Power Window Control System: Diagnosis — Nissan Maxima A35 (2008-2014)

BCM : Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

Scheme 3

Scheme 3: BCM : Diagnosis Procedure

Scheme 4

CHECK FUSE AND FUSIBLE LINK Check if the following BCM fuses or fusible link are blown. FUSE REFERENCE CHART Terminal No. Signal name Fuse and fusible link No. 1 Battery power supply H 11 10 24 7 Is the fuse or fusible link blown? YES >> Replace the blown fuse or fusible link after repairing the affected circuit. NO >> GO TO 2
CHECK POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect BCM. Check voltage between BCM harness connector and ground. VOLTAGE REFERENCE CHART Terminals Voltage (Approx.) (+) (-) BCM Ground Connector Terminal M16 (A) 1 Battery voltage M17 (B) 11 M18 (C) 24 Is the measurement normal? YES >> GO TO 3 NO >> Repair or replace harness.
CHECK GROUND CIRCUIT Check continuity between BCM harness connector and ground. CONNECTOR TERMINAL REFERENCE CHART BCM Ground Continuity Connector Terminal M17 13 Yes Does continuity exist? YES >> Inspection End. NO >> Repair or replace harness.

POWER WINDOW MAIN SWITCH : Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 5

Scheme 5: POWER WINDOW MAIN SWITCH : Diagnosis Procedure

Scheme 6

Scheme 7

CHECK POWER SUPPLY CIRCUIT Turn ignition switch ON. Check voltage between main power window and door lock/unlock switch connectors D7 (A) terminal 10 and D8 (B) terminal 19 and ground. VOLTAGE REFERENCE CHART Terminal Voltage (V) (Approx.) (+) (-) Main power window and door lock/unlock switch connector Terminal D7 (A) 10 Ground Battery voltage D8 (B) 19 Is the inspection result normal? YES >> GO TO 3 NO >> GO TO 2
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect BCM connector M16 and main power window and door lock/unlock switch connectors. Check continuity between BCM connector M16 (A) terminals 2 and 3 and main power window and door lock/unlock switch connectors D7 (B) terminal 10 and D8 (C) terminal 19. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Main power window and door lock/unlock switch connector Terminal Continuity M16 (A) 3 D7 (B) 10 Yes 2 D8 (C) 19 Check continuity between BCM connector M16 (A) terminals 2 and 3 and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M16 (A) 3 No 2 Is the inspection result normal? YES >> Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-388072-S03584481162011022800000) ". NO >> Repair or replace harness or connectors.
CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector D8. Check continuity between main power window and door lock/unlock switch connector D8 terminal 17 and ground. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Ground Continuity D8 17 Yes Is the inspection result normal? YES >> Inspection End. NO >> Repair or replace harness or connectors.

FRONT POWER WINDOW SWITCH : Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 8

Scheme 8: FRONT POWER WINDOW SWITCH : Diagnosis Procedure

Scheme 9

Scheme 10

CHECK POWER SUPPLY CIRCUIT Check voltage between power window and door lock/unlock switch RH connector D105 terminal 10 and ground. VOLTAGE REFERENCE CHART Terminal Voltage (V) (Approx.) (+) (-) Power window and door lock/unlock switch RH connector Terminal D105 10 Ground Battery voltage Is the inspection result normal? YES >> GO TO 3 NO >> GO TO 2
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect BCM connector M16 and power window and door lock/unlock switch RH connector. Check continuity between BCM connector M16 (A) terminal 2 and power window and door lock/unlock switch RH connector D105 (B) terminal 10. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Power window and door lock/unlock switch RH connector Terminal Continuity M16 (A) 2 D105 (B) 10 Yes Check continuity between BCM connector M16 (A) terminal 2 and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M16 (A) 2 No Is the inspection result normal? YES >> Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-388072-S03584481162011022800000) ". NO >> Repair or replace harness or connectors.
CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect power window and door lock/unlock switch RH. Check continuity between power window and door lock/unlock switch RH connector D105 terminal 11 and ground. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH Terminal Ground Continuity D105 11 Yes Is the inspection result normal? YES >> Inspection End. NO >> Repair or replace harness or connectors.

REAR POWER WINDOW SWITCH : Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 11

Scheme 11: REAR POWER WINDOW SWITCH : Diagnosis Procedure

Scheme 12

Scheme 13

CHECK POWER SUPPLY CIRCUIT Check voltage between rear power window switch connector terminal 1 and ground. VOLTAGE REFERENCE CHART Terminal Condition Voltage (V) (Approx.) (+) (-) Rear power window switch connector Terminal LH D203 1 Ground Ignition switch ON Battery voltage RH D303 Is the inspection result normal? YES >> GO TO 3 NO >> GO TO 2
CHECK HARNESS CONTINUITY Disconnect BCM connector M16 and rear power window switch connector. Check continuity between BCM connector M16 (A) terminal 3 and rear power window switch connector (B) terminal 1. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Rear power window switch connector Terminal Continuity M16 (A) 3 LH D203 (B) 1 Yes RH D303 (B) Check continuity between BCM connector M16 (A) terminal 3 and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M16 (A) 3 No Is the inspection result normal? YES >> Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-388072-S03584481162011022800000) ". NO >> Repair or replace harness or connectors.
CHECK GROUND CIRCUIT Disconnect rear power window switch connector. Check continuity between rear power window switch connector terminal 7 and ground. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch connector Terminal Ground Continuity D203 7 No D303 Is the inspection result normal? YES >> Inspection End. NO >> Repair or replace harness or connectors.

Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 14

Scheme 14: Diagnosis Procedure

Scheme 15

Scheme 16

CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT INSPECTION»(ref-388086-S35116598352011022800000) ". Is the inspection result normal? YES >> GO TO 2 NO >> Replace rear power window switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S29603262682011022800000) ".
CHECK REAR POWER WINDOW SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect rear power window switch connector. Turn ignition switch ON. Check voltage between rear power window switch connector and ground. VOLTAGE REFERENCE CHART Rear power window switch Ground Condition Voltage (V) (Approx.) Connector Terminal D203 2 Power window main switch : LH UP Battery voltage DOWN 0V 3 UP 0V DOWN Battery voltage D303 2 Power window main switch : RH UP Battery voltage DOWN 0V 3 UP 0V DOWN Battery voltage Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> For rear power window switch LH, GO TO 3 For rear power window switch RH, GO TO 4
CHECK HARNESS CONTINUITY (REAR POWER WINDOW SWITCH LH) Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector D7 and rear power window switch LH connector. Check continuity between main power window and door lock/unlock switch connector D7 (A) terminals 1, 3 and rear power window switch LH connector D203 (B) terminals 2, 3. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Rear power window switch LH connector Terminal Continuity D7 (A) 1 D203 (B) 2 Yes 3 3 Check continuity between main power window and door lock/unlock switch connector D7 (A) terminals 1, 3 and ground. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Ground Continuity D7 (A) 1 No 3 Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.
CHECK HARNESS CONTINUITY (REAR POWER WINDOW SWITCH RH) Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector D7 and rear power window switch RH connector. Check continuity between main power window and door lock/unlock switch connector D7 (A) terminals 5, 7 and rear power window switch RH connector D303 (B) terminals 2, 3. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Rear power window switch RH connector Terminal Continuity D7 (A) 5 D303 (B) 3 Yes 7 2 Check continuity between main power window and door lock/unlock switch connector D7 (A) terminals 5, 7 and ground. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Ground Continuity D7 (A) 5 No 7 Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.

Scheme 17

Scheme 17: COMPONENT INSPECTION

CHECK REAR POWER WINDOW SWITCH Check rear power window switch. CONNECTOR TERMINAL REFERENCE CHART Terminal Power window switch condition Continuity 1 5 DOWN Yes 3 4 3 4 NEUTRAL 5 2 1 4 UP 5 2 Is the inspection result normal? YES >> Rear power window switch is OK. NO >> Replace rear power window switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S29603262682011022800000) ".

DRIVER SIDE : Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 18

Scheme 18: DRIVER SIDE : Diagnosis Procedure

Scheme 19

CHECK POWER WINDOW MOTOR Check front power window motor LH. Refer to " «DRIVER SIDE : COMPONENT INSPECTION»(ref-388086-S38996223992011022800000) ". Is the inspection result normal? YES >> GO TO 2 NO >> Replace power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ".
CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH OUTPUT SIGNAL Disconnect front power window motor LH connector. Turn ignition switch ON. Check voltage between front power window motor LH connector D9 terminals 1, 2 and ground. VOLTAGE REFERENCE CHART Terminal Main power window and door lock/unlock switch condition Voltage (V) (Approx.) (+) (-) Power window motor LH connector Terminal D9 2 Ground UP Battery voltage DOWN 0 1 UP 0 DOWN Battery voltage Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 3
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector D7. Check continuity between main power window and door lock/unlock switch connector D7 (A) terminals 8, 11 and front power window motor connector LH D9 (B) terminals 1, 2. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Front power window motor LH connector Terminal Continuity D7 (A) 8 D9 (B) 2 Yes 11 1 Check continuity between main power window and door lock/unlock switch connector D7 (A) terminals 8, 11 and ground. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Ground Continuity D7 (A) 8 No 11 Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.

DRIVER SIDE : Component Inspection

COMPONENT INSPECTION

CHECK FRONT POWER WINDOW MOTOR LH Disconnect front power window motor LH. Check motor operation by connecting battery voltage directly to front power window motor LH. CONNECTOR TERMINAL REFERENCE CHART Terminal Motor condition (+) (-) 1 2 DOWN 2 1 UP Is the inspection result normal? YES >> Inspection End. NO >> Replace front power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ".

PASSENGER SIDE : Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 20

Scheme 20: PASSENGER SIDE : Diagnosis Procedure

Scheme 21

CHECK FRONT POWER WINDOW MOTOR RH Check front power window motor RH. Refer to " «PASSENGER SIDE : COMPONENT INSPECTION»(ref-388086-S11105731212011022800000) ". Is the inspection result normal? YES >> GO TO 2 NO >> Replace front power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ".
CHECK FRONT POWER WINDOW SWITCH RH OUTPUT SIGNAL Disconnect front power window motor RH connector. Turn ignition switch ON. Check voltage between front power window motor RH connector D104 terminals 1, 2 and ground. VOLTAGE REFERENCE CHART Terminal Front power window motor RH condition Voltage (V) (Approx.) (+) (-) Front power window motor RH connector Terminal D104 2 Ground UP Battery voltage DOWN 0 1 UP 0 DOWN Battery voltage Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 3
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect power window and door lock/unlock switch RH connector. Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminals 8, 9 and front power window motor RH connector D104 (B) terminals 1, 2. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Front power window motor RH connector Terminal Continuity D105 (A) 8 D104 (B) 2 Yes 9 1 Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminals 8, 9 and ground. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Ground Continuity D105 (A) 8 No 9 Is the inspection result normal? YES >> Replace power window and door lock/unlock switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S07081875712011022800000) ". NO >> Repair or replace harness or connectors.

PASSENGER SIDE : Component Inspection

COMPONENT INSPECTION

CHECK FRONT POWER WINDOW MOTOR RH Disconnect front power window motor RH. Check motor operation by connecting battery voltage directly to front power window motor RH. CONNECTOR TERMINAL REFERENCE CHART Terminal Motor condition (+) (-) 1 2 DOWN 2 1 UP Is the inspection result normal? YES >> Inspection End. NO >> Replace front power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ".

REAR LH : Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 22

Scheme 22: REAR LH : Diagnosis Procedure

Scheme 23

CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to " «REAR LH : COMPONENT INSPECTION»(ref-388086-S33620616152011022800000) ". Is the inspection result normal? YES >> GO TO 2 NO >> Replace rear power window motor LH. Refer to " «REAR DOOR GLASS REGULATOR»(ref-388089-S40440642102011022800000) ".
CHECK REAR POWER WINDOW SWITCH OUTPUT SIGNAL Disconnect rear power window motor LH connector. Turn ignition switch ON. Check voltage between rear power window motor LH connector D204 terminal 1, 3 and ground. VOLTAGE REFERENCE CHART Terminal Window condition Voltage (V) (Approx.) (+) (-) Rear power window motor LH connector Terminal D204 3 Ground UP Battery voltage DOWN 0 1 UP 0 DOWN Battery voltage Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 3
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect rear power window switch LH connector. Check continuity between rear power window switch LH connector D203 (A) terminals 4, 5 and rear power window motor LH connector D204 (B) terminals 1, 3. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch LH connector Terminal Rear power window motor LH connector Terminal Continuity D203 (A) 5 D204 (B) 1 Yes 4 3 Check continuity between rear power window switch LH connector D203 (A) terminals 4, 5 and ground. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch LH connector Terminal Ground Continuity D203 (A) 5 No 4 Is the inspection result normal? YES >> Check rear power window switch LH. Refer to " «DIAGNOSIS PROCEDURE»(ref-388086-S21633426622011022800000) ". NO >> Repair or replace harness or connectors.

REAR LH : Component Inspection

COMPONENT INSPECTION

CHECK REAR POWER WINDOW MOTOR LH Disconnect rear power window motor LH. Check motor operation by connecting battery voltage directly to rear power window motor LH. CONNECTOR TERMINAL REFERENCE CHART Terminal Motor condition (+) (-) 3 1 UP 1 3 DOWN Is the inspection result normal? YES >> Inspection End. NO >> Replace rear power window motor LH. Refer to " «REAR DOOR GLASS REGULATOR»(ref-388089-S40440642102011022800000) ".

