tensioner (1). Secure the plunger at the most compressed position using a stopper pin (A), and then install it. Pull out the stopper pin after installing the chain tensioner.
5. Check matching mark position of timing chain and each sprocket again.
6. Install the front oil seal to the front cover. Refer to " «FRONT OIL SEAL: REMOVAL AND INSTALLATION»(ref-675577-S15120475872014120500000) ".
7. Install front cover with the following procedure: Apply a continuous bead of liquid gasket to the engine block joint locations (A) as shown in the figure. Use Genuine Silicone RTV Sealant or equivalent . Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-675571-S19021012742014120500000) " CAUTION: Do not confirm torque after the 5 minutes have elapsed. Do not confirm torque after the 5 minutes have elapsed. Then allow 30 minutes for the liquid gasket to set before adding oil to the engine. Apply a continuous bead of liquid gasket to front cover as shown using suitable tool. Use Genuine Silicone RTV Sealant or equivalent . Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-675571-S19021012742014120500000) ". CAUTION: Do not confirm torque after the 5 minutes have elapsed. Do not confirm torque after the 5 minutes have elapsed. Then allow 30 minutes for the liquid gasket to set before adding oil to the engine. Tighten bolts in the numerical order as shown in the figure. NOTE: Refer to the following for the installation position of bolts. M6 bolt: No. 1 6.6 N.m (0.67 kg-m, 58 in-lb) M10 bolts: No. 11, 12, 13 55.0 N.m (5.6 kg-m, 41 ft-lb) M10 bolts: No. 14, 15 55.0 N.m (5.6 kg-m, 41 ft-lb) M8 bolts: Except above 25.0 N.m (2.6 kg-m, 18 ft-lb) After all bolts are tightened, retighten them to specified torque in numerical order as shown in the figure. CAUTION: Be sure to wipe off any excessive liquid gasket leaking to surface.
8. Insert crankshaft pulley by aligning with crankshaft key. When inserting crankshaft pulley with a plastic hammer, tap on its center portion (not circumference). CAUTION: Do not damage front oil seal lip section.
9. Tighten crankshaft pulley bolt: Secure crankshaft pulley with a suitable tool and tighten crankshaft pulley bolt. Apply new engine oil to thread and seat surfaces of crankshaft pulley bolt. Tighten crankshaft pulley bolt. Crankshaft pulley bolt: 35.0 N.m (3.6 kg-m, 26 ft-lb) Put a paint mark (B) on crankshaft pulley, mating with any one of I six easy to recognize angle marks (A) on crankshaft bolt flange (1). Turn another 60 degrees clockwise (angle tightening). Check the tightening angle with movement of one angle mark.
10. Check that crankshaft turns smoothly by rotating by hand clockwise using suitable tool.
11. Installation of the remaining components is in the reverse order of removal.

