DTC INDEX
| DTC | Description |
|---|---|
| DTC C1101 | C1102, C1103, C1104 WHEEL SENSOR |
| DTC C1105 | C1106, C1107, C1108 WHEEL SENSOR |
| DTC C1109 | POWER AND GROUND SYSTEM |
| DTC C1110 | C1153, C1170 ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) |
| DTC C1111 | PUMP MOTOR |
| DTC C1115 | ABS SENSOR [ABNORMAL SIGNAL] |
| DTC C1116 | STOP LAMP SWITCH |
| DTC C1120 | C1122, C1124, C1126 ABS IN VALVE SYSTEM |
| DTC C1121 | C1123, C1125, C1127 ABS OUT VALVE SYSTEM |
| DTC C1130 | ENGINE SIGNAL |
| DTC C1140 | ACTUATOR RELAY SYSTEM |
| DTC C1142 | PRESS SENSOR |
| DTC C1143 | STEERING ANGLE SENSOR |
| DTC C1144 | INCOMPLETE STEERING ANGLE SENSOR ADJUSTMENT |
| DTC C1145 | C1146 YAW RATE/SIDE/DECEL G SENSOR |
| DTC C1155 | BR FLUID LEVEL LOW |
| DTC C1164 | C1165, C1166, C1167 CV/SV SYSTEM |
| DTC U1000 | CAN COMM CIRCUIT |
| DTC U1002 | SYSTEM COMM (CAN) |
| DTC U1010 | CONTROL UNIT (CAN) |
DTC INDEX
How To Erase Self Diagnostic Result
- After erasing DTC memory, start engine and drive vehicle at 30 km/h (19 MPH) or more for approximately 1 minute as the final inspection, and make sure that the ABS warning lamp, VDC OFF indicator lamp, SLIP indicator lamp and brake warning lamp turn OFF. CAUTION: If memory cannot be erased, perform applicable diagnosis. NOTE: When the wheel sensor malfunctions, after inspecting the wheel sensor system, the ABS warning lamp, SLIP indicator lamp and brake warning lamp will not turn OFF even when the system is normal, unless the vehicle is driven at approximately 30 km/h (19 MPH) or more for approximately 1 minute. Brake warning lamp will turn ON in case of parking brake operation (when switch is ON) or of brake fluid level switch operation (when brake fluid is insufficient). VDC OFF switch should not stay in ON position.
ACTIVE TEST MODE
| CAUTION | Do not perform active test while driving vehicle. Make sure to completely bleed air from brake system. The active test cannot be performed with the ABS warning lamp, VDC OFF indicator lamp, SLIP indicator lamp or brake warning lamp on. ABS warning lamp, VDC OFF indicator lamp, SLIP indicator lamp and brake warning lamp turn on during active test. |
Note. When active test is performed while depressing the pedal, the pedal depression amount will change. This is normal. "TEST IS STOPPED" is displayed 10 seconds after operation start. After "TEST IS STOPPED" is displayed, to perform test again, touch BACK.
Test Item
ABS SOLENOID VALVE
- Select "Up", "Keep" and "Down". Then use screen monitor to check that solenoid valve operates as shown in the table below.
| Test item | Display item | Display ( (2) ) | ||
|---|---|---|---|---|
| Up | Keep | Down | ||
| FR RH SOL | FR RH IN SOL | Off | On | On |
| FR RH OUT SOL | Off | Off | On (1) | |
| FR LH SOL | FR LH IN SOL | Off | On | On |
| FR LH OUT SOL | Off | Off | On (1) | |
| RR RH SOL | RR RH IN SOL | Off | On | On |
| RR RH OUT SOL | Off | Off | On (1) | |
| RR LH SOL | RR LH IN SOL | Off | On | On |
| RR LH OUT SOL | Off | Off | On (1) | |
| (1) On for 1 to 2 seconds after the select, and then Off. NOTE: (2) A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an operation for checking. | ||||
| (1) | On for 1 to 2 seconds after the select, and then Off. |
| NOTE |
|---|
| (2) A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an operation for checking. |
| (2) | A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an operation for checking. |
ABS SOLENOID VALVE (ACT)
- Select "Up", "ACT UP" and "ACT KEEP". Then use screen monitor to check that solenoid valve operates as shown in the table below.
| Test item | Display item | Display ( (2) ) | ||
|---|---|---|---|---|
| Up | ACT UP | ACT KEEP | ||
| FR RH ABS SOLENOID (ACT) | FR RH IN SOL | Off | Off | Off |
| FR RH OUT SOL | Off | Off | Off | |
| CV1 | Off | On | On | |
| CV2 | Off | On (1) | Off | |
| SV1 | Off | On | On | |
| SV2 | Off | On | Off | |
| FR LH ABS SOLENOID (ACT) | FR LH IN SOL | Off | Off | Off |
| FR LH OUT SOL | Off | Off | Off | |
| CV1 | Off | On | On | |
| CV2 | Off | On (1) | Off | |
| SV1 | Off | On | On | |
| SV2 | Off | On | Off | |
| RR RH ABS SOLENOID (ACT) | RR RH IN SOL | Off | Off | Off |
| RR RH OUT SOL | Off | Off | Off | |
| CV1 | Off | On | On | |
| CV2 | Off | On (1) | Off | |
| SV1 | Off | On | On | |
| SV2 | Off | On | Off | |
| RR LH ABS SOLENOID (ACT) | RR LH IN SOL | Off | Off | Off |
| RR LH OUT SOL | Off | Off | Off | |
| CV1 | Off | On | On | |
| CV2 | Off | On (1) | Off | |
| SV1 | Off | On | On | |
| SV2 | Off | On | Off | |
| (1) On for 1 to 2 seconds after the select, and then Off. NOTE: (2) A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an operation for checking. | ||||
| (1) | On for 1 to 2 seconds after the select, and then Off. |
| NOTE |
|---|
| (2) A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an operation for checking. |
| (2) | A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an operation for checking. |
ABS MOTOR
- Select "On" and "Off". Make sure motor relay and actuator relay operates as shown in table below.
| Test item | Display item | Display | |
|---|---|---|---|
| On | Off | ||
| ABS MOTOR | MOTOR RELAY | On | Off |
| ACTUATOR RLY ( (1) ) | On | On | |
| NOTE: (1) A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an operation for checking. | |||
| NOTE |
|---|
| (1) A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an operation for checking. |
| (1) | A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an operation for checking. |
VALUES ON THE DIAGNOSIS TOOL
| CAUTION | The display shows the control unit calculation data, so a normal value might be displayed even in the event the output circuit (harness) is open or short-circuited. |
| Monitor item | Display content | Data monitor | |
|---|---|---|---|
| Condition | Reference value in normal operation | ||
| FR LH SENSOR | Wheel speed | 0 [km/h, mph] | Vehicle stopped |
| Nearly matches the speed meter display (± 10% or less) | Vehicle running ( (1) ) | ||
| FR RH SENSOR | Wheel speed | 0 [km/h, mph] | Vehicle stopped |
| Nearly matches the speed meter display (± 10% or less) | Vehicle running ( (1) ) | ||
| RR LH SENSOR | Wheel speed | 0 [km/h, mph] | Vehicle stopped |
| Nearly matches the speed meter display (± 10% or less) | Vehicle running ( (1) ) | ||
| RR RH SENSOR | Wheel speed | 0 [km/h, mph] | Vehicle stopped |
| Nearly matches the speed meter display (± 10% or less) | Vehicle running ( (1) ) | ||
| FR RH IN SOL | Operation status of all solenoid valves | Actuator (solenoid valve) is active ("ACTIVE TEST" with CONSULT) or actuator relay is inactive (in fail-safe mode) | On |
| When the actuator (solenoid valve) is not active and actuator relay is active (ignition switch ON) | Off | ||