REAR RH : Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 24

Scheme 24: REAR RH : Diagnosis Procedure

Scheme 25

CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to " «REAR RH : COMPONENT INSPECTION»(ref-388086-S36017589012011022800000) ". Is the inspection result normal? YES >> GO TO 2 NO >> Replace rear power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S25700698102011022800000) ".
CHECK REAR POWER WINDOW SWITCH RH OUTPUT SIGNAL Disconnect rear power window motor RH connector. Turn ignition switch ON. Check voltage between rear power window motor RH connector D304 terminal 1, 3 and ground. VOLTAGE REFERENCE CHART Terminal Rear power window switch RH condition Voltage (V) (Approx.) (+) (-) Rear power window motor RH connector Terminal D304 3 Ground UP Battery voltage DOWN 0 1 UP 0 DOWN Battery voltage Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 3
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect rear power window switch RH connector. Check continuity between rear power window switch RH connector D303 (A) terminals 4, 5 and rear power window motor RH connector D304 (B) terminals 1, 3. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch RH connector Terminal Rear power window motor RH connector Terminal Continuity D303 (A) 5 D304 (B) 1 Yes 4 3 Check continuity between rear power window switch RH connector D303 (A) terminals 4, 5 and ground. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch RH connector Terminal Ground Continuity D303 (A) 5 No 4 Is the inspection result normal? YES >> Check rear power window switch RH. Refer to " «DIAGNOSIS PROCEDURE»(ref-388086-S21633426622011022800000) ". NO >> Repair or replace harness or connectors.

REAR RH : Component Inspection

COMPONENT INSPECTION

CHECK REAR POWER WINDOW MOTOR RH Disconnect rear power window motor RH. Check motor operation by connecting battery voltage directly to rear power window motor RH. CONNECTOR TERMINAL REFERENCE CHART Terminal Motor condition (+) (-) 3 1 UP 1 3 DOWN Is the inspection result normal? YES >> Inspection End. NO >> Replace rear power window motor RH. Refer to " «REAR DOOR GLASS REGULATOR»(ref-388089-S40440642102011022800000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 26

Scheme 26: DRIVER SIDE : Diagnosis Procedure

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

CHECK ENCODER OPERATION Turn ignition switch ON. Check signal between main power window and door lock/unlock switch connector D7 terminals 9, 13 and ground with oscilloscope. SIGNAL REFERENCE CHART Terminals Signal (Reference value) (+) (-) Main power window and door lock/unlock switch connector Terminal D7 9 Ground Refer to following signal (Scheme 27) 13 Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 2
CHECK ENCODER POWER SUPPLY Check voltage between front power window motor LH connector D9 terminal 4 and ground. VOLTAGE REFERENCE CHART Terminal Voltage (V) (Approx.) (+) (-) Front power window motor LH connector Terminal D9 4 Ground 10 Is the inspection result normal? YES >> GO TO 4 NO >> GO TO 3
CHECK HARNESS CONTINUITY 1 Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector D7 and front power window motor LH connector. Check continuity between main power window and door lock/unlock switch connector D7 (A) terminal 15 and front power window motor LH connector D9 (B) terminal 4. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Front power window motor LH connector Terminal Continuity D7 (A) 15 D9 (B) 4 Yes Check continuity between main power window and door lock/unlock switch connector D7 (A) terminal 15 and ground. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Ground Continuity D7 (A) 15 No Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.
CHECK ENCODER GROUND CIRCUIT Turn ignition switch OFF. Disconnect front power window motor LH connector. Check continuity between front power window motor LH connector D9 terminal 6 and ground. CONNECTOR TERMINAL REFERENCE CHART Front power window motor LH connector Terminal Ground Continuity D9 6 Yes Is the inspection result normal? YES >> GO TO 6 NO >> GO TO 5
CHECK HARNESS CONTINUITY 2 Disconnect main power window and door lock/unlock switch connector D7. Check continuity between main power window and door lock/unlock switch connector D7 (A) terminal 2 and front power window motor LH connector D9 (B) terminal 6. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Front power window motor LH connector Terminal Continuity D7 (A) 2 D9 (B) 6 Yes Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.
CHECK HARNESS CONTINUITY 3 Disconnect main power window and door lock/unlock switch connector D7. Check continuity between main power window and door lock/unlock switch connector D7 (A) terminals 9, 13 and front power window motor LH connector D9 (B) terminals 3, 5. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Front power window motor LH connector Terminal Continuity D7 (A) 9 D9 (B) 5 Yes 13 3 Check continuity between main power window and door lock/unlock switch connector D7 (A) terminals 9, 13 and ground. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Ground Continuity D7 (A) 9 No 13 Is the inspection result normal? YES >> Replace front power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ". NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 33

Scheme 33: PASSENGER SIDE : Diagnosis Procedure

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

CHECK ENCODER SIGNAL Turn ignition switch ON. Check signal between power window and door lock/unlock switch RH connector D105 terminal 12, 15 and ground with oscilloscope. SIGNAL REFERENCE CHART Terminals Signal (Reference value) (+) (-) Power window and door lock/unlock switch RH connector Terminal D105 12 Ground Refer to following signal (Scheme 34) 15 Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 2
CHECK ENCODER POWER SUPPLY Check voltage between front power window motor RH connector D104 terminal 4 and ground. VOLTAGE REFERENCE CHART Terminal Voltage (V) (Approx.) (+) (-) Front power window motor RH connector Terminal D104 4 Ground 10 Is the inspection result normal? YES >> GO TO 4 NO >> GO TO 3
CHECK HARNESS CONTINUITY 1 Turn ignition switch OFF. Disconnect power window and door lock/unlock switch RH and front power window motor RH connectors. Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminal 4 and front power window motor RH connector D104 (B) terminal 4. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Front power window motor RH connector Terminal Continuity D105 (A) 4 D104 (B) 4 Yes Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminal 4 and ground. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Ground Continuity D105 (A) 4 No Is the inspection result normal? YES >> Replace power window and door lock/unlock switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S07081875712011022800000) ". NO >> Repair or replace harness or connectors.
CHECK ENCODER GROUND CIRCUIT Turn ignition switch OFF. Disconnect front power window motor RH connector. Check continuity between front power window motor RH connector D104 terminal 6 and ground. CONNECTOR TERMINAL REFERENCE CHART Front power window motor RH connector Terminal Ground Continuity D104 6 Yes Is the inspection result normal? YES >> GO TO 6 NO >> GO TO 5
CHECK HARNESS CONTINUITY 2 Disconnect power window and door lock/unlock switch RH connector. Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminal 3 and front power window motor RH connector D104 (B) terminal 6. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Front power window motor RH connector Terminal Continuity D105 (A) 3 D104 (B) 6 Yes Is the inspection result normal? YES >> Replace power window and door lock/unlock switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S07081875712011022800000) ". NO >> Repair or replace harness or connectors.
CHECK HARNESS CONTINUITY 3 Disconnect power window and door lock/unlock switch RH connector. Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminals 12, 15 and front power window motor RH connector D104 (B) terminals 3, 5. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Front power window motor RH connector Terminal Continuity D105 (A) 12 D104 (B) 3 Yes 15 5 Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminals 12, 15 and ground. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Ground Continuity D105 (A) 12 No 15 Is the inspection result normal? YES >> Replace front power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ". NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 40

Scheme 40: Diagnosis Procedure

Scheme 41

Scheme 42

CHECK DOOR SWITCH INPUT SIGNAL Turn ignition switch OFF. Check signal between BCM connector and ground with oscilloscope. SIGNAL REFERENCE CHART Terminals Door condition Voltage (V) (Approx.) (+) (-) BCM connector Terminal A: M18 58 Ground Driver side OPEN 0 CLOSE 32 Passenger side OPEN 0 CLOSE Is the inspection result normal? YES >> GO TO 4 NO >> GO TO 2
CHECK DOOR SWITCH CIRCUIT Disconnect BCM connector. Check continuity between BCM connector and door switch connector. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Door switch connector Terminal Continuity M18 58 B8 (Driver side) 2 Yes 32 B108 (Passenger side) Check continuity between BCM connector and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M18 58 No 32 Is the inspection result normal? YES >> GO TO 3 NO >> Repair or replace harness between BCM and door switch.
CHECK DOOR SWITCH Refer to " «COMPONENT INSPECTION»(ref-388086-S35162032292011022800000) ". Is the inspection result normal? YES >> GO TO 4 NO >> Replace malfunctioning door switch.
CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". Inspection End.

Scheme 43

Scheme 43: Component Inspection

CHECK DOOR SWITCH Turn ignition switch OFF. Disconnect door switch connector. Check door switch. CONNECTOR TERMINAL REFERENCE CHART Terminal Door switch condition Continuity Door switch 2 Ground part of door switch Pressed No Released Yes Is the inspection result normal? YES >> Inspection End. NO >> Replace malfunctioning door switch.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 44

Scheme 44: Diagnosis Procedure

Scheme 45

Scheme 46

CHECK DOOR KEY CYLINDER SWITCH INPUT SIGNAL Turn ignition switch ON. Check voltage between main power window and door lock/unlock switch connector and ground. VOLTAGE REFERENCE CHART Terminals Key position Voltage (V) (Approx.) (+) (-) BCM Main power window and door lock/unlock switch connector Terminal D7 4 Ground Lock 0 Neutral / Unlock 5 6 Unlock 0 Neutral / Lock 5 Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". After that, refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S41823401722011022800000) ". NO >> GO TO 2
CHECK DOOR KEY CYLINDER SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector and front door lock assembly LH (key cylinder switch) connector. Check continuity between main power window and door lock/unlock switch connector and front door lock assembly LH (key cylinder switch) connector. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Front door lock assembly LH (key cylinder switch) connector Terminal Continuity A: D7 4 B: D10 6 Yes 6 5 Check continuity between main power window and door lock/unlock switch connector and ground. CONNECTOR TERMINAL REFERENCE CHART Power window main switch connector Terminal Ground Continuity A: D7 4 No 6 Is the inspection result normal? YES >> GO TO 3 NO >> Repair or replace harness.
CHECK DOOR KEY CYLINDER SWITCH GROUND CIRCUIT Check continuity between front door lock assembly LH connector and ground. CONNECTOR TERMINAL REFERENCE CHART Front door lock assembly LH connector Terminal Ground Continuity D10 4 Yes Is the inspection result normal? YES >> GO TO 4 NO >> Repair or replace harness.
CHECK DOOR KEY CYLINDER SWITCH Check door key cylinder switch. Refer to " «COMPONENT INSPECTION»(ref-388086-S42706568362011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Replace front door lock assembly LH (key cylinder switch). Refer to " «FRONT DOOR LOCK : REMOVAL AND INSTALLATION»(ref-388085-S24611053912011022800000) ". After that, Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S41823401722011022800000) ".

Scheme 47

Scheme 47: COMPONENT INSPECTION

CHECK DOOR KEY CYLINDER SWITCH Check front door lock assembly LH (key cylinder switch). CONNECTOR TERMINAL REFERENCE CHART Terminal Key position Continuity Front door lock assembly LH (key cylinder switch) connector 5 4 Unlock Yes Neutral / Lock No 6 Lock Yes Neutral / Unlock No Is the inspection result normal? YES >> Key cylinder switch is OK. NO >> Replace front door lock assembly LH (key cylinder switch). Refer to " «FRONT DOOR LOCK : REMOVAL AND INSTALLATION»(ref-388085-S24611053912011022800000) ". After that, refer to " «SPECIAL REPAIR REQUIREMENT»(ref-388086-S09938019672011022800000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 48

Scheme 48: POWER WINDOW MAIN SWITCH : Diagnosis Procedure

Scheme 49

Scheme 50

CHECK POWER WINDOW SWITCH OUTPUT SIGNAL Remove Intelligent Key, and close front door LH and RH. Check signal between BCM connector M18 terminal 40 and ground with oscilloscope when door lock and unlock switch (key cylinder switch) is turned to "LOCK" or "UNLOCK". Check that signals which are shown in the figure below can be detected during 10 seconds just after door lock and unlock switch (key cylinder switch) is turned to "LOCK" or "UNLOCK". SIGNAL REFERENCE CHART Terminal Signal (Reference value) (+) (-) BCM connector Terminal M18 40 Ground Is the inspection result normal? YES >> Power window serial link is OK. NO >> GO TO 2
CHECK POWER WINDOW SERIAL LINK CIRCUIT Turn ignition switch OFF. Disconnect BCM connector M18 and main power window and door lock/unlock switch connector D7. Check continuity between BCM connector M18 (A) terminal 40 and main power window and door lock/unlock switch connector D7 (B) terminal 14. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Main power window and door lock/unlock switch connector Terminal Continuity M18 (A) 40 D7 (B) 14 Yes Check continuity between BCM connector M18 (A) terminal 40 and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M18 (A) 40 No Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT LEFT AND RIGHT POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 51

Scheme 51: FRONT POWER WINDOW SWITCH : Diagnosis Procedure

Scheme 52

Scheme 53

CHECK POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH Remove Intelligent Key, and close the front door LH and RH. Check signal between BCM connector M18 terminal 40 and ground with oscilloscope when door lock and unlock switch (key cylinder switch) is turned to "LOCK" or "UNLOCK". Check that signals which are shown in the figure below can be detected during 10 seconds just after door lock and unlock switch (key cylinder switch) is turned to "LOCK" or "UNLOCK". SIGNAL REFERENCE CHART Terminal Signal (Reference value) (+) (-) BCM connector Terminal M18 40 Ground Is the inspection result normal? YES >> Power window serial link is OK. NO >> GO TO 2
CHECK POWER WINDOW SERIAL LINK CIRCUIT Turn ignition switch OFF. Disconnect BCM connector M18 and power window and door lock/unlock switch RH connector. Check continuity between BCM connector M18 (A) terminal 40 and power window and door lock/unlock switch RH connector D105 (B) terminal 16. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Power window and door lock/unlock switch RH connector Terminal Continuity M18 (A) 40 D105 (B) 16 Yes Check continuity between BCM connector M18 (A) terminal 40 and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M18 (A) 40 No Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.