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

1. Remove timing chain. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S36953346832014120500000) "
2. Remove camshaft sprocket (EXH) (1). CAUTION: Hold the camshaft hexagonal part (A), and then secure the camshaft. Do not rotate crankshaft and camshaft separately, so as not to contact valve with piston. NOTE: The timing chain with the front cover installed is not disengaged from the crankshaft sprocket and it is not dropped into the front cover. Therefore, the timing chain tension holding device is not necessary.
3. Turn the camshaft sprocket (INT) to the most advanced position. CAUTION: Installation and removal of the camshaft sprocket (INT) must be done in the most advanced position. Make sure to follow the procedure exactly. The sprocket (C) and vane (camshaft coupling) (B) are designed to spin and move within the range of a certain angle. With the engine stopped and the vane in the most retarded angle, it will not spin because it is locked to the sprocket side by the internal lock pin (A). If the camshaft sprocket bolts are turned in the situation described above, the lock pin will become damaged and cause malfunctions because of the increased horizontal load (cutting force) on the lock pin. Put the camshaft sprocket (INT) in the most advanced position: Remove camshaft bracket (No. 1) (1). NOTE: Timing chain is present only for illustration purposes. Timing chain is to be removed during removal procedure. Loosen the bolts in several steps, and then remove them. Apply the following air pressure to the No. 1 journal oil hole (A) of camshaft (INT) (1) shown using an air gun. Air pressure: 300 kPa (3.1 kg/cm 2 , 44 psi) or more Apply the air pressure into the oil hole on the second groove from the front of camshaft thrust (B). Proceed all the way through step "e" with the air pressure on. Attach the rubber nozzle narrowed to the top of the air gun to prevent air leaks from the oil hole (A). Securely apply the air pressure to the oil hole. WARNING: Eye protection should be worn as needed. CAUTION: There are other oil holes in the side grooves. Do not use the incorrect oil holes. Be sure not to damage the oil path with the tip of the air gun. Wipe all the oil off the air gun to prevent oil from being blown all over along with the air, and the area around the air gun should be wiped with a rag when applying air pressure. NOTE: The air pressure is used to move the lock pin into the disengage position. Hold the camshaft sprocket (INT) with hands, and then apply the power counterclockwise/clockwise alternately. Finally rotate the sprocket of the camshaft sprocket (INT) counterclockwise [the direction shown by the arrow ( (<==)]. Perform the work while continuously applying the air pressure to the oil hole. If the lock pin is not released, tap the camshaft sprocket (INT) lightly with a plastic hammer (A) using suitable tool. If the camshaft sprocket (INT) is not rotated counterclockwise even if the above procedures are performed, check the air pressure and the oil hole position. While doing the above, once you hear a click (the sound of the internal lock pin disengaging) from inside the camshaft sprocket (INT), start turning the camshaft sprocket (INT) in the counterclockwise direction in the most advanced angle position. Keep the air pressure on. If there is no click, as soon as the vane side (camshaft side) starts moving independently of the sprocket, the lock pin has become disengaged. Check that it is in the most advanced angle position by seeing if the stopper pin groove (A) and the stopper pin hole (B) are matched up as shown in the figure. Stop applying air pressure and release the camshaft (INT). Insert the stopper pin (A) into the stopper pin holes in the camshaft sprocket (INT) and lock in the most advanced angle position. CAUTION: No load is exerted on the stopper pin (spring reaction, etc.). Since it comes out easily, secure it with tape (B) to prevent it from falling out. NOTE: The stopper pin shows one example of a hexagonal wrench for 2.5 mm (0.098 in) [length of inserted section: approximately15 mm (0.59 in)].
4. Remove the camshaft sprocket (INT): Keeping the camshaft hexagonal part (A) in place using suitable tool, loosen the bolts for the camshaft sprocket (INT) (2). CAUTION: Do not drop stopper pin. Tape (C) the stopper pin (B) so it does not come out. Do not subject it to impact by dropping. Do not disassemble. [Do not loosen the three bolts (A)]. NOTE: While removing the camshaft sprocket (INT), if you have taken out the stopper pin and the lock pin has been rejoined in the most retarded angle, do the following to restore it. Install the camshaft (INT) and tighten the bolts enough to prevent air from leaking out. CAUTION: The internal lock pin will get damaged, so keep the torque on the bolts to the minimum required to prevent air from escaping. Apply the air pressure, disengage the lock pin, and turn the vane to the most advanced angle position. Insert the stopper pin. Remove camshaft sprocket (INT) from the camshaft.
5. Remove camshaft brackets (No. 2 to 5). Loosen bolts in several steps in the reverse order as shown in the figure. NOTE: The camshaft bracket (No. 1) has been already removed.
6. Remove camshaft (EXH).
7. Remove camshaft (INT).
8. Remove valve lifter (if necessary). Identify installation positions, and store lifters without mixing them up.
9. Remove the alternator and bracket. Refer to " «EXPLODED VIEW»(ref-675585-S38483171462014120500000) "
10. Remove the intake valve timing control solenoid valve (1) and the plug (2) securing the oil filter for intake valve timing control solenoid valve.
11. Remove the exhaust valve timing control solenoid valve.
12. Remove the plug on the exhaust valve timing control solenoid valve.
13. Remove the oil filter for exhaust valve timing control solenoid valve.
14. For component inspection after removal, refer to " «INSPECTION»(ref-675577-S07536733132014120500000) ".