| FR RH OUT SOL | Operation status of all solenoid valves | Actuator (solenoid valve) is active ("ACTIVE TEST" with CONSULT) or actuator relay is inactive (in fail-safe mode) | On |
| When the actuator (solenoid valve) is not active and actuator relay is active (ignition switch ON) | Off | ||
| FR LH IN SOL | Operation status of all solenoid valves | Actuator (solenoid valve) is active ("ACTIVE TEST" with CONSULT) or actuator relay is inactive (in fail-safe mode) | On |
| When the actuator (solenoid valve) is not active and actuator relay is active (ignition switch ON) | Off | ||
| FR LH OUT SOL | Operation status of all solenoid valves | Actuator (solenoid valve) is active ("ACTIVE TEST" with CONSULT) or actuator relay is inactive (in fail-safe mode) | On |
| When the actuator (solenoid valve) is not active and actuator relay is active (ignition switch ON) | Off | ||
| RR RH IN SOL | Operation status of all solenoid valves | Actuator (solenoid valve) is active ("ACTIVE TEST" with CONSULT) or actuator relay is inactive (in fail-safe mode) | On |
| When the actuator (solenoid valve) is not active and actuator relay is active (ignition switch ON) | Off | ||
| RR RH OUT SOL | Operation status of all solenoid valves | Actuator (solenoid valve) is active ("ACTIVE TEST" with CONSULT) or actuator relay is inactive (in fail-safe mode) | On |
| When the actuator (solenoid valve) is not active and actuator relay is active (ignition switch ON) | Off | ||
| RR LH IN SOL | Operation status of all solenoid valves | Actuator (solenoid valve) is active ("ACTIVE TEST" with CONSULT) or actuator relay is inactive (in fail-safe mode) | On |
| When the actuator (solenoid valve) is not active and actuator relay is active (ignition switch ON) | Off | ||
| RR LH OUT SOL | Operation status of all solenoid valves | Actuator (solenoid valve) is active ("ACTIVE TEST" with CONSULT) or actuator relay is inactive (in fail-safe mode) | On |
| When the actuator (solenoid valve) is not active and actuator relay is active (ignition switch ON) | Off | ||
| EBD WARN LAMP | EBD warning lamp ( (2) ) | When EBD warning lamp is ON | On |
| When EBD warning lamp is OFF | Off | ||
| STOP LAMP SW | Brake pedal operation | When brake pedal is depressed | On |
| When brake pedal is not depressed | Off | ||
| MOTOR RELAY | Motor and motor relay operation | When the motor relay and motor are operating | On |
| When the motor relay and motor are not operating | Off | ||
| ACTUATOR RLY | Actuator relay operation | When the actuator relay is operating | On |
| When the actuator relay is not operating | Off | ||
| ABS WARN LAMP | ABS warning lamp ( (2) ) | When ABS warning lamp is ON | On |
| When ABS warning lamp is OFF | Off | ||
| OFF LAMP | VDC OFF indicator lamp ( (2) ) | When VDC OFF indicator lamp is ON | On |
| When VDC OFF indicator lamp is OFF | Off | ||
| OFF SW | VDC OFF switch | When VDC OFF switch is in ON | On |
| When VDC OFF switch is in OFF | Off | ||
| SLIP/VDC LAMP | SLIP indicator lamp ( (2) ) | When SLIP indicator lamp is ON | On |
| When SLIP indicator lamp is OFF | Off | ||
| BATTERY VOLT | Battery voltage supplied to the ABS actuator and electric unit (control unit) | Ignition switch ON | 10 - 16 V |
| GEAR | Manual mode gear position determined by TCM | 1st gear 2nd gear 3rd gear 4th gear 5th gear | 1 2 3 4 5 |
| SLCT LVR POSI | Selector lever position. | Vehicle stopped | N/P |
| ENGINE SPEED | With engine running | When engine running | RPM |
| YAW RATE SEN | Yaw rate detected by yaw rate/side G sensor | When vehicle stop | Approx. 0 d/s |
| When vehicle turning | 75 to 75 d/s | ||
| R POSI SIG | Transmission range switch signal ON/OFF condition | CVT shift position = R position | On |
| CVT shift position = other than R position | Off | ||
| N POSI SIG | Transmission range switch signal ON/OFF condition | CVT shift position = N position | On |
| CVT shift position = other than N position | Off | ||
| P POSI SIG | Transmission range switch signal ON/OFF condition | CVT shift position = P position | On |
| CVT shift position = other than P position | Off | ||
| CV1 | ABS actuator cut valve 1 | When the cut valve is active | On |
| When the cut valve is inactive | Off | ||
| CV2 | ABS actuator cut valve 2 | When the cut valve is active | On |
| When the cut valve is inactive | Off | ||
| SV1 | ABS actuator suction valve | When the suction valve is active | On |
| When the suction valve is inactive | Off | ||
| SV2 | ABS actuator suction valve 2 | When the suction valve is active | On |
| When the suction valve is inactive | Off | ||
| ACCEL POS SIG | Throttle actuator opening/closing is displayed (linked with accelerator pedal) | Accelerator pedal not depressed (ignition switch is ON) | 0 % |
| Depress accelerator pedal (ignition switch is ON) | 0 - 100 % | ||
| SIDE G-SENSOR | Transverse G detected by side G sensor | Vehicle stopped | Approx. 0 m/s 2 |
| Vehicle turning right | Negative value (m/s 2 ) | ||
| Vehicle turning left | Positive value (m/s 2 ) | ||
| STR ANGLE SIG | Steering angle detected by steering angle sensor | Straight-ahead | Approx. 0° |
| Steering wheel turned | 720 to 720° | ||
| PRESS SENSOR | Brake fluid pressure detected by pressure sensor | With ignition switch turned ON and brake pedal released | Approx. 0 bar |
| With ignition switch turned ON and brake pedal depressed | 40 to 300 bar | ||
| EBD SIGNAL | EBD operation | EBD is active | On |
| EBD is inactive | Off | ||
| ABS SIGNAL | ABS operation | ABS is active | On |
| ABS is inactive | Off | ||
| TCS SIGNAL | TCS operation | TCS is active | On |
| TCS is inactive | Off | ||
| VDC SIGNAL | VDC operation | VDC is active | On |
| VDC is inactive | Off | ||
| EBD FAIL SIG | EBD fail-safe signal | In EBD fail-safe | On |
| EBD is normal | Off | ||
| ABS FAIL SIG | ABS fail-safe signal | In ABS fail-safe | On |
| ABS is normal | Off | ||
| TCS FAIL SIG | TCS fail-safe signal | In TCS fail-safe | On |
| TCS is normal | Off | ||
| VDC FAIL SIG | VDC fail-safe signal | In VDC fail-safe | On |
| VDC is normal | Off | ||
| CRANKING SIG | Crank operation | Crank is active | On |
| Crank is inactive | Off | ||
| FLUID LEV SW | Brake fluid level switch | When brake fluid level switch ON | On |
| When brake fluid level switch OFF | Off | ||
| (1) Confirm tire pressure is normal. (2) On and off timing for warning lamps and indicator lamps. Refer to " VDC/TCS/ABS: VDC FUNCTION ". Refer to " VDC/TCS/ABS: TCS FUNCTION ". Refer to " VDC/TCS/ABS: ABS FUNCTION ". Refer to " VDC/TCS/ABS: EBD FUNCTION ". | |||
| (1) | Confirm tire pressure is normal. |
| (2) | On and off timing for warning lamps and indicator lamps. |
DTC Inspection Priority Chart
When multiple DTCs are displayed simultaneously, check each one using the following priority list.