VALUES ON THE DIAGNOSIS TOOL

Monitor Item	Condition	Value/Status
FR WIPER HI	Other than front wiper switch HI	OFF
FR WIPER HI	Front wiper switch HI	ON
FR WIPER LOW	Other than front wiper switch LO	OFF
FR WIPER LOW	Front wiper switch LO	ON
FR WASHER SW	Front washer switch OFF	OFF
FR WASHER SW	Front washer switch ON	ON
FR WIPER INT	Other than front wiper switch INT	OFF
FR WIPER INT	Front wiper switch INT	ON
FR WIPER STOP	Front wiper is not in STOP position	OFF
FR WIPER STOP	Front wiper is in STOP position	ON
INT VOLUME	Wiper intermittent dial is in a dial position 1 - 7	Wiper intermittent dial position
TURN SIGNAL R	Other than turn signal switch RH	OFF
TURN SIGNAL R	Turn signal switch RH	ON
TURN SIGNAL L	Other than turn signal switch LH	OFF
TURN SIGNAL L	Turn signal switch LH	ON
TAIL LAMP SW	Other than lighting switch 1ST and 2ND	OFF
TAIL LAMP SW	Lighting switch 1ST or 2ND	ON
HI BEAM SW	Other than lighting switch HI	OFF
HI BEAM SW	Lighting switch HI	ON
HEAD LAMP SW 1	Other than lighting switch 2ND	OFF
HEAD LAMP SW 1	Lighting switch 2ND	ON
HEAD LAMP SW 2	Other than lighting switch 2ND	OFF
HEAD LAMP SW 2	Lighting switch 2ND	ON
PASSING SW	Other than lighting switch PASS	OFF
PASSING SW	Lighting switch PASS	ON
AUTO LIGHT SW	Other than lighting switch AUTO	OFF
AUTO LIGHT SW	Lighting switch AUTO	ON
FR FOG SW	Front fog lamp switch OFF	OFF
FR FOG SW	Front fog lamp switch ON	ON
DOOR SW-DR	Driver door closed	OFF
DOOR SW-DR	Driver door opened	ON
DOOR SW-AS	Passenger door closed	OFF
DOOR SW-AS	Passenger door opened	ON
DOOR SW-RR	Rear door RH closed	OFF
DOOR SW-RR	Rear door RH opened	ON
DOOR SW-RL	Rear door LH closed	OFF
DOOR SW-RL	Rear door LH opened	ON
CDL LOCK SW	Other than power door lock switch LOCK	OFF
CDL LOCK SW	Power door lock switch LOCK	ON
CDL UNLOCK SW	Other than power door lock switch UNLOCK	OFF
CDL UNLOCK SW	Power door lock switch UNLOCK	ON
KEY CYL LK-SW	Other than driver door key cylinder LOCK position	OFF
KEY CYL LK-SW	Driver door key cylinder LOCK position	ON
KEY CYL UN-SW	Other than driver door key cylinder UNLOCK position	OFF
KEY CYL UN-SW	Driver door key cylinder UNLOCK position	ON
HAZARD SW	When hazard switch is not pressed	OFF
HAZARD SW	When hazard switch is pressed	ON
REAR DEF SW	When rear window defogger switch is pressed	ON
TR CANCEL SW	Trunk lid opener cancel switch OFF	OFF
TR CANCEL SW	Trunk lid opener cancel switch ON	ON
TR/BD OPEN SW	Trunk lid opener switch OFF	OFF
TR/BD OPEN SW	While the trunk lid opener switch is turned ON	ON
TRNK/HAT MNTR	Trunk lid closed	OFF
TRNK/HAT MNTR	Trunk lid opened	ON
RKE-LOCK	When LOCK button of Intelligent Key is not pressed	OFF
RKE-LOCK	When LOCK button of Intelligent Key is pressed	ON
RKE-UNLOCK	When UNLOCK button of Intelligent Key is not pressed	OFF
RKE-UNLOCK	When UNLOCK button of Intelligent Key is pressed	ON
RKE-TR/BD	When TRUNK OPEN button of Intelligent Key is not pressed	OFF
RKE-TR/BD	When TRUNK OPEN button of Intelligent Key is pressed	ON
RKE-PANIC	When PANIC button of Intelligent Key is not pressed	OFF
RKE-PANIC	When PANIC button of Intelligent Key is pressed	ON
RKE-P/W OPEN	When UNLOCK button of Intelligent Key is not pressed and held	OFF
RKE-P/W OPEN	When UNLOCK button of Intelligent Key is pressed and held	ON
RKE-MODE CHG	When LOCK/UNLOCK button of Intelligent Key is not pressed and held simultaneously	OFF
RKE-MODE CHG	When LOCK/UNLOCK button of Intelligent Key is pressed and held simultaneously	ON
OPTICAL SENSOR	When outside of the vehicle is bright	Close to 5 V
OPTICAL SENSOR	When outside of the vehicle is dark	Close to 0 V
REQ SW-DR	When front door request switch is not pressed (driver side)	OFF
REQ SW-DR	When front door request switch is pressed (driver side)	ON
REQ SW-AS	When front door request switch is not pressed (passenger side)	OFF
REQ SW-AS	When front door request switch is pressed (passenger side)	ON
REQ SW-RL	When rear door request switch is not pressed (driver side)	OFF
REQ SW-RL	When rear door request switch is pressed (driver side)	ON
REQ SW-RR	When rear door request switch is not pressed (passenger side)	OFF
REQ SW-RR	When rear door request switch is pressed (passenger side)	ON
REQ SW-BD/TR	When trunk request switch is not pressed	OFF
REQ SW-BD/TR	When trunk request switch is pressed	ON
PUSH SW	When engine switch (push switch) is not pressed	OFF
PUSH SW	When engine switch (push switch) is pressed	ON
IGN RLY 2 -F/B	Ignition switch OFF or ACC	OFF
IGN RLY 2 -F/B	Ignition switch ON	ON
ACC RLY-F/B	Ignition switch OFF	OFF
ACC RLY-F/B	Ignition switch ACC or ON	ON
BRAKE SW 1	When the brake pedal is not depressed	ON
BRAKE SW 1	When the brake pedal is depressed	OFF
DETE/CANCL SW	When selector lever is in P position	OFF
DETE/CANCL SW	When selector lever is in any position other than P	ON
SFT PN/N SW	When selector lever is in any position other than P or N	OFF
SFT PN/N SW	When selector lever is in P or N position	ON
UNLK SEN-DR	Driver door UNLOCK status	OFF
UNLK SEN-DR	Driver door LOCK status	ON
PUSH SW-IPDM	When engine switch (push switch) is not pressed	OFF
PUSH SW-IPDM	When engine switch (push switch) is pressed	ON
IGN RLY1 -F/B	Ignition switch OFF or ACC	OFF
IGN RLY1 -F/B	Ignition switch ON	ON
DETE SW-IPDM	When selector lever is in P position	OFF
DETE SW-IPDM	When selector lever is in any position other than P	ON
SFT PN-IPDM	When selector lever is in any position other than P or N	OFF
SFT PN-IPDM	When selector lever is in P or N position	ON
SFT P-MET	When selector lever is in any position other than P	OFF
SFT P-MET	When selector lever is in P position	ON
SFT N-MET	When selector lever is in any position other than N	OFF
SFT N-MET	When selector lever is in N position	ON
ENGINE STATE	Engine stopped	STOP
	While the engine stalls	STALL
	At engine cranking	CRANK
	Engine running	RUN
VEH SPEED 1	While driving	Equivalent to speedometer reading
VEH SPEED 2	While driving	Equivalent to speedometer reading
DOOR STAT-DR	Driver door LOCK status	LOCK
	Wait with selective UNLOCK operation (5 seconds)	READY
	Driver door UNLOCK status	UNLK
DOOR STAT-AS	Passenger door LOCK status	LOCK
	Wait with selective UNLOCK operation (5 seconds)	READY
	Passenger door UNLOCK status	UNLK
ID OK FLAG	Ignition switch ACC or ON	RESET
ID OK FLAG	Ignition switch OFF	SET
PRMT ENG STRT	When the engine start is prohibited	RESET
PRMT ENG STRT	When the engine start is permitted	SET
KEY SW-SLOT	When Intelligent Key is not inserted into key slot	OFF
KEY SW-SLOT	When Intelligent Key is inserted into key slot	ON
RKE OPE COUN1	During the operation of Intelligent Key	Operation frequency of Intelligent Key
CONFRM ID ALL	The key ID that the key slot receives does not accord with any key ID registered to BCM.	YET
CONFRM ID ALL	The key ID that the key slot receives accords with any key ID registered to BCM.	DONE
CONFIRM ID4	The key ID that the key slot receives does not accord with the fourth key ID registered to BCM.	YET
CONFIRM ID4	The key ID that the key slot receives accords with the fourth key ID registered to BCM.	DONE
CONFIRM ID3	The key ID that the key slot receives does not accord with the third key ID registered to BCM.	YET
CONFIRM ID3	The key ID that the key slot receives accords with the third key ID registered to BCM.	DONE
CONFIRM ID2	The key ID that the key slot receives does not accord with the second key ID registered to BCM.	YET
CONFIRM ID2	The key ID that the key slot receives accords with the second key ID registered to BCM.	DONE
CONFIRM ID1	The key ID that the key slot receives does not accord with the first key ID registered to BCM.	YET
CONFIRM ID1	The key ID that the key slot receives accords with the first key ID registered to BCM.	DONE
TP 4	The ID of fourth key is not registered to BCM	YET
TP 4	The ID of fourth key is registered to BCM	DONE
TP 3	The ID of third key is not registered to BCM	YET
TP 3	The ID of third key is registered to BCM	DONE
TP 2	The ID of second key is not registered to BCM	YET
TP 2	The ID of second key is registered to BCM	DONE
TP 1	The ID of first key is not registered to BCM	YET
TP 1	The ID of first key is registered to BCM	DONE
AIR PRESS FL	Ignition switch ON (only when the signal from the transmitter is received)	Air pressure of front LH tire
AIR PRESS FR	Ignition switch ON (only when the signal from the transmitter is received)	Air pressure of front RH tire
AIR PRESS RR	Ignition switch ON (only when the signal from the transmitter is received)	Air pressure of rear RH tire
AIR PRESS RL	Ignition switch ON (only when the signal from the transmitter is received)	Air pressure of rear LH tire
ID REGST FL1	When ID of front LH tire transmitter is registered	DONE
ID REGST FL1	When ID of front LH tire transmitter is not registered	YET
ID REGST FR1	When ID of front RH tire transmitter is registered	DONE
ID REGST FR1	When ID of front RH tire transmitter is not registered	YET
ID REGST RR1	When ID of rear RH tire transmitter is registered	DONE
ID REGST RR1	When ID of rear RH tire transmitter is not registered	YET
ID REGST RL1	When ID of rear LH tire transmitter is registered	DONE
ID REGST RL1	When ID of rear LH tire transmitter is not registered	YET
WARNING LAMP	Tire pressure indicator OFF	OFF
WARNING LAMP	Tire pressure indicator ON	ON
BUZZER	Tire pressure warning alarm is not sounding	OFF
BUZZER	Tire pressure warning alarm is sounding	ON

BODY CONTROL MODULE REFERENCE CHART

Scheme 54

Scheme 54: Terminal Layout

DTC Inspection Priority Chart

If some DTCs are displayed at the same time, perform inspections one by one based on the following priority chart.

Priority	DTC
1	B2562: LO VOLTAGE
2	U1000: CAN COMM CIRCUIT U1010: CONTROL UNIT (CAN)
3	B2190: NATS ANTENNA AMP B2191: DIFFERENCE OF KEY B2192: ID DISCORD BCM-ECM B2193: CHAIN OF BCM-ECM
4	B2553: IGNITION RELAY B2555: STOP LAMP B2556: PUSH-BTN IGN SW B2557: VEHICLE SPEED B2560: STARTER CONT RELAY B2601: SHIFT POSITION B2602: SHIFT POSITION B2603: SHIFT POSI STATUS B2604: PNP SWITCH B2605: PNP SWITCH B2608: STARTER RELAY B260A: IGNITION RELAY B260F: ENG STATE SIG LOST B2614: ACC RELAY CIRC B2615: BLOWER RELAY CIRC B2616: IGN RELAY CIRC B2617: STARTER RELAY CIRC B2618: BCM B261A: PUSH-BTN IGN SW B26E1: ENG STATE NO RECIV C1729: VHCL SPEED SIG ERR U0415: VEHICLE SPEED SIG
5	C1704: LOW PRESSURE FL C1705: LOW PRESSURE FR C1706: LOW PRESSURE RR C1707: LOW PRESSURE RL C1708: [NO DATA] FL C1709: [NO DATA] FR C1710: [NO DATA] RR C1711: [NO DATA] RL C1712: [CHECKSUM ERR] FL C1713: [CHECKSUM ERR] FR C1714: [CHECKSUM ERR] RR C1715: [CHECKSUM ERR] RL C1716: [PRESSDATA ERR] FL C1717: [PRESSDATA ERR] FR C1718: [PRESSDATA ERR] RR C1719: [PRESSDATA ERR] RL C1720: [CODE ERR] FL C1721: [CODE ERR] FR C1722: [CODE ERR] RR C1723: [CODE ERR] RL C1724: [BATT VOLT LOW] FL C1725: [BATT VOLT LOW] FR C1726: [BATT VOLT LOW] RR C1727: [BATT VOLT LOW] RL C1734: CONTROL UNIT
6	B2622: INSIDE ANTENNA B2623: INSIDE ANTENNA

DTC INSPECTION PRIORITY CHART

DTC Index

Note. Details of time display CRNT: Displays when there is a malfunction now or after returning to the normal condition until turning ignition switch OFF --> ON again. 1 - 39: Displayed if any previous malfunction is present when current condition is normal. It increases 1 --> 2 --> 3...38 --> 39 after returning to the normal condition whenever ignition switch OFF --> ON. The counter remains at 39 even if the number of cycles exceeds it. It is counted from 1 again when turning ignition switch OFF --> ON after returning to the normal condition if the malfunction is detected again.