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

1. Install oil filter (1) for intake and exhaust valve timing control solenoid valves. CAUTION: Do not reuse washers. NOTE: The intake side is shown as an example. The oil filter (1) and washer (2) are assembled to the plug (3), and then install them in to the cylinder head. Refer to " «EXPLODED VIEW»(ref-675577-S06901738552014120500000) ".
2. Install intake and exhaust valve timing control solenoid valves. Insert it straight into the cylinder head. Tighten bolts. CAUTION: Do not reuse O-rings.
3. Install valve lifters. If they are reused, install them in the original positions.
4. Put a matching mark for positioning the camshaft (INT) and the camshaft sprocket (INT): NOTE: This helps prevent the knock pin from engaging with the incorrect pin hole after installing the camshaft (INT) and the camshaft sprocket (INT). Put the matching marks (A) on a line extending from the knock pin position of camshaft (INT) (1) front surface. Put the marks on the visible position with the camshaft sprocket installed as shown in the figure. Put the matching marks on a line extending from the knock pin hole (B) position of camshaft sprocket (INT) (2) as shown in the figure. Put the marks on the visible position with it installed to the camshaft.
5. Put a matching mark for positioning the camshaft (EXH) and the camshaft sprocket (EXH): NOTE: This helps prevent the knock pin from engaging with the incorrect pin hole after installing the camshaft (INT) and the camshaft sprocket (EXH). Put the matching marks (A) on a line extending from the knock pin position of camshaft (EXH) (1) front surface. Put the marks on the visible position with the camshaft sprocket installed as shown in the figure. Put the matching marks on a line extending from the knock pin hole (B) position of camshaft sprocket (EXH) (2) as shown in the figure. Put the marks on the visible position with it installed to the camshaft.
6. Install camshaft. Note that the camshafts (INT and EXH) have different shapes at the rear. Install camshafts to the cylinder head so that knock pins (A) on front end are positioned as shown in the figure. NOTE: Though camshaft does not stop at the portion as shown for the placement of cam nose, it is generally accepted camshaft is placed for the same direction as shown in the figure.
7. Install camshaft brackets (2 to 5) and (A to D).
8. Tighten bolts of camshaft brackets in the following steps, in numerical order as shown in the figure. Tighten No. 9 to 11 in numerical order. Camshaft bracket bolts: 1.96 N.m (0.20 kg-m, 17 in-lb) Tighten No. 1 to 8 in numerical order. Camshaft bracket bolts: 1.96 N.m (0.20 kg-m, 17 in-lb) Tighten all bolts in numerical order. Camshaft bracket bolts: 5.88 N.m (0.60 kg-m, 52 in-lb) Tighten all bolts in numerical order. Camshaft bracket bolts: 10.4 N.m (1.1 kg-m, 8 ft-lb)
9. Install the camshaft sprocket (INT/EXH) to the camshaft (INT/EXH): Refer to the matching mark (A) added in step 4. Securely align the knock pin and the pin hole, and then install them. NOTE: The intake side is shown as an example.
10. Tighten the camshaft sprocket bolt (INT/EXH). CAUTION: Hold the camshaft hexagonal part (A), using a suitable tool to secure the camshaft.
11. Align the matching mark (peripheral groove) (A/C) and the pink link (B) on the timing chain. If the positions of knock pin and pin groove are not aligned, move the camshaft (EXH) slightly to correct these positions.
12. Pull out the stopper pin (A), and then apply the tension to the timing chain by rotating the crankshaft pulley clockwise slightly.
13. Pull out the stopper pin of chain tensioner.
14. Install front cover.
15. Return the camshaft sprocket (INT) in the most retarded position: Remove the stopper pin (A) from the camshaft sprocket (INT). Turn the crankshaft pulley (1) slowly clockwise (A) and return the camshaft sprocket (INT) to the most retarded angle position. When first turning the crankshaft, the camshaft sprocket (INT) will turn. Once it is turned more, and the vane (camshaft) also turns, then it has reached the most retarded angle position. The most retarded angle position can be checked by seeing if the stopper pin groove (A) is shifted clockwise. After spinning the crankshaft slightly in the counterclockwise direction, you can check the lock pin has joined by seeing if the vane (camshaft) and the sprocket move together.
16. Install the camshaft position sensor (PHASE) to the rear end of cylinder head. Tighten bolts with it completely inserted.
17. Check and adjust valve clearance. Refer to " «INSPECTION AND ADJUSTMENT»(ref-675577-S00293879022014120500000) ".
18. Installation of the remaining components is in the reverse order of removal.

1. Remove front fender protector (RH). Refer to " «REMOVAL AND INSTALLATION»(ref-675580-S35121108852014120500000) ".
2. Remove drive belt. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S24278316382014120500000) ".
3. Remove crankshaft pulley. Refer to " «EXPLODED VIEW»(ref-675577-S42829733612014120500000) ".
4. Remove front oil seal using suitable tool. CAUTION: Be careful not to damage front cover and crankshaft.
5. Installation of the remaining components is in the reverse order of removal.