| Priority | Detected item (DTC) |
|---|---|
| 1 | U1000 CAN COMM CIRCUIT U1002 SYSTEM COMM (CAN) U1010 CAN CONTROLLER CIRCUIT |
| 2 | C1110 CONTROLLER FAILURE C1153 EMERGENCY BRAKE C1170 VARIANT CORDING |
| 3 | C1130 ENGINE SIGNAL 1 C1144 ST ANG SEN SIGNAL |
| 4 | C1109 BATTERY VOLTAGE [ABNORMAL] C1111 PUMP MOTOR C1140 ACTUATOR RLY |
| 5 | C1101 RR RH SENSOR-1 C1102 RR LH SENSOR-1 C1103 FR RH SENSOR-1 C1104 FR LH SENSOR-1 C1105 RR RH SENSOR-2 C1106 RR LH SENSOR-2 C1107 FR RH SENSOR-2 C1108 FR LH SENSOR-2 C1115 ABS SENSOR [ABNORMAL SIGNAL] C1116 STOP LAMP SW C1120 FR LH IN ABS SOL C1121 FR LH OUT ABS SOL C1122 FR RH IN ABS SOL C1123 FR RH OUT ABS SOL C1124 RR LH IN ABS SOL C1125 RR LH OUT ABS SOL C1126 RR RH IN ABS SOL C1127 RR RH OUT ABS SOL C1142 PRESS SEN CIRCUIT C1143 ST ANG SEN CIRCUIT C1145 YAW RATE SENSOR C1146 SIDE G-SEN CIRCUIT C1164 CV1 C1165 CV2 C1166 SV1 C1167 SV2 |
| 6 | C1155 BR FLUID LEVEL LOW |
| DTC | Items (CONSULT screen terms) | Reference |
|---|---|---|
| C1101 | RR RH SENSOR-1 | " DTC LOGIC " |
| C1102 | RR LH SENSOR-1 | |
| C1103 | FR RH SENSOR-1 | |
| C1104 | FR LH SENSOR-1 | |
| C1105 | RR RH SENSOR-2 | " DTC LOGIC " |
| C1106 | RR LH SENSOR-2 | |
| C1107 | FR RH SENSOR-2 | |
| C1108 | FR LH SENSOR-2 | |
| C1109 | BATTERY VOLTAGE [ABNORMAL] | " DTC LOGIC " |
| C1110 | CONTROLLER FAILURE | " DTC LOGIC " |
| C1111 | PUMP MOTOR | " DTC LOGIC " |
| C1115 | ABS SENSOR [ABNORMAL SIGNAL] | " DTC LOGIC " |
| C1116 | STOP LAMP SW | " DTC LOGIC " |
| C1120 | FR LH IN ABS SOL | " DTC LOGIC " |
| C1121 | FR LH OUT ABS SOL | " DTC LOGIC " |
| C1122 | FR RH IN ABS SOL | " DTC LOGIC " |
| C1123 | FR RH OUT ABS SOL | " DTC LOGIC " |
| C1124 | RR LH IN ABS SOL | " DTC LOGIC " |
| C1125 | RR LH OUT ABS SOL | " DTC LOGIC " |
| C1126 | RR RH IN ABS SOL | " DTC LOGIC " |
| C1127 | RR RH OUT ABS SOL | " DTC LOGIC " |
| C1130 | ENGINE SIGNAL 1 | " DTC LOGIC " |
| C1140 | ACTUATOR RLY | " DTC LOGIC " |
| C1142 | PRESS SEN CIRCUIT | " DTC LOGIC " |
| C1143 | ST ANG SEN CIRCUIT | " DTC LOGIC " |
| C1144 | ST ANG SEN SIGNAL | " DTC LOGIC " |
| C1145 | YAW RATE SENSOR | " DTC LOGIC " |
| C1146 | SIDE G-SEN CIRCUIT | |
| C1155 | BR FLUID LEVEL LOW | " DTC LOGIC " |
| C1164 | CV 1 | " DTC LOGIC " |
| C1165 | CV 2 | |
| C1166 | SV 1 | |
| C1167 | SV 2 | |
| U1000 | CAN COMM CIRCUIT | " DTC LOGIC " |
| U1002 | SYSTEM COMM (CAN) | " DTC LOGIC " |
| U1010 | CAN CONTROLLER CIRCUIT | " DTC LOGIC " |
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
DTC DETECTION LOGIC
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1101 | RR RH SENSOR-1 | When power supply voltage of rear wheel sensor RH is low. When an open or shorted circuit is detected in rear wheel sensor RH circuit. | Harness or connector Wheel sensor ABS actuator and electric unit (control unit) |
| C1102 | RR LH SENSOR-1 | When power supply voltage of rear wheel sensor LH is low. When an open or shorted circuit is detected in rear wheel sensor LH circuit. | |
| C1103 | FR RH SENSOR-1 | When power supply voltage of front wheel sensor RH is low. When an open or shorted circuit is detected in front wheel sensor RH circuit. | |
| C1104 | FR LH SENSOR-1 | When power supply voltage of front wheel sensor LH is low. When an open or shorted circuit is detected in front wheel sensor LH circuit. |
DTC CONFIRMATION PROCEDURE
- CHECK SELF-DIAGNOSTIC RESULT With CONSULT. Start engine and drive vehicle at approximately 21 km/h (13 MPH) or more for approximately 5 minutes. Perform self-diagnostic result. Is DTC C1101, C1102, C1103 or C1104 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S22923558502014120500000) ". NO: Inspection End.
Diagnosis Procedure
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CONFIRM DTC With CONSULT Perform self-diagnostic result of ABS and record all active DTCs. Clear all DTCs. Perform DTC confirmation procedure. Refer to " «DTC LOGIC»(ref-675599-S35584620412014120500000) ". Does DTC C1101, C1102, C1103 or C1104 reset? YES: GO TO 2. NO: Refer to " «INTERMITTENT INCIDENT»(ref-675571-S38824794042014120500000) ".
- INSPECT WHEEL SENSOR Inspect the suspect wheel sensor for damage or deformation. Is the inspection result normal? YES: GO TO 3. NO: Repair or replace as necessary.
- HARNESS AND CONNECTOR INSPECTION Disconnect ABS actuator and electric unit (control unit) connector E33 and wheel sensor connector of suspect wheel. Check harness, connectors and terminals for corrosion, deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 4. NO: Repair or replace as necessary.
- CHECK WHEEL SENSOR OUTPUT SIGNAL Connect ABS active wheel sensor tester (J-45741) to wheel sensor using appropriate adapter. Turn on the ABS active wheel sensor tester power switch. NOTE: The green POWER indicator should illuminate. If the POWER indicator does not illuminate, replace the battery in the ABS active wheel sensor tester before proceeding. Spin the wheel of the vehicle by hand and observe the red SENSOR indicator on the ABS active wheel sensor tester. The red SENSOR indicator should flash ON and OFF to indicate an output signal. NOTE: If the red SENSOR indicator illuminates but does not flash, reverse the polarity of the tester leads and retest. Does the ABS active wheel sensor tester detect a signal? YES: GO TO 5. NO: Replace the wheel sensor. Refer to " «FRONT WHEEL SENSOR: REMOVAL AND INSTALLATION»(ref-675599-S04822864502014120500000) " or " «REAR WHEEL SENSOR: REMOVAL AND INSTALLATION»(ref-675599-S42136619092014120500000) ".
- CHECK WIRING HARNESS FOR SHORT TO VOLTAGE Turn ignition switch ON. Check voltage between wheel sensor harness connector terminals of suspect wheel and ground. Wheel Sensor Ground Voltage Wheel Connector Terminal Front LH E51 1 - 0V 2 Front RH E52 1 2 Rear LH B22 1 2 Rear RH B35 1 2 Is the inspection result normal? YES: GO TO 6. NO: Repair the circuit.
- CHECK WIRING HARNESS FOR SHORT TO GROUND Turn ignition switch OFF. Check continuity between wheel sensor harness connector terminals of suspect wheel and ground. Wheel Sensor Ground Continuity Wheel Connector Terminal Front LH E51 1 - No 2 Front RH E52 1 2 Rear LH B22 1 2 Rear RH B35 1 2 Is the inspection result normal? YES: GO TO 7. NO: Repair the circuit.
- CHECK WIRING HARNESS FOR SHORT BETWEEN CIRCUITS Check continuity between wheel sensor harness connector terminals of suspect wheel. Wheel Sensor (+) (-) Continuity Wheel Connector Terminal Terminal Front LH E51 1 2 No Front RH E52 Rear LH B22 Rear RH B35 Is the inspection result normal? YES: GO TO 8. NO: Repair the circuit.
- CHECK WIRING HARNESS FOR OPEN CIRCUIT Check continuity between ABS actuator and electric unit (control unit) harness connector E33 and harness connector of suspect wheel sensor. Wheel sensor ABS actuator and electric unit (control unit) Wheel sensor Continuity Connector Terminal Connector Terminal Yes Front LH E33 37 E51 1 36 2 Front RH 26 E52 1 27 2 Rear LH 30 B22 1 29 2 Rear RH 33 B35 1 34 2 Is the inspection result normal? YES: GO TO 9. NO: Repair the circuit.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY CIRCUIT Turn ignition switch ON. Check voltage between ABS actuator and electric unit (control unit) harness connector E33 terminal and ground. ABS actuator and electric unit (control unit) Ground Condition Voltage (Approx.) Connector Terminal E33 6 - Ignition switch ON Battery voltage Ignition switch OFF 0V Is the inspection result normal? YES: GO TO 10. NO: Check the following: 10A fuse No. 50 located in the IPDM E/R Harness between ABS actuator and electric unit (control unit) and IPDM E/R
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT Turn ignition switch OFF. Check continuity between ABS actuator and electric unit (control unit) connector E33 terminals and ground. ABS actuator and electric unit (control unit) - Continuity Connector Terminal E33 13 Ground Yes 38 Is the inspection result normal? YES: GO TO 11. NO: Repair or replace malfunctioning components.
- CHECK WHEEL SENSOR INPUT VOLTAGE Connect ABS actuator and electric unit (control unit) connector E33. Turn ignition switch ON. Check voltage between suspect wheel sensor harness connector terminals. Wheel Sensor (+) (-) Voltage (Approx.) Wheel Connector Terminal Terminal Front LH E51 1 2 Battery voltage Front RH E52 Rear LH B22 Rear RH B35 Is the inspection result normal? YES: Replace wheel sensor. Refer to " «FRONT WHEEL SENSOR: REMOVAL AND INSTALLATION»(ref-675599-S04822864502014120500000) " or " «REAR WHEEL SENSOR: REMOVAL AND INSTALLATION»(ref-675599-S42136619092014120500000) ". Then, GO TO 12. NO: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ".
