FRONT WHEEL SENSOR: Removal and Installation
| CAUTION | Be careful not to damage front wheel sensor edge and sensor rotor teeth. When removing the front wheel hub, first remove the front wheel sensor from the steering knuckle. Failure to do so may result in damage to the front wheel sensor, making the front wheel sensor inoperative. Pull out the front wheel sensor, being careful to turn it as little as possible. Do not pull on the front wheel sensor harness. Before installation, check if foreign objects, such as iron fragments, the pick-up part of the front wheel sensor or to the inside of the hole in the steering knuckle for the front wheel sensor, or if a foreign object is caught in the surface of the sensor rotor. Fix as necessary and then install the front wheel sensor. |
REMOVAL
- Remove wheel and tire using power tool. Refer to " «REMOVAL AND INSTALLATION»(ref-675581-S28220831532014120500000) ".
- Remove fender protector. Refer to " «REMOVAL AND INSTALLATION»(ref-675580-S35121108852014120500000) ".
- Disconnect the harness connector from the front wheel sensor.
- Remove bolt and front wheel sensor from steering knuckle.
- Release front wheel sensor harness clips from the vehicle.
INSTALLATION
Installation is in the reverse order of the removal.
| CAUTION | Do not twist front wheel sensor harness when installing front wheel sensor. Check that grommet (2) is fully inserted to bracket (1). Check that front wheel sensor harness is not twisted after installation. |
Scheme 22
Scheme 23
REAR WHEEL SENSOR: Removal and Installation
| CAUTION | Be careful not to damage rear wheel sensor edge and sensor rotor teeth. When removing the rear wheel hub, first remove the rear wheel sensor from the back plate. Failure to do so may result in damage to the rear wheel sensor, making the rear wheel sensor inoperative. Pull out the rear wheel sensor, being careful to turn it as little as possible. Do not pull on the rear wheel sensor harness. Before installation, check if foreign objects, such as iron fragments, the pick-up part of the rear wheel sensor or to the inside of the hole in the back plate for the rear wheel sensor, or if a foreign object is caught in the surface of the sensor rotor. Fix as necessary and then install the rear wheel sensor. |
Scheme 24
- Remove bolts (A) and support bracket (1) (LH side only).
- Disconnect the harness connector from the rear wheel sensor.
- Release rear wheel sensor harness clips from the vehicle.
- Remove bolts and rear wheel sensor from back plate.
Installation is in the reverse order of removal.
| CAUTION | Do not twist rear wheel sensor harness when installing rear wheel sensor. Check that grommet (2) is fully inserted to bracket (1). Check that rear wheel sensor harness is not twisted after installation. |
Remove sensor rotor from steering knuckle. Refer to " EXPLODED VIEW ".
Installation is in the reverse order of removal.
Remove sensor rotor from brake drum. Refer to " EXPLODED VIEW ".
| CAUTION | Do not reuse rear sensor rotor. |
Installation is in the reverse order of removal.
Scheme 25
| CAUTION | Before servicing, disconnect the battery cable from negative terminal. Do not remove actuator by holding harness. |
Note. When removing components such as hoses, tubes/lines, etc., cap or plug openings to prevent fluid from spilling.
Scheme 26
- Disconnect negative battery cable. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-675572-S35311355862014120500000) ".
- Disconnect vacuum hose from intake manifold. Refer to " «EXPLODED VIEW»(ref-675601-S24182232422014120500000) ".
- Remove ground harness bolt (A) and ground harness from radiator core support.
- Disconnect high-pressure pipe from expansion valve. Refer to " «EXPLODED VIEW»(ref-675574-S42266835572014120500000) ". CAUTION: Cap or wrap the joint of the A/C piping and expansion valve with suitable material such as vinyl tape to avoid the entry of air.
- Remove low-pressure flexible hose. Refer to " «LOW-PRESSURE FLEXIBLE HOSE: REMOVAL AND INSTALLATION»(ref-675574-S37703863252014120500000) ".
- Loosen flare nut from brake tubes using a flare nut wrench, then remove brake tubes from ABS actuator and electric unit (control unit). Refer to " «FRONT: EXPLODED VIEW»(ref-675601-S39159554292014120500000) ".
- Disconnect the harness connector from the ABS actuator and electric unit (control unit).
- Remove ABS actuator and electric unit (control unit) bracket bolts.
- Remove the ABS actuator and electric unit (control unit) and bracket as an assembly.
- Remove bracket and bushing from ABS actuator and electric unit (if necessary).
Installation is in the reverse order of removal.
- Bleed the brake system. Refer to " «BLEEDING BRAKE SYSTEM»(ref-675601-S26412415452014120500000) ".
- Adjust the neutral position of steering angle sensor. Refer to " «WORK PROCEDURE»(ref-675599-S07952687682014120500000) ".
| CAUTION | Replace the ABS actuator electric unit (control unit) if it has been dropped or sustained an impact. Do not install actuator by holding harness. After installing harness connector in the ABS acutator and electric until (control unit), make sure harness connector is securely locked. |
Scheme 27
- Remove the instrument lower panel LH. Refer to " «REMOVAL AND INSTALLATION»(ref-675607-S42805239232014120500000) ".
- Release pawls (A) using suitable tool and remove the VDC OFF switch.
Installation is in the reverse order of removal.
Scheme 28
Scheme 29
- Remove the spiral cable. Refer to " «REMOVAL AND INSTALLATION»(ref-675573-S26258277352014120500000) ".
- Remove the screws (A), then release the pawls (B) and remove the steering angle sensor (2) from the spiral cable (1).
Installation is in the reverse order of removal.
Adjust the neutral position of the steering angle sensor. Refer to " WORK PROCEDURE ".
| CAUTION | Do not reuse steering angle sensor. |
