OUTLINE

1. Interior room lamp* is controlled by the interior room lamp timer control function of the BCM.
2. Cargo lamp is controlled by the cargo lamp control function of the BCM.
3. Push-button ignition switch illumination is controlled by the push-button ignition switch illumination control function of BCM and combination meter.

The timer control functions of the BCM activate based on inputs from the key cylinder lock/unlock switch LH, the door switches, the key switch and door lock/unlock switches.

*Interior room lamp and map lamp (if equipped) (when lamp switch is in DOOR position).

INTERIOR LAMP BATTERY SAVER CONTROL

If an interior lamp is left ON and does not turn OFF even when the doors are closed, the BCM turns off power to the interior lamps automatically to save the battery 10 minutes after the ignition switch is turned OFF.

The BCM controls power and ground to all interior lamps.

After the battery saver system turns the lamps OFF, the lamps will illuminate again when

1. a signal is received from a key fob, main power window and door lock/unlock switch, power window and door lock/unlock switch RH or when the front door lock assembly LH (key cylinder switch) is locked or unlocked
2. a door is opened or closed
3. the key is removed from or inserted into the ignition switch (without Intelligent Key).

The interior lamp battery saver control time period can be changed with the function setting of CONSULT.

Scheme 15

The illumination lamps operation is dependent upon the position of the combination switch (lighting and turn signal switch). When the combination switch (lighting and turn signal switch) is placed in the 1ST or 2ND position the BCM (body control module) receives input requesting the parking lamps to illuminate. This input is communicated to the IPDM E/R (intelligent power distribution module engine room) via the CAN communication lines. The CPU (central processing unit) of the IPDM E/R controls the tail lamp relay coil. When energized, this relay directs power to the parking and illumination lamps, which then illuminate.

BATTERY SAVER CONTROL

When the combination switch (lighting and turn signal switch) is in the 1st or 2nd position and the ignition switch is turned from ON or ACC to OFF, the battery saver control feature is activated. Under this condition, the illumination lamps remain illuminated for 10 minutes unless the combination switch (lighting and turn signal switch) position is changed. If the combination switch (lighting and turn signal switch) position is changed, then the illumination lamps are turned off after a 15 second delay. When the combination switch (lighting and turn signal switch) is turned from OFF to 1st or 2nd position after illumination lamps have been turned off by the battery saver control, the illumination lamps illuminate again.

DATA MONITOR

WORK SUPPORT

List of ECU Reference

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

DETAILED FLOW

1. INTERVIEW FOR MALFUNCTION Interview the symptom to the customer. : GO TO 2.
2. SYMPTOM CHECK Check the symptom from the customer's information. : GO TO 3.
3. BASIC INSPECTION Check the operation of each part. Check that any symptom occurs other than the interviewed symptom. : GO TO 4.
4. SELF-DIAGNOSIS WITH CONSULT Perform the self-diagnosis with CONSULT. Check that any DTC is detected. Is any DTC detected? YES: GO TO 5. NO: GO TO 6 .
5. TROUBLE DIAGNOSIS BY DTC Perform the trouble diagnosis for the detected DTC. Specify the malfunctioning part. : GO TO 9 .
6. FAIL-SAFE ACTIVATION CHECK Check that the symptom is applied to the fail-safe activation. Does the fail-safe activate? YES: GO TO 7. NO: GO TO 8 .
7. SYSTEM DIAGNOSIS Perform the system diagnosis for the system that the fail-safe activates. Specify the malfunctioning part. : GO TO 9 .
8. SYMPTOM DIAGNOSIS Perform the symptom diagnosis. Specify the malfunctioning part. : GO TO 9.
9. MALFUNCTION PART REPAIR Repair or replace the malfunctioning part. : GO TO 10.
10. REPAIR CHECK (SELF-DIAGNOSIS WITH CONSULT) Perform the self-diagnosis with CONSULT. Check that any DTC is not detected. Erase DTC if DTC is detected before the repair. Check that DTC is not detected again. Is any DTC detected? YES: GO TO 5 . NO: GO TO 11.
11. REPAIR CHECK (OPERATION CHECK) Check the operation of each part. Does it operate normally? YES: INSPECTION END NO: GO TO 3 .

Component Function Check

1. CHECK BATTERY SAVER OUTPUT/POWER SUPPLY FUNCTION CONSULT Turn ignition switch ON. Turn each interior lamp to the ON position. Interior room lamp Map lamp (if equipped) Cargo lamp Select BATTERY SAVER of BCM (BATTERY SAVER) active test item. While operating the test item, check that each interior room lamp turns ON/OFF. OFF: Interior room lamp OFF ON: Interior room lamp ON Is the inspection result normal? YES: Battery saver output/power supply circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-675625-S31803751252014120500000) ".

1. CHECK INTERIOR ROOM LAMP CONTROL FUNCTION CONSULT Switch the map lamp switch or interior room lamp switch to DOOR. Turn ignition switch ON. Select INT LAMP of BCM (INT LAMP) ACTIVE TEST item. While operating the test items, check that each interior room lamp turns ON/OFF. On: Interior room lamp gradual brightening Off: Interior room lamp gradual dimming Does the interior room lamp turns ON/OFF (gradual brightening/dimming)? YES: Interior room lamp control circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-675625-S16625594452014120500000) ".

1. CHECK PUSH-BUTTON IGNITION SWITCH ILLUMINATION OPERATION CONSULT Turn the ignition switch ON. Select ENGINE SW ILLUMI of BCM (INTELLGENT KEY) active test item. While operating the test item, check that the push-button ignition switch illumination turns ON/OFF ON: Push-button ignition switch illumination ON OFF: Push-button ignition switch illumination OFF Is the inspection result normal? YES: Push-button ignition switch illumination circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-675625-S25967827232014120500000) ".