- CONFIRM REPAIR With CONSULT Clear all DTCs. Perform DTC confirmation procedure. Refer to " «DTC LOGIC»(ref-675599-S35584620412014120500000) ". Does DTC C1101, C1102, C1103 or C1104 reset? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Inspection End.
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1105 | RR RH SENSOR-2 | When distance between rear wheel sensor RH and rear wheel sensor RH rotor is large. When installation of rear wheel sensor RH or rear wheel sensor RH rotor is not normal. | Wheel sensor ABS actuator and electric unit (control unit) Sensor rotor |
| C1106 | RR LH SENSOR-2 | When distance between rear wheel sensor LH and rear wheel sensor LH rotor is large. When installation of rear wheel sensor LH or rear wheel sensor LH rotor is not normal. | |
| C1107 | FR RH SENSOR-2 | When distance between front wheel sensor RH and front wheel sensor RH rotor is large. When installation of front wheel sensor RH or front wheel sensor RH rotor is not normal. | |
| C1108 | FR LH SENSOR-2 | When distance between front wheel sensor LH and front wheel sensor LH rotor is large. When installation of front wheel sensor LH or front wheel sensor LH rotor is not normal. |
- CHECK SELF-DIAGNOSTIC RESULT With CONSULT. Start engine and drive vehicle at approximately 21 km/h (13 MPH) or more for approximately 5 minutes. Perform self-diagnostic result. Is DTC C1105, C1106, C1107 or C1108 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S38811854472014120500000) ". NO: Inspection End.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CONFIRM DTC With CONSULT Perform self-diagnostic result of ABS and record all active DTCs. Clear all DTCs. Perform DTC confirmation procedure. Refer to " «DTC LOGIC»(ref-675599-S35584620412014120500000) ". Does DTC C1105, C1106, C1107 or C1108 reset? YES: GO TO 2. NO: Refer to GI-XX, "Intermittent Incident".
- CHECK TIRE PRESSURE AND TIRE WEAR Check tires for excessive wear and proper inflation. Refer to " «INSPECTION»(ref-675581-S27213440002014120500000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace as necessary.
- CHECK WHEEL SENSOR Check wheel sensor for the following: Proper installation Physical damage Contamination Is the inspection result normal? YES: GO TO 4. NO: Repair or replace as necessary.
- CHECK SENSOR ROTOR Check sensor rotor for the following: Contamination Physical damage (missing teeth, cracks, etc.) Foreign material Looseness Is the inspection result normal? YES: Replace the wheel sensor. Refer to " «FRONT WHEEL SENSOR: REMOVAL AND INSTALLATION»(ref-675599-S04822864502014120500000) " or " «REAR WHEEL SENSOR: REMOVAL AND INSTALLATION»(ref-675599-S42136619092014120500000) ". Then, GO TO 5. NO: Repair or replace as necessary.
- CONFIRM REPAIR With CONSULT Clear all DTCs. Perform DTC confirmation procedure. Refer to " «DTC LOGIC»(ref-675599-S35584620412014120500000) ". Does DTC C1105, C1106, C1107 or C1108 reset? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Inspection End.
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1109 | BATTERY VOLTAGE [ABNORMAL] | When ignition voltage is 10 V or less. When ignition voltage is 16 V or more. | Harness or connector ABS actuator and electric unit (control unit) Fuse Ignition power supply system Battery |
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Turn the ignition switch ON. Perform self diagnostic result. Is DTC C1109 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S03150143302014120500000) ". NO: Inspection End.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CONNECTOR INSPECTION Turn ignition switch OFF. Disconnect ABS actuator and electric unit (control unit) connectors. Check connectors and terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) IGNITION POWER SUPPLY CIRCUIT Check voltage between ABS actuator and electric unit (control unit) connector E33 terminal 6 and ground. ABS actuator and electric unit (control unit) Ground Condition Voltage Connector Terminal E33 6 - Ignition switch ON Battery voltage Ignition switch OFF 0V Is the inspection result normal? YES: GO TO 3 NO: Repair or replace malfunctioning components.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT Turn ignition switch OFF. Check continuity between ABS actuator and electric unit (control unit) connector E33 terminals 13, 38 and ground. ABS actuator and electric unit (control unit) - Continuity Connector Terminal E33 13 Ground Yes 38 Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Repair or replace malfunctioning components.
| DTC | Display item | Malfunction detected condition | Possible cause |
|---|---|---|---|
| C1110 | CONTROLLER FAILURE | When there is an internal malfunction in the ABS actuator and electric unit (control unit). | ABS actuator and electric unit (control unit) |
| C1153 | EMERGENCY BRAKE | When ABS actuator and electric unit (control unit) is malfunctioning. (Pressure increase is too much or too little) | |
| C1170 | VARIANT CODING | In a case where VARIANT CODING is different. |
- CHECK SELF-DIAGNOSIS RESULTS Check the self-diagnosis results. Self-diagnosis results CONTROLLER FAILURE EMERGENCY BRAKE VARIANT CODING Is above displayed on the self-diagnosis display? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S39055886022014120500000) ". NO: Inspection End.
- REPLACE ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) CAUTION: Replace ABS actuator and electric unit (control unit) when self diagnostic result shows items other than those applicable. : Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ".
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1111 | PUMP MOTOR | When a malfunction is detected in motor or motor relay. When a low pressure malfunction is detected in accumulator. When a malfunction is detected in accumulator pressure sensor. | Harness or connector ABS actuator and electric unit (control unit) Fusible link Battery power supply system Motor/accumulator assembly |
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Turn ignition switch OFF. Depress brake pedal 20 times or more. Start the engine and wait for 3 minutes or more. Perform self diagnostic result. Is DTC C1111 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S41669913322014120500000) ". NO: Inspection End.
Regarding Wiring Diagram information, refer to " REMOVAL AND INSTALLATION ".
- CONNECTOR INSPECTION Turn ignition switch OFF. Disconnect ABS actuator and electric unit (control unit) connectors. Check connectors and terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK ABS MOTOR AND MOTOR RELAY BATTERY POWER SUPPLY Check voltage between ABS actuator and electric unit (control unit) connector E33 terminal 1 and ground. ABS actuator and electric unit (control unit) - Voltage Connector Terminal E33 1 Ground Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Repair or replace malfunctioning components.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT Check continuity between ABS actuator and electric unit (control unit) connector E33 terminals 13, 38 and ground. ABS actuator and electric unit (control unit) - Continuity Connector Terminal E33 13 Ground Yes 38 Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Repair or replace malfunctioning components.
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1115 | ABS SENSOR [ABNORMAL SIGNAL] | When difference in wheel speed between any wheel and others is detected while the vehicle is driven, because of installation of tires other than specified. | Harness or connector Wheel sensor Sensor rotor ABS actuator and electric unit (control unit) |
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Start engine and drive vehicle at approximately 30 km/h (19 MPH) or more for approximately 1 minute. Perform self diagnostic result. Is DTC C1115 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S24206640362014120500000) ". NO: Inspection End.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
| CAUTION | Do not check between wheel sensor terminals. |
- CONNECTOR INSPECTION Disconnect ABS actuator and electric unit (control unit) connector E33 and wheel sensor connector of wheel with DTC. Check terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK WHEEL SENSOR OUTPUT SIGNAL Connect ABS active wheel sensor tester (J-45741) to wheel sensor using appropriate adapter. Turn on the ABS active wheel sensor tester power switch. NOTE: The green POWER indicator should illuminate. If the POWER indicator does not illuminate, replace the battery in the ABS active wheel sensor tester before proceeding. Spin the wheel of the vehicle by hand and observe the red SENSOR indicator on the ABS active wheel sensor tester. The red SENSOR indicator should flash on and off to indicate an output signal. NOTE: If the red SENSOR indicator illuminates but does not flash, reverse the polarity of the tester leads and retest. Does the ABS active wheel sensor tester detect a signal? YES: GO TO 3 NO: Replace the wheel sensor. Refer to " «FRONT WHEEL SENSOR: REMOVAL AND INSTALLATION»(ref-675599-S04822864502014120500000) " (front) or " «REAR WHEEL SENSOR: REMOVAL AND INSTALLATION»(ref-675599-S42136619092014120500000) " (rear).