CONSULT display	Fail-safe	Intelligent Key warning lamp ON	Tire pressure monitor warning lamp ON	Reference
No DTC is detected. further testing may be required.
U1000: CAN COMM CIRCUIT				U1000 CAN COMM CIRCUIT
U1010: CONTROL UNIT (CAN)				U1010 CONTROL UNIT (CAN)
U0415: VEHICLE SPEED SIG				U0415 VEHICLE SPEED SIG
B2190: NATS ANTENNA AMP	X			B2190 NATS ANTENNA AMP
B2191: DIFFERENCE OF KEY	X			B2191 DIFFERENCE OF KEY
B2192: ID DISCORD BCM-ECM	X			B2192 ID DISCORD, IMMU-ECM
B2193: CHAIN OF BCM-ECM	X			B2193 CHAIN OF ECM-IMMU
B2553: IGNITION RELAY				B2553 IGNITION RELAY
B2555: STOP LAMP				B2555 STOP LAMP
B2556: PUSH-BTN IGN SW		X		B2556 PUSH-BUTTON IGNITION SWITCH
B2557: VEHICLE SPEED	X	X		B2557 VEHICLE SPEED
B2560: STARTER CONT RELAY	X	X		B2560 STARTER CONTROL RELAY
B2562: LOW VOLTAGE				B2562 LOW VOLTAGE
B2601: SHIFT POSITION	X	X		B2601 SHIFT POSITION
B2602: SHIFT POSITION	X	X		B2602 SHIFT POSITION
B2603: SHIFT POSI STATUS	X	X		B2603 SHIFT POSITION STATUS
B2604: PNP SWITCH	X	X		B2604 TRANSMISSION RANGE SWITCH
B2605: PNP SWITCH	X	X		B2605 TRANSMISSION RANGE SWITCH
B2608: STARTER RELAY	X	X		B2608 STARTER RELAY
B260A: IGNITION RELAY	X	X		B260A IGNITION RELAY
B260F: ENG STATE SIG LOST	X	X		B260F ENGINE STATUS
B2614: ACC RELAY CIRC		X		B2614 ACC RELAY CIRCUIT
B2615: BLOWER RELAY CIRC		X		B2615 FRONT BLOWER MOTOR RELAY CIRCUIT
B2616: IGN RELAY CIRC		X		B2616 IGNITION RELAY CIRCUIT
B2617: STARTER RELAY CIRC	X	X		B2617 STARTER RELAY CIRCUIT
B2618: BCM	X	X		B2618 BCM
B261A: PUSH-BTN IGN SW		X		B261A PUSH-BUTTON IGNITION SWITCH
B2622: INSIDE ANTENNA				B2622 INSIDE KEY ANTENNA 2
B2623: INSIDE ANTENNA				B2623 INSIDE KEY ANTENNA 3
B26E1: ENG STATE NO RES	X	X		B26E1 NO RECEPTION OF ENGINE STATUS SIGNAL
C1704: LOW PRESSURE FL			X	SELF-DIAGNOSIS (WITH CONSULT-III)
C1705: LOW PRESSURE FR			X	SELF-DIAGNOSIS (WITH CONSULT-III)
C1706: LOW PRESSURE RR			X	SELF-DIAGNOSIS (WITH CONSULT-III)
C1707: LOW PRESSURE RL			X	SELF-DIAGNOSIS (WITH CONSULT-III)
C1708: [NO DATA] FL			X	C1708 - C1711 DATA FROM TRANSMITTER NOT BEING RECEIVED
C1709: [NO DATA] FR			X	C1708 - C1711 DATA FROM TRANSMITTER NOT BEING RECEIVED
C1710: [NO DATA] RR			X	C1708 - C1711 DATA FROM TRANSMITTER NOT BEING RECEIVED
C1711: [NO DATA] RL			X	C1708 - C1711 DATA FROM TRANSMITTER NOT BEING RECEIVED
C1712: [CHECKSUM ERR] FL			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1713: [CHECKSUM ERR] FR			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1714: [CHECKSUM ERR] RR			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1715: [CHECKSUM ERR] RL			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1716: [PRESSDATA ERR] FL			X	C1716 - C1719 TRANSMITTER PRESSURE MALFUNCTION
C1717: [PRESSDATA ERR] FR			X	C1716 - C1719 TRANSMITTER PRESSURE MALFUNCTION
C1718: [PRESSDATA ERR] RR			X	C1716 - C1719 TRANSMITTER PRESSURE MALFUNCTION
C1719: [PRESSDATA ERR] RL			X	C1716 - C1719 TRANSMITTER PRESSURE MALFUNCTION
C1720: [CODE ERR] FL			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1721: [CODE ERR] FR			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1722: [CODE ERR] RR			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1723: [CODE ERR] RL			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1724: [BATT VOLT LOW] FL			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1725: [BATT VOLT LOW] FR			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1726: [BATT VOLT LOW] RR			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1727: [BATT VOLT LOW] RL			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1729: VHCL SPEED SIG ERR			X	C1729 VEHICLE SPEED SIGNAL
C1734: CONTROL UNIT			X	C1734 CONTROL UNIT

DIAGNOSTIC TROUBLE CODE CHART

Scheme 55

Scheme 55: Wiring Diagram - With Front Left And Right Power Window Anti-Pinch System

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

CHECK BCM POWER SUPPLY AND GROUND CIRCUIT Check BCM power supply and ground circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-388072-S07430202432011022800000) ". Is the inspection result normal? YES >> GO TO 2 NO >> Repair or replace the malfunctioning parts.
CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH POWER SUPPLY AND GROUND CIRCUIT Check main power window and door lock/unlock switch power supply and ground circuit. Refer to " «POWER WINDOW MAIN SWITCH : DIAGNOSIS PROCEDURE»(ref-388086-S08600061402011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace the malfunctioning parts.

CHECK FRONT POWER WINDOW MOTOR LH Check front power window motor LH. Refer to " «DRIVER SIDE : COMPONENT FUNCTION CHECK»(ref-388086-S20481824142011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ".

CHECK FRONT POWER WINDOW MOTOR RH CIRCUIT Check front power window motor RH circuit. Refer to " «PASSENGER SIDE : COMPONENT FUNCTION CHECK»(ref-388086-S04939714702011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ".

CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to " «REAR LH : COMPONENT FUNCTION CHECK»(ref-388086-S26975366152011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ".

CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to " «REAR RH : COMPONENT FUNCTION CHECK»(ref-388086-S25701273942011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ".

PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S41823401722011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> GO TO 2
CHECK ENCODER CIRCUIT Check encoder circuit. Refer to " «DRIVER SIDE : COMPONENT FUNCTION CHECK»(ref-388086-S17973960652011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace malfunctioning parts.

PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S41823401722011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> GO TO 2
CHECK ENCODER CIRCUIT Check encoder circuit. Refer to " «PASSENGER SIDE : COMPONENT FUNCTION CHECK»(ref-388086-S20369341642011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace the malfunctioning parts.

PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S41823401722011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> GO TO 2
CHECK ENCODER Check encoder. Refer to " «DRIVER SIDE : COMPONENT FUNCTION CHECK»(ref-388086-S17973960652011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace the malfunctioning parts.

PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S41823401722011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> GO TO 2
CHECK ENCODER Check encoder. Refer to " «PASSENGER SIDE : COMPONENT FUNCTION CHECK»(ref-388086-S20369341642011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace the malfunctioning parts.

CHECK FRONT DOOR SWITCH Check front door switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-388086-S22467534732011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace malfunctioning parts.

CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH) Check front door lock assembly LH (key cylinder switch). Refer to " «DIAGNOSIS PROCEDURE»(ref-388086-S42222807792011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace malfunctioning parts.

CHECK INTELLIGENT KEY FUNCTION Check Intelligent Key function. Refer to " «COMPONENT FUNCTION CHECK»(ref-388085-S22466078172011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-388072-S03584481162011022800000) ".

CHECK POWER WINDOW LOCK SWITCH Check power window lock switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-388086-S18481702332011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace malfunctioning parts.

BASIC INSPECTION

INSPECTION START Check the service history. Check the following parts. Fuse/circuit breaker blown. Poor connection, open or short circuit of harness connector. Battery voltage. Is the inspection result normal? YES >> Inspection End. NO >> Repair or replace the malfunctioning parts.

Scheme 63

Scheme 63: REMOVAL

Scheme 64

Remove the front door grip cover. Refer to " «EXPLODED VIEW»(ref-388080-S33815184282011022800000) ".
Remove the main power window/door lock switch locking clip (A).
Using a suitable tool, release the metal clip and lift the main power window/door lock switch and finisher as an assembly upward to remove it from the front door finisher. []: Metal clip o: Pawl CAUTION: Wrap a cloth around suitable tool to protect components from damage.
Disconnect the harness connector.
Release the pawls on each side, then separate the switch finisher (1) from the main power window/door lock switch (2) and remove. CAUTION: Do not fold the pawl of the main power window/door lock switch finisher.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

Scheme 65

Scheme 65: BCM : Diagnosis Procedure

Scheme 66

CHECK FUSE AND FUSIBLE LINK Check if the following BCM fuses or fusible link are blown. FUSE REFERENCE CHART Terminal No. Signal name Fuse and fusible link No. 1 Battery power supply H 11 10 24 7 Is the fuse or fusible link blown? YES >> Replace the blown fuse or fusible link after repairing the affected circuit. NO >> GO TO 2
CHECK POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect BCM. Check voltage between BCM harness connector and ground. VOLTAGE REFERENCE CHART Terminals Voltage (Approx.) (+) (-) BCM Ground Connector Terminal M16 (A) 1 Battery voltage M17 (B) 11 M18 (C) 24 Is the measurement normal? YES >> GO TO 3 NO >> Repair or replace harness.
CHECK GROUND CIRCUIT Check continuity between BCM harness connector and ground. CONNECTOR TERMINAL REFERENCE CHART BCM Ground Continuity Connector Terminal M17 13 Yes Does continuity exist? YES >> Inspection End. NO >> Repair or replace harness.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 67

Scheme 67: POWER WINDOW MAIN SWITCH : Diagnosis Procedure

Scheme 68

Scheme 69

CHECK POWER SUPPLY CIRCUIT Turn ignition switch ON. Check voltage between main power window and door lock/unlock switch connectors D7 (A) terminal 10 and D8 (B) terminal 19 and ground. VOLTAGE REFERENCE CHART Terminal Voltage (V) (Approx.) (+) (-) Main power window and door lock/unlock switch connector Terminal D7 (A) 10 Ground Battery voltage D8 (B) 19 Is the inspection result normal? YES >> GO TO 3 NO >> GO TO 2
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect BCM connector M16 and main power window and door lock/unlock switch connectors. Check continuity between BCM connector M16 (A) terminals 2 and 3 and main power window and door lock/unlock switch connectors D7 (B) terminal 10 and D8 (C) terminal 19. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Main power window and door lock/unlock switch connector Terminal Continuity M16 (A) 3 D7 (B) 10 Yes 2 D8 (C) 19 Check continuity between BCM connector M16 (A) terminals 2 and 3 and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M16 (A) 3 No 2 Is the inspection result normal? YES >> Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-388072-S03584481162011022800000) ". NO >> Repair or replace harness or connectors.
CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector D8. Check continuity between main power window and door lock/unlock switch connector D8 terminal 17 and ground. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Ground Continuity D8 17 Yes Is the inspection result normal? YES >> Inspection End. NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 70

Scheme 70: FRONT POWER WINDOW SWITCH : Diagnosis Procedure

Scheme 71

Scheme 72

CHECK POWER SUPPLY CIRCUIT Check voltage between power window and door lock/unlock switch RH connector D105 terminal 10 and ground. VOLTAGE REFERENCE CHART Terminal Voltage (V) (Approx.) (+) (-) Power window and door lock/unlock switch RH connector Terminal D105 10 Ground Battery voltage Is the inspection result normal? YES >> GO TO 3 NO >> GO TO 2
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect BCM connector M16 and power window and door lock/unlock switch RH connector. Check continuity between BCM connector M16 (A) terminal 2 and power window and door lock/unlock switch RH connector D105 (B) terminal 10. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Power window and door lock/unlock switch RH connector Terminal Continuity M16 (A) 2 D105 (B) 10 Yes Check continuity between BCM connector M16 (A) terminal 2 and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M16 (A) 2 No Is the inspection result normal? YES >> Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-388072-S03584481162011022800000) ". NO >> Repair or replace harness or connectors.
CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect power window and door lock/unlock switch RH. Check continuity between power window and door lock/unlock switch RH connector D105 terminal 11 and ground. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH Terminal Ground Continuity D105 11 Yes Is the inspection result normal? YES >> Inspection End. NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 73

