Power Window Control System: Removal & Installation Nissan Maxima A35

Windows 7 illustrations ~454 words

INSTALLATION

Installation is in the reverse order of removal.

Note. After every switch harness disconnection, it is necessary to perform the initialization procedure. Refer to " ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT ".

Scheme 143

Scheme 143: REMOVAL
Scheme 143: REMOVAL

Scheme 144

Scheme 144
Scheme 144
  1. Remove the front door grip cover. Refer to " «EXPLODED VIEW»(ref-388080-S33815184282011022800000) ".
  2. Remove the front power window switch locking clip (A).
  3. Using a suitable tool, release the metal clip and lift the front power window switch and finisher as an assembly upward to remove it from the front door finisher. []: Metal clip o: Pawl CAUTION: Wrap a cloth around suitable tool to protect components from damage.
  4. Disconnect the harness connector.
  5. Release the pawls on each side, then separate the switch finisher (1) from the front power window switch (2) and remove. CAUTION: Do not fold the pawl of front power window switch finisher.

Installation is in the reverse order of removal.

Scheme 145

Scheme 145: REMOVAL
Scheme 145: REMOVAL
  1. Remove the rear door arm rest finisher (1), then disconnect the harness connector. Refer to " «EXPLODED VIEW»(ref-388080-S33229524572011022800000) ".
  2. Release the pawls on each side using a suitable tool (A), then separate the rear power window switch (2) from the finisher (1) and remove. o: Pawl CAUTION: Wrap a cloth around suitable tool to protect components from damage.

Installation is in the reverse order of removal.

Scheme 146

Scheme 146: OVERALL SEQUENCE
Scheme 146: OVERALL SEQUENCE

Installation is in the reverse order of removal.

Note. After every switch harness disconnection, it is necessary to perform the initialization procedure. Refer to " ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SPECIAL REPAIR REQUIREMENT ".

Scheme 147

Scheme 147: REMOVAL
Scheme 147: REMOVAL

Scheme 148

Scheme 148
Scheme 148
  1. Using a suitable tool, remove the front door grip cover. Refer to " «EXPLODED VIEW»(ref-388080-S33815184282011022800000) ".
  2. Remove the front power window switch locking clip (A).
  3. Using a suitable tool, release the metal clip and lift the front power window switch and finisher as an assembly upward to remove it from the front door finisher. : Metal clip : Pawl CAUTION: Wrap a cloth around suitable tools to protect components from damage.
  4. Disconnect the harness connector.
  5. Release the pawls on each side, then separate the switch finisher (1) from the front power window switch (2) and remove. CAUTION: Do not fold the pawl of front power window switch finisher.

Installation is in the reverse order of removal.

Scheme 149

Scheme 149: REMOVAL
Scheme 149: REMOVAL
  1. Remove the rear door arm rest finisher (1), then disconnect the harness connector. Refer to " «EXPLODED VIEW»(ref-388080-S33229524572011022800000) ".
  2. Release the pawls on each side using a suitable tool (A), then separate the rear power window switch (2) from the finisher (1) and remove. : Pawl CAUTION: Wrap a cloth around suitable tools to protect components from damage.

Installation is in the reverse order of removal.