- CHECK TIRES Check the inflation pressure, wear and size of each tire. Is the inspection result normal? YES: GO TO 4 NO: Adjust tire pressure, or replace tire(s).
- CHECK WIRING HARNESS FOR SHORT CIRCUIT Check continuity between wheel sensor connector terminals and ground of wheel with DTC. Wheel Sensor Ground Continuity Wheel Connector Terminal Front LH E51 1 - No 2 Front RH E52 1 2 Rear LH B22 1 2 Rear RH B35 1 2 Is the inspection result normal? YES: GO TO 5 NO: Repair the circuit.
- CHECK WIRING HARNESS FOR OPEN CIRCUIT Check continuity between ABS actuator and electric unit (control unit) connector E33 and wheel sensor connector of wheel with DTC. Wheel sensor ABS actuator and electric unit (control unit) Wheel sensor Continuity Connector Terminal Connector Terminal Yes Front LH E33 37 E51 1 36 2 Front RH 26 E52 1 27 2 Rear LH 30 B22 1 29 2 Rear RH 33 B35 1 34 2 Is the inspection result normal? YES: Replace the ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Repair the circuit.
| DTC | Display item | Malfunction detected condition | Possible cause |
|---|---|---|---|
| C1116 | STOP LAMP SW | When stop lamp switch circuit is open. | Harness or connector Stop lamp switch ABS actuator and electric unit (control unit) |
- CHECK SELF-DIAGNOSIS RESULTS Check the self-diagnosis results. Self-diagnosis results STOP LAMP SW Is above displayed on the self-diagnosis display? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S42700786032014120500000) ". NO: Inspection End.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CONNECTOR INSPECTION Disconnect stop lamp switch connector and ABS actuator and electric unit (control unit) connector. Check terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK STOP LAMP SWITCH CIRCUIT Connect stop lamp switch connector. Check voltage between ABS actuator and electric unit (control unit) connector E33 terminal 12 and ground. ABS actuator and electric unit (control unit) Ground Condition Voltage (Approx.) Connector Terminal E33 12 - Brake pedal depressed Battery voltage Brake pedal released 0V Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: GO TO 3
- CHECK STOP LAMP SWITCH CIRCUIT FOR OPEN Disconnect stop lamp switch connector. Check continuity between ABS actuator and electric unit (control unit) connector E33 terminal 12 and stop lamp switch connector E13 (with CVT) or E57 (with M/T) terminal 2. ABS actuator and electric unit (control unit) Stop lamp switch Continuity Connector Terminal Connector Terminal E33 12 E13 (with CVT) 2 Yes E57 (with M/T) Is the inspection result normal? YES: GO TO 4. NO: Repair or replace as necessary.
- CHECK STOP LAMP SWITCH CIRCUIT FOR SHORT Check continuity between ABS actuator and electric unit (control unit) connector E33 terminal 12 and ground. ABS actuator and electric unit (control unit) Ground Continuity Connector Terminal E33 12 - No Is the inspection result normal? YES: Replace stop lamp switch. NO: Repair harness or connectors.
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1120 | FR LH IN ABS SOL | When a malfunction is detected in front LH ABS IN valve. | Harness or connector ABS actuator and electric unit (control unit) Fusible link Battery power supply system |
| C1122 | FR RH IN ABS SOL | When a malfunction is detected in front RH ABS IN valve. | |
| C1124 | RR LH IN ABS SOL | When a malfunction is detected in rear LH ABS IN valve. | |
| C1126 | RR RH IN ABS SOL | When a malfunction is detected in rear RH ABS IN valve. |
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Turn ignition switch ON. Perform self diagnostic result. Is DTC C1120, C1122, C1124 or C1126 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S20105079022014120500000) ". NO: Inspection End.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CONNECTOR INSPECTION Turn ignition switch OFF. Disconnect ABS actuator and electric unit (control unit) connector. Check connector and terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) BATTERY POWER SUPPLY Check voltage between ABS actuator and electric unit (control unit) connector E33 terminal 25 and ground. ABS actuator and electric unit (control unit) - Voltage (Approx.) Connector Terminal E33 25 Ground Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Repair or replace malfunctioning components.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT Check continuity between ABS actuator and electric unit (control unit) connector E33 terminals 13, 38 and ground. ABS actuator and electric unit (control unit) - Continuity Connector Terminal E33 13 Ground Yes 38 Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Repair or replace malfunctioning components.
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1121 | FR LH OUT ABS SOL | When a malfunction is detected in front LH ABS OUT valve. | Harness or connector ABS actuator and electric unit (control unit) Fusible link Battery power supply system |
| C1123 | FR RH OUT ABS SOL | When a malfunction is detected in front RH ABS OUT valve. | |
| C1125 | RR LH OUT ABS SOL | When a malfunction is detected in rear LH ABS OUT valve. | |
| C1127 | RR RH OUT ABS SOL | When a malfunction is detected in rear RH ABS OUT valve. |
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Turn ignition switch ON. Perform self diagnostic result. Is DTC C1121, C1123, C1125 or C1127 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S31466902272014120500000) ". NO: Inspection End.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CONNECTOR INSPECTION Turn ignition switch OFF. Disconnect ABS actuator and electric unit (control unit) connector. Check connector and terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) BATTERY POWER SUPPLY Check voltage between ABS actuator and electric unit (control unit) connector E33 terminal 25 and ground. ABS actuator and electric unit (control unit) - Voltage (Approx.) Connector Terminal E33 25 Ground Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Repair or replace malfunctioning components.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT Check continuity between ABS actuator and electric unit (control unit) connector E33 terminals 13, 38 and ground. ABS actuator and electric unit (control unit) - Continuity Connector Terminal E33 13 Ground Yes 38 Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Repair or replace malfunctioning components.
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1130 | ENGINE SIGNAL 1 | When a malfunction is detected in ECM system. | ECM ABS actuator and electric unit (control unit) CAN communication line |
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Turn ignition switch ON. Perform self diagnostic result. Is DTC C1130 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S24300883622014120500000) ". NO: Inspection End.
- CHECK SELF DIAGNOSTIC RESULT FOR ENGINE SYSTEM With CONSULT. Perform self diagnostic result. Refer to " «CONSULT FUNCTION (ABS)»(ref-675599-S00147093492014120500000) ". Are any ECM DTCs detected? YES: Refer to " «DTC INDEX»(ref-675599-S09934599962014120500000) ". NO: GO TO 2.
- CHECK SELF DIAGNOSTIC RESULT FOR ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) With CONSULT. Perform self diagnostic result and erase DTCs. Turn ignition switch OFF. Start engine and drive vehicle for a short period of time. Check that malfunction indicator lamp (MIL) turns OFF. Stop vehicle and perform self diagnostic result. Is DTC C1130 detected? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Check pin terminals and connection of connectors for abnormal conditions. Repair or replace malfunctioning components.
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1140 | ACTUATOR RLY | When a malfunction is detected in actuator relay. | Harness or connector ABS actuator and electric unit (control unit) Fusible link Battery power supply system |
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Turn ignition switch ON. Perform self diagnostic result. Is DTC C1140 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S19354579632014120500000) ". NO: Inspection End.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CONNECTOR INSPECTION Turn ignition switch OFF. Disconnect ABS actuator and electric unit (control unit) connector. Check connector and terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) BATTERY POWER SUPPLY Check voltage between ABS actuator and electric unit (control unit) connector E33 terminal 25 and ground. ABS actuator and electric unit (control unit) - Voltage (Approx.) Connector Terminal E33 25 Ground Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Repair or replace malfunctioning components.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT Check continuity between ABS actuator and electric unit (control unit) connector E33 terminals 13, 38 and ground. ABS actuator and electric unit (control unit) - Continuity Connector Terminal E33 13 Ground Yes 38 Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Repair or replace malfunctioning components.
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1142 | PRESS SEN CIRCUIT | When a malfunction is detected in master cylinder pressure sensor. | Stop lamp switch system ABS actuator and electric unit (control unit) Brake system |
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Turn ignition switch ON. Perform self diagnostic result. Is DTC C1142 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S05326684592014120500000) ". NO: Inspection End.
- CHECK STOP LAMP SWITCH SYSTEM Check stop lamp switch system. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S42700786032014120500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace malfunctioning components.
- CHECK BRAKE FLUID LEAKAGE Check brake fluid leakage. Refer to " «INSPECTION»(ref-675601-S37175112292014120500000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace malfunctioning components.
- CHECK BRAKE PEDAL Check brake pedal. Refer to " «INSPECTION AND ADJUSTMENT»(ref-675601-S07977721252014120500000) ". Is the inspection result normal? YES: GO TO 4. NO: Repair or replace malfunctioning components.