Scheme 73: REAR POWER WINDOW SWITCH : Diagnosis Procedure

Scheme 74

Scheme 75

CHECK POWER SUPPLY CIRCUIT Check voltage between rear power window switch connector terminal 10 and ground. VOLTAGE REFERENCE CHART (+) (-) Voltage (V) (Approx.) Rear power window switch Connector Terminal D207 (LH) 10 Ground Battery voltage D307 (RH) Is the inspection result normal? YES >> GO TO 3 NO >> GO TO 2
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect BCM connector M16 and rear power window switch connector. Check continuity between BCM connector M16 (A) terminal 2 and rear power window switch connector (B) terminal 10. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Rear power window switch connector Terminal Continuity M16 (A) 2 D207 (LH) (B) 10 Yes D307 (RH) (B) Check continuity between BCM connector M16 (A) terminal 2 and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M16 (A) 2 No Is the inspection result normal? YES >> Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-388072-S03584481162011022800000) ". NO >> Repair or replace harness or connectors.
CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect rear power window switch connector. Check continuity between rear power window switch connector terminal 11 and ground. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch connector Terminal Ground Continuity D207 (LH) 11 Yes D307 (RH) Is the inspection result normal? YES >> Inspection End. NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 76

Scheme 76: DRIVER SIDE : Diagnosis Procedure

Scheme 77

CHECK POWER WINDOW MOTOR Check front power window motor LH. Refer to " «DRIVER SIDE : COMPONENT INSPECTION»(ref-388086-S21454971782011022800000) ". Is the inspection result normal? YES >> GO TO 2 NO >> Replace power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ".
CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH OUTPUT SIGNAL Disconnect front power window motor LH connector. Turn ignition switch ON. Check voltage between front power window motor LH connector D9 terminals 1, 2 and ground. VOLTAGE REFERENCE CHART Terminal Main power window and door lock/unlock switch condition Voltage (V) (Approx.) (+) (-) Power window motor LH connector Terminal D9 2 Ground UP Battery voltage DOWN 0 1 UP 0 DOWN Battery voltage Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 3
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector D7. Check continuity between main power window and door lock/unlock switch connector D7 (A) terminals 8, 11 and front power window motor connector LH D9 (B) terminals 1, 2. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Front power window motor LH connector Terminal Continuity D7 (A) 8 D9 (B) 2 Yes 11 1 Check continuity between main power window and door lock/unlock switch connector D7 (A) terminals 8, 11 and ground. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Ground Continuity D7 (A) 8 No 11 Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.

COMPONENT INSPECTION

CHECK FRONT POWER WINDOW MOTOR LH Disconnect front power window motor LH. Check motor operation by connecting battery voltage directly to front power window motor LH. CONNECTOR TERMINAL REFERENCE CHART Terminal Motor condition (+) (-) 1 2 DOWN 2 1 UP Is the inspection result normal? YES >> Inspection End. NO >> Replace front power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 78

Scheme 78: PASSENGER SIDE : Diagnosis Procedure

Scheme 79

CHECK FRONT POWER WINDOW MOTOR RH Check front power window motor RH. Refer to " «PASSENGER SIDE : COMPONENT INSPECTION»(ref-388086-S26023796582011022800000) ". Is the inspection result normal? YES >> GO TO 2 NO >> Replace front power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ".
CHECK FRONT POWER WINDOW SWITCH RH OUTPUT SIGNAL Disconnect front power window motor RH connector. Turn ignition switch ON. Check voltage between front power window motor RH connector D104 terminals 1, 2 and ground. VOLTAGE REFERENCE CHART Terminal Front power window motor RH condition Voltage (V) (Approx.) (+) (-) Front power window motor RH connector Terminal D104 2 Ground UP Battery voltage DOWN 0 1 UP 0 DOWN Battery voltage Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 3
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect power window and door lock/unlock switch RH connector. Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminals 8, 9 and front power window motor RH connector D104 (B) terminals 1, 2. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Front power window motor RH connector Terminal Continuity D105 (A) 8 D104 (B) 2 Yes 9 1 Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminals 8, 9 and ground. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Ground Continuity D105 (A) 8 No 9 Is the inspection result normal? YES >> Replace power window and door lock/unlock switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S07081875712011022800000) ". NO >> Repair or replace harness or connectors.

COMPONENT INSPECTION

CHECK FRONT POWER WINDOW MOTOR RH Disconnect front power window motor RH. Check motor operation by connecting battery voltage directly to front power window motor RH. CONNECTOR TERMINAL REFERENCE CHART Terminal Motor condition (+) (-) 1 2 DOWN 2 1 UP Is the inspection result normal? YES >> Inspection End. NO >> Replace front power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 80

Scheme 80: REAR LH : Diagnosis Procedure

Scheme 81

CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to " «REAR LH : COMPONENT INSPECTION»(ref-388086-S35657284442011022800000) ". Is the inspection result normal? YES >> GO TO 2 NO >> Replace rear power window motor LH. Refer to " «REAR DOOR GLASS REGULATOR»(ref-388089-S40440642102011022800000) ".
CHECK REAR POWER WINDOW SWITCH LH OUTPUT SIGNAL Disconnect rear power window motor LH connector. Turn ignition switch ON. Check voltage between rear power window motor LH connector D204 terminals 1, 3 and ground. VOLTAGE REFERENCE CHART Terminal Condition Voltage (V) (Approx.) (+) (-) Rear power window motor LH connector Terminal D204 1 Ground UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 3
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect rear power window switch LH connector. Check continuity between rear power window switch LH connector D207 (A) terminals 8, 9 and rear power window motor LH connector D204 (B) terminals 1, 3. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch LH connector Terminal Rear power window motor LH connector Terminal Continuity D207 (A) 8 D204 (B) 1 Yes 9 3 Check continuity between rear power window switch LH connector D207 (A) terminals 8, 9 and ground. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch LH connector Terminal Ground Continuity D207 (A) 8 No 9 Is the inspection result normal? YES >> Replace rear power window switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S07081875712011022800000) ". NO >> Repair or replace harness or connectors.

COMPONENT INSPECTION

CHECK REAR POWER WINDOW MOTOR LH Disconnect rear power window motor LH. Check motor operation by connecting battery voltage directly to rear power window motor LH. CONNECTOR TERMINAL REFERENCE CHART Terminal Motor condition (+) (-) 3 1 DOWN 1 3 UP Is the inspection result normal? YES >> Inspection End. NO >> Replace rear power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 82

Scheme 82: REAR RH : Diagnosis Procedure

Scheme 83

CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to " «REAR RH : COMPONENT INSPECTION»(ref-388086-S06941322832011022800000) ". Is the inspection result normal? YES >> GO TO 2 NO >> Replace rear power window motor RH. Refer to " «REAR DOOR GLASS REGULATOR»(ref-388089-S40440642102011022800000) ".
CHECK REAR POWER WINDOW SWITCH RH OUTPUT SIGNAL Disconnect rear power window motor RH connector. Turn ignition switch ON. Check voltage between rear power window motor RH connector D304 terminals 1, 3 and ground. VOLTAGE REFERENCE CHART Terminal Condition Voltage (V) (Approx.) (+) (-) Rear power window motor RH connector Terminal D304 1 Ground UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 3
CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect rear power window switch RH connector. Check continuity between rear power window switch RH connector D307 (A) terminals 8, 9 and rear power window motor RH connector D304 (B) terminals 1, 3. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch RH connector Terminal Rear power window motor RH connector Terminal Continuity D307 (A) 8 D304 (B) 1 Yes 9 3 Check continuity between rear power window switch RH connector D307 (A) terminals 8, 9 and ground. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch RH connector Terminal Ground Continuity D307 (A) 8 No 9 Is the inspection result normal? YES >> Replace rear power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S07081875712011022800000) ". NO >> Repair or replace harness or connectors.

COMPONENT INSPECTION

CHECK REAR POWER WINDOW MOTOR RH Disconnect rear power window motor RH. Check motor operation by connecting battery voltage directly to rear power window motor RH. CONNECTOR TERMINAL REFERENCE CHART Terminal Motor condition (+) (-) 3 1 DOWN 1 3 UP Is the inspection result normal? YES >> Inspection End. NO >> Replace rear power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 84

Scheme 84: DRIVER SIDE : Diagnosis Procedure

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

CHECK ENCODER OPERATION Turn ignition switch ON. Check signal between main power window and door lock/unlock switch connector D7 terminals 9, 13 and ground with oscilloscope. SIGNAL REFERENCE CHART Terminals Signal (Reference value) (+) (-) Main power window and door lock/unlock switch connector Terminal D7 9 Ground Refer to following signal see scheme 95 13 Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 2
CHECK ENCODER POWER SUPPLY Check voltage between front power window motor LH connector D9 terminal 4 and ground. VOLTAGE REFERENCE CHART Terminal Voltage (V) (Approx.) (+) (-) Front power window motor LH connector Terminal D9 4 Ground 10 Is the inspection result normal? YES >> GO TO 4 NO >> GO TO 3
CHECK HARNESS CONTINUITY 1 Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector D7 and front power window motor LH connector. Check continuity between main power window and door lock/unlock switch connector D7 (A) terminal 15 and front power window motor LH connector D9 (B) terminal 4. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Front power window motor LH connector Terminal Continuity D7 (A) 15 D9 (B) 4 Yes Check continuity between main power window and door lock/unlock switch connector D7 (A) terminal 15 and ground. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Ground Continuity D7 (A) 15 No Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.
CHECK ENCODER GROUND CIRCUIT Turn ignition switch OFF. Disconnect front power window motor LH connector. Check continuity between front power window motor LH connector D9 terminal 6 and ground. CONNECTOR TERMINAL REFERENCE CHART Front power window motor LH connector Terminal Ground Continuity D9 6 Yes Is the inspection result normal? YES >> GO TO 6 NO >> GO TO 5
CHECK HARNESS CONTINUITY 2 Disconnect main power window and door lock/unlock switch connector D7. Check continuity between main power window and door lock/unlock switch connector D7 (A) terminal 2 and front power window motor LH connector D9 (B) terminal 6. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Front power window motor LH connector Terminal Continuity D7 (A) 2 D9 (B) 6 Yes Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.
CHECK HARNESS CONTINUITY 3 Disconnect main power window and door lock/unlock switch connector D7. Check continuity between main power window and door lock/unlock switch connector D7 (A) terminals 9, 13 and front power window motor LH connector D9 (B) terminals 3, 5. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Front power window motor LH connector Terminal Continuity D7 (A) 9 D9 (B) 5 Yes 13 3 Check continuity between main power window and door lock/unlock switch connector D7 (A) terminals 9, 13 and ground. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Ground Continuity D7 (A) 9 No 13 Is the inspection result normal? YES >> Replace front power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ". NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 91

Scheme 91: PASSENGER SIDE : Diagnosis Procedure

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

CHECK ENCODER SIGNAL Turn ignition switch ON. Check signal between power window and door lock/unlock switch RH connector D105 terminal 12, 15 and ground with oscilloscope. SIGNAL REFERENCE CHART Terminals Signal (Reference value) (+) (-) Power window and door lock/unlock switch RH connector Terminal D105 12 Ground Refer to following signal see scheme 102 15 Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 2
CHECK ENCODER POWER SUPPLY Check voltage between front power window motor RH connector D104 terminal 4 and ground. VOLTAGE REFERENCE CHART Terminal Voltage (V) (Approx.) (+) (-) Front power window motor RH connector Terminal D104 4 Ground 10 Is the inspection result normal? YES >> GO TO 4 NO >> GO TO 3
CHECK HARNESS CONTINUITY 1 Turn ignition switch OFF. Disconnect power window and door lock/unlock switch RH and front power window motor RH connectors. Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminal 4 and front power window motor RH connector D104 (B) terminal 4. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Front power window motor RH connector Terminal Continuity D105 (A) 4 D104 (B) 4 Yes Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminal 4 and ground. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Ground Continuity D105 (A) 4 No Is the inspection result normal? YES >> Replace power window and door lock/unlock switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S07081875712011022800000) ". NO >> Repair or replace harness or connectors.
CHECK ENCODER GROUND CIRCUIT Turn ignition switch OFF. Disconnect front power window motor RH connector. Check continuity between front power window motor RH connector D104 terminal 6 and ground. CONNECTOR TERMINAL REFERENCE CHART Front power window motor RH connector Terminal Ground Continuity D104 6 Yes Is the inspection result normal? YES >> GO TO 6 NO >> GO TO 5
CHECK HARNESS CONTINUITY 2 Disconnect power window and door lock/unlock switch RH connector. Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminal 3 and front power window motor RH connector D104 (B) terminal 6. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Front power window motor RH connector Terminal Continuity D105 (A) 3 D104 (B) 6 Yes Is the inspection result normal? YES >> Replace power window and door lock/unlock switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S07081875712011022800000) ". NO >> Repair or replace harness or connectors.
CHECK HARNESS CONTINUITY 3 Disconnect power window and door lock/unlock switch RH connector. Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminals 12, 15 and front power window motor RH connector D104 (B) terminals 3, 5. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Front power window motor RH connector Terminal Continuity D105 (A) 12 D104 (B) 3 Yes 15 5 Check continuity between power window and door lock/unlock switch RH connector D105 (A) terminals 12, 15 and ground. CONNECTOR TERMINAL REFERENCE CHART Power window and door lock/unlock switch RH connector Terminal Ground Continuity D105 (A) 12 No 15 Is the inspection result normal? YES >> Replace front power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ". NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 98