Scheme 127

1. Apply new engine oil to new front oil seal joint surface and seal lip.
2. Install front oil seal so that each seal lip is oriented as shown in the figure. Press-fit front oil seal using a suitable drift. CAUTION: Be careful not to damage front cover and crankshaft. Press-fit oil seal straight to avoid causing burrs or tilting.
3. Installation of the remaining components is in the reverse order of removal.

1. Remove engine and transaxle assembly. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675587-S28373499602014120500000) " (M/T models) and " «UNIT REMOVAL AND INSTALLATION»(ref-675588-S41582721042014120500000) " (CVT models).
2. Remove clutch cover and clutch disk (M/T models). Refer to " «REMOVAL AND INSTALLATION»(ref-675589-S39858996212014120500000) ".
3. Remove flywheel (M/T models) or drive plate (CVT models). Refer to " «EXPLODED VIEW»(ref-675577-S03417513952014120500000) ".
4. Remove rear oil seal using suitable tool.

Scheme 128

Scheme 129

1. Apply the liquid gasket lightly to entire outside area of new rear oil seal. Use Genuine Silicone RTV Sealant or equivalent . Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-675571-S19021012742014120500000) ".
2. Install rear oil seal so that each seal lip is oriented as shown in the figure. Press-fit rear oil seal with a suitable drift (A) outer diameter 113 mm (4.45 in) and inner diameter 90 mm (3.54 in). CAUTION: Be careful not to damage crankshaft and cylinder block. Press-fit oil seal straight to avoid causing burrs or tilting. Do not touch grease applied onto oil seal lip. Press in rear oil seal (1) to the position as shown.
3. Installation of the remaining components is in the reverse order of removal.

Scheme 130

Note. When removing components such as hoses, tubes/lines, etc., cap or plug openings to prevent fluid from spilling.

Scheme 131

1. Release fuel pressure. Refer to " «WORK PROCEDURE»(ref-675578-S29860079602014120500000) ".
2. Remove the following components and related parts. Air duct. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S21280789682014120500000) ". Fuel tube and fuel injector. Refer to " «EXPLODED VIEW»(ref-675577-S06336226562014120500000) ". Water outlet. Refer to " «REMOVAL AND INSTALLATION»(ref-675579-S33026669172014120500000) ". Exhaust manifold. Refer to " «EXPLODED VIEW»(ref-675577-S28226386642014120500000) ". Front cover and timing chain. Refer to " «EXPLODED VIEW»(ref-675577-S42829733612014120500000) ". Camshaft. Refer to " «EXPLODED VIEW»(ref-675577-S06901738552014120500000) ".
3. Remove cylinder head loosening bolts in reverse order as shown.
4. Remove cylinder head gasket.

Scheme 132

Scheme 133

1. Install new cylinder head gasket.
2. Install cylinder head, and tighten cylinder head bolts in order as shown using Tool (A). Clean threads and seating surfaces of bolts. Apply new engine oil to threads and seating surface of bolts. CAUTION: If cylinder head bolts are reused, check their outer diameters before installation. Refer to " «INSPECTION»(ref-675577-S04627131462014120500000) ". Check and confirm the tightening angle by using Tool. Do not judge by visual inspection without the tool. Tool number: KV10112100 (BT-8653-A) Step 1: 40.0 N.m (4.1 kg-m, 30 ft-lb) Step 2: 100° clockwise in order Step 3: 0 N.m (0 kg-m, 0 ft-lb) Step 4: 40.0 N.m (4.1 kg-m, 30 ft-lb) Step 5: 100° clockwise in order Step 6: 100° clockwise in order
3. Installation of the remaining components is in the reverse order of removal.

Scheme 134

Scheme 135

1. Remove spark plug using suitable tool.
2. Remove valve lifter. Identify installation positions, and store lifters without mixing them up.
3. Remove valve collet, valve spring retainer, and valve spring using Tools. Tool number (A): KV1016200 (J-26336-A) Tool number (B): KV10109220 (-) Tool number (C): KV10115900 (J-26336-20) CAUTION: Do not damage valve lifter holes. Install Tool (A) in the center of valve spring retainer to press it. Tool number: KV10115900 (J-26336-20)
4. Remove valve spring retainer and valve spring.
5. Push valve stem to combustion chamber side, and remove valve. Identify installation positions, and store without mixing them up.
6. Remove valve oil seal using Tool (A). Tool number: KV10107902 (J-38959)
7. Remove valve spring seat.
8. When valve seat must be replaced, refer to " «INSPECTION»(ref-675577-S04627131462014120500000) " for removal.
9. When valve guide must be replaced, refer to " «INSPECTION»(ref-675577-S04627131462014120500000) " for removal.

