Transfer: Specifications Nissan Murano Z50

Pinion Bearing Preload Torque

1. Remove the pinion sleeve assembly. Refer to «PINION SLEEVE ASSEMBLY»(ref-234001-S28549241092006052800000).
2. Rotate the companion flange back and forth 2 to 3 times. Check for unusual noise, rotation malfunction, and other malfunctions.
3. Rotate the companion flange at least 20 times to check for smooth operation of the bearing.
4. Using a preload gauge, measure the preload torque of the pinion bearing. Tool number: ST3127S000 (J-25765-A) Preload torque : 0.10 - 0.39 N.m (0.01 - 0.04 kg-m, 1 - 3 in-lb) CAUTION: Every rotational part shall rotate smoothly with the specified gear oil. If measured value is out of the specification, disassemble the pinion sleeve assembly to check and adjust each part.

Total Preload Torque

1. Measure pinion bearing preload torque (P1). Refer to «PINION BEARING PRELOAD TORQUE»(ref-234001-S35304644762006052800000). Pinion bearing preload torque (P1) 0.10 - 0.39 N.m (0.01 - 0.04 kg-m, 1 - 3 in-lb)
2. Install the pinion sleeve shims and pinion sleeve assembly.
3. Rotate the companion flange at least 20 times to check for smooth operation of the bearing.
4. Using the preload gauge, measure the total preload torque. Tool number: ST3127S000 (J-25765-A) Total preload torque With all oil seals P1 + 0.16 - 0.22 N.m (0.016 - 0.023 kg-m, 1.4 -1.9 in-lb) Without transfer case oil seal and adapter case oil seal P1 + 0.06 - 0.12 N.m (0.006 - 0.013 kg-m, 0.6-1.1 in-lb)

1. If measured value is out of the specification, disassemble it to check and adjust each part. If measuring the total preload torque after the disassembly, measure it with the transfer case oil seals and gear ring oil seals removed, then install the oil seals.

Scheme 1

1. Fit a dial indicator onto the companion flange face (inner side of the propeller shaft mounting bolt holes).
2. Rotate the companion flange to check for runout. Runout limit: 0.1 mm (0.004 in)
3. Fit a test indicator to the inner side of the companion flange (socket diameter).
4. Rotate the companion flange to check for runout. Runout limit: 0.1 mm (0.004 in)
5. If the runout value is outside the repair limit, follow the procedure below to adjust. While changing the phase between companion flange and drive pinion gear by 90° at a time, check runout and determine which phase angle minimizes the runout. If the runout value is still outside of the limit after the phase has been changed, replace the companion flange. If the runout is out of the specification after replacement of companion flange, adjust the assembly status of the pinion bearings and drive pinion gear, or replace the pinion bearings.

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. Remove pinion sleeve mounting bolts.
2. Using a plastic hammer, tap companion flange to remove pinion sleeve assembly.
3. Remove the pinion sleeve shim.
4. Remove the pinion lock nut.
5. Using the drift, remove drive pinion assembly from pinion sleeve with a press. Tool number: ST33220000 (J-25804-01)
6. Remove companion flange.
7. Remove the O-ring from pinion sleeve.
8. Using a flat-bladed screwdriver, remove the pinion sleeve oil seal. CAUTION: Be careful not to damage the pinion sleeve.
9. Remove the pinion rear bearing inner race.
10. Using the puller, remove the pinion rear bearing outer race. Tool number: KV381054S0 (J-34286)
11. Using the puller, remove the pinion front bearing outer race. Tool number: KV381054S0 (J-34286)
12. Remove dust cover.
13. Remove the collapsible spacer from the drive pinion.
14. Using the replacer, press the pinion front bearing inner race out of the drive pinion. Tool number: ST30031000 (J-22912-01)

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. Remove the adapter case mounting bolts.
2. Using a plastic hammer, tap the adapter case to remove.
3. Remove the O-ring.
4. Using a flat-bladed screwdriver, remove the adapter case oil seal. CAUTION: Be careful not to damage the adapter case.
5. Using a brass rod, tap the gear ring bearing adjusting shim from the cutout on the adapter case to remove the gear ring bearing adjusting shim and gear ring bearing outer race.
6. Remove the oil gutter.
7. Remove the drain plug.

Scheme 14

Scheme 15

Scheme 16

Scheme 17

1. Remove the adapter case. Refer to «ADAPTER CASE»(ref-234001-S05447459562006052800000).
2. Remove the drive gear assembly from the transfer case.
3. Using the drift and replacer, remove the gear ring bearing inner race (adapter case side) on the gear ring. Tool number: ST33200000 (J-26082)
4. Using the drift and puller, remove the gear ring bearing inner race (transfer case side) on the gear ring. Tool number: ST33061000 (J-8107-2)
5. Remove the drive gear mounting bolts.
6. Using a plastic hammer, tap the drive gear to remove the drive gear from the gear ring.
7. Using the puller, remove the gear ring oil seal from the gear ring. Tool number: KV381054S0 (J-34286)

Scheme 18

Scheme 19

Scheme 20

1. Remove the pinion sleeve assembly. Refer to «PINION SLEEVE ASSEMBLY»(ref-234001-S28549241092006052800000).
2. Remove the adapter case. Refer to «ADAPTER CASE»(ref-234001-S05447459562006052800000).
3. Remove the drive gear assembly from the transfer case. Refer to «DRIVE GEAR ASSEMBLY»(ref-234001-S07776331042006052800000).
4. Using a flat-bladed screwdriver, remove the transfer case oil seal. CAUTION: Be careful not to damage the transfer case.
5. Remove the oil defense.
6. Using a brass rod, tap the gear ring bearing adjusting shim evenly from the 2 cutouts on the transfer case to remove the gear ring bearing adjusting shim and gear ring bearing outer race.
7. Remove the filler plug, plug and breather tube.

General Specifications

Service Data & Specifications

Scheme 21

Scheme 22