Scheme 98: REAR LH : Diagnosis Procedure

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

CHECK ENCODER SIGNAL Turn ignition switch ON. Check signal between rear power window switch LH connector D207 terminal 12, 15 and ground with oscilloscope. SIGNAL REFERENCE CHART Terminals Signal (Reference value) (+) (-) Rear power window switch LH connector Terminal D207 12 Ground Refer to following signal see scheme 109 15 Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 2
CHECK ENCODER POWER SUPPLY Check voltage between rear power window motor LH connector D204 terminal 2 and ground. VOLTAGE REFERENCE CHART Terminal Voltage (V) (Approx.) (+) (-) Rear power window motor LH connector Terminal D204 2 Ground 10 Is the inspection result normal? YES >> GO TO 4 NO >> GO TO 3
CHECK HARNESS CONTINUITY 1 Turn ignition switch OFF. Disconnect rear power window switch LH and rear power window motor LH connectors. Check continuity between rear power window switch LH connector D207 (A) terminal 4 and rear power window motor LH connector D204 (B) terminal 2. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch LH connector Terminal Rear power window motor LH connector Terminal Continuity D207 (A) 4 D204 (B) 2 Yes Check continuity between rear power window switch LH connector D207 (A) terminal 4 and ground. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch LH connector Terminal Ground Continuity D207 (A) 4 No Is the inspection result normal? YES >> Replace rear power window switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S26135344112011022800000) ". NO >> Repair or replace harness or connectors.
CHECK ENCODER GROUND CIRCUIT Turn ignition switch OFF. Disconnect rear power window motor LH connector. Check continuity between rear power window motor LH connector D204 terminal 4 and ground. CONNECTOR TERMINAL REFERENCE CHART Rear power window motor LH connector Terminal Ground Continuity D204 4 Yes Is the inspection result normal? YES >> GO TO 6 NO >> GO TO 5
CHECK HARNESS CONTINUITY 2 Disconnect rear power window switch LH connector. Check continuity between rear power window switch LH connector D207 (A) terminal 3 and rear power window motor LH connector D204 (B) terminal 4. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch LH connector Terminal Rear power window motor LH connector Terminal Continuity D207 (A) 3 D204 (B) 4 Yes Is the inspection result normal? YES >> Replace rear power window switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S26135344112011022800000) ". NO >> Repair or replace harness or connectors.
CHECK HARNESS CONTINUITY 3 Disconnect rear power window switch LH connector. Check continuity between rear power window switch LH connector D207 (A) terminals 12, 15 and rear power window motor LH connector D204 (B) terminals 5, 6. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch LH connector Terminal Rear power window motor LH connector Terminal Continuity D207 (A) 12 D204 (B) 5 Yes 15 6 Check continuity between rear power window switch LH connector D207 (A) terminals 12, 15 and ground. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch LH connector Terminal Ground Continuity D207 (A) 12 No 15 Is the inspection result normal? YES >> Replace rear power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ". NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 105

Scheme 105: REAR RH : Diagnosis Procedure

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

CHECK ENCODER SIGNAL Turn ignition switch ON. Check signal between rear power window switch RH connector D307 terminal 12, 15 and ground with oscilloscope. SIGNAL REFERENCE CHART Terminals Signal (Reference value) (+) (-) Rear power window switch RH connector Terminal D307 12 Ground Refer to following signal (Scheme 60) 15 Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> GO TO 2
CHECK ENCODER POWER SUPPLY Check voltage between rear power window motor RH connector D304 terminal 2 and ground. VOLTAGE REFERENCE CHART Terminal Voltage (V) (Approx.) (+) (-) Rear power window motor RH connector Terminal D304 2 Ground 10 Is the inspection result normal? YES >> GO TO 4 NO >> GO TO 3
CHECK HARNESS CONTINUITY 1 Turn ignition switch OFF. Disconnect rear power window switch RH and rear power window motor RH connectors. Check continuity between rear power window switch RH connector D307 (A) terminal 4 and rear power window motor RH connector D304 (B) terminal 2. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch RH connector Terminal Rear power window motor RH connector Terminal Continuity D307 (A) 4 D304 (B) 2 Yes Check continuity between rear power window switch RH connector D307 (A) terminal 4 and ground. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch RH connector Terminal Ground Continuity D307 (A) 4 No Is the inspection result normal? YES >> Replace rear power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S07081875712011022800000) ". NO >> Repair or replace harness or connectors.
CHECK ENCODER GROUND CIRCUIT Turn ignition switch OFF. Disconnect rear power window motor RH connector. Check continuity between rear power window motor RH connector D304 terminal 4 and ground. CONNECTOR TERMINAL REFERENCE CHART Rear power window motor RH connector Terminal Ground Continuity D304 4 Yes Is the inspection result normal? YES >> GO TO 6 NO >> GO TO 5
CHECK HARNESS CONTINUITY 2 Disconnect rear power window switch RH connector. Check continuity between rear power window switch RH connector D307 (A) terminal 3 and rear power window motor RH connector D304 (B) terminal 4. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch RH connector Terminal Rear power window motor RH connector Terminal Continuity D307 (A) 3 D304 (B) 4 Yes Is the inspection result normal? YES >> Replace rear power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S26135344112011022800000) ". NO >> Repair or replace harness or connectors.
CHECK HARNESS CONTINUITY 3 Disconnect rear power window switch RH connector. Check continuity between rear power window switch RH connector D307 (A) terminals 12, 15 and rear power window motor RH connector D304 (B) terminals 5, 6. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch RH connector Terminal Rear power window motor RH connector Terminal Continuity D307 (A) 12 D304 (B) 5 Yes 15 6 Check continuity between rear power window switch RH connector D307 (A) terminals 12, 15 and ground. CONNECTOR TERMINAL REFERENCE CHART Rear power window switch RH connector Terminal Ground Continuity D307 (A) 12 No 15 Is the inspection result normal? YES >> Replace rear power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388089-S38688826282011022800000) ". NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 112

Scheme 112: Diagnosis Procedure

Scheme 113

Scheme 114

CHECK DOOR SWITCH INPUT SIGNAL Turn ignition switch OFF. Check signal between BCM connector and ground with oscilloscope. SIGNAL REFERENCE CHART Terminals Door condition Voltage (V) (Approx.) (+) (-) BCM connector Terminal A: M18 58 Ground Driver side OPEN 0 CLOSE 32 Passenger side OPEN 0 CLOSE B: M21 148 Rear RH OPEN 0 CLOSE 149 Rear LH OPEN 0 CLOSE Is the inspection result normal? YES >> GO TO 4 NO >> GO TO 2
CHECK DOOR SWITCH CIRCUIT Disconnect BCM connector. Check continuity between BCM connector and door switch connector. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Door switch connector Terminal Continuity A: M18 58 C: B8 (Driver side) 2 Yes 32 C: B108 (Passenger side) B: M21 148 C: B116 (Rear RH) 149 C: B18 (Rear LH) Check continuity between BCM connector and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity A: M18 58 No 32 B: M21 148 149 Is the inspection result normal? YES >> GO TO 3 NO >> Repair or replace harness between BCM and door switch.
CHECK DOOR SWITCH Refer to " «COMPONENT INSPECTION»(ref-388086-S28704489202011022800000) ". Is the inspection result normal? YES >> GO TO 4 NO >> Replace malfunctioning door switch.
CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". Inspection End.

Scheme 115

Scheme 115: Component Inspection

CHECK DOOR SWITCH Turn ignition switch OFF. Disconnect door switch connector. Check door switch. CONNECTOR TERMINAL REFERENCE CHART Terminal Door switch condition Continuity Door switch 2 Ground part of door switch Pressed No Released Yes Is the inspection result normal? YES >> Inspection End. NO >> Replace malfunctioning door switch.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 116

Scheme 116: Diagnosis Procedure

Scheme 117

Scheme 118

CHECK DOOR KEY CYLINDER SWITCH INPUT SIGNAL Turn ignition switch ON. Check voltage between main power window and door lock/unlock switch connector and ground. VOLTAGE REFERENCE CHART Terminals Key position Voltage (V) (Approx.) (+) (-) Main power window and door lock/unlock switch connector Terminal D7 4 Ground Lock 0 Neutral / Unlock 5 6 Unlock 0 Neutral / Lock 5 Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". After that, refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S41823401722011022800000) ". NO >> GO TO 2
CHECK DOOR KEY CYLINDER SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector and front door lock assembly LH (key cylinder switch) connector. Check continuity between main power window and door lock/unlock switch connector and front door lock assembly LH (key cylinder switch) connector. CONNECTOR TERMINAL REFERENCE CHART Main power window and door lock/unlock switch connector Terminal Front door lock assembly LH (key cylinder switch) connector Terminal Continuity A: D7 4 B: D10 6 Yes 6 5 Check continuity between main power window and door lock/unlock switch connector and ground. CONNECTOR TERMINAL REFERENCE CHART Power window main switch connector Terminal Ground Continuity A: D7 4 No 6 Is the inspection result normal? YES >> GO TO 3 NO >> Repair or replace harness.
CHECK DOOR KEY CYLINDER SWITCH GROUND CIRCUIT Check continuity between front door lock assembly LH connector and ground. CONNECTOR TERMINAL REFERENCE CHART Front door lock assembly LH connector Terminal Ground Continuity D10 4 Yes Is the inspection result normal? YES >> GO TO 4 NO >> Repair or replace harness.
CHECK DOOR KEY CYLINDER SWITCH Check door key cylinder switch. Refer to " «COMPONENT INSPECTION»(ref-388086-S42706568362011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Replace front door lock assembly LH (key cylinder switch). Refer to " «FRONT DOOR LOCK : REMOVAL AND INSTALLATION»(ref-388085-S24611053912011022800000) ". After that, Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S41823401722011022800000) ".

Scheme 119

Scheme 119: COMPONENT INSPECTION

CHECK DOOR KEY CYLINDER SWITCH Check front door lock assembly LH (key cylinder switch). CONNECTOR TERMINAL REFERENCE CHART Terminal Key position Continuity Front door lock assembly LH (key cylinder switch) connector 5 4 Unlock Yes Neutral / Lock No 6 Lock Yes Neutral / Unlock No Is the inspection result normal? YES >> Key cylinder switch is OK. NO >> Replace front door lock assembly LH (key cylinder switch). Refer to " «FRONT DOOR LOCK : REMOVAL AND INSTALLATION»(ref-388085-S24611053912011022800000) ". After that, refer to " «SPECIAL REPAIR REQUIREMENT»(ref-388086-S09938019672011022800000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 120

Scheme 120: POWER WINDOW MAIN SWITCH : Diagnosis Procedure

Scheme 121

Scheme 122

CHECK POWER WINDOW SWITCH OUTPUT SIGNAL Remove Intelligent Key, and close front door LH and RH. Check signal between BCM connector M18 terminal 40 and ground with oscilloscope when door lock and unlock switch (key cylinder switch) is turned to "LOCK" or "UNLOCK". Check that signals which are shown in the figure below can be detected during 10 seconds just after door lock and unlock switch (key cylinder switch) is turned to "LOCK" or "UNLOCK". SIGNAL REFERENCE CHART Terminal Signal (Reference value) (+) (-) BCM connector Terminal M18 40 Ground Is the inspection result normal? YES >> Power window serial link is OK. NO >> GO TO 2
CHECK POWER WINDOW SERIAL LINK CIRCUIT Turn ignition switch OFF. Disconnect BCM connector M18 and main power window and door lock/unlock switch connector D7. Check continuity between BCM connector M18 (A) terminal 40 and main power window and door lock/unlock switch connector D7 (B) terminal 14. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Main power window and door lock/unlock switch connector Terminal Continuity M18 (A) 40 D7 (B) 14 Yes Check continuity between BCM connector M18 (A) terminal 40 and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M18 (A) 40 No Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 123

Scheme 123: FRONT POWER WINDOW SWITCH : Diagnosis Procedure

Scheme 124

Scheme 125

CHECK POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH Remove Intelligent Key, and close the front door LH and RH. Check signal between BCM connector M18 terminal 40 and ground with oscilloscope when door lock and unlock switch (key cylinder switch) is turned to "LOCK" or "UNLOCK". Check that signals which are shown in the figure below can be detected during 10 seconds just after door lock and unlock switch (key cylinder switch) is turned to "LOCK" or "UNLOCK". SIGNAL REFERENCE CHART Terminal Signal (Reference value) (+) (-) BCM connector Terminal M18 40 Ground Is the inspection result normal? YES >> Power window serial link is OK. NO >> GO TO 2
CHECK POWER WINDOW SERIAL LINK CIRCUIT Turn ignition switch OFF. Disconnect BCM connector M18 and power window and door lock/unlock switch RH connector. Check continuity between BCM connector M18 (A) terminal 40 and power window and door lock/unlock switch RH connector D105 (B) terminal 16. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Power window and door lock/unlock switch RH connector Terminal Continuity M18 (A) 40 D105 (B) 16 Yes Check continuity between BCM connector M18 (A) terminal 40 and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M18 (A) 40 No Is the inspection result normal? YES >> Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 126

Scheme 126: REAR LH : Diagnosis Procedure

Scheme 127

Scheme 128

CHECK REAR POWER WINDOW SWITCH LH Remove Intelligent Key, and close all doors. Check signal between BCM connector M18 terminal 40 and ground with oscilloscope when door lock and unlock switch (key cylinder switch) is turned to "LOCK" or "UNLOCK". Check that signals which are shown in the figure below can be detected during 10 seconds just after door lock and unlock switch (key cylinder switch) is turned to "LOCK" or "UNLOCK". SIGNAL REFERENCE CHART Terminal Signal (Reference value) (+) (-) BCM connector Terminal M18 40 Ground Is the inspection result normal? YES >> Power window serial link is OK. NO >> GO TO 2
CHECK POWER WINDOW SERIAL LINK CIRCUIT Turn ignition switch OFF. Disconnect BCM connector M18 and rear power window switch LH connector. Check continuity between BCM connector M18 (A) terminal 40 and rear power window switch LH connector D207 (B) terminal 16. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Rear power window switch LH connector Terminal Continuity M18 (A) 40 D207 (B) 16 Yes Check continuity between BCM connector M18 (A) terminal 40 and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M18 (A) 40 No Is the inspection result normal? YES >> Replace rear power window switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM - WITH FRONT AND REAR POWER WINDOW ANTI-PINCH SYSTEM ".