Scheme 136

1. Install valve guide if removed. Refer to " «INSPECTION»(ref-675577-S04627131462014120500000) ".
2. Install valve seat if removed. Refer to " «INSPECTION»(ref-675577-S04627131462014120500000) ".
3. Install valve oil seal. Install with Tool (A) to match dimension as shown. Height "H": 13.2 - 13.8 mm (0.520 - 0.543 in) Tool number: KV10115600 (J-38958)
4. Install valve spring seat.
5. Install valve. Install larger diameter to intake side.
6. Install valve spring. NOTE: It can be installed in either direction.
7. Install valve spring retainer.
8. Remove valve collet, valve spring retainer, and valve spring using Tools. Tool number (A): KV1016200 (J-26336-A) Tool number (B): KV10109220 (-) Tool number (C): KV10115900 (J-26336-20) CAUTION: Do not damage valve lifter holes. Install Tool (A) in the center of valve spring retainer to press it. Tool number: KV10115900 (J-26336-20)
9. Install valve lifter.
10. Install spark plug with a suitable tool.

VALVE GUIDE REPLACEMENT

When valve guide is removed, replace with oversized [0.2 mm (0.008 in)] valve guide.

Scheme 137

Scheme 138

Scheme 139

Scheme 140

1. To remove valve guide, heat cylinder head to 110 to 130°C (230 to 266°F) by soaking in heated oil.
2. Drive out valve guide with a press [under a 20 kN (2 ton, 2.2 US ton, 2.0 lmp ton) force] or suitable tool. WARNING: Cylinder head contains heat; when working, wear protective equipment to avoid getting burned.
3. Ream cylinder head valve guide hole with a suitable tool. Valve guide hole diameter (for service parts): Intake and exhaust: 9.175 - 9.201 mm (0.3612 - 0.3622 in)
4. Heat cylinder head to 110 to 130°C (230 to 266°F) by soaking in heated oil.
5. Using a suitable tool, press valve guide (1) from camshaft side of cylinder head (2) to dimensions as shown in the figure. Projection "H":: 11.4 - 11.8 mm (0.448 - 0.464 in) WARNING: Cylinder head contains heat; when working, wear protective equipment to avoid getting burned.
6. Apply reamer finish to valve guide with a suitable tool. Standard 5.000 - 5.018 mm (0.1968 - 0.1975 in)

Scheme 141

1. After confirming that the dimensions of valve guides and valves are within the specifications, perform this procedure.
2. Apply prussian blue (or white lead) onto contacting surface of valve seat to check the condition of the valve contact on the surface.
3. Check if the contact area band is continuous all around the circumference.
4. If not, grind to adjust valve fitting and check again. If the contacting surface still has "NG" conditions (B) even after the recheck, replace valve seat. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-675577-S29588861382014120500000) ".

VALVE SEAT REPLACEMENT

When valve seat is removed, replace with oversized [0.5 mm (0.020 in)] valve seat.

Scheme 142

Scheme 143

1. Bore out old seat until it collapses. Boring should not continue beyond the bottom face of the seat recess in cylinder head. Set the machine depth stop to ensure this. CAUTION: Prevent scoring cylinder head by excessive boring.
2. Ream cylinder head recess diameter for service valve seat. Oversize [0.5 mm (0.020 in)] Intake: 32.500 - 32.527 mm (1.2795 - 1.2805 in) Exhaust: 26.400 - 26.427 mm (1.0393 - 1.0404 in) Be sure to ream in circles concentric to the valve guide center. This will enable valve seat to fit correctly.
3. Heat cylinder head to 110 to 130°C (230 to 266°F) by soaking in heated oil.
4. Provide valve seats cooled well with dry ice. Press-fit valve seats into cylinder head. WARNING: Cylinder head contains heat; when working, wear protective equipment to avoid getting burned. CAUTION: Avoid directly touching cold valve seats.
5. Using a suitable tool finish valve seat to the specified dimensions. For dimensions, refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-675584-S23480474382014120500000) ". CAUTION: When using a valve seat cutter, firmly grip the cutter handle with both hands. Then, press the contacting surface evenly around the valve seat to cut in a single attempt. Improper pressure or cutting several times may result in wavy valve seat.
6. Using compound, grind to adjust valve fitting.
7. Check again for normal contact. Refer to " «VALVE SEAT CONTACT»(ref-675577-S34243404102014120500000) ".