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Turn ignition switch ON. Perform self diagnostic result. Erase DTCs. Start engine and drive vehicle for a short period of time. Turn ignition switch ON. Perform self diagnostic result. Is DTC C1142 detected? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Inspection End.
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1143 | ST ANG SEN CIRCUIT | When a malfunction is detected in steering angle sensor. | Harness or connector Steering angle sensor ABS actuator and electric unit (control unit) Fuse Ignition power supply system CAN communication line |
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Turn ignition switch ON. Perform self diagnostic result. Is DTC C1143 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S17821717582014120500000) ". NO: Inspection End.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CONNECTOR INSPECTION Turn ignition switch OFF. Disconnect ABS actuator and electric unit (control unit) and steering angle sensor connectors. Check connectors and terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK STEERING ANGLE SENSOR MOUNTING CONDITION Check steering angle sensor mounting condition. Is the inspection result normal? YES: GO TO 3. NO: Repair or replace malfunctioning components.
- CHECK STEERING ANGLE SENSOR POWER SUPPLY Turn ignition switch OFF. Disconnect steering angle sensor connector. Turn ignition switch ON. Check voltage between steering angle sensor connector M64 terminal 4 and ground. Steering angle sensor - Voltage (Approx.) Connector Terminal M64 4 Ground Battery voltage Is the inspection result normal? YES: GO TO 5 . NO: GO TO 4.
- CHECK STEERING ANGLE SENSOR POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect IPDM E/R connector E45. Check continuity between steering angle sensor connector M64 terminal 4 and IPDM E/R connector E45 terminal 20. Steering angle sensor IPDM E/R Continuity Connector Terminal Connector Terminal M64 4 E45 20 Yes Check continuity between steering angle sensor connector M64 terminal 4 and ground. Steering angle sensor - Continuity Connector Terminal M64 4 Ground No Is the inspection result normal? YES: Perform trouble diagnosis for ignition power supply. Refer to " «WIRING DIAGRAM»(ref-675597-S09725142012014120500000) " (with I-Key) or " «WIRING DIAGRAM»(ref-675598-S21641641262014120500000) " (without I-Key). NO: Repair or replace malfunctioning components.
- CHECK STEERING ANGLE SENSOR GROUND CIRCUIT Turn ignition switch OFF. Check continuity between steering angle sensor connector M64 terminal 1 and ground. Steering angle sensor - Continuity Connector Terminal M64 1 Ground Yes Is the inspection result normal? YES: GO TO 6. NO: Repair or replace malfunctioning components.
- CHECK CAN COMMUNICATION LINE Check "STRG BRANCH LINE CIRCUIT". Refer to " «DIAGNOSIS PROCEDURE»(ref-675615-S09012723122014120500000) " (type 1) or " «DIAGNOSIS PROCEDURE»(ref-675616-S03574131472014120500000) " (type 2) or " «DIAGNOSIS PROCEDURE»(ref-675616-S25880915082014120500000) " (type 3). Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Repair or replace malfunctioning components.
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1144 | ST ANG SEN SIGNAL | When neutral position adjustment of steering angle sensor is not complete. | Harness or connector Steering angle sensor ABS actuator and electric unit (control unit) Incomplete neutral position adjustment of steering angle sensor |
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Turn ignition switch ON. Perform self diagnostic result. Is DTC C1144 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S07102803322014120500000) ". NO: Inspection End.
- ADJUST THE NEUTRAL POSITION OF STEERING ANGLE SENSOR Perform neutral position adjustment of steering angle sensor. Refer to " «WORK PROCEDURE»(ref-675599-S14805241842014120500000) ". : GO TO 2.
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Perform self diagnostic result. Is DTC C1144 detected? YES: GO TO 3. NO: Inspection End.
- CHECK STEERING ANGLE SENSOR SYSTEM Check steering angle sensor system. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S17821717582014120500000) ". Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Repair or replace malfunctioning components.
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1145 | YAW RATE SENSOR | When a malfunction is detected in yaw rate signal. When yaw rate signal is not continuously received for 2 seconds or more. When side G signal is not continuously received for 2 seconds or more. When decel G signal is not continuously received for 2 seconds or more. | Harness or connector Yaw rate/side/decel G sensor ABS actuator and electric unit (control unit) Ignition power supply system Fuse |
| C1146 | SIDE G-SEN CIRCUIT | When a malfunction is detected in side/decel G signal. |
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Turn ignition switch OFF to ON. Perform self diagnostic result. Is DTC C1145 or C1146 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S36690099142014120500000) ". NO: Inspection End.
- REPLACE ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) Replace ABS actuator and electric unit (control unit). : Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ".
| DTC | Display item | Malfunction detected condition | Possible cause |
|---|---|---|---|
| C1155 | BR FLUID LEVEL LOW | Brake fluid level is low or communication line between the ABS actuator and electric unit (control unit) and brake fluid level switch is open or shorted. | Harness or connector Brake fluid level switch |
- CHECK SELF-DIAGNOSIS RESULTS Check the self-diagnosis results. Self-diagnosis results BR FLUID LEVEL LOW Is above displayed on the self-diagnosis display? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S13911240432014120500000) ". NO: Inspection End.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
Note. Check brake fluid level in brake reservoir tank before starting inspection.
- CONNECTOR INSPECTION Turn ignition switch OFF. Disconnect combination meter and brake fluid level switch connectors. Check connectors and terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK BRAKE FLUID LEVEL SWITCH Perform the brake fluid level switch component inspection. Refer to " «COMPONENT INSPECTION»(ref-675599-S08957802642014120500000) ". Is the inspection result normal? YES: GO TO 3 NO: Replace brake fluid level switch. Refer to " «BRAKE FLUID LEVEL SWITCH»(ref-675599-S19663204892014120500000) ".
- CHECK BRAKE FLUID LEVEL SWITCH HARNESS Check continuity between combination meter connector and brake fluid level switch connector E40 terminal 1. Combination meter Brake fluid level switch Continuity Connector Terminal Connector Continuity M24 11 E40 1 Yes Check continuity between combination meter connector and ground. Combination meter - Continuity Connector Terminal M24 11 Ground No Is the inspection result normal? YES: GO TO 4 NO: Repair or replace malfunctioning components.
- CHECK BRAKE FLUID LEVEL SWITCH GROUND CIRCUIT Check continuity between brake fluid level switch connector E40 terminal 2 and ground. Brake fluid level switch - Continuity Connector Terminal E40 2 Ground Yes Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) " NO: Repair or replace malfunctioning components.
Component Inspection
- CHECK BRAKE FLUID LEVEL SWITCH Turn ignition switch OFF. Disconnect brake fluid level switch connector. Check continuity between brake fluid level switch terminals 1 and 2. Brake fluid level switch terminals Condition Continuity 1- 2 Brake fluid reservoir full No Brake fluid reservoir empty Yes Is the inspection result normal? YES: Inspection End. NO: Replace brake fluid level switch. Refer to " «EXPLODED VIEW»(ref-675601-S11082977022014120500000) ".
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| C1164 | CV 1 | When a malfunction is detected in cut valve 1. | Harness or connector ABS actuator and electric unit (control unit) Fusible link Battery power supply system |
| C1165 | CV 2 | When a malfunction is detected in cut valve 2. | |
| C1166 | SV 1 | When a malfunction is detected in suction valve 1. | |
| C1167 | SV 2 | When a malfunction is detected in suction valve 2. |
- CHECK SELF DIAGNOSTIC RESULT With CONSULT. Turn ignition switch OFF to ON. Perform self diagnostic result. Is DTC C1164, C1165, C1166 or C1167 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S36055661352014120500000) ". NO: Inspection End.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CONNECTOR INSPECTION Turn ignition switch OFF. Disconnect ABS actuator and electric unit (control unit) connector. Check connector and terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) BATTERY POWER SUPPLY Check voltage between ABS actuator and electric unit (control unit) connector E33 terminal 25 and ground. ABS actuator and electric unit (control unit) - Voltage (Approx.) Connector Terminal E33 25 Ground Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Repair or replace malfunctioning components.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT Check continuity between ABS actuator and electric unit (control unit) connector E33 terminals 13, 38 and ground. ABS actuator and electric unit (control unit) - Continuity Connector Terminal E33 13 Ground Yes 38 Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Repair or replace malfunctioning components.
| DTC | Display Item | Malfunction detected condition | Possible causes |
|---|---|---|---|
| U1000 | CAN COMM CIRCUIT | When CAN communication signal is not continuously received for 2 seconds or more | CAN communication system malfunction |
- CHECK DTC DETECTION With CONSULT. Turn ignition switch ON. Perform self diagnostic result. Is DTC U1000 detected? YES: Proceed to diagnosis procedure. Refer to " «TROUBLE DIAGNOSIS FLOW CHART»(ref-675575-S41142210102014120500000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-675571-S38824794042014120500000) ".
| DTC | Display item | Malfunction detected condition | Possible cause |
|---|---|---|---|
| U1002 | SYSTEM COMM (CAN) | When ABS actuator and electric unit (control unit) is not transmitting or receiving CAN communication signal for 2 seconds or less. | CAN communication line ABS actuator and electric unit (control unit) |
- PRECONDITIONING If "DTC CONFIRMATION PROCEDURE" has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test. : GO TO 2.