Scheme 129

Scheme 129: REAR RH : Diagnosis Procedure

Scheme 130

Scheme 131

CHECK REAR POWER WINDOW SWITCH RH Remove Intelligent Key, and close all doors. Check signal between BCM connector M18 terminal 40 and ground with oscilloscope when door lock and unlock switch (key cylinder switch) is turned to "LOCK" or "UNLOCK". Check that signals which are shown in the figure below can be detected during 10 seconds just after door lock and unlock switch (key cylinder switch) is turned to "LOCK" or "UNLOCK". SIGNAL REFERENCE CHART Terminal Signal (Reference value) (+) (-) BCM connector Terminal M18 40 Ground Is the inspection result normal? YES >> Power window serial link is OK. NO >> GO TO 2
CHECK POWER WINDOW SERIAL LINK CIRCUIT Turn ignition switch OFF. Disconnect BCM connector M18 and rear power window switch RH connector. Check continuity between BCM connector M18 (A) terminal 40 and rear power window switch RH connector D307 (B) terminal 16. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Rear power window switch RH connector Terminal Continuity M18 (A) 40 D307 (B) 16 Yes Check continuity between BCM connector M18 (A) terminal 40 and ground. CONNECTOR TERMINAL REFERENCE CHART BCM connector Terminal Ground Continuity M18 (A) 40 No Is the inspection result normal? YES >> Replace rear power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-388086-S20732770822011022800000) ". NO >> Repair or replace harness or connectors.

Monitor Item	Condition	Value/Status
FR WIPER HI	Other than front wiper switch HI	OFF
FR WIPER HI	Front wiper switch HI	ON
FR WIPER LOW	Other than front wiper switch LO	OFF
FR WIPER LOW	Front wiper switch LO	ON
FR WASHER SW	Front washer switch OFF	OFF
FR WASHER SW	Front washer switch ON	ON
FR WIPER INT	Other than front wiper switch INT	OFF
FR WIPER INT	Front wiper switch INT	ON
FR WIPER STOP	Front wiper is not in STOP position	OFF
FR WIPER STOP	Front wiper is in STOP position	ON
INT VOLUME	Wiper intermittent dial is in a dial position 1 - 7	Wiper intermittent dial position
TURN SIGNAL R	Other than turn signal switch RH	OFF
TURN SIGNAL R	Turn signal switch RH	ON
TURN SIGNAL L	Other than turn signal switch LH	OFF
TURN SIGNAL L	Turn signal switch LH	ON
TAIL LAMP SW	Other than lighting switch 1ST and 2ND	OFF
TAIL LAMP SW	Lighting switch 1ST or 2ND	ON
HI BEAM SW	Other than lighting switch HI	OFF
HI BEAM SW	Lighting switch HI	ON
HEAD LAMP SW 1	Other than lighting switch 2ND	OFF
HEAD LAMP SW 1	Lighting switch 2ND	ON
HEAD LAMP SW 2	Other than lighting switch 2ND	OFF
HEAD LAMP SW 2	Lighting switch 2ND	ON
PASSING SW	Other than lighting switch PASS	OFF
PASSING SW	Lighting switch PASS	ON
AUTO LIGHT SW	Other than lighting switch AUTO	OFF
AUTO LIGHT SW	Lighting switch AUTO	ON
FR FOG SW	Front fog lamp switch OFF	OFF
FR FOG SW	Front fog lamp switch ON	ON
DOOR SW-DR	Driver door closed	OFF
DOOR SW-DR	Driver door opened	ON
DOOR SW-AS	Passenger door closed	OFF
DOOR SW-AS	Passenger door opened	ON
DOOR SW-RR	Rear door RH closed	OFF
DOOR SW-RR	Rear door RH opened	ON
DOOR SW-RL	Rear door LH closed	OFF
DOOR SW-RL	Rear door LH opened	ON
CDL LOCK SW	Other than power door lock switch LOCK	OFF
CDL LOCK SW	Power door lock switch LOCK	ON
CDL UNLOCK SW	Other than power door lock switch UNLOCK	OFF
CDL UNLOCK SW	Power door lock switch UNLOCK	ON
KEY CYL LK-SW	Other than driver door key cylinder LOCK position	OFF
KEY CYL LK-SW	Driver door key cylinder LOCK position	ON
KEY CYL UN-SW	Other than driver door key cylinder UNLOCK position	OFF
KEY CYL UN-SW	Driver door key cylinder UNLOCK position	ON
HAZARD SW	When hazard switch is not pressed	OFF
HAZARD SW	When hazard switch is pressed	ON
REAR DEF SW	When rear window defogger switch is pressed	ON
TR CANCEL SW	Trunk lid opener cancel switch OFF	OFF
TR CANCEL SW	Trunk lid opener cancel switch ON	ON
TR/BD OPEN SW	Trunk lid opener switch OFF	OFF
TR/BD OPEN SW	While the trunk lid opener switch is turned ON	ON
TRNK/HAT MNTR	Trunk lid closed	OFF
TRNK/HAT MNTR	Trunk lid opened	ON
RKE-LOCK	When LOCK button of Intelligent Key is not pressed	OFF
RKE-LOCK	When LOCK button of Intelligent Key is pressed	ON
RKE-UNLOCK	When UNLOCK button of Intelligent Key is not pressed	OFF
RKE-UNLOCK	When UNLOCK button of Intelligent Key is pressed	ON
RKE-TR/BD	When TRUNK OPEN button of Intelligent Key is not pressed	OFF
RKE-TR/BD	When TRUNK OPEN button of Intelligent Key is pressed	ON
RKE-PANIC	When PANIC button of Intelligent Key is not pressed	OFF
RKE-PANIC	When PANIC button of Intelligent Key is pressed	ON
RKE-P/W OPEN	When UNLOCK button of Intelligent Key is not pressed and held	OFF
RKE-P/W OPEN	When UNLOCK button of Intelligent Key is pressed and held	ON
RKE-MODE CHG	When LOCK/UNLOCK button of Intelligent Key is not pressed and held simultaneously	OFF
RKE-MODE CHG	When LOCK/UNLOCK button of Intelligent Key is pressed and held simultaneously	ON
OPTICAL SENSOR	When outside of the vehicle is bright	Close to 5 V
OPTICAL SENSOR	When outside of the vehicle is dark	Close to 0 V
REQ SW-DR	When front door request switch is not pressed (driver side)	OFF
REQ SW-DR	When front door request switch is pressed (driver side)	ON
REQ SW-AS	When front door request switch is not pressed (passenger side)	OFF
REQ SW-AS	When front door request switch is pressed (passenger side)	ON
REQ SW-RL	When rear door request switch is not pressed (driver side)	OFF
REQ SW-RL	When rear door request switch is pressed (driver side)	ON
REQ SW-RR	When rear door request switch is not pressed (passenger side)	OFF
REQ SW-RR	When rear door request switch is pressed (passenger side)	ON
REQ SW-BD/TR	When trunk request switch is not pressed	OFF
REQ SW-BD/TR	When trunk request switch is pressed	ON
PUSH SW	When engine switch (push switch) is not pressed	OFF
PUSH SW	When engine switch (push switch) is pressed	ON
IGN RLY 2 -F/B	Ignition switch OFF or ACC	OFF
IGN RLY 2 -F/B	Ignition switch ON	ON
ACC RLY-F/B	Ignition switch OFF	OFF
ACC RLY-F/B	Ignition switch ACC or ON	ON
BRAKE SW 1	When the brake pedal is not depressed	ON
BRAKE SW 1	When the brake pedal is depressed	OFF
DETE/CANCL SW	When selector lever is in P position	OFF
DETE/CANCL SW	When selector lever is in any position other than P	ON
SFT PN/N SW	When selector lever is in any position other than P or N	OFF
SFT PN/N SW	When selector lever is in P or N position	ON
UNLK SEN-DR	Driver door UNLOCK status	OFF
UNLK SEN-DR	Driver door LOCK status	ON
PUSH SW-IPDM	When engine switch (push switch) is not pressed	OFF
PUSH SW-IPDM	When engine switch (push switch) is pressed	ON
IGN RLY1 -F/B	Ignition switch OFF or ACC	OFF
IGN RLY1 -F/B	Ignition switch ON	ON
DETE SW-IPDM	When selector lever is in P position	OFF
DETE SW-IPDM	When selector lever is in any position other than P	ON
SFT PN-IPDM	When selector lever is in any position other than P or N	OFF
SFT PN-IPDM	When selector lever is in P or N position	ON
SFT P-MET	When selector lever is in any position other than P	OFF
SFT P-MET	When selector lever is in P position	ON
SFT N-MET	When selector lever is in any position other than N	OFF
SFT N-MET	When selector lever is in N position	ON
ENGINE STATE	Engine stopped	STOP
	While the engine stalls	STALL
	At engine cranking	CRANK
	Engine running	RUN
VEH SPEED 1	While driving	Equivalent to speedometer reading
VEH SPEED 2	While driving	Equivalent to speedometer reading
DOOR STAT-DR	Driver door LOCK status	LOCK
	Wait with selective UNLOCK operation (5 seconds)	READY
	Driver door UNLOCK status	UNLK
DOOR STAT-AS	Passenger door LOCK status	LOCK
	Wait with selective UNLOCK operation (5 seconds)	READY
	Passenger door UNLOCK status	UNLK
ID OK FLAG	Ignition switch ACC or ON	RESET
ID OK FLAG	Ignition switch OFF	SET
PRMT ENG STRT	When the engine start is prohibited	RESET
PRMT ENG STRT	When the engine start is permitted	SET
KEY SW-SLOT	When Intelligent Key is not inserted into key slot	OFF
KEY SW-SLOT	When Intelligent Key is inserted into key slot	ON
RKE OPE	COUN1 During the operation of Intelligent Key	Operation frequency of Intelligent Key
CONFRM ID ALL	The key ID that the key slot receives does not accord with any key ID registered to BCM.	YET
CONFRM ID ALL	The key ID that the key slot receives accords with any key ID registered to BCM.	DONE
CONFIRM ID4	The key ID that the key slot receives does not accord with the fourth key ID registered to BCM.	YET
CONFIRM ID4	The key ID that the key slot receives accords with the fourth key ID registered to BCM.	DONE
CONFIRM ID3	The key ID that the key slot receives does not accord with the third key ID registered to BCM.	YET
CONFIRM ID3	The key ID that the key slot receives accords with the third key ID registered to BCM.	DONE
CONFIRM ID2	The key ID that the key slot receives does not accord with the second key ID registered to BCM.	YET
CONFIRM ID2	The key ID that the key slot receives accords with the second key ID registered to BCM.	DONE
CONFIRM ID1	The key ID that the key slot receives does not accord with the first key ID registered to BCM.	YET
CONFIRM ID1	The key ID that the key slot receives accords with the first key ID registered to BCM.	DONE
TP 4	The ID of fourth key is not registered to BCM	YET
TP 4	The ID of fourth key is registered to BCM	DONE
TP 3	The ID of third key is not registered to BCM	YET
TP 3	The ID of third key is registered to BCM	DONE
TP 2	The ID of second key is not registered to BCM	YET
TP 2	The ID of second key is registered to BCM	DONE
TP 1	The ID of first key is not registered to BCM	YET
TP 1	The ID of first key is registered to BCM	DONE
AIR PRESS FL	Ignition switch ON (only when the signal from the transmitter is received)	Air pressure of front LH tire
AIR PRESS FR	Ignition switch ON (only when the signal from the transmitter is received)	Air pressure of front RH tire
AIR PRESS RR	Ignition switch ON (only when the signal from the transmitter is received)	Air pressure of rear RH tire
AIR PRESS RL	Ignition switch ON (only when the signal from the transmitter is received)	Air pressure of rear LH tire
ID REGST FL1	When ID of front LH tire transmitter is registered	DONE
ID REGST FL1	When ID of front LH tire transmitter is not registered	YET
ID REGST FR1	When ID of front RH tire transmitter is registered	DONE
ID REGST FR1	When ID of front RH tire transmitter is not registered	YET
ID REGST RR1	When ID of rear RH tire transmitter is registered	DONE
ID REGST RR1	When ID of rear RH tire transmitter is not registered	YET
ID REGST RL1	When ID of rear LH tire transmitter is registered	DONE
ID REGST RL1	When ID of rear LH tire transmitter is not registered	YET
WARNING LAMP	Tire pressure indicator OFF	OFF
WARNING LAMP	Tire pressure indicator ON	ON
BUZZER	Tire pressure warning alarm is not sounding	OFF
BUZZER	Tire pressure warning alarm is sounding	ON

BODY CONTROL MODULE REFERENCE CHART

Scheme 132

Scheme 132: Terminal Layout

If some DTCs are displayed at the same time, perform inspections one by one based on the following priority chart.

