Interior Lighting System: Removal & Installation Nissan Note E12

Interior/illumination Lights 5 illustrations ~207 words

INSTALLATION

Installation is in the reverse order of removal.

Bulb Replacement

WARNINGDo not touch bulb while it is lit or right after being turned OFF. Burning may result.
CAUTIONDo not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to bulb. Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect the performance of lamp.

Scheme 4

Scheme 4: REMOVAL
Scheme 4: REMOVAL
  1. Release lens pawls using suitable tool (A) and remove.
  2. Remove the bulb.

Installation is in the reverse order of removal.

Scheme 5

Scheme 5: Exploded View
Scheme 5: Exploded View

REMOVAL

  1. Release interior room lamp metal clips using a suitable tool.
  2. Disconnect the harness connector from room lamp and remove.

Installation is in the reverse order of removal.

WARNINGDo not touch bulb while it is lit or right after being turned OFF. Burning may result.
CAUTIONDo not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to bulb. Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect the performance of lamp.
  1. Release interior room lamp lens pawls using a suitable tool and remove.
  2. Remove bulb.

Installation is in the reverse order of removal.

Note. Insert the lens hook end RH side first when installing lens.

Scheme 6

Scheme 6: Exploded View
Scheme 6: Exploded View

Scheme 7

Scheme 7: REMOVAL
Scheme 7: REMOVAL
  1. Release cargo room lamp pawl with a suitable tool (A)
  2. Disconnect harness connector from cargo room lamp and remove.

Installation is in the reverse order of removal.

WARNINGDo not touch bulb while it is lit or right after being turned OFF. Burning may result.
CAUTIONDo not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to bulb. Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect the performance of lamp.
  1. Release cargo room lamp lens pawl using a suitable tool.
  2. Remove the bulb.

Installation is in the reverse order of removal.

WARNINGDo not touch bulb while it is lit or right after being turned OFF. Burning may result.
CAUTIONDo not touch the glass surface of the bulb with bare hands or allow oil or grease to get on it to protect damage to bulb. Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect the performance of lamp.

Scheme 8

Scheme 8: REMOVAL
Scheme 8: REMOVAL
  1. Remove the center console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-675607-S31298837932014120500000) ".
  2. Remove shift selector lamp bulb from bulb socket (1).

Installation is in the reverse order of removal.

Removal and Installation

The illumination control switch is part of the combination meter. Refer to " UNIT REMOVAL AND INSTALLATION ".