- DTC REPRODUCTION PROCEDURE With CONSULT Turn the ignition switch ON. Perform self diagnosis for "ABS". Is DTC "U1002" detected? YES: Proceed to " «DIAGNOSIS PROCEDURE»(ref-675599-S21737704582014120500000) ". NO: Inspection End.
| CAUTION | Never apply 7.0 V or more to the measurement terminal. Use a tester with open terminal voltage of 7.0 V or less. Turn the ignition switch OFF and disconnect the battery cable from the negative terminal when checking the harness. |
- CHECK CAN DIAGNOSIS SUPPORT MONITOR Select "ABS" and "CAN Diagnosis Support Monitor" in order with CONSULT. Check malfunction history between each control unit connected to ABS actuator and electric unit (control unit). Check the result of "PAST"? All items are "OK": Refer to " «INTERMITTENT INCIDENT»(ref-675571-S38824794042014120500000) ". "TRANSMIT DIAG" is other than "OK": GO TO 2. A control unit other than ABS actuator and electric unit (control unit) is anything other than "OK": GO TO 3 .
- CHECK TRANSMITTING SIDE UNIT Check the ABS actuator and electric unit (control unit) harness connector terminals 10 and 11 for damage or loose connection. Is the inspection result normal? YES: Erase self-diagnosis results. Then perform self-diagnosis for "ABS" with CONSULT. NO: Recheck terminals for damage or loose connection.
- CHECK APPLICABLE CONTROL UNIT Check damage or loose connection of each CAN communication line harness connector terminals. Is the inspection result normal? YES: Erase self-diagnosis results. Then perform self-diagnosis for applicable control unit with CONSULT. NO: Recheck terminals for damage or loose connection.
| DTC | Items (CONSULT screen terms) | DTC detection condition | Possible cause |
|---|---|---|---|
| U1010 | CONTROL UNIT (CAN) | When detecting error during the initial diagnosis of CAN controller of ABS actuator and electric unit (control unit). | ABS actuator and electric unit (control unit) |
- PERFORM SELF-DIAGNOSIS With CONSULT. Turn ignition switch ON. Perform self diagnostic result. Is DTC U1010 detected? YES: Proceed to diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-675599-S41225461432014120500000) ". NO: Inspection End.
- REPLACE ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". : Inspection End.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CONNECTOR INSPECTION Turn ignition switch OFF. Disconnect combination meter and parking brake switch connectors. Check connectors and terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK PARKING BRAKE SWITCH Check parking brake switch. Refer to " «COMPONENT INSPECTION»(ref-675599-S37509755922014120500000) ". Is the inspection result normal? YES: GO TO 3. NO: Replace parking brake switch. Refer to " «REMOVAL AND INSTALLATION»(ref-675606-S29245309142014120500000) ".
- CHECK PARKING BRAKE SWITCH SIGNAL With CONSULT. Connect combination meter connector and parking brake switch connectors. Turn ignition switch ON. In "DATA MONITOR" select "PARK BRAKE SW" and check parking brake switch signal. Condition DATA MONITOR Actuate parking brake On Release parking brake Off Is the inspection result normal? YES: Refer to " «WORK FLOW»(ref-675599-S11367724492014120500000) ". NO: GO TO 4.
- CHECK PARKING BRAKE SWITCH CIRCUIT Turn ignition switch OFF. Disconnect combination meter and parking brake switch connectors. Check continuity between combination meter connector and parking brake switch connector M17 terminal 1. Combination meter Parking brake switch Continuity Connector Terminal Connector Terminal M24 10 M17 1 Yes Check continuity between combination meter connector and ground. Combination meter - Continuity Connector Terminal M24 10 Ground No Is the inspection result normal? YES: Replace combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ". NO: Repair or replace malfunctioning components.
- CHECK PARKING BRAKE SWITCH Turn ignition switch OFF. Disconnect parking brake switch connector. Check continuity between parking brake switch terminal 1 and ground. Parking brake switch terminal - Condition Continuity 1 Ground Parking brake actuated Yes Parking brake released No Is the inspection result normal? YES: Inspection End. NO: Replace parking brake switch. Refer to " «REMOVAL AND INSTALLATION»(ref-675606-S29245309142014120500000) ".
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CONNECTOR INSPECTION Turn ignition switch OFF. Disconnect ABS actuator and electric unit (control unit) and VDC OFF switch connectors. Check connectors and terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK VDC OFF SWITCH Check VDC OFF switch. Refer to " «COMPONENT INSPECTION»(ref-675599-S01090130272014120500000) ". Is the inspection result normal? YES: GO TO 3. NO: Replace VDC OFF switch. Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S23118158972014120500000) ".
- CHECK VDC OFF SWITCH SIGNAL With CONSULT. Connect ABS actuator and electric unit (control unit) and VDC OFF switch connectors. Turn ignition switch ON. In "DATA MONITOR" select "OFF SW" and check VDC OFF switch signal. Condition DATA MONITOR VDC OFF switch is pressed and released On VDC OFF switch is pressed and released again Off Is the inspection result normal? YES: Refer to " «WORK FLOW»(ref-675599-S11367724492014120500000) ". NO: GO TO 4.
- CHECK VDC OFF SWITCH CIRCUIT Turn ignition switch OFF. Disconnect ABS actuator and electric unit (control unit) and VDC OFF switch connectors. Check continuity between ABS actuator and electric unit (control unit) connector E33 terminal 20 and VDC OFF switch connector M34 terminal 1. ABS actuator and electric unit (control unit) VDC OFF switch Continuity Connector Terminal Connector Terminal E33 20 M34 1 Yes Check continuity between ABS actuator and electric unit (control unit) connector terminal E33 terminal 20 and ground. ABS actuator and electric unit (control unit) - Continuity Connector Terminal E33 20 Ground No Is the inspection result normal? YES: GO TO 5. NO: Repair or replace malfunctioning components.
- CHECK VDC OFF SWITCH GROUND CIRCUIT Check continuity between VDC OFF switch connector M34 terminal 2 and ground. VDC OFF switch - Continuity Connector Terminal M34 2 Ground Yes Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Repair or replace malfunctioning components.
- CHECK VDC OFF SWITCH Turn ignition switch OFF. Disconnect VDC OFF switch connector. Check continuity between terminals of VDC OFF switch connector. VDC OFF switch terminals Condition Continuity 1 - 2 VDC OFF switch pressed Yes VDC OFF switch released No Is the inspection result normal? YES: Inspection End. NO: Replace VDC OFF switch. Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S23118158972014120500000) ".
- PERFORM THE SELF-DIAGNOSIS With CONSULT. Perform self diagnostic result. Are any DTCs detected? YES: Refer to " «DTC INDEX»(ref-675599-S09934599962014120500000) ". NO: GO TO 2.
- CHECK COMBINATION METER Check if indication and operation of combination meter are normal. Refer to " «METER SYSTEM: SYSTEM DESCRIPTION»(ref-675593-S40444546932014120500000) ". Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Replace combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ".
- PERFORM THE SELF-DIAGNOSIS With CONSULT. Perform self diagnostic result. Are any DTCs detected? YES: Refer to " «DTC INDEX»(ref-675599-S09934599962014120500000) ". NO: GO TO 2.
- CHECK COMBINATION METER Check if indication and operation of combination meter are normal. Refer to " «METER SYSTEM: SYSTEM DESCRIPTION»(ref-675593-S40444546932014120500000) ". Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Replace combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ".
- PERFORM THE SELF-DIAGNOSIS With CONSULT. Perform self diagnostic result. Are any DTCs detected? YES: Refer to " «DTC INDEX»(ref-675599-S09934599962014120500000) ". NO: GO TO 2.
- CHECK COMBINATION METER Check if indication and operation of combination meter are normal. Refer to " «METER SYSTEM: SYSTEM DESCRIPTION»(ref-675593-S40444546932014120500000) ". Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Replace combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ".