Priority	DTC
1	B2562: LO VOLTAGE
2	U1000: CAN COMM CIRCUIT U1010: CONTROL UNIT (CAN)
3	B2190: NATS ANTENNA AMP B2191: DIFFERENCE OF KEY B2192: ID DISCORD BCM-ECM B2193: CHAIN OF BCM-ECM
4	B2553: IGNITION RELAY B2555: STOP LAMP B2556: PUSH-BTN IGN SW B2557: VEHICLE SPEED B2560: STARTER CONT RELAY B2601: SHIFT POSITION B2602: SHIFT POSITION B2603: SHIFT POSI STATUS B2604: PNP SWITCH B2605: PNP SWITCH B2608: STARTER RELAY B260A: IGNITION RELAY B260F: ENG STATE SIG LOST B2614: ACC RELAY CIRC B2615: BLOWER RELAY CIRC B2616: IGN RELAY CIRC B2617: STARTER RELAY CIRC B2618: BCM B261A: PUSH-BTN IGN SW B26E1: ENG STATE NO RECIV C1729: VHCL SPEED SIG ERR U0415: VEHICLE SPEED SIG
5	C1704: LOW PRESSURE FL C1705: LOW PRESSURE FR C1706: LOW PRESSURE RR C1707: LOW PRESSURE RL C1708: [NO DATA] FL C1709: [NO DATA] FR C1710: [NO DATA] RR C1711: [NO DATA] RL C1712: [CHECKSUM ERR] FL C1713: [CHECKSUM ERR] FR C1714: [CHECKSUM ERR] RR C1715: [CHECKSUM ERR] RL C1716: [PRESSDATA ERR] FL C1717: [PRESSDATA ERR] FR C1718: [PRESSDATA ERR] RR C1719: [PRESSDATA ERR] RL C1720: [CODE ERR] FL C1721: [CODE ERR] FR C1722: [CODE ERR] RR C1723: [CODE ERR] RL C1724: [BATT VOLT LOW] FL C1725: [BATT VOLT LOW] FR C1726: [BATT VOLT LOW] RR C1727: [BATT VOLT LOW] RL C1734: CONTROL UNIT
6	B2622: INSIDE ANTENNA B2623: INSIDE ANTENNA

DTC INSPECTION PRIORITY CHART

CONSULT display	Fail-safe	Intelligent Key warning lamp ON	Tire pressure monitor warning lamp ON	Reference
No DTC is detected. further testing may be required.
U1000: CAN COMM CIRCUIT				U1000 CAN COMM CIRCUIT
U1010: CONTROL UNIT (CAN)				U1010 CONTROL UNIT (CAN)
U0415: VEHICLE SPEED SIG				U0415 VEHICLE SPEED SIG
B2190: NATS ANTENNA AMP	X			B2190 NATS ANTENNA AMP
B2191: DIFFERENCE OF KEY	X			B2191 DIFFERENCE OF KEY
B2192: ID DISCORD BCM-ECM	X			B2192 ID DISCORD, IMMU-ECM
B2193: CHAIN OF BCM-ECM	X			B2193 CHAIN OF ECM-IMMU
B2553: IGNITION RELAY				B2553 IGNITION RELAY
B2555: STOP LAMP				B2555 STOP LAMP
B2556: PUSH-BTN IGN SW		X		B2556 PUSH-BUTTON IGNITION SWITCH
B2557: VEHICLE SPEED	X	X		B2557 VEHICLE SPEED
B2560: STARTER CONT RELAY	X	X		B2560 STARTER CONTROL RELAY
B2562: LOW VOLTAGE				B2562 LOW VOLTAGE
B2601: SHIFT POSITION	X	X		B2601 SHIFT POSITION
B2602: SHIFT POSITION	X	X		B2602 SHIFT POSITION
B2603: SHIFT POSI STATUS	X	X		B2603 SHIFT POSITION STATUS
B2604: PNP SWITCH	X	X		B2604 TRANSMISSION RANGE SWITCH
B2605: PNP SWITCH	X	X		B2605 TRANSMISSION RANGE SWITCH
B2608: STARTER RELAY	X	X		B2608 STARTER RELAY
B260A: IGNITION RELAY	X	X		B260A IGNITION RELAY
B260F: ENG STATE SIG LOST	X	X		B260F ENGINE STATUS
B2614: ACC RELAY CIRC		X		B2614 ACC RELAY CIRCUIT
B2615: BLOWER RELAY CIRC		X		B2615 FRONT BLOWER MOTOR RELAY CIRCUIT
B2616: IGN RELAY CIRC		X		B2616 IGNITION RELAY CIRCUIT
B2617: STARTER RELAY CIRC	X	X		B2617 STARTER RELAY CIRCUIT
B2618: BCM	X	X		B2618 BCM
B261A: PUSH-BTN IGN SW		X		B261A PUSH-BUTTON IGNITION SWITCH
B2622: INSIDE ANTENNA				B2622 INSIDE KEY ANTENNA 2
B2623: INSIDE ANTENNA				B2623 INSIDE KEY ANTENNA 3
B26E1: ENG STATE NO RES	X	X		B26E1 NO RECEPTION OF ENGINE STATUS SIGNAL
C1704: LOW PRESSURE FL			X	SELF-DIAGNOSIS (WITH CONSULT-III)
C1705: LOW PRESSURE FR			X	SELF-DIAGNOSIS (WITH CONSULT-III)
C1706: LOW PRESSURE RR			X	SELF-DIAGNOSIS (WITH CONSULT-III)
C1707: LOW PRESSURE RL			X	SELF-DIAGNOSIS (WITH CONSULT-III)
C1708: [NO DATA] FL			X	C1708 - C1711 DATA FROM TRANSMITTER NOT BEING RECEIVED
C1709: [NO DATA] FR			X	C1708 - C1711 DATA FROM TRANSMITTER NOT BEING RECEIVED
C1710: [NO DATA] RR			X	C1708 - C1711 DATA FROM TRANSMITTER NOT BEING RECEIVED
C1711: [NO DATA] RL			X	C1708 - C1711 DATA FROM TRANSMITTER NOT BEING RECEIVED
C1712: [CHECKSUM ERR] FL			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1713: [CHECKSUM ERR] FR			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1714: [CHECKSUM ERR] RR			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1715: [CHECKSUM ERR] RL			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1716: [PRESSDATA ERR] FL			X	C1716 - C1719 TRANSMITTER PRESSURE MALFUNCTION
C1717: [PRESSDATA ERR] FR			X	C1716 - C1719 TRANSMITTER PRESSURE MALFUNCTION
C1718: [PRESSDATA ERR] RR			X	C1716 - C1719 TRANSMITTER PRESSURE MALFUNCTION
C1719: [PRESSDATA ERR] RL			X	C1716 - C1719 TRANSMITTER PRESSURE MALFUNCTION
C1720: [CODE ERR] FL			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1721: [CODE ERR] FR			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1722: [CODE ERR] RR			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1723: [CODE ERR] RL			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1724: [BATT VOLT LOW] FL			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1725: [BATT VOLT LOW] FR			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1726: [BATT VOLT LOW] RR			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1727: [BATT VOLT LOW] RL			X	C1712 - C1715, C1720 - C1723, C1724 - C1727 TRANSMITTER MALFUNCTION
C1729: VHCL SPEED SIG ERR			X	C1729 VEHICLE SPEED SIGNAL
C1734: CONTROL UNIT			X	C1734 CONTROL UNIT

DIAGNOSTIC TROUBLE CODE CHART

Scheme 133

Scheme 133: Wiring Diagram - With Front And Rear Power Window Anti-Pinch System

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

CHECK BCM POWER SUPPLY AND GROUND CIRCUIT Check BCM power supply and ground circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-388072-S07430202432011022800000) ". Is the inspection result normal? YES >> GO TO 2 NO >> Repair or replace the malfunctioning parts.
CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH POWER SUPPLY AND GROUND CIRCUIT Check main power window and door lock/unlock switch power supply and ground circuit. Refer to " «POWER WINDOW MAIN SWITCH : DIAGNOSIS PROCEDURE»(ref-388086-S30192094392011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace the malfunctioning parts.

CHECK FRONT POWER WINDOW MOTOR LH Check front power window motor LH. Refer to " «DRIVER SIDE : COMPONENT FUNCTION CHECK»(ref-388086-S29264497342011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ".

CHECK FRONT POWER WINDOW MOTOR RH CIRCUIT Check front power window motor RH circuit. Refer to " «PASSENGER SIDE : COMPONENT FUNCTION CHECK»(ref-388086-S03638217242011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ".

CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to " «REAR LH : COMPONENT FUNCTION CHECK»(ref-388086-S26975366152011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ".

CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to " «REAR RH : COMPONENT FUNCTION CHECK»(ref-388086-S25701273942011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ".

PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S41823401722011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> GO TO 2
CHECK ENCODER CIRCUIT Check encoder circuit. Refer to " «DRIVER SIDE : COMPONENT FUNCTION CHECK»(ref-388086-S21541204722011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace malfunctioning parts.

PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S41823401722011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> GO TO 2
CHECK ENCODER CIRCUIT Check encoder circuit. Refer to " «PASSENGER SIDE : COMPONENT FUNCTION CHECK»(ref-388086-S30874121812011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace the malfunctioning parts.

PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S17366526132011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> GO TO 2
CHECK ENCODER CIRCUIT Check encoder circuit. Refer to " «REAR LH : COMPONENT FUNCTION CHECK»(ref-388086-S03857447722011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace the malfunctioning parts.

PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S17366526132011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> GO TO 2
CHECK ENCODER CIRCUIT Check encoder circuit. Refer to " «REAR RH : COMPONENT FUNCTION CHECK»(ref-388086-S17384609452011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace the malfunctioning parts.

PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S41823401722011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> GO TO 2
CHECK ENCODER Check encoder. Refer to " «DRIVER SIDE : COMPONENT FUNCTION CHECK»(ref-388086-S21541204722011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace the malfunctioning parts.

PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S41823401722011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> GO TO 2
CHECK ENCODER Check encoder. Refer to " «PASSENGER SIDE : COMPONENT FUNCTION CHECK»(ref-388086-S30874121812011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace the malfunctioning parts.

PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S17366526132011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> GO TO 2
CHECK ENCODER Check encoder. Refer to " «REAR LH : COMPONENT FUNCTION CHECK»(ref-388086-S03857447722011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace the malfunctioning parts.

PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT»(ref-388086-S17366526132011022800000) ". Is the inspection result normal? YES >> Inspection End. NO >> GO TO 2
CHECK ENCODER Check encoder. Refer to " «REAR RH : COMPONENT FUNCTION CHECK»(ref-388086-S17384609452011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace the malfunctioning parts.

CHECK FRONT DOOR SWITCH Check front door switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-388086-S22467534732011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace malfunctioning parts.

CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH) Check front door lock assembly LH (key cylinder switch). Refer to " «DIAGNOSIS PROCEDURE»(ref-388086-S41048389902011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace malfunctioning parts.

CHECK INTELLIGENT KEY FUNCTION Check Intelligent Key function. Refer to " «COMPONENT FUNCTION CHECK»(ref-388085-S22466078172011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-388072-S03584481162011022800000) ".

CHECK POWER WINDOW LOCK SWITCH Check power window lock switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-388086-S18481702332011022800000) ". Is the inspection result normal? YES >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ". NO >> Repair or replace malfunctioning parts.

INSPECTION START Check the service history. Check the following parts. Fuse/circuit breaker blown. Poor connection, open or short circuit of harness connector. Battery voltage. Is the inspection result normal? YES >> Inspection End. NO >> Repair or replace the malfunctioning parts.

Scheme 141

Scheme 141: REMOVAL

Scheme 142

Remove the front door grip cover. Refer to " «EXPLODED VIEW»(ref-388080-S33815184282011022800000) ".
Remove the main power window/door lock switch locking clip (A).
Using a suitable tool, release the metal clip and lift the main power window/door lock switch and finisher as an assembly upward to remove it from the front door finisher. : Metal clip : Pawl CAUTION: Wrap a cloth around suitable tool to protect components from damage.
Disconnect the harness connector.
Release the pawls on each side, then separate the switch finisher (1) from the main power window/door lock switch (2) and remove. CAUTION: Do not fold the pawl of main power window/door lock switch finisher.

Power Window Control System: Diagnosis Nissan Maxima A35

BCM : Diagnosis Procedure

Scheme 3

Scheme 4

POWER WINDOW MAIN SWITCH : Diagnosis Procedure

Scheme 5

Scheme 6

Scheme 7

FRONT POWER WINDOW SWITCH : Diagnosis Procedure

Scheme 8

Scheme 9

Scheme 10

REAR POWER WINDOW SWITCH : Diagnosis Procedure

Scheme 11

Scheme 12

Scheme 13

Diagnosis Procedure

Scheme 14

Scheme 15

Scheme 16

Scheme 17

DRIVER SIDE : Diagnosis Procedure

Scheme 18

Scheme 19

DRIVER SIDE : Component Inspection

PASSENGER SIDE : Diagnosis Procedure

Scheme 20

Scheme 21

PASSENGER SIDE : Component Inspection

REAR LH : Diagnosis Procedure

Scheme 22

Scheme 23

REAR LH : Component Inspection

REAR RH : Diagnosis Procedure

Scheme 24

Scheme 25

REAR RH : Component Inspection

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

VALUES ON THE DIAGNOSIS TOOL

Scheme 54

DTC Inspection Priority Chart

DTC Index

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

BASIC INSPECTION

Scheme 63

Scheme 64