VALVE SPRING SQUARENESS

Scheme 144

1. Set a tri-square (A) along the side of valve spring and rotate spring. Measure the maximum clearance between the top of spring and tri-square. Limit: Refer to " «CYLINDER HEAD»(ref-675577-S26662564432014120500000) ".
2. If it exceeds the limit, replace valve spring.

Note. When removing components such as hoses, tubes/lines, etc., cap or plug openings to prevent fluid from spilling. Remove the engine and the transaxle assembly from the vehicle downward. Separate the engine and the transaxle.

Scheme 145

Scheme 146

Scheme 147

Scheme 148

1. Release fuel pressure. Refer to " «WORK PROCEDURE»(ref-675578-S29860079602014120500000) ".
2. Drain engine coolant from radiator. Refer to " «DRAINING ENGINE COOLANT»(ref-675579-S13508668632014120500000) ". CAUTION: Perform this step when the engine is cold. Do not spill engine coolant on drive belts.
3. Front fender protector (RH/LH). Refer to «FENDER PROTECTOR»(ref-675580-S32924174032014120500000) .
4. Drive belt: Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S24278316382014120500000) ".
5. Battery and battery tray. Refer to «REMOVAL AND INSTALLATION»(ref-675585-S20352736192014120500000) .
6. Air duct (inlet), air duct, and air cleaner case assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-675577-S21280789682014120500000) ".
7. Radiator hose (upper and lower). Refer to «REMOVAL AND INSTALLATION»(ref-675579-S31149802102014120500000) .
8. Exhaust front tube. Refer to «REMOVAL AND INSTALLATION»(ref-675582-S15756993792014120500000) .
9. Disconnect engine room harness connector at the ECM and CVT (if equipped). CAUTION: Protect connectors against foreign materials during the operation by wrapping in a plastic bag.
10. Disconnect heater hoses. Refer to " «EXPLODED VIEW»(ref-675579-S38159217522014120500000) ".
11. Disconnect fuel feed hose at engine side. Refer to " «EXPLODED VIEW»(ref-675577-S06336226562014120500000) ".
12. Disconnect control linkage cable from transaxle. Refer to " «EXPLODED VIEW»(ref-675587-S07483238622014120500000) " (M/T models) and " «EXPLODED VIEW»(ref-675588-S31052589552014120500000) " (CVT models).
13. Disconnect clutch tube on transaxle side from clutch damper (M/T models). Refer to " «EXPLODED VIEW»(ref-675589-S18303767572014120500000) ".
14. Remove alternator. Refer to " «EXPLODED VIEW»(ref-675585-S38483171462014120500000) ".
15. Disconnect vacuum hose at engine side.
16. Remove EVAP hoses at engine side.
17. Remove a/c compressor from the engine with the piping connected. Temporarily position the a/c compressor on the vehicle side with a rope without placing a heavy load on the piping.
18. Remove ground cable at transaxle side.
19. Remove drive shafts (RH/LH). Refer to " «REMOVAL AND INSTALLATION»(ref-675590-S29289701052014120500000) ".
20. Remove rear torque rod (1).
21. When engine can be hoisted, install engine slinger to cylinder head front left side (A) and rear right side (B) and support the engine position with a suitable tool. Slinger (A) bolts: 65 N.m (6.6 kg-m, 48 ft-lb) Slinger (B) bolts: 25 N.m (2.6 kg-m, 18 ft-lb)
22. Use a suitable jack (A) to securely support the bottom of the engine and the transaxle assembly. CAUTION: Put a piece of wood or an equivalent as the supporting surface and secure in a stable condition.
23. Remove engine mounting insulator (RH) (1).
24. Remove engine through bolt-securing nut (C).
25. Carefully lower suitable jack, or raise lift to remove the engine and the transaxle assembly. Observe the following cautions: CAUTION: Check that no part interferes with the vehicle side. Before and during lifting, always check if any harnesses are left connected. During removal, always be careful to prevent the vehicle from falling off the lift due to changes in the center of gravity. If necessary, support the vehicle by setting jack or suitable tool at the rear.
26. Remove starter motor. Refer to " «EXPLODED VIEW»(ref-675591-S28899360972014120500000) ".
27. Lift with a hoist and separate the engine from the transaxle assembly. Refer to " «EXPLODED VIEW»(ref-675587-S35707786372014120500000) " (M/T models) and " «EXPLODED VIEW»(ref-675588-S15673838752014120500000) " (CVT models).

Installation is in the reverse order of removal.