- PERFORM THE SELF-DIAGNOSIS With CONSULT. Perform self diagnostic result. Are any DTCs detected? YES: Refer to " «DTC INDEX»(ref-675599-S09934599962014120500000) ". NO: GO TO 2.
- CHECK COMBINATION METER Check if indication and operation of combination meter are normal. Refer to " «METER SYSTEM: SYSTEM DESCRIPTION»(ref-675593-S40444546932014120500000) ". Is the inspection result normal? YES: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ". NO: Replace combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ".
Symptom Table
If ABS warning lamp and SLIP indicator lamp turn ON, perform self-diagnosis.
| Symptom | Check item | Reference |
|---|---|---|
| Excessive ABS function operation frequency | Brake force distribution | " DIAGNOSIS PROCEDURE " |
| Looseness of front and rear axle | ||
| Wheel sensor and rotor system | ||
| Unexpected pedal reaction | Brake pedal stroke | " DIAGNOSIS PROCEDURE " |
| Make sure the braking force is sufficient when the ABS is not operating. | ||
| The braking distance is long | Check stopping distance when the ABS is not operating. | " DIAGNOSIS PROCEDURE " |
| ABS function does not operate ( (1) ) | ABS actuator and electric unit (control unit) | " DIAGNOSIS PROCEDURE " |
| Pedal vibration or ABS operation sound occurs ( (2) ) | Brake pedal | " DIAGNOSIS PROCEDURE " |
| ABS actuator and electric unit (control unit) | ||
| Vehicle jerks during VDC/TCS/ABS control | ABS actuator and electric unit (control unit) | " DIAGNOSIS PROCEDURE " |
| TCM | ||
| ECM | ||
| NOTE: (1) The ABS does not operate when the speed is 10 km/h (6 MPH) or less. (2) Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly depressed (just place a foot on it). However, this is normal. When shifting gears When driving on slippery road During cornering at high speed When passing over bumps or grooves [approximately 50 mm (1.97 in) or more] When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher] | ||
| NOTE |
|---|
| (1) The ABS does not operate when the speed is 10 km/h (6 MPH) or less. (2) Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly depressed (just place a foot on it). However, this is normal. When shifting gears When driving on slippery road During cornering at high speed When passing over bumps or grooves [approximately 50 mm (1.97 in) or more] When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher] |
| (1) | The ABS does not operate when the speed is 10 km/h (6 MPH) or less. |
| (2) | Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly depressed (just place a foot on it). However, this is normal. |
- CHECK START Check front and rear brake force distribution using a brake tester. Is the inspection result normal? YES: GO TO 2 NO: Check brake system.
- CHECK FRONT AND REAR AXLE Make sure that there is no excessive play in the front and rear axles. Refer to front: " «INSPECTION»(ref-675590-S13946050682014120500000) ", rear: " «INSPECTION»(ref-675609-S17643831662014120500000) ". Is the inspection result normal? YES: GO TO 3 NO: Repair or replace malfunctioning components.
- CHECK WHEEL SENSOR AND SENSOR ROTOR Check the following: Wheel sensor installation for damage Sensor rotor installation for damage Wheel sensor connector Wheel sensor harness Is the inspection result normal? YES: GO TO 4 NO: Replace wheel sensor " «FRONT WHEEL SENSOR: REMOVAL AND INSTALLATION»(ref-675599-S04822864502014120500000) " (front) or " «REAR SENSOR ROTOR: REMOVAL AND INSTALLATION»(ref-675599-S15276181552014120500000) " (rear). Replace sensor rotor " «FRONT SENSOR ROTOR: REMOVAL AND INSTALLATION»(ref-675599-S23940365622014120500000) " (front) or " «REAR SENSOR ROTOR: REMOVAL AND INSTALLATION»(ref-675599-S15276181552014120500000) " (rear). Repair harness.
- CHECK ABS WARNING LAMP DISPLAY Make sure that the ABS warning lamp is turned off after the ignition switch is turned ON or when driving. Is the inspection result normal? YES: Inspection End. NO: Perform self diagnostic result. Refer to " «CONSULT FUNCTION (ABS)»(ref-675599-S00147093492014120500000) ".
- CHECK BRAKE PEDAL STROKE Check brake pedal stroke. Refer to " «INSPECTION AND ADJUSTMENT»(ref-675601-S07977721252014120500000) ". Is the stroke too big? YES: Bleed air from brake line and hose. Refer to " «BLEEDING BRAKE SYSTEM»(ref-675601-S26412415452014120500000) ". Check brake pedal, brake booster, and master cylinder for mount play, looseness, brake system fluid leakage, etc. Refer to brake pedal: " «INSPECTION AND ADJUSTMENT»(ref-675601-S07977721252014120500000) " or brake booster assembly " «INSPECTION»(ref-675601-S36286677882014120500000) ". NO: GO TO 2
- CHECK ABS FUNCTION Disconnect ABS actuator and electric unit (control unit) connector to deactivate ABS. Check if braking force is normal in this condition. Reconnect connector after inspection. Is the inspection result normal? YES: Inspection End. NO: Check brake system.
| CAUTION | The stopping distance on slippery road surfaces might be longer with the ABS operating than when the ABS is not operating. |
- CHECK ABS FUNCTION Turn ignition switch OFF. Disconnect ABS actuator and electric unit (control unit) connector to deactivate ABS. Check stopping distance. After inspection, reconnect connector. Is the inspection result normal? YES: Inspection End. NO: Check brake system.
| CAUTION | ABS does not operate when speed is 10 km/h (6 MPH) or lower. |
- CHECK ABS WARNING LAMP DISPLAY Make sure that the ABS warning lamp turns OFF after ignition switch is turned ON or when driving. Is the inspection result normal? YES: Inspection End. NO: Perform self diagnostic result. Refer to " «CONSULT FUNCTION (ABS)»(ref-675599-S00147093492014120500000) ".
| CAUTION | Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly depressed (just place a foot on it). However, this is normal. When shifting gears When driving on slippery road During cornering at high speed When passing over bumps or grooves [approximately 50 mm (1.97 in) or more] When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher] |
- SYMPTOM CHECK 1 Check that there are pedal vibrations when the engine is started. Do symptoms occur? YES: GO TO 2 NO: Inspect the brake pedal.
- SYMPTOM CHECK 2 Check that there are ABS operation noises when the engine is started. Do symptoms occur? YES: GO TO 3 NO: Perform self diagnostic result. Refer to " «CONSULT FUNCTION (ABS)»(ref-675599-S00147093492014120500000) ".
- SYMPTOM CHECK 3 Check symptoms when electrical component (headlamps, etc.) switches are operated. Do symptoms occur? YES: Check if there is a radio, antenna, antenna lead wire, or wiring close to the control unit. If there is, move it farther away. NO: Inspection End.
- SYMPTOM CHECK Check if the vehicle jerks during VDC/TCS/ABS control. Is the inspection result normal? YES: Inspection End. NO: GO TO 2
- CHECK SELF DIAGNOSTIC RESULT Perform self diagnostic result of ABS actuator and electric unit (control unit). Refer to " «CONSULT FUNCTION (ABS)»(ref-675599-S00147093492014120500000) ". Are self diagnostic results indicated? YES: Check corresponding items, make repairs, and perform ABS actuator and electric unit (control unit) self diagnostic result again. Refer to " «CONSULT FUNCTION (ABS)»(ref-675599-S00147093492014120500000) ". NO: GO TO 3
- CHECK CONNECTOR Turn ignition switch OFF. Disconnect ABS actuator and electric unit (control unit) connector. Check terminals for deformation, disconnection, looseness, etc. Securely reconnect connector and perform ABS actuator and electric unit (control unit) self diagnostic result. Refer to " «CONSULT FUNCTION (ABS)»(ref-675599-S00147093492014120500000) ". Are self diagnostic results indicated? YES: If poor contact, damage, open or short circuit of connector terminal is found, repair or replace. NO: GO TO 4
- CHECK ECM AND TCM SELF DIAGNOSTIC RESULT Perform ECM self diagnostic result. Refer to " «CONSULT FUNCTION»(ref-675578-S05166819052014120500000) ". Perform TCM self diagnostic result. Refer to " «CONSULT FUNCTION»(ref-675588-S25818641912014120500000) ". Are self diagnostic results indicated? YES: Check the corresponding items. ECM: Refer to " «DTC INDEX»(ref-675578-S08797913902014120500000) ". TCM: Refer to " «CONSULT FUNCTION»(ref-675588-S25818641912014120500000) ". NO: Replace ABS actuator and electric unit (control unit). Refer to " «REMOVAL AND INSTALLATION»(ref-675599-S01875700792014120500000) ".
